Analysis of shale gas accumulation conditions of the Niutitang Formation of Lower Cambrian in Sangzhi area, Hunan Province
-
摘要: 桑植地区发育了牛蹄塘组海相黑色页岩,前人对该区古生界下寒武统页岩气成藏条件研究相对较少。在文献调研的基础上,结合野外实地勘查和试验分析,对桑植下寒武统牛蹄塘组页岩储层地质要素和成藏条件进行研究,以期为该区页岩气下一步勘探开发提供借鉴与参考。结果表明: 沉积环境方面,桑植牛蹄塘组页岩沉积相类型为陆棚相和斜坡相,埋深条件好,厚度大; 有机地化特征方面,有机质丰度在2%以上,干酪根类型主要为Ⅱ1型,少见Ⅰ型,有机质成熟度3.5%,为较好烃源岩; 有机质演化与黏土矿物成岩阶段有较好的对应关系,其成岩矿物转化阶段与有机质生油、生气门限基本一致,源岩处于大量生成干气和裂解气阶段; 储集条件方面,孔隙度为9%,发育了原生孔、次生孔、矿物质孔及天然裂缝、构造裂缝,为页岩气富集提供了空间; 脆性矿物含量高,易造缝造储。整体而言,牛蹄塘组页岩为优质页岩,页岩气的成藏条件为较好—好,其勘探、开发潜力较大。Abstract: The marine facies shales of Niutitang Formation are developed in Sangzhi area, with relatively few stu-dies on the shale gas accumulation conditions of Lower Cambrian in Paleozoic in this area. On the basis of literature research and combining with field survey and experimental analysis, the authors in this paper have studies the geological factors and reservoir-forming conditions of shale reservoir in the Niutitang Formation of Lower Cambrian in Sangzhi area, in order to provide reference for the next shale gas exploration and development in this area. The results show that the sedimentary facies in Niutitang Formation shale are shelf facies and slope facies, with good burial depth condition and large thickness. The abundance of organic matter is above 2% in terms of organic geochemical characteristics, with kerogen types of type II1 and rare type I and organic matter maturity of 3.5%, which are the high-quality source rocks. The organic matter evolution and clay mineral diagenetic stage have a good corresponding relationship, and the diagenetic mineral transformation stage is basically the same as the organic matter oil and gas generation threshold, with the source rock in the stage of massive generation of dry gas and cracked gas. In terms of storage conditions, the porosity is 9% with primary pores, secondary pores, mineral pores, natural fractures, and structural fractures, which provide space for shale gas accumulation. The high content of brittle minerals makes fractures created easily. Overall, the shale of the Niutitang Formation is high-quality shale, and the accumulation conditions of shale gas are good, with great potential of exploration and development.
-
-
[1] 自然资源部中国地质调查局国际矿业研究中心.全球矿业发展报告(2020—2021)[C]//第二十三届中国国际矿业大会.北京:中国地质调查局,2021.
[2] International Mining Research Center,China Geological Survey,Ministry of Natural Resources.Global mining development report (2020-2021)[C].Beijing:China Geological Survey,2021.
[2] 张成龙,郝文杰,胡丽莎,等.泄漏情景下碳封存项目的环境影响监测技术方法[J].中国地质调查,2021,8(4):92-100.
[4] Zhang C L,Hao W J,Hu L S,et al.Environmental impact monitoring technology for carbon storage projects under leakage scena-rios[J].Geol Surv China,2021,8(4):92-100.
[3] 张中尧. 湘西北桑植区块五峰—龙马溪组页岩气保存条件研究[D].北京:中国地质大学(北京),2020.
[6] Zhang Z Y.Shale Gas Preservation Conditions of Wufeng-Longmaxi formation in Sangzhi Block,Northwestern Hunan Province[D].Beijing:China University of Geosciences(Beijing),2020.
[4] 崔龙,熊涛,朱宝存.湖南桑植地区牛蹄塘组页岩气储层特征及有利区预测[J].中国煤炭地质,2019,31(12):48-56.
[8] Cui L,Xiong T,Zhu B C.Niutitang formation shale gas reservoir features and favorable area prediction in Sangzhi area,Hunan[J].Coal Geol China,2019,31(12):48-56.
[5] 黄俨然,杨荣丰,肖正辉,等.湘西北下寒武统牛蹄塘组页岩含气性影响因素分析[J].岩性油气藏,2015,27(4):11-16.
[10] Huang Y R,Yang R F,Xiao Z H,et al.Influencing factors of shale gas-bearing property of Lower Cambrian Niutitang Formation in northwestern Hunan[J].Lithol Reserv,2015,27(4):11-16.
[6] 张成龙,唐书恒,姜文,等.湘东南龙潭组页岩气储层特征与勘探前景浅析[J].特种油气藏,2014,21(1):26-30.
[12] Zhang C L,Tang S H,Jiang W,et al.Characteristics and exploration prospect of the Longtan shale gas reservoir in the southeastern Hunan[J].Spec Oil Gas Reserv,2014,21(1):26-30.
[7] 蒲泊伶,蒋有录,王毅,等.四川盆地下志留统龙马溪组页岩气成藏条件及有利地区分析[J].石油学报,2010,31(2):225-230.
[14] Pu B L,Jiang Y L,Wang Y,et al.Reservoir-forming conditions and favorable exploration zones of shale gas in Lower Silurian Longmaxi Formation of Sichuan Basin[J].Acta Pet Sin,2010,31(2):225-230.
[8] 张金川,徐波,聂海宽,等.中国页岩气资源勘探潜力[J].天然气工业,2008,28(6):136-140.
[16] Zhang J C,Xu B,Nie H K,et al.Exploration potential of shale gas resources in China[J].Nat Gas Ind,2008,28(6):136-140.
[9] Zhang T W,Ellis G S,Ruppel S C,et al.Effect of organic-matter type and thermal maturity on methane adsorption in shale-gas systems[J].Org Geochem,2012,47:120-131.
[10] 聂海宽,张金川.页岩气聚集条件及含气量计算——以四川盆地及其周缘下古生界为例[J].地质学报,2012,86(2):349-361.
[19] Nie H K,Zhang J C.Shale gas accumulation conditions and gas content calculation:A case study of Sichuan Basin and its peri-phery in the Lower Paleozoic[J].Acta Geol Sin,2012,86(2):349-361.
[11] 吴鹏,曹地,朱光辉,等.鄂尔多斯盆地东缘临兴地区海陆过渡相页岩气地质特征及成藏潜力[J].煤田地质与勘探,2021,49(6):24-34.
[21] Wu P,Cao D,Zhu G H,et al.Geological characteristics and reservoir-forming potential of shale gas of transi-tional facies in Linxing area,eastern margin of Ordos Basin[J].Coal Geol Explor,2021,49(6):24-34.
[12] 黄璜. 赣西北地区新开岭组泥页岩层地球化学特征[J].江西煤炭科技,2021(4):111-113.
[23] Huang H.Geochemical characteristics of shale formation in Xinkailing Formation in northwestern Jiangxi[J].Jiangxi Coal Sci Technol,2021(4):111-113.
[13] 蒲泊伶. 四川盆地页岩气成藏条件分析[R].青岛:中国石油大学(华东),2008.
[25] Pu B L.Analysis of the Reservoir-Forming Conditions of Shale Gas Potential in Sichuan Basin[R].Qingdao:China University of Petroleum (East China),2008.
[14] 曾玲. 沁水盆地中段煤系页岩气地球化学特征研究[J].中国煤炭地质,2021,33(10):71-75.
[27] Zeng L.Study on coal measures shale gas geochemical features in Qinshui Basin middle segment[J].Coal Geol China,2021,33(10):71-75.
[15] Curtis J B.Fractured shale-gas systems[J].AAPG Bull,2002,86(11):1921-1938.
[16] 周洵. 渝东南地区五峰组—龙马溪组页岩含气性特征研究[D].成都:成都理工大学,2016.
[30] Zhou X.The Research on Shale Gas Bearing Characteristics of Wufeng Formation-Long Maxi Formation from Southeastern Region of Chongqing[D].Chengdu:Chengdu University of Technology,2016.
[17] 李艳红,金奎励.烃源岩成熟度评价指标及选取[J].地质地球化学,2000,28(2):94-96.
[32] Li Y H,Jin K L.Evaluation indices for maturity of hydrocarbon-source rocks[J].Geol-Geochem,2000,28(2):94-96.
[18] Pollastro R M,Jarvie D M,Hill R J,et al.Geologic framework of the Mississippian Barnett shale,Barnett-Paleozoic total petro-leum system,Bend arch-Fort Worth Basin,Texas[J].AAPG Bull,2007,91(4):405-436.
[19] Jarvie D M,Hill R J,Ruble T E,et al.Unconventional shale-gas systems:The Mississippian Barnett shale of north-central Texas as one model for thermogenic shale-gas assessment[J].AAPG Bull,2007,91(4):475-499.
[20] Ross D J K,Bustin R M.Characterizing the shale gas resource potential of Devonian-Mississippian strata in the western Canada sedimentary basin:Application of an integrated formation evaluation[J].AAPG Bull,2008,92(1):87-125.
[21] 储亦睿,张婷婷,刘玉霞,等.川东南地区五峰-龙马溪组海相页岩有机质与黏土矿物吸附能力表征研究[J].中国煤层气,2021,18(3):42-47.
[37] Chu Y R,Zhang T T,Liu Y X,et al.Characterization of adsorption capacity of organic matter and clay minerals in marine shale of Wufeng Longmaxi Formation[J].China Coalbed Methane,2021,18(3):42-47.
[22] 赵杏媛. 黏土矿物与油气[J].新疆石油地质,2009,30(4):533-536.
[39] Zhao X Y.The impact of clay minerals on oil-gas reservoir[J].Xinjiang Pet Geol,2009,30(4):533-536.
[23] 毛俊莉. 辽河西部凹陷页岩油气成藏机理与富集模式[D].北京:中国地质大学(北京),2020.
[41] Mao J L.Reservoir Formation Mechanism and Enrichment Modes of Shale Oil and Gas in the Western Liaohe Depression[D].Beijing:China University of Geosciences (Beijing),2020.
[24] 胡文瑄,姚素平,陆现彩,等.典型陆相页岩油层系成岩过程中有机质演化对储集性的影响[J].石油与天然气地质,2019,40(5):947-956,1047.
[43] Hu W X,Yao S P,Lu X C,et al.Effects of organic matter evolution on oil reservoir property during diagenesis of typical continental shale sequences[J].Oil Gas Geol,2019,40(5):947-956,1047.
[25] 刘晓艳. 黏土矿物对有机质演化的影响[J].天然气地球科学,1995,6(1):23-26.
[45] Liu X Y.Effects of clay minerals on organic matter evolution[J].Nat Gas Geosci,1995,6(1):23-26.
[26] 赵杏媛,王行信,张有瑜,等.中国含油气盆地黏土矿物[M].武汉:中国地质大学出版社,1995.
[47] Zhao X Y,Wang X X,Zhang Y Y,et al.Clay Minerals from Petroliferous Basins in China[M].Wuhan:China University of Geosciences Press,1995.
[27] Curtis J B.Fractured shale-gas systems[J].AAPG Bull,2002,86(11):1921-1938.
[28] Hildenbrand A,Krooss B M,Busch A,et al.Evolution of methane sorption capacity of coal seams as a function of burial history:A case study from the Campine Basin,NE Belgium[J].Int J Coal Geol,2006,66(3):179-203.
[29] 赵俊斌,唐书恒,张松航,等.湘西北牛蹄塘组页岩孔隙特征及影响因素分析[J].煤炭科学技术,2014,42(S1):261-265.
[51] Zhao J B,Tang S H,Zhang S H,et al.Analysis on characteristics and influence factors of shale pore in Niutitang formation of northwestern Hunan[J].Coal Sci Technol,2014,42(S1):261-265.
[30] 唐书恒,范二平,张松航,等.湘西北下古生界海相页岩储层特征与含气性分析[J].地学前缘,2016,23(2):135-146.
[53] Tang S H,Fan E P,Zhang S H,et al.Reservoir characteristics and gas-bearing capacity of the Lower Palaeozoic marine shales in northwestern Hunan[J].Earth Sci Front,2016,23(2):135-146.
[31] Klaver J,Desbois G,Urai J L,et al.BIB-SEM study of the pore space morphology in early mature Posidonia shale from the Hils area,Germany[J].Int J Coal Geol,2012,103:12-25.
[32] 王川,董田,蒋恕,等.中扬子地区上奥陶—下志留统五峰组—龙马溪组页岩纵向非均质性及主控因素[J/OL].地质科技通报,2021:1-14.(2021-08-27).
[56] Wang C,Dong T,Jiang S,et al.Vertical heterogeneity and the main controlling factors of the upper Ordovi cian-Lower Silurian Wufeng-Longmaxi shales in the middle Yangtze Region[J].Bull Geol Technol,2021:1-14.(2021-08-27).
[33] 龚训,李洪辉,张君龙,等.塔东地区下寒武统泥页岩特征与页岩气有利区优选[J].天然气地球科学,2021,32(6):899-913.
[58] Gong X,Li H H,Zhang J L,et al.Characteristics of the Lower Cambrian shale and optimization of favorable shale gas areas in Tadong area[J].Nat Gas Geosci,2021,32(6):899-913.
-
