Application of comprehensive geophysical prospecting method in concealed karst area: A case study from Ning 2019H18 drilling platform in Changning shale gas area
-
摘要: 岩溶塌陷具有隐蔽性和突发性,是碳酸盐岩地区工程建设过程中常见的不良地质问题。长宁地区岩溶发育广泛,其页岩气开发利用受困于岩溶塌陷危害,综合运用微动、高精度重力、瞬态面波和等值反磁通多项物探方法,调查长宁页岩气区块宁2019H18钻井平台下伏地质体特征,查明土洞和溶洞的发育状况,结合钻孔数据进行验证,主要成果包括: ①微重力探测呈现重力值南东高、北西低,重力场响应特征表明该场地南东放向基岩密度较大且完整,而场地NE向基岩密度低; ②微动剖面响应结果与微重力成果对应较好,场地速度结构南东高、北西低,岩石的波速与密度呈正相关; ③进一步查明了场地下方软弱岩层的分布范围,场地SN向基岩完整性好,场地NW向存在着一条裂隙带,裂隙带内充填较为破碎松软的全风化砂岩,其承载力较低。通过物探三维可视化成果,可以为下一步场地建设指明方向,为类似工程案例提供科学依据。Abstract: Karst collapse is a common geological problem in the process of engineering construction in carbonate rock areas because of its concealment and sudden occurrence. The karst collapse is widely developed in Changning area, therefore, the exploitation and utilization of shale gas is hampered by extensive karst collapse. In this paper, the authors used micromotion, high-precision gravity, transient surface wave and equivalent anti-flux geophysical prospecting methods to investigate the subsurface geological condition of Ning 2019H18 drilling platform, and ascertained the development of earth cave and karst cave, which were tested by the drilling data. The main achievements are as follous. ①The microgravity is high in southeast and low in northwest, and the gravity response indicates that the southeast bedrock has large density and complete structure, and that the northwest bedrock has low density. ②The micromotion response profile is well corresponded with the microgravity, and the court page is high in southeast and low in northwest. And the wave velocity is positively related to its density. ③The distribution of underground soft strata was also verified, and the southeast bedrocks were completely preserved. A fractured zone exists in the northwest of the area, filled with cracked and soft completely weathered sandstane, which has low bearing capacity. The 3D visualized physical prospecting achievements could provide directions for the next establishment of the area, and some scientific references for similar engineering cases.
-
-
[1] 罗小杰,罗程.岩溶地面塌陷三机理理论及其应用[J].中国岩溶,2021,40(2):171-188.
[2] Luo X J,Luo C.Three-Mechanism Theory (TMT) of karst ground collapse and its application[J].Carsologica Sinica,2021,40(2):171-188.
[2] 刘洋,郑俊杰,曾彦.基于极限分析下限法的溶洞顶板承载力研究[J].岩土工程学报,2019,41(S2):181-184.
[4] Liu Y,Zheng J J,Zeng Y.Bearing capacity of karst roof based on lower bound method[J].Chinese Journal of Geotechnical Engineering,2019,41(S2):181-184.
[3] 钟宇,张明堃,潘玲,等.基于GIS的武汉市武昌区岩溶塌陷危险性评价[J].天津师范大学学报:自然科学版,2015,35(1):48-53.
[6] Zhong Y,Zhang M K,Pan L,et al.Risk assessment for urban karst collapse in Wuchang District of Wuhan based on GIS[J].Journal of Tianjin Normal University:Natural Science Edition,2015,35(1):48-53.
[4] 潘健,周森,林培源,等.广州市白云区岩溶塌陷风险初探[J].岩土力学,2013,34(9):2589-2600.
[8] Pan J,Zhou S,Lin P Y,et al.Preliminary study of risks of karst collapse in Guangzhou Baiyun district[J].Rock and Soil Mechanics,2013,34(9):2589-2600.
[5] 肖先煊. 覆盖型岩溶区水气相互驱动盖层变形演化及塌陷机理研究[D].成都:成都理工大学,2018.
[10] Xiao X X.Deformation Behavior Evolution and Collapse Mechanism of Karst Covers Under Water-Air Interaction in Karst Area[D].Chengdu:Chengdu University of Technology,2018.
[6] 张丽芬,曾夏生,姚运生,等.我国岩溶塌陷研究综述[J].中国地质灾害与防治学报,2007,18(3):126-130.
[12] Zhang L F,Zeng X S,Yao Y S,et al.Review on karst collapse in China[J].The Chinese Journal of Geological Hazard and Control,2007,18(3):126-130.
[7] 徐联泽. 综合物探方法在复杂岩溶勘察中的应用[J].科技经济导刊,2020,28(33):51-52.
[14] Xu L Z.The application of comprehensive geophysical methods in complex karst exploration[J].Technology and Economic Guide,2020,28(33):51-52.
[8] 刘伟,甘伏平,赵伟,等.高密度电法与微动技术组合在岩溶塌陷分区中的应用分析——以广西来宾吉利塌陷为例[J].中国岩溶,2014,33(1):118-122.
[16] Liu W,Gan F P,Zhao W,et al.Application analysis of combining high density resistivity and microtremor survey methods in areas of karst collapse:A case study of the collapse in Jili village,Laibin,Guangxi[J].Carsologica Sinica,2014,33(1):118-122.
[9] 王鹏,谢丹,罗乃菲.长宁地区页岩气地质特征与勘探开发前景[J].宜宾学院学报,2020,20(12):10-15,99.
[18] Wang P,Xie D,Luo N F.Geological characteristics of shale gas and prospects for exploration and development in Changning area[J].Journal of Yibin University,2020,20(12):10-15,99.
[10] 张坦. 川南地区断裂特征与构造样式分析[D].北京:中国地质大学,2020.
[20] Zhang T.Fracture Characteristics and Construal Styles in Southern Sichuan Area[D].Beijing:China University of Geosciences,2020.
[11] 赵瑞. 四川盆地南缘地形梯度带区域岩溶水系统研究[D].成都:成都理工大学,2016.
[22] Zhao R.Research on the System of Regional Karst Water in the Topographic Gradient Zone of the South Edge of Sichuan Basin[D].Chengdu:Chengdu University of Technology,2016.
[12] 余长恒,周昊,邹忠平,等.长宁地区页岩气钻井平台不同开孔层位不良地质体勘查[J].工程地球物理学报,2019,16(1):61-69.
[24] Yu C H,Zhou H,Zou Z P,et al.The exploration of unfavorable geological body of shale gas drilling platform at different openings in Changning Area[J].Chinese Journal of Engineering Geophysics,2019,16(1):61-69.
[13] 余长恒,张旭林,王强,等.高密度电法在岩溶勘查中的参数试验——以四川南部宜宾市长宁页岩气开发区为例[J].矿产勘查,2020,11(9):1986-1992.
[26] Yu C H,Zhang X L,Wang Q,et al.Parameter test of high density electrical method in Karst exploration:Take the Changning shale gas development area in Yibin,southern Sichuan Province as an example[J].Mineral Exploration,2020,11(9):1986-1992.
[14] Foudili D,Bouzid A,Berguig M C,et al.Investigating karst collapse geohazards using magnetotellurics:A case study of M'rara basin,Algerian Sahara[J].Journal of Applied Geophysics,2019,160:144-156.
[15] McCormack T,O'Connell Y,Daly E,et al.Characterisation of karst hydrogeology in Western Ireland using geophysical and hydraulic modelling techniques[J].Journal of Hydrology:Regional Studies,2017,10:1-17.
[16] 张伟,甘伏平,梁东辉,等.多道瞬态面波法与微动法联合推断岩溶塌陷区覆盖层的结构和厚度分布[J].中国岩溶,2018,37(2):272-279.
[30] Zhang W,Gan F P,Liang D H,et al.Joint inference of multi-channel transient surface wave method and microtremor method to investigate the structure and thickness of the overburden layer in the typical area of karst collapse[J].Carsologica Sinica,2018,37(2):272-279.
[17] 徐燕君,陈明,伍卓鹤,等.高精度重力在城市地下空间探测研究中的应用[J].地质学刊,2021,45(4):425-432.
[32] Xu Y J,Chen M,Wu Z H,et al.Application of high precision gravity in the research of urban underground space exploration[J].Journal of Geology,2021,45(4):425-432.
[18] 李巧灵,张辉,雷晓东,等.综合利用多道瞬态面波和微动探测分析斜坡内部结构[J].物探与化探,2022,46(1):258-267.
[34] Li Q L,Zhang H,Lei X D,et al.Analyses of internal structure of slopes using multi-channel transient surface wave exploration and microtremor survey[J].Geophysical and Geochemical Exploration,2022,46(1):258-267.
[19] 王鑫文. 瞬态面波勘探技术在岩土工程勘察中的应用[J].中国水运(下半月),2017,17(11):233-234.
[36] Wang X W.Application of transient surface wave exploration technology in geotechnical investigation[J].China Water Transport,2017,17(11):233-234.
[20] 席振铢,龙霞,周胜,等.基于等值反磁通原理的浅层瞬变电磁法[J].地球物理学报,2016,59(9):3428-3435.
[38] Xi Z Z,Long X,Zhou S,et al.Opposing coils transient electromagnetic method for shallow subsurface detection[J].Chinese Journal of Geophysics,2016,59(9):3428-3435.
[21] 郑福龙,余舟,蔡从德,等.微重力和微动法相结合的隐伏岩溶探测效果分析——以长宁某页岩气钻井平台为例[J].地球物理学进展,2023,38(2):967-976.
[40] Zheng F L,Yu Z,Cai C D,et al.Analysis of the effect of combining microgravity and microdynamic methods for the detection of hidden karst:Taking a shale gas drilling platform in Changning as an example[J].Progress in Geophysics,2023,38(2):967-976.
-
