Tectonic setting and provenance analysis for Tailegula Formation black shales in Hala-alat Mountain of Xinjiang
-
摘要: 新疆哈拉阿拉特山地区(简称哈山地区)在晚石炭世为沟弧盆体系下岛弧较发育的构造格局,上石炭统太勒古拉组黑色页岩被认为是岛弧作用相对减弱时期海沟和弧前盆地深水沉积的产物,但尚缺乏地球化学依据。对哈山地区太勒古拉组黑色页岩开展探槽施工并进行采样分析,结果表明: 黑色页岩具有富MgO和Na2O,贫TiO2、Al2O3、Fe2O3及CaO,SiO2含量适中,大离子亲石元素相对贫乏,轻稀土相对富集,重稀土相对亏损,负Eu异常的特征,与上地壳稀土元素配分模式相近; 哈山地区太勒古拉组黑色页岩的构造背景主要为大陆岛弧,母岩属于中酸性-长英质物源,主要来自上地壳,物源区可能为北部的塔尔巴哈台—纳尔曼得早古生代沟弧带和谢米斯台—东泉晚古生代岛弧带。研究可为哈山地区巨厚页岩的物质来源提供参考。Abstract: The tectonic framework in Hala-alate Mountain area of Xinjiang at the Late Carboniferous is island arc developed under trench-arc-basin system, and the Upper Carboniferous Tailegula Formation black shale is considered to be a product of deep-water deposition in the trench and forearc basin during the period of island arc effect being relatively weakened, but with a lack of geochemical evidence. Trench exploration and sampling analysis were conducted on the black shales of Tailegula Formation in the study area. The results show that the black shale of Tailegula Formation in the study area is rich in MgO and Na2O, poor in TiO2, Al2O3, Fe2O3 and CaO2, and moderate in SiO2. The large ion lithophile element is relatively poor, and light rare earth element is relatively rich. The heavy rare earth element is relatively loss, and the δEu has negative anomaly, indicating similar distribution pattern with rare earth element in the upper crust. The tectonic setting of Tailegula Formation black shale in Hala-alate Mountain is mainly the continental island arc. The source rock belongs to intermediate to acid and felsic provenance, and it mainly originates from upper continental crust. The source region is probably Early Paleozoic trench-arc of Tarbagatay-Narmande and Late Paleozoic island arc of Xiemisitai-Dongquan in the north. This study could provide some references for the provenance analysis of the giant thick shales in Hala-alate Mountain area.
-
Key words:
- Tailegula Formation /
- black shale /
- tectonic setting /
- provenance
-
-
[1] 于炳松,樊太亮.塔里木盆地寒武系—奥陶系泥质烃源岩发育的构造和沉积背景控制[J].现代地质,2008,22(4):534-540.
Yu B S,Fan T L.Sedimentary-tectonic control on the development of muddy hydrocarbon source rocks of Cambrian-Ordovician from Tarim Basin[J].Geoscience,2008,22(4):534-540.
[2] Dickinson W R,Suczek C A.Plate tectonics and sandstone compositions[J].AAPG Bulletin,1979,63(2):2164-2182.
[3] Bhatia M R.Plate tectonics and geochemical composition of sandstones[J].The Journal of Geology,1983,91(6):611-627.
[4] Roser B P,Korsch R J.Determination of tectonic setting of sandstone-mudstone suites using SiO2 content and K2O/Na2O ratio[J].The Journal of Geology,1986,94(5):635-650.
[5] Taylor S R,McLennan S M.The Continental Crust:Its Composition and Evolution[M].Oxford:Blackwell,1985.
[6] 龙建喜,周琦,张遂,等.黔东北松桃高地南华系铁丝坳组和两界河组碎屑组分及源区背景[J].中国地质调查,2024,11(4):42-49.
Long J X,Zhou Q,Zhang S,et al.Detrital composition of Tiesiao Formation and Liangjiehe Formation of Nanhua System in Songtao Highland of the northeastern Guizhou Province and tectonic setting of its source regions[J].Geological Survey of China,2024,11(4):42-49.
[7] 熊苗,邹光均,张晓阳,等.湘西北永顺地区志留系砂岩稀土元素地球化学特征及其地质意义[J].中国地质调查,2023,10(3):67-74.
Xiong M,Zou G J,Zhang X Y,et al.REE geochemical characteristics and geological significance of Silurian sandstone in Yongshun area of Northwestern Hunan[J].Geological Survey of China,2023,10(3):67-74.
[8] 马风华. 哈山上石炭统太勒古拉组黑色页岩地球化学及有机质特征[J].新疆地质,2018,36(4):507-512.
Ma F H.Geochemical and organic features of black black shale shale in Tailegula Formation within upper carboniferous,Halaalate mountain[J].Xinjiang Geology,2018,36(4):507-512.
[9] 马小平,雷国明,肖鸿.准噶尔盆地西北缘晚石炭统泥页岩地球化学特征及生烃潜力评价[J].西部探矿工程,2022,34(6):167-170,173.
Ma X P,Lei G M,Xiao H.Geochemical characteristics and hydrocarbon generation potential evaluation of late Carboniferous mud shale in the northwest margin of the Junggar Basin[J].West-China Exploration Engineering,2022,34(6):167-170,173.
[10] 梁斌,史美超,白洪海,等.新疆和什托洛盖盆地石炭系太勒古拉组泥页岩储层特征及含气性[J].新疆地质,2020,38(2):232-236.
Liang B,Shi M C,Bai H H,et al.The reservoir feature and gas content of carbonaceous Tailugula Formation mud shale in Hoxtolgay Basin[J].Xinjiang Geology,2020,38(2):232-236.
[11] 朱宝清,冯益民.新疆西准噶尔板块构造及演化[J].新疆地质,1994,12(2):91-105.
Zhu B Q,Feng Y M.Plate tectonics and evolution in West Junggar of Xinjiang[J].Xinjiang Geology,1994,12(2):91-105.
[12] 霍有光. 西准噶尔的放射虫硅质岩[J].西北地质,1987(3):15-21.
Huo Y G.Radiolarian siliceous rocks in West Junggar[J].Northwestern Geology,1987(3):15-21.
[13] Chen J F,Han B F,Ji J Q,et al.Zircon U-Pb ages and tectonic implications of Paleozoic plutons in northern West Junggar,North Xinjiang,China[J].Lithos,2010,115(1/2/3/4):137-152.
[14] 孟祥化. 中国东部晚震旦—早寒武世含磷建造分析和聚磷沉积模式[J].沉积学报,1983,1(2):31-46.
Meng X H.Analysis of phosphatic formation and sedimentary model of phosphatic accumulation of upper Sinian-lower cambrian system in china[J].Acta Sedimentologica Sinica,1983,1(2):31-46.
[15] Li S H.Non-periodicity of base-level curve and a partial suggestion of standardization of sequence stratigraphy[C]//Proceedings of the International Workshop on Sequence Stratigraphy.Beijing:China University of Geosciences,2011:94-96.
[16] 吉利明,邱军利,夏燕青,等.常见黏土矿物电镜扫描微孔隙特征与甲烷吸附性[J].石油学报,2012,33(2):249-256.
Ji L M,Qiu J L,Xia Y Q,et al.Micro-pore characteristics and methane adsorption properties of common clay minerals by electron microscope scanning[J].Acta Petrolei Sinica,2012,33(2):249-256.
[17] Bhatia M R,Crook K A W.Trace element characteristics of graywackes and tectonic setting discrimination of sedimentary basins[J].Contributions to Mineralogy and Petrology,1986,92(2):181-193.
[18] 毛光周,刘池洋.地球化学在物源及沉积背景分析中的应用[J].地球科学与环境学报,2011,33(4):337-348.
Mao G Z,Liu C Y.Application of geochemistry in provenance and depositional setting analysis[J].Journal of Earth Sciences and Environment,2011,33(4):337-348.
[19] 李双建,王清晨.库车坳陷第三系泥岩地球化学特征及其对构造背景和物源属性的指示[J].岩石矿物学杂志,2006,25(3):219-229.
Li S J,Wang Q C.Geochemical characteristics of Tertiary mudstones in Kuqa depression and their implications to tectonic setting and provenance attribute[J].Acta Petrologica et Mineralogica,2006,25(3):219-229.
[20] 李娟,于炳松,郭峰.黔北地区下寒武统底部黑色页岩沉积环境条件与源区构造背景分析[J].沉积学报,2013,31(1):20-31.
Li J,Yu B S,Guo F.Depositional setting and tectonic background analysis on lower Cambrian black shales in the North of Guizhou Province[J].Acta Sedimentologica Sinica,2013,31(1):20-31.
[21] Bhatia M R.Rare earth element geochemistry of Australian Paleozoic graywackes and mudrocks:provenance and tectonic control[J].Sedimentary Geology,1985,45(1/2):97-113.
[22] 岳艳. 浅谈重矿物物源分析方法[J].科技情报开发与经济,2010,20(12):138-139,146.
Yue Y.Introduction of the provenance analysis of heavy mineral[J].Sci-Tech Information Development & Economy,2010,20(12):138-139,146.
[23] 朱筱敏. 沉积岩石学[M].4版.北京:石油工业出版社,2008:1-483.
Zhu X M.Sedimentary Petrology[M].4th ed.Beijing:Petroleum Industry Press,2008:1-483.
[24] Cullers R L,Chaudhuri S,Arnold B,et al.Rare earth distributions in clay minerals and in the clay-sized fraction of the Lower Permian Havensville and Eskridge shales of Kansas and Oklahoma[J].Geochimica et Cosmochimica Acta,1975,39(12):1691-1703.
[25] McCulloch M T,Wasserburg G J.Sm-Nd and Rb-Sr chronology of continental crust formation[J].Science,1978,200(4345):1003-1011.
[26] Cullers R.Mineralogical and chemical changes of soil and stream sediment formed by intense weathering of the Danburg granite,Georgia,U.S.A.[J].Lithos,1988,21(4):301-314.
[27] Schieber J.A combined petrographical-geochemical provenance study of the Newland Formation,Mid-Proterozoic of Montana[J].Geological Magazine,1992,129(2):223-237.
[28] Paikaray S,Banerjee S,Mukherji S.Geochemistry of shales from the Paleoproterozoic to Neoproterozoic Vindhyan Supergroup:implications on provenance,tectonics and paleoweathering[J].Journal of Asian Earth Sciences,2008,32(1):34-48.
[29] Rudnick R L,Gao S.Composition of the continental crust[J].Treatise on Geochemistry,2003,3:1-64.
[30] Floyd P A,Leveridge B E.Tectonic environment of the Devonian Gramscatho basin,south Cornwall:framework mode and geochemical evidence from turbiditic sandstones[J].Journal of the Geological Society,1987,144(4):531-542.
-
