Seismic exploration of potassium salt in Dalangtan-Heibei concave of Qaidam Basin and its preliminary results
-
摘要: 柴西北大浪滩—黑北凹地钾盐资源储量丰富,但常规地震探测技术浅层覆盖次数不足,影响成像品质。为探测大浪滩—黑北凹地地下含钾卤水储层精细结构等特征,开展高分辨率反射地震探测研究,通过采集参数优化试验、有效数据处理,获得该区高品质地震资料与初步勘探成果。结果表明: ①采用小道距、长排列、高覆盖接收、可控震源强能量宽频激发的采集方案,有利于获得高品质原始数据; ②通过多次迭代动校正+F-K滤波有效压制线性干扰,同时保护了浅层有效波,避免了断层假象,成像品质显著提高,有力刻画了地质构造特征; ③地震资料揭示深部砂砾型储卤层顶部与上覆地层呈角度不整合接触,储层两端受两条断层控制,储层空间由不整合面、断层和底部强反射界面组成由南向北逐渐尖灭的三角形区域,推测该三角形储层可能为砂砾型含钾卤水有利储集空间。应用有效地震探测技术可揭示地下基础构造格架,精细刻画含钾卤水储层地层结构等特征,研究结果可为探究含钾卤水储层特征提供地球物理依据,对进一步研究砂砾型含钾卤水具有一定意义。Abstract: The potassium salt resources are abundant in Dalangtan-Heibei concave in northwestern Qaidam Basin, but the shallow folds of conventional seismic detection technology are insufficient, affecting the imaging quality. In order to detect the fine structure of potassium brine reservoir in Dalangtan-Heibei concave, the authors carried out high-resolution reflection seismic detection. The high-quality seismic data and preliminary exploration results were obtained in this area, through the acquisition parameter optimization test and effective data processing. ① The acquisition scheme of small trace spacing, long array, high folds, vibroseis excitation with strong energy and broadband is conducive to obtaining high quality original data. ② The linear interference is effectively suppressed through multiple iterative dynamic correction and F-K filtering, and shallow effective waves were preserved to avoid fault illusion. The imaging quality was significantly improved, and the geological structures were effectively deciphered. ③ The seismic data reveal that the top of the deep gravel type halogen reservoir is in angular unconformity contact with the overlying strata, and the two ends of the reservoir are controlled by two faults. The reservoir space is composed of unconformity surface, faults and strong reflection interface at the bottom, which gradually peaks out in a triangular area from south to north, suggesting that the triangular reservoir may be a favorable storage space for gravel type potccssium-containing brine. In this paper, the effective seismic detection technology was used to successfully reveal the underground structural framework, and the characteristics of the formation structure of the potassium brine reservoir were finely deciphered. This work could provide geophysical basis for the exploration of the characteristics of the potassium brine reservoir, and is of significance for the further study of the gravel type potassium-containing brine.
-
-
[1] 郑绵平,齐文,张永生.中国钾盐地质资源现状与找钾方向初步分析[J].地质通报,2006,25(11):1239-1246.
Zheng M P,Qi W,Zhang Y S.Present situation of potash resources and direction of potash search in China[J].Geological Bulletin of China,2006,25(11):1239-1246.
[2] 韩光,潘彤,马宗德,等.柴达木盆地别勒滩杂卤石矿床特征及其沉积环境研究[J].矿床地质,2023,42(4):811-827.
Han G,Pan T,Ma Z D,et al.Study on characteristics and depositional environment of polyhalite deposits in Bieletan area of Qai-dam Basin[J].Mineral Deposits,2023,42(4):811-827.
[3] 邢万里,陈其慎.中国钾资源安全分析[J].中国矿业,2013,22(12):11-14.
Xing W L,Chen Q S.Analysis of potash resource security in China[J].China Mining Magazine,2013,22(12):11-14.
[4] 刘成林,余小灿,赵艳军,等.华南陆块液体钾、锂资源的区域成矿背景与成矿作用初探[J].矿床地质,2016,35(6):1119-1143.
Liu C L,Yu X C,Zhao Y J,et al.A tentative discussion on regional metallogenic background and mineralization mechanism of subterranean brines rich in potassium and lithium in South China Block[J].Mineral Deposits,2016,35(6):1119-1143.
[5] 亓昭英,商立朋,杜双江,等.中国钾盐(肥)行业运行现状及未来发展建议[J].化肥工业,2017,44(5):59-64.
Qi Z Y,Shang L P,Du S J,et al.Current operation status and future development proposals of Potassium fertilizer industry in China[J].Chemical Fertilizer Industry,2017,44(5):59-64.
[6] 韩佳欢,郑绵平,乜贞,等.我国深层地下卤水钾、锂资源及其开发前景[J].盐湖研究,2024,32(2):90-100.
Han J H,Zheng M P,Nie Z,et al.Lithium and Potassium resources of oilfield brine and development prospects in China[J].Journal of Salt Lake Research,2024,32(2):90-100.
[7] 孙宏伟,任军平,许康康,等.非洲钾盐矿床地质特征及资源潜力.地质通报,2023,42(8):1390-1401.
Sun H W,Ren J P,Xu K K,et al.Geological characteristics and resource potential analysis of potash deposits in Africa.Geological Bulletin of China,2023,42(8):1390-1401.
[8] 王春宁,余俊清,陈良,等.钾盐资源全球分布和我国找钾实践及方法探究[J].盐湖研究,2007,15(3):56-72.
Wang C N,Yu J Q,Chen L,et al.A review on the exploration of global potash resources with an emphasis on the past and present status of China with a methodological perspective[J].Journal of Salt Lake Research,2007,15(3):56-72.
[9] 樊启顺,马海州,谭红兵,等.柴达木盆地西部卤水特征及成因探讨[J].地球化学,2007,36(6):601-611.
Fan Q S,Ma H Z,Tan H B,et al.Characteristics and origin of brines in western Qaidam Basin[J].Geochimica,2007,36(6):601-611.
[10] 马玉波,张永生,陈伟,等.2023年新一轮找矿突破战略行动主要科研成果[J].矿床地质,2024,43(1):225-226.
Ma Y B,Zhang Y S,Chen W,et al.The main scientific research achievements of the strategic action for a new round of prospecting breakthrough in 2023[J].Mineral Deposits,2024,43(1):225-226.
[11] 孟军海,林佳富,才智杰,等.柴达木盆地盐湖型锂矿床地质特征与地球物理探测[J].地球科学与环境学报,2022,44(1):124-131.
Meng J H,Lin J F,Cai Z J,et al.geological characteristics and geophysical exploration of salt lake-type Lithium deposits in Qaidam Basin,China[J].Journal of Earth sciences and environment,2022,44(1):124-131.
[12] 刘建勋,周建勇,徐明才,等.地震勘查技术在喀拉通克矿区的应用[J].物探与化探,2017,41(3):437-444.
Liu J X,Zhou J Y,Xu M C,et al.The application of seismic exploration technology in the Kalatongke orefield[J].Geophysical and Geochemical Exploration,2017,41(3):437-444.
[13] 李广才,李培,姜春香,等.我国城市地球物理勘探方法应用进展[J].地球物理学进展,2023,38(4):1799-1814.
Li G C,Li P,Jiang C X,et al.Advances of the application of urban geophysical exploration methods in China[J].Progress in Geophysics,2023,38(4):1799-1814.
[14] 李广才,王小江,王凯.浅层高分辨率反射地震试验研究:以雄安新区第四系为例[J].地质与勘探,2024,60(2):329-338.
Li G C,Wang X J,Wang K.Experiment of shallow high-resolution reflection seismic technology:A case study of the Quaternary System in Xiong'an New Area[J].Geology and Exploration,2024,60(2):329-338.
[15] 梁光河,徐兴旺,刘兴江,等.老挝万象盆地萨塔尼钾盐矿的构造变形与深部矿预测[J].大地构造与成矿学,2019,43(5):934-942.
Liang G H,Xu X W,Liu X J,et al.Structural deformation and deep ore prediction for Satani Potash deposit in Vientiane Basin,Laos[J].Geotectonica et Metallogenia,2019,43(5):934-942.
[16] 侯献华,王伟,郑绵平,等.柴达木盆地西部黑北凹地—大浪滩深层卤水钾盐储卤层地震响应特征研究[J].地学前缘,2021,28(6):134-145.
Hou X H,Wang W,Zheng M P,et al.Seismic response characteristics of the Heibei Concave-Dalangtan potassium-rich deep brine reservoir in western Qaidam Basin[J].Earth Science Frontiers,2021,28(6):134-145.
[17] 朱允铸,钟坚华,李文生.柴达木盆地新构造运动及盐湖发展演化[M].北京:地质出版社,1994.Zhu Y Z,Zhong J H,Li W S.The Neotectonic Movement and the Evolution of Saline Lakes of Qaidam Basin in Northwestern China[M].Beijing:Geological Publishing House,1994.
[18] 袁见齐,霍承禹,蔡克勤.高山深盆的成盐环境:一种新的成盐模式的剖析[J].地质论评,1983,29(2):159-165.
Yuan J Q,Huo C Y,Cai K Q.The High Mountain-deep Basin Saline Environment:A New Genetic Model of Salt Deposits[J].Geological Review,1983,29(2):159-165.
[19] 潘彤,贾建团,李东生,等.柴达木盆地盐类及地下水矿床成矿系列与找矿方向[J].地球科学与环境学报,2024,46(01):96-113.
Pan T,Jia J T,Li D S,et al.Mineralization series and prospecting direction of salt and groundwater mineral deposits in Qaidam Basin,China[J].Journal of Earth Sciences and Environment,2024,46(01):96-113.
[20] 张彭熹,于升松,支霞臣,等.柴达木盆地盐湖[M].北京:科学出版社,1987.Zhang P X,Yu S S,Zhi X C,et al.Salt Lake in Qaidam Basin[M].Beijing:Science Press,1987.
[21] 校韩立. 柴达木盆地黑北凹地新型砂砾型含钾卤水成因研究[D].北京:中国矿业大学,2017.Xiao H L.Study on Origin of Potassium-bearing Brine in Sandy Gravel Bed of Heibei Concave in Qaidam Basin[D].Beijing:China University of Mining & Technology,2017.
[22] 郑绵平,侯献华,于常青,等.成盐理论引领我国找钾取得重要进展[J].地球学报,2015,36(2):129-139.
Zheng M P,Hou X H,Yu C Q,et al.The Leading Role of Salt Formation Theory in the Breakthrough and Important Progress in Potash Deposit Prospecting[J].Acta Geoscientica Sinica,2015,36(2):129-139.
-
