Stability of zircon during mylonitization: a case study of granitic mylonite in Gaoligong and Ximeng, Southwest China
-
摘要: 自然条件下锆石的稳定性对于合理解释锆石年龄及深入理解锆石同位素年代学有重要意义。本文对西南三江造山带高黎贡山和西盟地区的花岗质糜棱岩进行了显微构造和锆石U-Pb年代学研究。高黎贡山和西盟糜棱岩中主要造岩矿物长石、石英、云母发生了明显的变形和重结晶，而锆石则以独立晶体或以残留核的形式保存了原始的岩浆结构。高黎贡山和西盟糜棱岩锆石U-Pb年龄分别为513±8 Ma和459±2 Ma，代表花岗质原岩的时代。受新生代构造变质影响，锆石边部发育有窄的海绵状结构和溶蚀结构，指示变质重结晶作用发生在有少量流体参与条件下。石英变质机制为颗粒边界迁移重结晶，指示变形温度为500~700℃。石英C组构EBSD分析表明，糜棱岩经历了早期550~650℃和晚期400~550℃的递进变形作用。岩石显微构造、锆石结构及年代学研究结果表明，岩石糜棱岩化过程中，还有少量流体参与的情况下，温度在550~650℃时锆石晶体结构就受到破坏，发生变质重结晶作用。这为解释自然界复杂条件下锆石年龄提供了重要约束。Abstract: The stability of zircon under natural conditions is of great significance for reasonable interpretation of zircon age and further understanding of zircon isotopic chronology. In this paper, the microstructure and zircon U-Pb chronology of granitic mylonites in Gaoligongshan and Ximeng areas of the Sanjiang orogenic belt in the southwestern China have been studied. Finerals feldspar, which are the main rock-forming quartz and mica in granitic mylonite from the Gaoligong and Ximeng areas were significantly deformed and recrystallized, while zircon preserved the original structure in the form of independent crystal or residual core. The zircon U-Pb ages of the Gaoligongshan and the Ximeng mylonites are 513 ±8 Ma and 459 ±2 Ma, respectively, which represent the age of granitic protolith. Influenced by the Cenozoic tectonic metamorphism, some zircon grains developed spongy structure and dissolution structure at the rim, indicating the metamorphic recrystallization under the condition of a small amount of fluid. The metamorphic mechanism of quartz is grain boundary migration recrystallization, which indicates that the deformation temperature is 500-700℃. Quartz c-axis fabrics revealed by the electron backscatter diffraction (EBSD) technique reflect two stages of metamorphic temperature in the mylonites:the early stage of 550-650℃ and the late stage of 400-550℃. The results of rock microstructure, zircon structure and chronology show that the crystal structure of zircon is destroyed and metamorphic recrystallization occurred at 550-650℃ in the process of mylonization with a small amount of fluid involved. These conditions provide important constraints for the interpretation of zircon ages under complex natural conditions.
-
Key words:
- Zircon /
- stability /
- recrystallization temperature /
- mylonitization /
- granitic mylonite /
- Sanjiang orogenic belt
-
-
[1] Hanchar J M, Hoskin P W O. Zircon[J]. Reviews in Mineralogy and Geochemistry, 2003, 53:Ⅴ~Ⅶ.
[2] Harley S L, Kelly N M. Zircon Tiny but Timely[J]. Elements, 2007, 3(1):13-18.
[3] Wu Y B, Zheng Y F. Genesis of zircon and its constraints on interpretation of U-Pb age[J]. Chinese Science Bulletin, 2004, 49(5):1554-1569.
[4] Lee J K, Williams I S, Ellis D J. Pb, U and Th diffusion in natural zircon[J]. Nature, 1997, 390(6656):159-162.
[5] Cherniak D J, Watson E B. Pb diffusion in zircon[J]. Chemical Geology, 2000, 172(1-2):5-24.
[6] Zheng J P, Griffin W L, O'Reilly S Y, et al. Widespread Archean basement beneath the Yangtze craton[J]. Geology, 2006, 34(6):417-420.
[7] Wilde S A, Valley J W, Peck W H, et al. Evidence from detrital zircons for the existence of continental crust and oceans on the Earth 4.4 Gyr ago[J]. Nature, 2001, 409:175-178.
[8] Liu D Y, Nutman A P, Compston W, et al. Remnants of > = 3800 Ma crust in the Chinese part of the Sino-Korean craton[J]. Geology, 1992, 20(4):339-342.
[9] Wu Y B, Gao S, Zhang H F, et al. Timing of UHP metamorphism in the Hong'an area, western Dabie Mountains, China:evidence from zircon U-Pb age, trace element and Hf isotope composition[J]. Contributions to Mineralogy & Petrology, 2008, 155(1):123-133.
[10] Zong K Q, Liu Y S, Gao C G, et al. In situ U-Pb dating and trace element analysis of zircons in thin sections of eclogite:Refining constraints on the ultra high-pressure metamorphism of the Sulu terrane, China[J]. Chemical Geology, 2010, 269:237-251.
[11] Rizvanova N G, Levchenkov O A, Belous A E,et al. Zircon reaction and stability of the U-Pb isotope system during interaction with carbonate fluid:experimental hydrothermal study[J]. Contributions to Mineralogy and Petrology, 2000, 139(1):101-134.
[12] Geisler T, Ulonska M, Schleicher H,et al. Leaching and differential recrystallization of metamict zircon under experimental hydrothermal conditions[J]. Contributions to Mineralogy and Petrology, 2001, 141(1):53-65.
[13] 胡玲, 刘俊来, 纪沫, 等. 变形显微构造识别手册[M].北京:地质出版社, 2009:1-96.
[14] 向必伟, 朱光, 王勇生, 等. 糜棱岩化过程中矿物变形温度计[J]. 地球科学进展, 2007, 22(2):126-135.
[15] Passchier C W, Thouw R A J. Microtectonics[M].New York:Springer Berlin Heidelberg, 2005:1-366.
[16] 刘俊来, 宋志杰, 曹淑云, 等. 印度-欧亚侧向碰撞带构造-岩浆演化的动力学背景与过程——以藏东三江地区构造演化为例[J]. 岩石学报, 2006, 22(4):775-786.
[17] 范承钧, 张翼飞. 云南西部地质构造格局[J]. 云南地质, 1993, 12(2):139-147.
[18] Leloup P H, Harrison T M, Ryerson F J, et al. Structural, petrological and thermal evolution of a Tertiary ductile strike-slip shear zone, Diancang Shan, Yunnan[J]. Journal of geophysical research, 1993, 98(B4):6715-6743.
[19] Harrison T M, Chen W J, Leloup P H, et al. An Early Miocene Transition in Deformation Regime within the Red River Fault Zone, Yunnan, And Its Significance for Indo-Asian Tectonics[J]. Journal of geophysical research, 1992, 97(B5):7159-7182.
[20] Tapponnier P, Lacassin R, Leloup P H,et al. The Ailao Shan/Red River metamorphic belt:tertiary left-lateral shear between Indochina and South China[J]. Nature, 1990, 343:431-437.
[21] Schärer U, Tapponnier P, Lacassin R, et al. Intraplate tectonics in Asia:A precise age for large-scale Miocene movement along the Ailao Shan-Red River shear zone, China[J]. Earth and Planetary Science Letters, 1990, 97(1-2):65-77.
[22] 钟大赉. 滇川西部古特提斯造山带[M]. 北京:科学出版社, 1998, 1-217.
[23] 唐渊, 王冬兵, 廖世勇, 等. 滇西三江地区西盟群的再认识——来自构造变形特征及锆石U-Pb年代学的证据[J]. 岩石学报, 2017, 33(7):2054-2072.
[24] 王冬兵, 罗亮, 王保弟, 等. 昌宁-孟连结合带斜长角闪岩锆石U-Pb年龄、地球化学特征及其地质意义[J]. 沉积与特提斯地质,2017, 37(4):15-28.
[25] 唐渊, 王冬兵, 廖世勇, 等. 滇西高黎贡山变质岩带南段淡色花岗岩脉年代学特征及构造意义[J]. 岩石学报, 2016, 32(8):2347-2366.
[26] Wang Y J, Fan W M, Zhang Y H,et al. Kinematics and 40Ar/39Ar geochronology of the Gaoligong and Chongshan shear systems, western Yunnan, China:Implications for early Oligocene tectonic extrusion of SE Asia[J]. Tectonophysics, 2006, 418(3-4):235-254.
[27] Lin T H, Lo C H, Chung S L, et al. 40Ar/39Ar dating of the Jiali and Gaoligong shear zones:Implications for crustal deformation around the Eastern Himalayan Syntaxis[J]. Journal of Asian Earth Sciences, 2009, 34(5):674-685.
[28] Tapponnier P, Peltzer G, Armijo R. On the mechanics of the collision between India and Asia. Geological Society, London, Special Publications[J], 1986, 19(1):113-157.
[29] Leloup, P H, Lacassin R, Tapponnier P, et al. The Ailao Shan-Red River shear zone (Yunnan, China), Tertiary transform boundary of Indochina[J]. Tectonophysics, 1995, 251(1-4):3-84.
[30] Wang Y J, Xing X W, Cawood P A,et al. Petrogenesis of early Paleozoic peraluminous granite in the Sibumasu Block of SW Yunnan and diachronous accretionary orogenesis along the northern margin of Gondwana[J]. Lithos, 2013, 182-183:67-85.
[31] 邢晓婉, 张玉芝. 滇西南西盟群帕可组沉积时代厘定及构造意义:锆石U-Pb年代学及Lu-Hf同位素证据[J]. 矿物岩石地球化学通报, 2016, 35(5):936-948.
[32] 邢晓婉, 张玉芝, 王岳军, 等. 西盟地区奥陶纪花岗片麻岩的锆石U-Pb年代学、Hf同位素组成特征及其大地构造意义[J]. 大地构造与成矿学, 2015, 39(3):470-480.
[33] Chen X Y, Liu J L, Qi Y C, et al. Miocene structural evolution and exhumation of the Ximeng dome in Yunnan, Southeastern Tibet:implication for intraplate deformation during extrusion of the Sundaland block[J]. Journal of Asian Earth Sciences, 2017, 141:194-212.
[34] 夏浩然, 刘俊来. 石英结晶学优选与应用[J]. 地质通报, 2011, 30(1):58-70.
[35] Vincenzo Festa. C-axis fabrics of quartz-ribbons during high-temperature deformation of syn-tectonic granitoids (Sila Massif, Calabria, Italy)[J]. Comptes Rendus Geoscience, 2009, 341(7):557-567.
[36] Stipp M, Stünitz H, Heilbronner R, et al. The eastern Tonale fault zone:a ‘natural laboratory’ for crystal plastic deformation of quartz over a temperature range from 250 to 700℃[J]. Journal of Structural Geology, 2002, 24(12):1861-1884.
[37] Neumann, B. Texture development of recrystallised quartz polycrystals unravelled by orientation and misorientation characteristics[J]. Journal of Structural Geology, 2000,22(11-12):1695-1711.
-
