Assessing the impact of artificial recharge on groundwater in an over-exploited aquifer: A case study in the Cheria Basin, North-East of Algeria
-
Abstract:
The Cheria region in Northeastern Algeria has been facing aquifer overexploitation by the agricultural sector and prolonged droughts, resulting in a considerable decline in groundwater levels. This study investigates the feasibility of implementing artificial recharge techniques to replenish the Eocene aquifer which serves as the primary water source in the Cheria region. A 3D transient numerical model, based on the finite difference method, was used to simulate groundwater flow from 2021 to 2031 using Visual MODFLOW Flex. During the modelling process, three scenarios were considered: (1) including pumping without a recharge, (2) recharge of the entire area through efficient infiltration without pumping, and (3) artificial recharge using river water infiltration basins at two sites, Draa Douamis sinkholes and Eocene limestone outcrops. The simulation results showed that aquifer exploitation without recharge caused significant drawdowns, which were 3 m to 7 m in the north-eastern part and 8 m to 12 m in the central and southern parts. In contrast, the second scenario, involving recharge without pumping, showed a rise in groundwater levels of 2 m to 2.7 m in the north-eastern part and 3 m to 3.62 m in the central and southern parts. The third scenario, employing artificial recharge, indicated a positive response to artificial recharge, with increased piezometric levels at the proposed sites, signifying a beneficial impact on the aquifer. These findings underline the potential of artificial recharge as a promising approach to address the groundwater depletion and environmental issues in the Cheria Basin.
-
Key words:
- Eocene limestone /
- Piezometric level /
- Numerical simulation /
- Visual MODFLOW Flex /
- Artificial recharge
-
-
Table 2. Transmissivity values of 09 boreholes
Well X /m Y /m Z /m T / m2/s F9 bis 964075 235215 1133 2.58 ×10−3 CH4 957831 231000 1099 2.7 ×10−1 CH1 bis 957160 231177 1093 0.19 ×10−2 CH5 960529 233045 1103 8.05 ×10 −1 CH6 960964 233818 1112 1.91 ×10−2 Abla1 958657 228065 1089 2.83 ×10−3 HA1 959413 228508 1138 1.513 ×10−3 CH3 958904 231230 1090 12.81×10−1 T9 952160 214571 1011 0.16 ×10−1
下载: 导出CSV
Table 1. Hydraulic parameters layer
Layer (kx)
Hydraulic conductivity/m/s(kz)
Hydraulic conductivity/m/s(Ss)
Specific storage/m−1(Sy)Specific
yieldEffective porosity/% Total porosity/% 1 1.28× 10−5 1.28 × 10−6 6.9 × 10−5 0.14 10 20
下载: 导出CSV
Table 3. Parameters of the artificial recharge of the Cheria aquifer for one year
Site 1 Site 2 River Douamis El Blilia El Goussa Cheria Flow / m3/s 4.68 7.39 16.05 16 28.12 Annual inflows / Mm3/an 2.02 1.15 Recharge to the water table 80% 1.62 0.92 Height of rechage /m Area of 0.5 km2 3.24 1.84
下载: 导出CSV
-
Abdoulhalik A, Ahmed A, Hamill GA. 2017. A new physical barrier system for seawater intrusion control. Journal of Hydrology, 549: 416−427. DOI:10.1016/j.jhydrol.2017.04.005.
Alam S, Borthakur A, Ravi S, et al. 2021. Managed aquifer recharge implementation criteria to achieve water sustainability. Science of the Total Environment, 768: 144992. DOI:10.1016/j.scitotenv.2021.144992.
Baali F, Fehdi C, Rouabhia A, et al. 2015. Hydrochemistry and isotopic exploration for a karstic aquifer in a semi-arid region: Case of Cheria Plain, Eastern Algeria. Carbonates and Evaporites, 30(1): 99−107. DOI:10.1007/s13146-014-0214-5.
Baali F, Rouabhia A, Kherici N, et al. 2007. Qualite des eaux souterraines et risque de pollution en milieu semi-aride. Cas de la cuvette de Cheria (NE Algerien). Estudios Geolo´gicos Journal, Spain, 63(2): 127-133. ISSN: 0367-0449
Bai L, Jiang LM, Zhao Y, et al. 2022. Quantifying the influence of long-term overexploitation on deep groundwater resources across Cangzhou in the North China Plain using InSAR measurements. Journal of Hydrology, 605: 127368. DOI:10.1016/j.jhydrol.2021.127368.
Bakalowicz M. 2005. Karst groundwater: A challenge for new resources. Hydrogeology Journal, 13(1): 148−160. DOI:10.1007/s10040-004-0402-9.
Barceló D, Sabater S. 2010. Water quality and assessment under scarcity: Prospects and challenges in Mediterranean watersheds. Journal of Hydrology, 383(1): 1−4. DOI:10.1016/j.jhydrol.2010.01.010.
Batlle-Aguilar J, Xie YQ, Cook PG. 2015. Importance of stream infiltration data for modelling surface water-groundwater interactions. Journal of Hydrology, 528: 683−693. DOI:10.1016/j.jhydrol.2015.07.012.
Britto AL, Maiello A, Quintslr S. 2019. Water supply system in the Rio de Janeiro Metropolitan Region: Open issues, contradictions, and challenges for water access in an emerging megacity. Journal of Hydrology, 573: 1007−1020. DOI:10.1016/j.jhydrol.2018.02.045.
Chamekh K, Baali F, El Wahab Yahiaoui A, et al. 2018. Hydrogeological setting of a karstic aquifer in a semi-arid region: A case from Cheria plain, Eastern Algeria. Carbonates and Evaporites, 33(4): 697−704. DOI:10.1007/s13146-017-0400-3.
Cheng ZS, Su C, Zheng ZX, et al. 2021. Characterize groundwater vulnerability to intensive groundwater exploitation using tritium time-series and hydrochemical data in Shijiazhuang, North China Plain. Journal of Hydrology, 603: 126953. DOI:10.1016/j.jhydrol.2021.126953.
Daher W, Pistre S, Kneppers A, et al. 2011. Karst and artificial recharge: Theoretical and practical problems. Journal of Hydrology, 408(3−4): 189−202. DOI:10.1016/j.jhydrol.2011.07.017.
Dillon P, Stuyfzand P, Grischek T, et al. 2018. Sixty years of global progress in managed aquifer recharge. Hydrogeology Journal, 27(1): 1−30. DOI:10.1007/s10040-018-1841-z.
Einsiedl F. 2005. Flow system dynamics and water storage of a fissured-porous Karst aquifer characterized by artificial and environmental tracers. Journal of Hydrology, 312(1−4): 312−321. DOI:10.1016/j.jhydrol.2005.03.031.
Eltarabily MG, Abd-Elaty I, Elbeltagi A, et al. 2023. Investigating climate change effects on evapotranspiration and groundwater recharge of the Nile delta aquifer, Egypt. Water, 15(3): 572. DOI:10.3390/w15030572.
Fehdi C, Baali F, Boubaya D, et al. 2011. Detection of sinkholes using 2D electrical resistivity imaging in the Cheria Basin (north-east of Algeria). Arabian Journal of Geosciences, 4(1): 181−187. DOI:10.1007/s12517-009-0117-2.
Fehdi C, Nouioua I, Belfar D, et al. 2014. Detection of underground cavities by combining electrical resistivity imaging and ground penetrating radar surveys: A case study from draa douamis area (north east of Algeria). H2Karst Research in Limestone Hydrogeology. Cham: Springer: 69−82. DOI:10.1007/978-3-319-06139-9_5.
Filippini M, Squarzoni G, De Waele J, et al. 2018. Differentiated spring behavior under changing hydrological conditions in an alpine Karst aquifer. Journal of Hydrology, 556: 572−584. DOI:10.1016/j.jhydrol.2017.11.040.
Gaud J. 1977. Etude géologique et hydrogéologique du plateau de Chéria Wilaya de Tébessa. Rapport interne N. ° 2. A. N. R. H de Tébessa (Agence Nationale des ressources hydriques): 96.
Glass J, Via Rico DA, Stefan C, et al. 2018. Simulation of the impact of managed aquifer recharge on the groundwater system in Hanoi, Vietnam. Hydrogeology Journal, 26(7): 2427−2442. DOI:10.1007/s10040-018-1779-1.
Iftekhar MS, Fogarty J. 2017. Impact of water allocation strategies to manage groundwater resources in Western Australia: Equity and efficiency considerations. Journal of Hydrology, 548: 145−156. DOI:10.1016/j.jhydrol.2017.02.052.
Luo ZR, Zhao SQ, Wu J, et al. 2019. The influence of ecological restoration projects on groundwater in Yongding River Basin in Beijing, China. Water Supply, 19(8): 2391−2399. DOI:10.2166/ws.2019.119.
Kimrey JO. 1989. Artificial recharge of groundwater and its role in water management. Desalination, 72(1−2): 135−147. DOI:10.1016/0011-9164(89)80031-1.
Maurice LD, Atkinson TC, Barker JA, et al. 2012. The nature and distribution of flowing features in a weakly karstified porous limestone aquifer. Journal of Hydrology, 438−439: 3−15. DOI:10.1016/j.jhydrol.2011.11.050.
McDonald MG, Harbaugh AW. 1988. A modular three-dimensional finite-difference ground-water flow model. In Techniques of Water-Resources Investigations.
Müller AB, Avellán T, Schanze J. 2020. Risk and sustainability assessment framework for decision support in 'water scarcity - water reuse' situations. Journal of Hydrology, 591: 125424. DOI:10.1016/j.jhydrol.2020.125424.
Mushtaq F, Rehman H, Ali U, et al. 2023. An investigation of recharging groundwater levels through river ponding: New strategy for water management in sutlej river. Sustainability, 15(2): 1047. DOI:10.3390/su15021047.
Nouioua I, Rouabhia A, Fehdi C, et al. 2013. The application of GPR and electrical resistivity tomography as useful tools in detection of sinkholes in the Cheria Basin (northeast of Algeria). Environmental Earth Sciences, 68(6): 1661−1672. DOI:10.1007/s12665-012-1859-9.
Qin HH. 2021. Numerical groundwater modeling and scenario analysis of Beijing plain: Implications for sustainable groundwater management in a region with intense groundwater depletion. Environmental Earth Sciences, 80(15): 499. DOI:10.1007/s12665-021-09795-0.
RodrÃguez-RodrÃguez M, Aguilera H, Guardiola-Albert C, et al. 2021. Climate influence vs. local drivers in surface water-groundwater interactions in eight ponds of doana National Park (southern Spain). Wetlands, 41(2): 25. DOI:10.1007/s13157-021-01425-6.
Saghi-Jadid M, Ketabchi H. 2021. Result-based management approach for aquifer restoration problems using a combined numerical simulation - parallel evolutionary optimization model. Journal of Hydrology, 594: 125709. DOI:10.1016/j.jhydrol.2020.125709.
Samanta S, Sheng ZP, Munster CL, et al. 2020. Seasonal variation of infiltration rates through pond bed in a managed aquifer recharge system in St-André, Belgium. Hydrological Processes, 34(18): 3807−3823. DOI:10.1002/hyp.13827.
Sasidharan S, Bradford SA, Jong B De, et al. 2019. Evaluating drywells for stormwater management and enhanced aquifer recharge. Advances in Water Resources, 116: 167−177.
Sawyer AH, David CH, Famiglietti JS. 2016. Continental patterns of submarine groundwater discharge reveal coastal vulnerabilities. Science, 353(6300): 705−707. DOI:10.1126/science.aag1058.
Silva MI, Gonçalves AML, Lopes WA, et al. 2021. Assessment of groundwater quality in a Brazilian semiarid basin using an integration of GIS, water quality index and multivariate statistical techniques. Journal of Hydrology, 598: 126346. DOI:10.1016/j.jhydrol.2021.126346.
Vila JM. 1980. La chaîne alpine de l'Algérie orientale et des confins Algéro-Tunisiens. Thèse de Doctorat- es sciences, Université Pierre et Marie curie, Paris VI.
Waterloo. 2019. Visual MODFLOW Flex 6.1 user's manual: Integrated Conceptual and Numerical Groundwater Modeling Software: Waterloo Hydrogeologic, Print.
Xanke J, Jourde H, Liesch T, et al. 2016. Numerical long-term assessment of managed aquifer recharge from a reservoir into a Karst aquifer in Jordan. Journal of Hydrology, 540: 603−614. DOI:10.1016/j.jhydrol.2016.06.058.
-
