Quantitative study on vertical distribution of heat flow in Niutuozhen geothermal field, Xiong'an New Area—Evidence from heat flow determination in the Archean of D01 well
-
Abstract:
The karst geothermal reservoir in Xiong'an New Area is a representative example of an ancient buried hill geothermal system. However, published heat flow data are predominantly derived from the Cenozoic sedimentary cap. Due to the limited depth of borehole exploration, heat flow measurements and analyses of the Archean crystalline basement in the study area are rare. Further investigation of the heat flow and temperature field characteristics within the Archean crystalline basement beneath the karst geothermal reservoir is necessary to understand the vertical distribution of heat flow and improve the geothermal genetic mechanism in the area. The D01 deep geothermal scientific drilling parameter well was implemented in the Niutuozhen geothermal field of Xiong'an New Area. The well exposed the entire Gaoyuzhaung Formation karst geotheremal reservoir of the Jixian system and drilled 1,723.67 m into the Archean crystalline basement, providing the necessary conditions for determining its heat flow. This study involved borehole temperature measurements and thermophysical property testing of core samples from the D01 well to analyze the vertical distribution of heat flow. The findings revealed distinct segmentation in the geothermal gradient and rock thermophysical properties. The geothermal reservoir of Gaoyuzhuang Formation is dominated by convection, with significant temperature inversions corresponding to karst fracture developments. In contrast, the Archean crystalline basement exhibits conductive heat transfer. After 233 days of static equilibrium, the average geothermal gradients of the Gaoyuzhuang Formation and the Archean crystalline basement were determined to be 1.5°C/km and 18.3°C/km, respectively. These values adjusted to −0.8°C/km and 18.2°C/km after 551 days, with the longer static time curve approaching steady-state conditions. The average thermal conductivity of dolomite in Gaoyuzhuang Formation was measured as 4.37±0.82 W/(K·m), and that of Archean gneiss as 2.41±0.40 W/(K·m). The average radioactive heat generation rate were 0.30±0.32 μW/m3 for dolomite and 1.32±0.69 μW/m3 for gneiss. Using the temperature curve after 551 days and thermal conductivity data, the Archean heat flow at the D01 well was calculated as (43.9±7.0) mW/m2, While the heat flow for the Neogene sedimentary cap was estimated at 88.6mW/m2. The heat flow of Neogene sedimentary caprock is significantly higher than that of Archean crystalline basement at the D01 well, with an excess of 44.7 mW/m2 accounting for approximately 50% of the total heat flow in the Neogene sedimentary caprock. This is primarily attributed to lateral thermal convection within the high-porosity and high-permeability karst dolomite layer, and vertical thermal convection facilitated by the Niudong fault, which collectively contribute to the heat supply of the Neogene sedimentary caprock. Thermal convection in karst fissure and fault zone contribute approximately 50% of the heat flow in the Neogene sedimentary caprock. This study quantitatively revealed the vertical distribution of heat flow, providing empirical evidence for the genetic mechanism of the convection-conduction geothermal system in sedimentary basins.
-
-
Table 1. Thermal conductivity of Archean gneiss core samples in D01 well
Depth (m) Number of samples Test value of thermal conductivity at room temperature (W/(K·m)) Temperature at different depths (°C) Thermal conductivity correction value according to temperature (W/(K·m)) Transient plane heat source method Transient hot wire method Average value of two methods 2,355.47–2,356.47 4 3.15 3.26 3.20 87.4 2.94 2,445.65–2,447.85 8 2.07 2.06 2.07 89.1 2.05 2,533.56–2,536.26 12 2.94 2.91 2.92 90.7 2.71 2,581.76–2,584.46 14 2.24 2.20 2.22 91.5 2.16 2,603.58–2,605.58 12 2.29 2.25 2.27 91.9 2.20
下载: 导出CSV
Table 2. Radiogenic heat production values for core samples from the D01 well
Sample number Depth(m) ρ (kg/m3) CU (μg/g) CTh (μg/g) CK (%) Radiogenic heat
production (μW/m3)Lithology 1 1,185.98 2,810.3 0.071 0.421 0.459 0.09 Dolomite 2 1,191.335 2,814.6 0.278 0.7 0.642 0.19 Dolomite 3 1,322.64 2,756.1 0.247 0.521 0.22 0.12 Dolomite 4 1,401.445 2,711.5 0.143 0.372 0.08 0.07 Dolomite 5 1,500.68 2,763.4 0.597 2.33 0.683 0.39 Dolomite 6 1,498.93 2,745.1 1.57 5.54 1.17 0.91 Dolomite 7 1,717.24 2,801.7 3.01 5.86 0.214 1.24 Gneiss 8 1,915 2,843.7 2.77 6.16 0.142 1.21 Gneiss 9 2,017.83 2,834.1 3.59 0.631 2.86 1.30 Gneiss 10 2,144.2 2,934.1 2.06 6.51 1.44 1.21 Gneiss 11 2,237.73 2,853.7 4.8 9.86 11.3 3.15 Gneiss 12 2,355.97 2,689.3 6.72 2.47 0.835 1.97 Gneiss 13 2,446.75 2,853.1 1.42 12.8 3.28 1.65 Gneiss 14 2,534.905 2,859.4 1.66 0.476 0.511 0.54 Gneiss 15 2,581.96 2,897.3 2.2 0.013 0.381 0.65 Gneiss 16 2,604.38 2,853.4 2.9 2.31 0.694 1.03 Gneiss 17 2,725 2,893.1 1.45 1.07 1.38 0.62 Gneiss 18 2,817.87 2,836.7 3.53 0.548 0.867 1.08 Gneiss 19 2,893.52 2,854.3 3.52 5.32 1.94 1.54 Gneiss
下载: 导出CSV
Table 3. Heat flow of the Neogene and Archean formations from the D01 well
Stratum Depth (m) Average value of heat flow (mW/m2) 233 days after the cessation of drilling 551 daysafter the cessation of drilling N 400–800 84.6 88.6 Ar 2,300–2,700 44.1 43.9
下载: 导出CSV
Table 4. Burial depth of karst reservoir roof, geothermal gradient and heat flow of the Cenozoic sedimentary cap in the three wells within Niudong fault zone
Well Depth of well (m) Burial depth of karst reservoir roof (m) Geothermal gradient of the Cenozoic sedimentary cap (°C/km) Rock thermal conductivity of
of the Cenozoic sedimentary cap (W/(K·m))Heat flow of the Cenozoic sedimentary cap (mW/m2) D09 1,653.2 1,015 49.3 1.74 85.8 XZ1 1,407.9 893.5 62.4 1.74 108.6 XZ2 1,282.6 778 72.8 1.74 126.7
下载: 导出CSV
-
Chen MX, Huang GS, Zhang WR, et al. 1982. The temperature distribution pattern and the utilization of geothermal water at Niutuozhen basement protrusion of central Hebei province. Chinese Journal of Geology, 17(3): 239−252. (in Chinese)
Cui Y, Zhu CQ, Qiu NS, et al. 2019. Radioactive heat production and terrestrial heat flow in the Xiong'an Area, North China. Energies, 12(24): 4608. DOI:10.3390/en12244608.
Dai MG, Lei HF, Hu JG, et al. 2019. Evaluation of recoverable geothermal resources and development parameters of Mesoproterozoic thermal reservoir with the top surface depth of 3500m and shallow in Xiong'an New Area. Acta Geologica Sinica, 93(11): 2874−2888. (in Chinese) DOI:10.19762/j.cnki.dizhixuebao.2019200.
Furlong KP, Chapman DS. 2013. Heat flow, heat generation, and the thermal state of the lithosphere. Annual Review of Earth and Planetary Sciences, 41(1): 385−410. DOI:10.1146/annurev.earth.031208.100051.
Guo SS, Zhu CQ, Qiu NS, et al. 2019. Present Geothermal Characteristics and Influencing Factors in the Xiong'an New Area, North China. Energies, 12(20). DOI:10.3390/en12203884.
Guo SS. 2020. Present geothermal characteristics and its influencing factors in Xiong'an New Area. M. S. thesis. Beijing: China University of Petroleum: 54−58. (in Chinese) DOI:10.27643/d.cnki.gsybu.2020.001411.
Hao ZJ. 2021. Geothermal field characteristics and influencing factors of Niutuozhen Uplift area in Jizhong Depression. M. S. thesis. Beijing: China University of Petroleum: 44−52. (in Chinese) DOI:10.27643/d.cnki.gsybu.2021.001474.
He LJ, Hu SB, Huang SP, et al. 2008. Heat flow study at the Chinese Continental Scientific Drilling site: Borehole temperature, thermal conductivity, and radiogenic heat production. Journal of Geophysics Research, 113(B2). DOI:10.1029/2007JB004958.
He LJ, Wang JY. 2021. Concept and application of some important terms in Geothermics and Geophysics such as terrestrial heat flow. China Terminology, 23(03): 3−9. (in Chinese) DOI:10.12339/j.issn.1673-8578.2021.03.001.
Jiang GZ, Gao P, Rao S, et al. 2016. Compilation of heat flow data in the continental area of China (4th edition). Chinese Journal of Geophysics, 59(8): 2892−2910. (in Chinese) DOI:10.6038/cjg20160815.
Li WW, Rao S, Tang XY, et al. 2014. Borehole temperature logging and temperature field in the Xiongxian geothermal field, Hebei Province. Chinese Journal of Geology, 49(03): 850−863. (in Chinese) DOI:10.3969/j.issn.0563-5020.2014.03.012.
Liu YG, Long XT, Liu F. 2022. Tracer test and design optimization of doublet system of carbonate geothermal reservoirs. Geothermics, 105: 102533. DOI:10.1016/j.geothermics.2022.102533.
Norden B, Förster A, Förster H, et al. 2020. Temperature and pressure corrections applied to rock thermal conductivity: Impact on subsurface temperature prognosis and heat-flow determination in geothermal exploration. Geothermal energy (Heidelberg), 8(1): 1−19. DOI:10.1186/s40517-020-0157-0.
Pang ZH, Kong YL, Pang JM, et al. 2017. Geothermal resources and development in Xiong'an New Area. Bulletin of Chinese Academy of Sciences, 32(11): 1224−1230. (in Chinese) DOI:10.16418/j.issn.1000-3045.2017.11.007.
Pang ZH, Pang JM, Kong YL, et al. 2020. Large-scale karst thermal storage identification method and large-scale sustainable mining technology. Science and Technology for Development, 16(Z1): 299−306. (in Chinese) DOI:10.11842/chips.20200516001.
Pribnow D, Williams CF, Sass JH, et al. 1996. Thermal conductivity of water-saturated rocks from the KTB Pilot Hole at temperatures of 25 to 300°C. Geophysical Research Letters, 23(4): 391−394. DOI:10.1029/95GL00253.
Rao S, Luo Y, Huang SD, et al. 2024. Heat accumulation effect of groundwater convective activity in karst geotherma reservoir in Jizhong Depression, Bohai Bay Basin. Chinese Journal of Geophysics, 67(08): 3075−3088. (in Chinese) DOI:10.6038/cig2024S0016.
Rybach L. 1988. Determination of heat production rate, in handbook of terrestrial heat flow density determination, edited by R. Haenel et al. Kluwer Acad., Dordrecht, Netherlands: 125−142.
Sass JH, Lachenbruch AH, Moses TH, et al. 1992. Heat flow from a scientific research well at Cajon Pass, California. Journal of Geophysical Research, 97(B4): 5017−5030. DOI:10.1029/91JB01504.
Seipold U, Huenges E. 1998. Thermal properties of gneisses and amphibolites — high pressure and high temperature investigations of KTB-rock samples. Tectonophysics, 291(1): 173−178. DOI:10.1016/S0040-1951(98)00038-9
Sun JX, Yue GF, Zhang W. 2023. Simulation of thermal breakthrough factors affecting carbonate geothermal-to-well systems. Journal of Groundwater Science and Engineering, 11(4): 379−390. DOI:10.26599/JGSE.2023.9280030.
Wang GL, Li J, Wu AM, et al. 2018a. A study of the thermal storage characteristics of Gaoyuzhuang Formation, A new layer system of thermal reservoir in Rongcheng uplift area, Hebei province. Acta Geoscientica Sinica, 39(05): 533−541. (in Chinese) DOI:10.3975/cagsb.2018.071901.
Wang GL, Liu YG, Duan HX, et al. 2023a. Crust-mantle differentiation and thermal accumulation mechanisms in the north China plain. Renewable Energy, 213: 63−74. DOI:10.1016/j.renene.2023.05.136.
Wang GL, Wang WL, Zhang W, et al. 2020. The status quo and prospect of geothermal resources exploration and development in Beijing-Tianjin-Hebei region in China. China Geology, 3(1): 173−181. DOI:10.31035/cg2020013.
Wang JY, Huang SP. 1988. Compilation of heat flow data in the China Continental area. Chinese Journal of Geology (Scientia Geologica Sinica), 23(2): 196−204. (in Chinese)
Wang K, Zhang J, Bai DW, et al. 2021a. Geothermal-geological model of Xiong'an New Area: Evidence from geophysics. Geology in China, 48(05): 1453−1468. (in Chinese) DOI:10.12029/gc20210511.
Wang K. 2022. Study on the geothermal geological structure and deep geothermal source mechanism of Xiong'an New Area based on comprehensive geophysical exploration. Ph. D. thesis. Chang Chun: Jilin University: 117−122. (in Chinese) DOI:10.27162/d.cnki.gjlin.2022.007525.
Wang SF, Liu JR, Sun Y, et al. 2018b. Study on the geothermal production and reinjection mode in Xiong County. Journal of Groundwater Science and Engineering, 6(3): 178−186. DOI:10.19637/j.cnki.2305-7068.2018.03.003.
Wang XW, Guo SY, Gao NA, et al. 2023b. Detection of carbonate geothermal reservoir in Niudong fault zone of Xiong'an New Area and its geothermal exploration significance. Geological Bulletin of China, 42(1): 14−26. (in Chinese) DOI:10.12097/j.issn.1671-2552.2023.01.002.
Wang ZT, Gao P, Jiang GZ, et al. 2021b. Heat flow correction for the high-permeability formation: A Case Study for Xiong'an New Area. Lithosphere, 2021(Special 5). DOI: 10.2113/2021/9171191
Wang ZT, Hu SB, Wang YB, et al. 2022. Influence of the groundwater convection within the high permeability formation on the overlying temperature field in Niutuozhen uplift. Chinese Journal of Geophysics, 65(2): 726−736. (in Chinese) DOI:10.6038/cjg2022P0341.
Wang ZT, Jiang GZ, Zhang C, et al. 2019a. Thermal regime of the lithosphere and geothermal potential in Xiong'an New Area. Energy Exploration & Exploitation, 37(2): 787−810. DOI:10.1177/0144598718778163.
Wang ZT, Zhang C, Jiang GZ, et al. 2019b. Present-day geothermal field of Xiong'an New Area and its heat source mechanism. Chinese Journal of Geophysics, 62(11): 4313−4322. (in Chinese) DOI:10.6038/cig2019M0326.
Wollenberg HA, Smith AR. 1987. Radiogenic heat production of crustal rocks: An assessment based on geochemical data. Geophysical Research Letters, 14(3): 295−298. DOI:10.1029/GL014i003p00295.
Wu AM, Ma F, Wang GL, et al. 2018. A study of deep-seated karst geothermal reservoir exploration and huge capacity geothermal well parameters in Xiongan New Area. Acta Geoscientica Sinica, 39(05): 523−532. (in Chinese) DOI:10.3975/cagsb.2018.071104.
Wang YB, Liu SW, Chen CQ, et al. 2024. Compilation of terrestrial heat flow data in continental China (5th edition). Chinese Journal of Geophysics, 67(11): 4233−4265. (in Chinese) DOI:10.6038/cjg2024S0284.
Xing YF, Wang HQ, Li J, et al. 2022. Chemical field of geothermal water in Xiong'an New Area and analysis of influencing factors. Geology in China, 49(06): 1711−1722. (in Chinese) DOI:10.12029/gc20220601.
Yao YH, Jia XF, Li ST, et al. 2022. Heat flow determination of Archean strata under the karst thermal reservoir of D01 well in Xiong'an New Area. Geology in China, 49(6): 1723−1731. (in Chinese) DOI:10.12029/gc20220602.
-
