GRAIN SIZE DISTRIBUTION IN THE TIDAL ZONE AND SHALLOW SEA ON THE NORTH SIDE OF THE HUANGHUA HARBOR
-
摘要: 在黄骅港北侧潮间带和浅海区,分别获得1个柱状样品(岩心长度132 cm,共分得44个样品)和50个底质样品,通过激光粒度分析仪对沉积物粒度进行了测试,获得了研究区底质和柱状样品的沉积物粒度特征,结果显示:研究区底质样品只有3种类型,即黏土质粉砂、粉砂和砂质粉砂;砂质粉砂分布在港池防沙堤附近的潮下带地区,粉砂主要分布在大辛堡村东水深-2~-5 m的浅海区及站位13,其余区域均为黏土质粉砂;黄骅港防沙堤截断了沿岸流,并改变了其方向,使其携带的沉积物在潮间带和防沙堤附近沉积,形成了黏土质粉砂在潮间带和港池防沙堤附近的沉积;与其相邻的砂质粉砂区是废弃三角洲海岸自然演化的证据;表层沉积物的粒度特征表面,黄骅港防沙堤的影响仅限于潮间带和其附近海区;根据沉积物粒度参数特征,HHG2孔可分为4个演化阶段,从下至上分别为:(1)132~100.5 cm的沉积物粗细小幅波动段;(2)100.5~56 cm的沉积物缓慢粗化段;(3)56~16 cm的事件影响型沉积物粗细快速波动段;(4)16~0 cm的沉积物快速粗化段。结合137Cs示踪定年和黄河在大口河附近入海历史,可知16~0 cm的沉积物快速粗化段,是对1917年以来黄河入海位置逐渐东移引起的河流作用减弱以及海平面上升导致的海洋作用增强的响应。Abstract: 1 core (132 cm long and 44 samples) and 50 bottom sediments samples were collected in the offshore area on the north side of the Huanghua Harbor, and grain size analysis was carried out with Mastersizer2000. Results indicate that there are three types of bottom sediments, namely sandy silt, silt and clayey silt, in the area. Sandy silt is distributed in the subtidal zone on the north side of the harbor, silt mainly in the offshore area -2m~-5m in water depth at Daxinpu and sampling site 13, and clayey silt in the other area. The Harbor has cut off the coastal current, and changed it to the direction along the dam of the Harbor, that caused the currents-carried sediments deposited on the tidal flat and the area near the dam. As an evidence of the abandoned deltaic coast, sandy silt near the Harbor suggests that the impact of the construction of the Harbor is limited to the tidal flat and its nearshore area. According to the vertical grain size distribution pattern of the sediments, the Hole HHG2 can be divided into four segments from bottom to top:(1) the segment with slight fluctuation of coarse-fine grains in 132~100.5 cm, (2) the segment slowly coarsening up in 100.5~56 cm, (3) the segment with rapidly coarse-fine fluctuation caused by episodic events in 56~16 cm, and (4) the segment rapidly coarsening up in 16~0 cm. Furthermore, the forth segment of 16~0 cm is well correlated to the period from 1917 up to present defined by 137Cs tracing and dating. During the period, the fluvial process was weakened due to the shift of the Yellow River eastward, and the enhancement of marine process by sea level rise.
-
Key words:
- grain size /
- bottom sediment /
- core /
- Huanghua Harbor
-
-
[1] Folk R L,Ward W C.Brazos river bar:a study in the significance of grain size parameters[J].Journal of Sedimentary Petrology,1957,(27):3-27.
[2] Visher G S.Grain size distribution and depositional processes[J].Journal of Sedimentary Petrology,1969,(39):1074-1106.
[3] Gao S,Collins M.Net sediment transport patterns inferred from grain size trends,based upon definition of "transport vectors"[J].Sedimentary Geology,1992,81:47-60.
[4] 高抒,Collins M.沉积物粒径趋势与海洋沉积动力学[J].中国科学基金,1998(4):241-246.[GAO Shu,Collins M.The use of grain size trends in marine sediment dynamics[J].Science Foundation in China,1998
(4):241-246.]
[5] 成都地质学院陕北队.沉积岩(物)粒度分析及其应用[M].北京:地质出版社,1978.[Chengdu College of Geology,Shanbei team.Sedimentary rock (material) particle-size analysis and its application[M].Beijing:Geological Publishing House,1978.]
[6] 孙有斌,高抒,鹿化煜.前处理方法对北黄海沉积物粒度的影响[J].海洋与湖沼,2001,32(6):665-671.
[SUN Youbin,GAO Shu,LU Huayu.Influence of different pretreatment procedures on the particle-size distribution of surficial sediments in the northern Yellow Sea[J].Oceanologia et Limnologia Sinica,2001,32(6):665-671.]
[7] 王德杰,范代读,李从先.不同预处理对沉积物粒度分析结果的影响[J].同济大学学报,2003,31(3):314-318.
[WANG Dejei,FAN Dadu,LI Congxian.Influence of different pretreatments on size analysis and its implication[J].Journal of Tongji University,2003,31(3):314-318.]
[8] 中华人民共和国国家质量监督检验检疫局,中国国家标准化管理委员会.海洋地质调查规范第8部分:海洋地质地球物理调查(GB/T 12763.8-2007
)[S].2007:1-79.[General Administration of Quality Supervision,Inspection and Quarantine of the People's Republic of China,Standardization administration of the People's Republic of China.Specifications for Oceanographic Survey-Part8:Marine Geology and Geoiphysics survey.(GB/T 12763.8-2007)[S].2007:1-79.]
[9] 贾建军,高抒,薛允传.图解法与矩法沉积物粒度参数的对比[J].海洋与湖沼,2002,33(6):577-582.
[JIA Jianjun,GAO Shu,XUE Yunchuan.Grain-size parameters derived from graphic and moment methods:A comparative study[J].Oceanologia et Limnologia Sinica,2002,33(6):577-582.]
[10] 李春初.大口河海岸特性和黄骅港的扩建问题[J].港口工程,1993(5):6-14.[LI Chunchu.Coastal characteristic of Dakouhe River and the expansion of Huanghua Harbor[J].Harbor Engineering,1993
(5):6-14.]
[11] McManus J.Grain size determination and interpretation[M]//Techniques in Sedimentlogy.Oxford,Blackwell,1988:63-85.
[12] 徐家声,刘鹤智.黄骅海岸带开发环境概论[M].北京:海洋出版社,1991.[XU Jiasheng,LIU Hezhi.Coastal Zone Development Environment of Huanghua[M].Beijing:China Ocean prass,1991.]
[13] 张庆河,王崇贤,杨华,等.黄骅港海域表层泥砂特性及其影响[J].中国港湾建设,2004(4):14-17.[ZHANG Qinghe,WANG Chongxian,YANG Hua,et al.Property and influence of sediments on seabed surface around Huanghua Harbor[J].China Harbour Engineering,2004
(4):14-17.]
[14] 张庆河,林全泓.黄骅港海域沿堤流现象遥感图像分析[J].中国港湾建设,2004(1):29-31.[ZHANG Qinghe,LIN Quanhong.Investigation of currents along breakwater for Huanghua Port with help of satellite romote sensing images[J].China Harbor Engineering,2004
(1):29-31.]
[15] 王宏,李建芬,康慧,等.泥质海岸带现代地质作用(沉积,剥蚀及岸线变迁)与精细测年[R].天津地质矿产研究所地调项目研究报告,2002:1-62.[WANG Hong,LI Jianfen,KANG Hui,et al.Modern Sedimentation of the Muddy Coast (Accumulation Rate,Erosion and Coastline Change) and High Resolution Dating Report[R].Tianjin Institute of Geology and Mineral Resources,China,2002,1
-82.]
[16] 李建芬,王宏,夏威岚,等.渤海湾西岸210Pbexc和137Cs测年与现代沉积速率[J].地质调查与研究,2003,26(2):114-128.
[LI Jiafen,WANG Hong,XIA Weilan,et al.210Pbexc and 137Cs dating and modern sedimentation rate on the western coast of Bohai Bay[J].Geological Survey and Research,2003,26(2):114-128.]
[17] 王福.渤海湾海岸带210Pb、137Cs示踪与测年研究:现代沉积及环境意义[D].中国地质科学院博士学位论文,2009.[WANG Fu.210Pbexc,137Cs tracing and dating on Bohai Bay Coast:modern sedimentation and implication[D].PhD thesis,Chinese Academy of Geological Sciences,China,2009.
]
[18] 王福,裴艳东,刘志广,等.137Cs示踪的黄骅港两侧海区的沉积特征[J].地质通报,2008,27(7):1054-1059.
[WANG Fu,PEI Yangdong,LIU Zhiguang,et al.Sedimentary characteristics of Huanghua Harbour traced by 137Cs[J].Geological Bulletin of China,2008,27(7):1054-1059.]
[19] 王福,王宏,王云生,等.黄骅港地区岸线变迁及滩面(浅海区形态变化研究[J].海洋地质与第四纪地质,2010,30(5):25-32.
[WANG Fu,WANG Hong,WANG Yunsheng,et al.Shoreline changes and morphology changes of tidal flat-shallow sea area of Huanghua Harbor[J].Marine Geology and Quaternary Geology,2010,30(5):25-32.]
[20] 王福,王宏,王云生,等.黄骅港地质环境研究报告[R].河北省国土资源厅/海洋局、中国地质调查局天津地质调查中心,2008.[WANG Fu,WANG Hong,WANG Yunsheng,et al.Study report of Geological environment in Huanghua Harbor[R].Hebei Province Department Land&Resources/SOA,Tianjin Center of Geological Survey,CGS,2008.]
-
