FEATURES OF CANYON MORPHOLOGY AND THEIR ORIGIN IN THE SHENHU AREA,NORTHERN SLOPE OF THE SOUTH CHINA SEA
-
摘要: 利用多波束水深及高分辨率数字单道地震测量手段,对南海北部陆坡神狐海域进行了精细地形和浅部地层结构探测,认为研究区存在4条海底峡谷及3条槽谷。其外形呈喇叭型或直线型,规模不等,长度为8~25 km,宽度为1.5~4 km,下切深度最大可达175 m。研究区浅地层自下而上可划分为U1和U2两套层序。地层总体上以高频、强振幅、中-高连续、平行-亚平行反射地震相为主,但在峡谷区层序U2则以杂乱或低连续反射为特征。在详细分析峡谷与槽谷地貌形态及浅地层地震反射特征的基础上,对其成因进行了初步分析,研究表明神狐海域浅地层发育与天然气水合物有关的BSR及滑塌体,水合物的分解导致地层滑塌并发生塌陷,在NW向构造以及底流冲刷共同作用下,最终形成本区形态各异的峡谷及槽谷地貌。其形成时间推测为第四纪,属幼年期阶段。Abstract: Detailed interpretation of morphology and shallow stratigraphic structure were carried out base on high-resolution multi-beam water depth data and single-channel seismic profiles. Three canyons and four channels were recognized in the study area. The bird view of the shape and length of the canyons or channels vary greatly in a range of 8~25km long, 1.5~4 km wide, with a maximum incised depth up to 175 m. The shallow strata of the study area can be divided to two parts from bottom to top:namely U1 and U2 respectively. The seismic reflection in general is characterized by a high frequency, strong amplitude, medium-high continuation, and parallel to sub-parallel pattern. However, the reflection in the canyon is chaotic with low continuation or even discontinued. The research result indicates that slumping was well developed in the sequence U2 in the canyons area, which has close relationship with the occurrence of gas hydrate. The canyons or channels were initially formed by the decomposition of gas hydrate and further developed under the control of NW trend faults and the erosion of bottom current. The canyons and channels were formed in Quaternary according to its shape and stratigraphic position. The results may contribute to the study of oceanic morphology and the exploration of gas hydrate in the region.
-
Key words:
- continental slope /
- canyon /
- morphology /
- origin /
- South China Sea
-
-
[1] Irina Popescu, Gilles Lericolais, Nicolae Panin, et al. The Danube submarine canyon (Black Sea):morphology and sedimentary processes[J]. Marine Geology, 2004,206:249-265.
[2] 韩喜彬,李家彪,龙江平,等.我国海底峡谷研究进展[J].海洋地质动态,2007,26(2):41-48.
[HAN Xibin,LI Jiabiao,LONG Jiangping,et al. Development of research on submarine canyon in China[J]. Marine Geology Letters, 2007,26(2):41-48.]
[3] 吴自银,王小波,金翔龙,等.冲绳海槽弧后扩张证据及关键问题探讨[J].海洋地质与第四纪地质,2004,24(3):67-76.
[WU Zhiyin,WANG Xiaobo.JlN Xianglong,et a1.The evidence of the back arc spreading and discussion on the key issues in the Okinawa Trough[J].Marine Geology and Quaternary Geology,2004,24(3):67-76]
[4] 刘守全,刘锡清,王圣洁,等. 南海灾害地质类型及分区[J].中国地质灾害与防治学报,2000,11(4):39-44.
[LIU Shouquan, LIU Xiqing, WANG Shengjie, et al. Kinds of hazardous geology and division in South China Sea[J]. The Chinese Journal of Geological Hazard and Control, 2000, 11(4):39-44.]
[5] Arzola R G,Wynn R B,Lastras G,et a1.Sedimentary features and processes in the Nazare and setubal submarine canyons,west Iberian Margin[J].Marine Geology,2008,205(1-2):64-88.
[6] Posamentier H W,Jervey M T,Vail P R.Eustatic Controls on Clastic Depositional Conceptual Framework[M].1988:109-124.
[7] 祝有海,吴必豪,卢振权.中国近海天然气水合物找矿前景[J].矿床地质,2001,20(2):172-180.
[ZHU Youhai,WU Bihao, LU Zhcnquan. The prospecting for gas hydrate offshore China[J]. Mineral Deposits, 2001,20(2):172-180.]
[8] 刘忠臣,陈义兰,丁继胜,等.东海海底地形分区特征和成因研究[J].海洋科学进展,2003,21(2):160-173.
[LIU Zhongchen,CHEN Yilan,DING Jisheng,et al. Study on zoned characteristics and formation cause of the East China Sea submarine topography[J]. Advances in Marine Science, 2003,21(2):160-173.]
[9] 李家彪.东海区域地质[M].北京:海洋出版社,2008:109-112.[LI Jiabiao. Regional Geology of East China Sea[M].Beijing:Ocean Press, 2008:109
-112.]
[10] Lee J T.Topography,Echo Characters (3.5 kHz) and Tectonics of the Kaoping Slope off Southwesten Taiwan Coast[D].Taipei:National Taiwan University,1992.
[11] 戚筱俊.台湾海峡地形、地质及地震概述[J].西部探矿工程,1999,11(4):4-6.
[QI Youjun. Brief introduction of morphology, geology and earth quake in Taiwan Straits[J].West China Exploration Engineering, 1999,11(4):4-6.]
[12] 金庆焕.南海地质与油气资源[M].北京:地质出版社,1989:84-111.[JIN Qinghuan. Oil and Gas Resource and Geology of South China Sea[M].Beijing; Geology Press,1989:84
-111.]
[13] 郑晓东,朱明,何敏,等.珠江口盆地白云凹陷荔湾深水扇砂体分布预测[J].石油勘探与开发,2007,34(5):529-533.
[ZHENG Xiaodong, ZHU Ming, HE Min. Prediction of Liwan deep submarine fan sand body distribution, Baiyun Sag, Pearl River Mouth Basin[J]. Petroleum Exploration and Development, 2007,34(5):529-533.]
[14] 姚伯初.南海的天然气水合物矿藏[J].热带海洋学报,2001,20(2):20-28.
[YAO Bochu. The gas hydrate in the South China Sea[J]. Journal of Tropical Oceanography,2001,20(2):20-28.]
[15] 李守军,初凤友,方银霞,等. 南海北部陆坡神狐海域浅地层与单道地震剖面联合解释-水合物区沉积地层特征[J].热带海洋学报,2010,29(4):56-62.
[LI Shoujun,CHU Fengyou,FANG Yinxia,et al. Associated interpretation of sub-bottom and single-channel seismic profiles from slope of Shenhu area in the northern South China Sea for characteristics of gas hydrate sediment[J]. Journal of Tropical Oceanography, 2010,29(4):56-62.]
[16] 张光学,祝有海,梁金强,等.构造控型天然气水合物矿藏及其特征[J].现代地质,2006,20(4):605-612.
[ZHANG Guangxue, ZHU Youhai, LIANG Jinqiang, et al. Tectonic controls on gas hydrate deposits and their characteristics[J].Geoscience, 2006, 20(4):605-612.]
[17] 陆敬安,杨胜雄,吴能友,等. 南海神狐海域天然气水合物地球物理测井评价[J].现代地质,2008,22(3):447-451.
[LU Jingan, YANG Shengxiong, WU Nengyou, et al. Well logging evaluation of gas hydrates in Shenhu area, South China Sea[J].Geoscience, 2008,22(3):447-451.]
[18] 傅宁, 米立军, 张功成. 珠江口盆地白云凹陷烃源岩及北部油气成因[J]. 石油学报,2007,28(3):32-38.
[FU Ning, MI Lijun, ZHANG Gongcheng. Source rocks and origin of oil and gas in the northern Baiyun Depression of Pearl River Mouth Basin[J].Acta Petrolei Sinica,2007,28(3):32-38.]
[19] 龚跃华,杨胜雄,王宏斌,等.南海北部神狐海域天然气水合物成藏特征[J]. 现代地质,2009,23(2):210-216.
[GONG Yuehua, YANG Shengxiong, WANG Hongbin, et al. Gas hydrate reservoir characteristics of Shenhu area, north slope of the South China Sea[J]. Geoscience, 23(2):210-216.]
[20] 赵月霞,刘保华,李西双,等. 东海陆坡不同类型海底峡谷的分布构造响应[J].海洋科学进展,2009,17(4):460-468.
[ZHAO Yuexia,LIU Baohua,LI Xishuang,et al. Distributions of different submarine canyons on the East China Sea slope and their tectonic response[J]. Advances in Marine Science, 2009,17(4):460-468.]
[21] 刘忠臣.中国近海及邻近海域地形地貌[M].北京:海洋出版社,2005:227.[LIU Zhongchen. Landform and Morphology of Offshore and Adjacent Marine Area in China[M].Beijing:Ocean Press,2005:227.]
[22] Coleman J M, Prior D B, Lindsay J F. Deltaic influences on shelf edge instability processes[C]//In:Stanley D J, Moore G T (Eds.). The Shelf Break:Critical Interface on Continental Margins. SEPM Special Publication, 1983, 33:121-137.
[23] Kolla V, Perlmutter M A. Timing of turbidity sedimentation on the Mississippi fan[J]. AAPG Bulletin, 1993, 77(7):1129-1141.
[24] Kolla V, Macurda Jr D B. Sea-level changes and timing of turbidity-current events in deep-sea fan systems[C]//In:Wilgus C K, Hastings B S, Kendall C G St C, et al. Sea-Level Changes:An Integrated Approach. SEPM Special Publication,1988,42:381-392.
[25] Wong H K, Panin N, Dinu C, et al. Morphology and post-Chaudian (Late Pleistocene) evolution of the submarine Danube fan complex[J]. Terra Nova,1994,6:502-511.
[26] 陈泓君,李文成,陈弘,等. 南海北部中更新世晚期以来古海岸变迁及其地质意义[J].南海地质研究,2005:57-66.[CHEN Hongjun,LI Wencheng,CHEN Hong. Ancient coastline transfer since late middle-Pleistocene in northern South China Sea and its geological significance[J]. Geological South China Sea,2005:57
-66.]
[27] Rowe M M, Gettrust J F. Faulted structure of the bottom simulating reflector on the black Ridge, west North Atlantic[J].Geology,1993,21(9):833-836.
[28] Xu W,Ruppel C. Predicting the occurrence, distribution, and evolution of methane gas hydrate in porous marine sediments[J]. Journal of Geophysical Research B,1999,104(3):5081-5095.
[29] 孙运宝,吴时国,王志君,等.南海北部白云大型海底滑坡的几何形态与变形特征[J].海洋地质与第四纪地质,2008,28(6):69-77.
[SUN Yunbao1,WU Shiguo1,WANG Zhijun,et al. The geometry and deformation characteristics Of Baiyun submarine landslide[J]. Marine Geology and Quaternary Geology, 2008,28(6):69-77.]
[30] 张光学,黄永样,祝有海,等.南海天然气水合物的成矿远景[J].海洋地质与第四纪地质,2002,22(1):75-81.
[ZHANG Guangxue, HUANG Yongyang, ZHU Youhai. et al. Prospect of gas hydrate resources in the South China Sea[J].Marine Geology and Quaternary Geology,2002,22(1):75-81.]
[31] Brown H E,Holbrook W S,Hornbach M J,et al. Slide structure and role of gas hydrate at the northern boundary of the Storegga Slide,off shore Norway[J]. Marine Geology,2006,229:179-186.
[32] 吴时国,姚根顺,董冬冬,等. 南海北部陆坡大型气田天然气水合物的成藏地质构造特征[J].石油学报,2008,29(3):324-328.
[WU Shiguo, YAO Genshun, DONG Dongdong, et al.Geological structures for forming gas hydrate reservoir in the huge deepwater gas field of the northern South China Sea[J].Acta Petrolei Sinica,2008,29(3):324-328.]
[33] 张树林. 珠江口盆地白云凹陷天然气水合物成藏条件及资源量前景[J]. 中国石油勘探,2007(6):23-27.[ZHANG Shulin. Accumulation conditions and prospect for natural gas hydrate resources in Baiyun Sag, Pearl River Mouth Basin[J].China Petroleum Exploration,2007
(6):23-27.]
[34] 沙志彬,杨木壮,梁劲,等. 南海北部陆坡海底异常地貌特征与天然气水合物的关系[J]. 南海地质研究,2003(14):29-34.[SHA Zhibin,YANG Muzhuang, LIANG Jin, et al. The characteristics of the abnormal physiognomys of seabed related to gas hydrate in north slope, South China Sea[J].Geological South China Sea,2003
(14):29-34.]
[35] 阎贫,陈多福.南海北部白云凹陷渗漏型天然气水合物地球物理证据[J].热带海洋学报,2009,28(3):25.[YAN Pin,CHEN Duofu. New geophysical evidence for gas hydrates in Baiyun Sag in the northern margin of the South China Sea[J]. Journal of Tropical Oceanography, 2009
,28(3):25.]
[36] 吴时国,姚伯初. 天然气水合物赋存的地质构造分析与资源评价[M]. 北京:科学出版社,2008:16-20.[WU Shiguo,YAO Bochu. Analysis of Geology Tectonic and Evaluation to Gas Hydrate Resources[M].Beijing:Science Press,2008:16
-20.]
[37] 邓希光,吴庐山,付少英,等.南海北部天然气水合物研究进展[J].海洋学研究,26(2):67-74.[DENG Xiguang,WU Lushan,FU Shaoying,et al. The research advances of natural gas hydrates in northern South China Sea[J].Journal of Marine Sciences,26
(2):67-74.]
[38] 王宏斌,张光学,梁劲,等.南海北部陆坡构造坡折带中的天然气水合物[J].沉积学报,2008,26(2):283-293.
[WANG Hongbin,ZHANG Guangxue,LIANG Jin, et al.Gas Hydrates in the SSBZ in the North Slope of the South China Sea[J]. Acta Sedimentologica Sinica, 2008,26(2):283-293.]
[39] 刘以宣,卓家伦.从南海北部新构造运动特征试论该区地质环境稳定性[J].热带海洋,1984,3(3):55-64.
[LIU Yixuan,ZHUO Jialun. A discuss on the stability of geology environments in terms of the neotectonic features of the Northern South China Sea[J].Tropical Oceanology,1984,3(3):55-64.]
-
