DISCOVERY OF MESOZOIC GRANODIORITES IN THE SOUTHWEST BASIN OF THE SOUTH CHINA SEA AND ITS TECTONIC IMPLICATIONS
-
摘要: 利用在南海西南海盆南缘首次发现的花岗闪长岩样品,通过等离子质谱仪、岩相显微镜和电子探针等设备对其地球化学组成进行了分析;并对其组分中黑云母矿物进行了40Ar/39Ar年代学研究。40Ar/39Ar等时线年龄显示岩石的结晶年龄为(109.5±1.5) Ma,是早白垩世岩浆入侵的产物。地球化学测试表明:样品以富SiO2、K2O,高Al2O3、贫TiO2为特征。地球化学-构造判别图解显示,样品属于火山弧花岗岩,为造山类花岗岩。样品可能是海盆早期张裂阶段裂谷系组成的重要岩石类型,而裂谷拉张的过程可能与现代红海的演化相似,经历了裂谷沉陷过程,当裂谷宽度、深度达到一定规模时,洋壳随之而产生。该样品的发现,揭示其产出位置可能是南海西南海盆的南部边界,而且是洋盆扩张初期断裂系统的组成部分,为探讨南海的张裂、形成与演化历史提供了新的线索。
-
关键词:
- 中生代花岗闪长岩 /
- 40Ar-39Ar年龄 /
- 构造意义 /
- 南海西南海盆
Abstract: The Southwestern Basin is the key region to the understanding of the origin and the evolvement of the South China Sea.Some critical geological problems remain in a dilemma so far concerning the evolution of the South China Sea, such as the formation of the sea floor and the boundaries of the basin because its complexity in regional tectonic background, active sedimentation and lack of rock samples.Granodiorite samples have been collected recently from the southern margin of the southwest basin of the South China Sea (SCS).The samples were analyzed for major elements, trace elements and rare earth trace elements (REE) with ICP-MS.Mineralogy was studied using the petrographic microscope and electron microprobe.The 40Ar/39Ar laser probe was used to date the biotite in the samples.The 40Ar-39Ar ages of the biotite of the samples are in the range of 109.5±1.5Ma, indicating that they are products of magmatic intrusion in Early Cretaceous.Their geochemistry shows that the granodiorites are characterized by high SiO2, K2O, and Al2O3, but low TiO2.Tectonic discrimination diagrams suggest an extension-related magmatism, either in an arc or forearc setting, mainly belonging to the syncollision type and is hardly related to orogeny.They may be the main rocks formed in a rift system in the early tensional rifting stage.The process of tensional rifting is somewhat similar with the evolutionary process of the Red Sea, which has experienced rifting and sagging.The oceanic crust was come into being when the rift valley reached certain scale of width and depth.The granodiorite samples have also provided important evidence to define the boundary of the Southwestern Basin and the clues to study the expanding model.-
Key words:
- Mesozoic granodiorite /
- discovery /
- chronology of 40Ar-39Ar /
- tectonic implications
-
-
[1] Taylor B,Hayes D E.The Origin and History of the South China Sea Basin[M]. In Hayes D E (ed).The Tectonic and Geologic Evolution of Southeast Asia Seas and Islands, Part 2.Geophysical Monograph, AGU, Washington, 1983,27:23-56.
[2] Tapponier P.On the Mechanics of the Collision Between India and Asia[M]. In:Coward M P, Rise A C(eds.). Collision Tectonics.New York:Blackwell Scientific Publication, 1986, 115-117.
[3] 何廉声.南海的形成、演化与油气资源[J].海洋地质与第四纪地质, 1988,8(2):15-28.
[HE Liansheng.The formation, evolution and the resources of oil and gas in the South China Sea[J].Marine Geology and Quaternary Geology, 1988,8(2):15-28.]
[4] Briais A, Patriat P, Tapponnier P.Updated interpretation of magnetic anomalies and seafloor spreading stages in the South China Sea:implications for the Tertiary tectonics of Southeast Asia[J].Geophys.Res., 1993, 98:6299-6328
[5] 姚伯初.南海海盆在新生代的构造演化[J].海洋地质与第四纪地质, 1996,16(2):1-13.
[YAO Bochu.Tectonic evolution of the South China Sea in Cenozoic[J].Marine Geology and Quaternary Geology, 1996,16(2):1-13.]
[6] 周蒂,陈汉宗,吴世敏,等.南海的右行陆缘裂解成因[J].地质学报, 2002,76(2):180-190.
[ZHOU Di, CHEN Hanzong, WU Shimin, et al.Opening of the South China Sea by dextral splitting of the East Asian continental margin[J].Acta Geologica Sinica, 2002,76(2):180-190.]
[7] 姚伯初,万玲,吴能友.南海新生代构造演化及岩石圈三维结构特征[J].地质通报, 2005,24(1):1-8.
[YAO Bochu, WAN Ling, WU Nengyou.Cenozoic tectonic evolution and the 3D structure of the lithosphere of the South China Sea[J].Regional Geology of China, 2005,24(1):1-8.]
[8] 詹文欢,朱照宇,孙龙涛,等.试论南海新构造运动的时限及其差异性[J].地质学报, 2006,80(4):491-496.
[ZHAN Wenhuan, ZHU Zhaoyu, SUN Longtao, et al.The epoch and diversities of neotectonic movement in the South China Sea[J].Acta Geologica Sinica, 2006,80(4):491-496.]
[9] 曾维军,李振五,吴能友,等.南海海域的上地慢活动特征及印支地幔柱[J].地质学报, 1999,73(4):376.[ZENG Weijun, LI Zhenwu, WU Nengyou,et al.Characteristics of the upper mantle in the South China Sea and the plume of Indo-Sinia[J].Acta Geologica Sinica, 1999
,73(4):376.]
[10] 鲍才旺.南海地貌图[C]//见:何廉声,陈邦彦.南海地质地球物理图集.广州:广东省地图出版社,1987.[BAO Caiwang.Physiognomy of South China Sea[C]//In:HE Liangsheng, CHEN Bangyan eds. Geological and geophysical atlas of South China Sea.Guangdong Atlas Publishing House, Guangzhou,1987.]
[11] 薛万俊.南海地貌图[C]//见:何廉声,陈邦彦.南海地质地球物理图集.广州:广东地图出版社,1987.[XUE Wanjun.Physiognomy of South China Sea[C]//In:HE Liangsheng, CHEN Bangyan eds. Geological and geophysical atlas of South China Sea.Guangdong Atlas Publishing House, Guangzhou,1987.]
[12] 姚伯初.南海西南海盆的岩石圈张裂模式探讨[J].海洋地质与第四纪地质, 1999,19(2):37-49.
[YAO Bochu.On the lithospheric rifting model in the southwest sub-basin of South China Sea[J].Marine Geology and Quaternary Geology, 1999,19(2):37-49.]
[13] 黄维,汪品先.南海沉积物总量的统计:方法与结果[J].地球科学进展, 2006,21:465-473.[HUANG Wei, WANG Pinxian.The statistics of sediment mass in the South China Sea:method and result[J].Advances in Earth Science, 2006
,21:465-473.]
[14] Shipboard Scientific Party.Leg 184 Preliminary Report[R].Proceedings of the Ocean Drilling Program, Volume 184, 1999:1-89.
[15] Shipboard Scientific Party.Leg 184 Summary:Exploring the Asian Monsoon through Drilling in the South China Sea[R].Proceedings of the Ocean Drilling Program, Initial Reports, Volume 184, 2000.
[16] 刘金萍,阎贫.南海西南次海盆声呐浮标地震测深资料研究[J].海洋科学, 2003,27(9):35-40.
[LIU Jinping, YAN Pin.2003.Study on the sonobuoy seismic survey data from southwestern sub-basin in the South China Sea[J].Marine Sciences, 2003,27(9):35-40.]
[17] 刘金萍,阎贫,赵明辉.南海西南海盆地震反射特征及其形成时代[J].海洋地质与第四纪地质, 2003,23(1):67-72.
[LIU Jinping, YAN Pin, ZHAO Minghui.Seismic reflective characteristics and the age of the southwest sub-basin in the South China Sea[J].Marine Geology and Quaternary Geology, 2003,23(1):67-72.]
[18] 张健,宋海斌,李家彪.南海西南海盆构造演化的热模拟研究[J].地球物理学报, 2005,48(6):1357-1365.
[ZHANG Jian, SONG Haibin, LI Jiabiao.Thermal modeling of the tectonic evolution of the southwest subbasin in the South China Sea[J].Chinese Journal of Geophysics, 2005,48(6):1357-1365.]
[19] Li X H.Cretaceous magmatism and lithospheric extension in SE China[J].Journal of Asian Earth Science, 2000, 18:293-305.
[20] 刘海龄,孙岩,郭令智,等.南沙微板块边界的动力学演化[J].海洋学报, 2001,23(5):95-103.
[LIU Hailing, SUN Yan, GUO Lingzhi, et al.On dynamic process and boundary faults kinematic characteristics of Nansha microplate[J].Acta Oceanologica Sinica, 2001,23(5):95-103.]
[21] 李兆鼐,权恒,李之彤,等.中国东部中、新生代火成岩及其深部过程[M].北京:地质出版社, 2003:220-283.[LI Zhaonai, QUAN Heng, LI Zhitong, et al.Meso-Cenozoic Volcanic Rocks and Their Deep Process in Eastern China[M].Geological Press House, Beijing, 2003:220
-283.]
[22] 陈汉宗,孙珍,周蒂.华南中生代岩相变化及海相地层时空分布[J].热带海洋学报, 2003,22(2):74-82.
[CHEN Hanzong, SUN Zhen, ZHOU Di.Distributions of Mesozoic lithofacies and marine strata in South China[J].Tropic Oceanology, 2003,22(2):74-82.]
[23] 刘海龄,阎贫,孙岩,等.南沙微板块的层块构造[J].中国地质, 2002, 29(4):374-381.
[LIU Hailing, YAN Pin, SUN Yan, et al.Layer-block tectonics of the Nansha microplate[J].Chinese Geology, 2002, 29(4):374-381.]
[24] 周蒂,刘海龄,陈汉宗.南沙海区及其周缘中-新生代岩浆活动及构造意义[J].大地构造与成矿学, 2005, 29(3):354-363.
[ZHOU Di, LIU Hailing, CHEN Hanzong.Mesozoic-Cenozoic magmatism in southern South China Sea and its surrounding areas and its implications to tectonics[J].Geotectonica Et Metallogenia, 2005,29(3):354-363.]
[25] 阎贫,刘海龄.南海及其周缘中新生代火山活动时空特征与南海的形成模式[J].热带海洋学报, 2005,24(2):33-41.
[YAN Pin, LIU Hailing.Temporal and spatial distributions of Meso-Cenozoic igneous rocks over South China Sea[J].Tropic Oceanology, 2005,24(2):33-41.]
[26] 颜佳新,周蒂.南海及周边部分地区特提斯构造遗迹:问题与思考[J].热带海洋学报, 2002,21(2):43-49.
[YAN Jiaxin, ZHOU Di.Reviews on Tethyan trace in South China Sea and some adjacent regions[J].Tropic Oceanology, 2002,21(2):43-49.]
[27] 周蒂,孙珍,陈汉宗,等.南海及其围区中生代岩相古地理和构造演化[J].地学前缘, 2005,12(3):204-218.
[ZHOU Di, SUN Zhen, CHEN Hanzong, et al.Mesozoic lithofacies, paleo-geography, and tectonic evolution of the South China Sea and surrounding areas[J].Earth Science Frontiers, 2005,12(3):204-218.]
[28] 刘海龄,谢国发,阎贫,等.南沙海区中生界岩相分布及构造特征[J].海洋与湖沼, 2007,38(3):272-278.
[LIU Hailing, XIE Guofa, YAN Pin, et al. Tectonic implication of Mesozoic marine deposits in the Nansha Islands of the South China Sea[J].Oceanologia et Limnologia Sinica, 2007,38(3):272-278.]
[29] Kudrass H R, Wiedicke M, Cepek P, et al.Mesozoic and Cenozoic rocks dredged from the South China Sea (Reed Bank area) and Sulu Sea and their significance for plate-tectonic reconstructions[J].Marine and Petroleum Geology, 1986,3:19-30.
[30] Hutchison C S.Geological Evolution of Southeast Asia[M].Clarendon Press, Oxford, 1989:354.
[31] Areshev E G, Dong T L, San N T, et al.Reservoirs in fractured basement on the continental shelf of southern Vietnam[J].J. Petrol. Geol., 1992,15(4):451-464.
[32] 鄢全树,石学法,王昆山,等.南沙微地块花岗质岩石LA-ICP-MS锆石U-Pb定年及其地质意义[J].地质学报, 2008,82(8):1057-1067.
[YAN Quanshu, SHI Xuefa, WANG Kunshan, et al.LA-ICPMS zircon U-Pb dating of granitic rocks from the Nansha micro-block,South China Sea,and its geological significance[J].Acta Geologica Sinica, 2008,82(8):1057-1067.]
[33] [34] 董申保.近代花岗岩的研究回顾[J].高校地质学报, 1995,1(2):1-12.
[DONG Shenbao.Review of the study with granite[J].Geological Journal of China Universities, 1995,1(2):1-12.]
[35] Pitcher W S.The Nature and Origin of Granite (Second Printing)[M], Bounbary Row, London, SE18HN:Chapman and Hall, 1997:2-6.
[36] Barbarin B.A review of the relationships between granitoid types, their origins and their geodynamic environments[J].Lithos, 1999,46:605-626.
[37] Harris N B, Pearce J A, Tindle A G.Geochemical characteristics of collision zone magmatism[C]//In:Coward M P, Ries A C,eds.Collision Tectonics.Ceol Soc Lond Spec Publ, 1986,19:67-81.
[38] 徐夕生,周新民, Rreilly S Y,等.中国东南部下地壳物质与花岗岩成因探索[J].岩石学报, 1999,15(2):217-223.
[XU Xisheng, ZHOU Xinmin, Rreilly S Y, et al.Exploration for the lower crustal materials and granite genesis in southeast China[J].Acta Petrologica Sinica, 1999,15(2):217-223.]
[39] Pearce J A, Harris N B, Tindle A G.Trace element discrimination diagrams for the tectonic interpretation of granitic rocks[J].J.Petrol., 1984,25,956-983.
[40] Batchelor R A, Bowden P.Petrogenetic interpretation of granitoid rock series using multicationic parameters[J].Chemical Geology, 1985,48(1-4):43-55.
[41] Maniar P D, Piccoli P M.Tectonic discrimination of granitoids[J].Geol.Soc.Am.Bull., 1989,101:635-643.
[42] 金庆焕主编.南海地质与油气资源[M].北京:地质出版社, 1989:1-83.[JIN Qinghuan.Geology of the South China Sea and its Resources of Petroleum and Gas[M].Geological Press House, Beijing, 1989:1
-83.]
[43] 陈圣源.南海扩张磁异常及海盆成因探讨[M]//南海地质.北京:科学出版社, 1985.[CHEN Shengyuan.Discuss of the magnetism abnormity and expanded of the South China Sea[M].Geology of the South China Sea.Science Press, Beijing, 1985.]
[44] 吕文正,柯长志,吴声迪,等.南海中央海盆条带磁异常特征及构造演化[J].海洋学报, 1987,9(1):69-78.
[LU Wenzheng, KE Changzhi, WU Shengdi, et al.Characteristics of magnetic lineations and tectonic evolution of the South China Sea basin[J].Acta Oceanologica Sinica, 1987,9(1):69-78]
[45] Ru Ke, Pigott J D.Episodic rifting and subsidence in the South China Sea[J].AAPG Bull., 1986,70(9):1136-1155.
[46] 姚伯初,曾维军, Hayes D E,等.中美合作调研南海地质专报[M].武汉:中国地质大学出版社, 1994:191-194.[YAO Bochu, ZENG Weijun, Hayes D E, et al.The Geological Memoir of South China Sea Surveyed Jointly by China & USA[M].Press of University of Geosciences, Wuhan, 1994:191
-194.]
[47] Taylor B, Hayes D E.The tectonic evolution of the South China Sea Basin[C]//In Hayes D E(ed). The tectonic and geologic evolution of Southeast Asia seas and islands, Geophysical Monograph, AGU, Washington, 1980,23:89-104
[48] 刘昭蜀, 陈忠, 潘宇.南海海盆的形成演化探讨[J].海洋科学, 1992,4:20-24.[LIU Zhaoshu, CHEN Zhong, PAN Yu.A discussion on the origin and history of South China Sea basin[J].Marine Sciences, 1992
,4:20-24.]
[49] 丁巍伟, 陈汉林, 杨树锋,等.南海西南次海盆与东部次海盆地质与地球物理分析[J].高校地质学报, 2002, 8(3):268-279.
[DING Weiwei, CHEN Hanlin, YANG Shufeng, et al.Geological and geophysical analysis of the southwestern and eastern sub-basins, South China Sea[J].Geological Journal of China Universities, 2002, 8(3):268-279.]
-
