GRAVITY FIELD IN TAIWAN AREA AND ITS RELATION WITH MOHO FEATURES
-
摘要: 台湾地区空间重力异常幅值在-240~340 mGal之间变化,布格重力异常幅值在-140~380 mGal之间变化,重力异常及圈闭走向呈现北东、北北东向。将小波分析方法引入台湾地区的重力异常数据处理,经过分析比对,台湾地区布格重力异常小波分析三阶逼近结果代表莫霍面起伏形态,利用重力数据反演了深部界面莫霍面,研究区莫霍面深度为12~32 km,莫霍面展布呈现北东走向,台湾岛区莫霍面深,在24~31 km之间变化,由西北往东南为厚-薄-厚分布,台湾东部海区莫霍面深度浅,在12~17 km之间变化,台湾岛属于陆壳结构,靠近菲律宾海的台湾岛外海地区,属于海洋性地壳结构。Abstract: Newly acquired gravity data from the Taiwan area are used in this paper for revealing the characteristics of the gravity anomaly field of the region. The wavelet analysis method is for the first time introduced into gravity anomaly data processing for the area. The deep basement is also calculated for inversion of the Moho Discontinuity. The features of the basement are studied together with geological data. In this area, the free air gravity changes from -240 to 340 mGal. and the Bouguer gravity from -140 to 380 mGal. Gravity anomalies and anomaly closures of this area are all in a trend of NE and NNE direction. After analysis and comparison, it is found that the 3th order approximation of the Bouguer gravity anomaly may represent the Moho fluctuation. Data shows that the Moho depth, calculated with the Bouguer gravity anomaly data, changes from 13 to 31 km and extends in NE direction in the area. It is deeper in Taiwan Island rather than other areas and shows a thick-thin-thick pattern from northwest to southeast between 24 and 31 km. The Moho depth in the sea area to the east of Taiwan Island is much shallower in a range between 13 and 17 km. In conclusion, the Taiwan island itself based upon a continental crust, but the sea area surrounding the Taiwan Island and near the Philippine sea based on the oceanic crust.
-
Key words:
- gravity anomaly /
- moho /
- Taiwan area
-
-
[1] 张季生,高锐,李秋生,等.台湾海峡及邻区地球物理特征及地壳密度结构[J].地质论评,2008,54(5):694-700.
[ZHANG Jisheng, GAO Rui, LI Qiusheng, et al. Geophysical characteristic and density structure of crust in Taiwan strait and neighboring area[J]. Geological Review, 2008,54(5):694-700.]
[2] 沈金瑞,许世远,傅文杰.台湾海峡地区横向构造及其对东南沿海地震的作用[J].大地构造与成矿学,2009,32(4):535-541.
[SHEN Jinrui, XU Shiyuan, FU Weijie, et al. Transverse structure of Taiwan strait area and its effect on the earthquakes of southeast coastal regions[J]. Geotectonica et Metallogenia, 2009,32(4):535-541.]
[3] 李三忠, 索艳慧, 刘鑫,等.南海的基本构造特征与成因模型:问题与进展及论争[J]. 海洋地质与第四纪地质,2012, 32(6):35-53.
[LI Sanzhong, SUO Yanhui, LIU Xin, et al. Basic structural pattern and tectonic models of the South China Sea:problems, advances and controversites[J].Marine Geology and Quaternary Geology, 2012, 32(6):35-53.]
[4] 李三忠, 索艳慧, 刘鑫, 等. 南海的盆地群与盆地动力学[J]. 海洋地质与第四纪地质,2012, 32(6):55-78.
[LI Sanzhong, SUO Yanhui, LIU Xin, et al. Basin dynamics and basin groups of the South China Sea[J]. Marine Geology and Quaternary Geology, 2012, 32(6):55-78.]
[5] 李三忠, 赵淑娟, 余珊,等.东亚大陆边缘的板块重建与构造转换[J]. 海洋地质与第四纪地质,2013, 33(3):65-94.
[LI Sanzhong, SUO Yanhui, LIU Xin, et al. Tectonic transition and plate reconstructions of the East Asian Continental Margin[J]. Marine Geology and Quaternary Geology, 2013, 33(3):65-94.
[6] Ai Y, Chen Q, Zeng F, et al. The crust and upper mantle structure beneath southeastern China[J]. Earth and Planetary Science Letters, 2007,260:549-563.
[7] Kim K H, Chiu J M, Kao H, et al. A preliminary study of crustal structure in Taiwan region using receiver function analysis[J]. Geophysical Journal International, 2004,159(1):146-164.
[8] Yeh Y H, Shih R C, Lin C H, et al. Onshore/Offshore wdie-angle deep seismic profiling in Taiwan[J]. TAO,1998,9(3):301-316.
[9] Yen Y H, Yeh Y H, Wu F T. Two-dimensional crustal structures of Taiwan from gravity data[J]. Tectonics,1998,17(1):103-111.
[10] Yen Y H, Yeh Y H, Lin C H. Free-air gravity map of Taiwan and its applications[J]. TAO, 1990,1(2):143-155.
[11] Hwang R D,Yu G K. Shear-wave velocity structure of upper mantle under Taiwan from the array analysis of surface waves[J]. Geophys. Res. Lett., 2005,32,L07310.doi:10.1029/2004GL021868.
[12] Huang B S, Chen K C, Wang K L, et al. Velocities of Pn-waves in the Taiwan Strait and its surrounding area from regional earthquakes[J]. TAO, 1998,9:473-486.
[13] 廖其林,王振民,王屏路,等.福州-泉州-汕头地区地壳结构的爆炸地震研究[J].地球物理学报,1988,31(3):270-280.
[LIAO Qilin, WANG Zemin, WANG Pinlu, et al. Explosion seismic study of the crustal structure in Fuzhou-Quanzhou-Shantou region[J]. Acta Geophysica Cinica,1988,31(3):270-280.]
[14] 余兆康,史磷华.台湾周围海域地区的居里等温面及其与地震关系的初步探讨[J].中国地震,1989,5(3):67-72.
[YU Zhaokang, SHI Linhua. The preliminary analysis of isothermal surface of Curie temperature around the offshore Taiwan and its relations to earthquakes[J]. Earthquake Research in China,1989,5(3):67-72.]
[15] 高德章,赵金海,薄玉玲,等.东海重磁地震综合探测剖面研究[J].地球物理学报,2004,47(5):853-861.
[GAO Dezhang, ZHAO Jinhai, BO Yuling, et al. A profile study of gravitive-magnetic and seismic comprehensive survey in the East China Sea[J]. Chinese Journal of Geophysics, 2004,47(5):853-861.]
[16] 高德章,赵金海,薄玉玲,等.东海及邻近地区岩石圈三维结构研究[J].地质科学,2006,41(1):10-26.
[GAO Dezhang,ZHAO Jinhai,BO Yuling, et al. A study on lithosphere 3D structures in the East China Sea and adjacent regions[J]. Chinese Journal of Geology, 2006,41(1):10-26.]
[17] 戴明刚.东海及邻域的两条剖面地球物理反演与综合解释[J]. 地球物理学进展,2004,19(2):331-340.
[DAI Minggang. Inversion research for gravity and synthetical interpretation of two profiles in the area of East China Sea and its adjacency[J]. Progress in Geophysics, 2004,19(2):331-340.]
[18] 韩波,张训华,裴建新,等.东海及其邻域壳-幔结构与展布特征[J].地球物理学进展,2007,22(2):376-382.
[HAN Bo, ZHANG Xunhua, PEI Jianxin, et al. Characteristics of crust-mantle in East China sea and adjacent regions[J]. Progress in Geophysics, 2007, 22(2):376-382.]
[19] [20] 侯遵泽,杨文采.中国重力异常的小波变换与多尺度分析[J].地球物理学报,1997,40(1):85-95.
[HOU Zunze, YANG Wencai. Two-dimensional wavelet transform and multi-scale analysis of the gravity field of China[J]. Chinese Journal of Geophysics,1997, 40(1):85-95.]
[21] 杨宇山,李媛媛,刘天佑,等.小波细节的微分特征及其子重力场断裂分析中的应用[J].地质与勘探,2003,39(1):41-44.
[YANG Yushan, LI Yuanyuan, LIU Tianyou, et al. The differential characteristic of the wavelet details and its application in fault analysis of gravity field[J]. Geology and Prospecting,2003,39(1):41-44.]
[22] 杨文采,施志群,侯遵泽,等. 离散小波变换与重力异常多重分解[J].地球物理学报,2001,44(4):534-541.
[YANG Wencai, SHI Zhiqun, HOU Zunze. Discrete wavelet transform for multiple decomposition of gravity anomalies[J]. Chinese Journal of Geophysics,2001,44(4):534-541.]
[23] 江为为,刘少华,郝天珧,等.应用重力资料估算东海冲绳海槽地壳厚度[J].地球物理学进展,2002,17(1):35-41.
[JIANG Weiwei, LIU Shaohua, HAO Tianyao, et al. Using gravity data to compute crustal thickness of East China Sea and Okinawa Trough[J]. Progress in Geophysics, 2002,17(1):35-41.]
[24] Chung S L, Jahn B M, Chen S J, et al. Miocene basalts in northwestern Taiwan:Evidence for EM-type mantle source in the continental lithosphere[J]. Geochim. Cosmochim. Acta, 1995,9:549-555.
-
