BURIAL DISSOLUTION OF ZHUJIANG REEF LIMESTONE ON THE LIUHUA CARBONATE PLATFORM, SOUTH CHINA SEA
-
摘要: 南海流花碳酸盐岩台地近年来利用高精度3D地震资料处理解释技术,新发现珠江组礁灰岩地层发育数量众多的灰岩坑,平面上沿NWW向断层分布。由于灰岩坑的形成导致该区储层非均质性增强,油气成藏更加复杂,给油气勘探带来诸多困难和挑战。以岩心抽提物GC、GC/MS分析为基础,结合区域构造运动史、地层水动力特征等,分析该区埋藏酸性流体的成因与来源;并对"白垩状"灰岩成因提出新的认识,探讨了研究区埋藏酸性流体溶蚀模式。研究认为,埋藏酸性流体主要来源于:(1)烃源岩内有机质热演化作用及其生成的烃类与矿物和水的有机无机氧化作用,(2)原油运移过程中在输导层内的有机无机氧化作用,(3)油藏内原油的生物降解作用等形成的有机酸性流体。研究表明原油生物降解成因有机酸浓度可达4 300 μg/g油以上。流花碳酸盐岩台地上发育的"白垩状"结构灰岩,是在活跃地层水动力条件下,由有机酸性流体长期溶蚀、浸泡和淘洗形成。在含油层段内发育的致密夹层,仅外部受酸性流体溶蚀改造而内部未受影响部分仍保留致密结构而未能形成"白垩状"灰岩。埋藏可溶性有机酸性流体在活跃的地层水动力条件下,通过复杂的裂缝网络发生运移,在断层和裂缝最发育区岩体破碎,酸-岩反应空间最大,速率最高,造成碳酸盐岩地层溶蚀垮塌,从而形成沿NWW向断裂体系分布的灰岩坑。Abstract: A number of sinkholes have been discovered in the Zhujiang reef limestone on the Liuhua carbonate platform, South China Sea, by high resolution 3D seismic survey. Most of the sinkholes occur along the faults in NWW direction. The high heterogeneity of reservoir caused by sinkholes has much increased the complexity of hydrocarbon distribution, and thus the difficulties and challenges in exploration. In this paper, we discussed the origin of the sinkholes in the chalk-like limestone and the source of acid fluids after burial, studied the burial dissolution based upon the GC, GC/MS extracts from the Zhujiang reef limestone as well as the regional tectonics and the dynamic characteristics of formation water. It is concluded that the acid fluids are mainly from:①pyrolysis of organic matter and interactions of organic-inorganic matters with hydrocarbon in source rocks; ②oxidation of oil compounds and generation of organic acids in the process of migration; ③biodegradation of oil in reservoirs, and the concentration of organic acids generated by biodegradation may reach the value of 4 300 μg/g oil. The chalky limestone is formed by the continuous corrosion, soaking and washing by organic acid. Tight limestone layers found in the oil-bearing zone are caused by partial solution of the external part by acidic fluid with the inner part remaining unaffected. The acid fluids migrated together with active formation water along complex fracture networks. Therefore, along the faults and fractures and in the areas of broken strata, there is more space and highest acid-rock interaction. With the collapse of carbonate strata, sinkholes are formed.
-
Key words:
- acid fluids /
- burial dissolution /
- reef limestone /
- Liuhua carbonate platform
-
-
[1] 马永生.四川盆地普光超大型气田的形成机制[J].石油学报,2007,28(2):9-14
,21.[MA Yongsheng. Generation mechanism of Puguang gas field in Sichuan Basin[J]. Acta Petrolei Sinica, 2007, 28(2):9-14,21.]
[2] 朱光有,张水昌,梁英波.四川盆地深部海相优质储集层的形成机理及其分布预测[J].石油勘探与开发,2006,33(2):161-166.
[ZHU Guangyou, ZHANG Shuichang, LIANG Yinbo. Formation mechanism and distribution prediction of high-quality marine reservoir in deeper Sichuan Basin[J].Petroleum Exploration and Development, 2006,33(2):161-166.]
[3] 顾家裕,贾进华,方辉.塔里木盆地储层特征与高孔隙度、高渗透率储层成因[J].科学通报,2002,47(S1):9-15.
[GU Jiayu, JIA Jinhua, FANG Hui. The genesis of high porosity, high permeability reservoirs and its characteristics in Tarim Basin[J]. Chinese Science Bulletin, 2002, 47(S1):9-15.]
[4] 朱光有,杨海军,苏劲,等.中国海相油气地质理论新进展[J].岩石学报,2012,28(3):722-738.
[ZHU GuangYou, YANG Haijun, SU Jin, et al. New progress of marine hydrocarbon geological theory in China[J].Acta Petrologica Sinica,2012,28(3):722-738.]
[5] 朱东亚,胡文瑄,张学丰,等.塔河油田奥陶系灰岩埋藏溶蚀作用特征[J].石油学报,2007,28(5):57-62.
[ZHU Dongya, Hu Wenxuan, ZHANG Xuefeng, et al. Characteristics of burial dissolution in the Ordovician limestone of Tahe Oilfield[J]. Acta Petrolei Sinica, 2007, 28(5):57-62.]
[6] 郑和荣,刘春燕,吴茂炳,等.塔里木盆地奥陶系颗粒石灰岩埋藏溶蚀作用[J].石油学报,2009,30(1):9-15.
[ZHENG Herong, LIU Chunyan, WU Maobing,et al. Burial dissolution of Ordovician granule limestone in Tarim Basin[J]. Acta Petrolei Sinica, 2009, 30(1):9-15.]
[7] 远光辉,操应长,杨田,等.论碎屑岩储层成岩过程中有机酸的溶蚀增孔能力[J].地学前缘,2013,20(5):207-219.
[YUANG Guanghui, CAO Yingchang, YANG Tian, et al. Porosity enhancement potential through mineral dissolution by organic acids in the diagenetic process of clastic reservoir[J].Earth Science Frontiers,2013,20(5):207-219.]
[8] Surdam R C, Jiao Z S, Macgowan D B.Redox reactions involving hydrocarbons and mineral oxidants:a mechanism for significant porosity enhancement in sandstones[J].AAPG Bulletin,1993,77(9):1509-1518.
[9] 蔡春芳,顾家裕,蔡洪美.塔中地区志留系烃类侵位对成岩作用的影响[J].沉积学报,2001,19(1):60-65.
[CAI Chunfang, GU Jiayu, CAI Hongmei. Effect of hydrocarbon emplacement on diagenesis of silurian sandstone of central Tarim Basin[J].Acta Sedimentologica Sinica,2001,19(1):60-65.]
[10] 陈端新,吴时国,施和生,等.珠江口盆地流花碳酸盐台地灰岩坑的地震反射特征及成因探讨[J].吉林大学学报:地球科学版,2012,42(6):1935-1943.
[CHEN Duanxin, WU Shiguo, SHI Hesheng, et al. Seismic characteristics and generations of sinkholes in the Liuhua carbonate platform,Pearl River Mouth Basin[J].Journal of JilinUniversity:Earth Science Edition,2012,42(6):1935-1943.]
[11] 张广旭,吴时国,朱伟林,等.南海北部陆坡流花碳酸盐台地地球物理响应[J].海洋地质与第四纪地质,2011,31(4):105-112.
[ZHANG Guangxu, WU Shiguo, ZHU Weilin,et al. Geophysical response of the Liuhua carbonate platform in Northern South China Sea[J]. Marine Geology and Quaternary Geology,2011,31(4):43-50.]
[12] 吕炳全,徐国强,王红罡,等.南海新生代碳酸盐台地淹没事件记录的海底扩张[J].地质科学,2002,37(4):405-414.
[LÜ Bingquan, XU Guoqiang, WANG Honggang, et al. Sea floor spreading recorded by drowning events of Cenozoic carbonate platforms in the South China Sea[J]. Chinese Journal of Geology, 2002,37(4):405-414.]
[13] 徐国强,吕炳全,王红罡.新生代南海北部碳酸盐岩台地的淹没事件研究[J].同济大学学报:自然科学版,2002,38(1):35-40.
[XU Guoqiang, LÜ Bingquan, WANG Hongfang. Drowning event research:insights from Cenozoic carbonate platforms in northern South China Sea[J].Journal of Tongji University, 2002,38(1):35-40.]
[14] 钱一雄,陈跃,陈强路,等.塔中西北部奥陶系碳酸盐岩埋藏溶蚀作用[J].石油学报,2006,27(3):47-52.
[QIAN Yixiong, CHEN Yu, CHEN Qianglu,et al. General characteristics of burial dissolution for Ordovician carbonate reservoirs in the Northwest of Tazhong Area[J]. Acta Petrolei Sinica, 2006, 27(3):47-52.]
[15] 蔡春芳,梅博文,马亭,等.塔里木盆地有机酸来源、分布及对成岩作用的影响[J].沉积学报,1997,15(3):105-111.
[CAI Chuanfang, MEI Bowen, MA Ting, et al. The source, distribution of organic acids in oilfield waters and their effects on mineral diagenesis in Tarim Basin[J].Acta Sedimentologica Sinica,1997, 15(3):105-111.]
[16] 马永生,蔡勋育,李国雄.四川盆地普光大型气藏基本特征及成藏富集规律[J].地质学报,2005,79(6):858-865.
[MA Yongsheng, CAI Xunyu, LI Guoxiong. Basic characteristics and concentration of the Puguang gas field in the Sichuan Basin[J].Acta Geologica Sinica,2005,79(6):858-865.]
[17] 郝乐伟,王琪,廖朋,等.番禺低隆起-白云凹陷北坡第三系储层次生孔隙形成机理分析[J].沉积学报,2011,29(4):734-743.
[HAO Lewei, WANG Qi, LIAO Peng, et al. Forming mechanism of secondary porosity in Tertiary reservoirs in Panyu low uplift and North slope of Baiyun Sag[J].Acta Sedimentologica Sinica,2011,29(4):734-743.]
[18] 禚喜准,王琪,陈国俊,等.恩平凹陷恩平组下段成岩过程分析与储层动态评价[J].沉积学报,2008,26(2):257-264
,282.[ZHUO Xizhun, WANG Qi, CHEN Guojun, et al. Analysis of diagenetic process and dynamic reservoir assessment[J].Acta Sedimentologica Sinica,2008, 26(2):257-264,282.]
[19] Wellsbury P, Goodman K, Barth T, et al. Deep marine biosphere fuelled by increasing organic matter availability during burial and heating[J]. Nature, 1997, 388(6642):573-576.
[20] Lewan M D, Fisher J B. Organic acids from petroleum source rocks[M]//Organic acids in geological processes. Springer Berlin Heidelberg, 1994:70-114.
[21] 曾溅辉,朱志强,吴琼,等.烃源岩的有机酸生成及其影响因素的模拟实验研究[J].沉积学报,2007,25(6):847-851.
[ZENG Jianhui, ZHU Zhiqiang, WU Qiang, et al. Experimental study on the generation of organic acids from source rocks and its effect factors[J].Acta Sedimentologica Sinica,2007, 25(6):847-851.]
[22] Seewald J S. Organic-inorganic interactions in petroleum-producing sedimentary basins[J]. Nature, 2003, 426(6964):327-333.
[23] 朱俊章,施和生,邓宏文,等.珠江口盆地惠州凹陷古近系烃源岩层序地层学和地球化学研究[J].天然气地球科学,2007,18(5):709-714.
[ZHU Junzhang, SHI Hesheng, DENG Hongwen, et al. Studies of sequence strata geochemistry of source rocks in Paleogenge in Huizhou Depression in Pearl River Mouth Basin[J].Natural Gas Geoscience, 2007,18(5):709-714.]
[24] 刘军,施和生,杜家元,等.东沙隆起台地生物礁、滩油藏成藏条件及勘探思路探讨[J].热带海洋学报,2007,26(1):22-27.
[LIU Jun, SHI Hesheng, DU Jiayuan, et al. Forming conditions and exploration direction of reef oil-gas pool in carbonate platform of Dongsha Massif[J].Journal of Tropical Oceangraphy, 2007,26(1):22-27.]
[25] Gaupp R, Schoener R. Intra-reservoir generation of organic acids and late stage enhanced porosity in sandstones (Best of AAPG)[C]//71st EAGE Conference & Exhibition. 2009.
[26] López L. Study of the biodegradation levels of oils from the Orinoco Oil Belt (Junin area) using different biodegradation scales[J]. Organic Geochemistry, 2014, 66:60-69.
[27] Larter S, Huang H, Adams J, et al. The controls on the composition of biodegraded oils in the deep subsurface:Part Ⅱ-Geological controls on subsurface biodegradation fluxes and constraints on reservoir-fluid property prediction1[J]. AAPG Bulletin, 2006, 90(6):921-938.
[28] Peters K E, Moldowan J M. The biomarker guide:interpreting molecular fossils in petroleum and ancient sediments[M]. Englewood Cliffs, NJ:Prentice Hall, 1993.
[29] Wenger L M, Davis C L, Isaksen G H. Multiple controls on petroleum biodegradation and impact on oil quality[J]. SPE Reservoir Evaluation & Engineering, 2002, 5(5):375-383.
[30] Larter S, Huang H, Adams J, et al. A practical biodegradation scale for use in reservoir geochemical studies of biodegraded oils[J]. Organic Geochemistry, 2012, 45:66-76.
[31] Jones D M, Head I M, Gray N D, et al. Crude oil biodegradation via methanogenesis in subsurface petroleum reservoirs[J]. Nature, 2008, 451(7175):176-180.
[32] Larter S, Wilhelms A, Head I, et al. The controls on the composition of biodegraded oils in the deep subsurface-part 1:biodegradation rates in petroleum reservoirs[J]. Organic Geochemistry, 2003, 34(4):601-613.
[33] 陈传平,梅博文,贾发敬,等.生油岩产生低分子量有机酸的模拟实验研究[J].地球化学,1994,23(2):155-160.
[CHEN Chunping, MEI Bowen, JIA Fajing, et al. Expermental study on simulation of the generation of Low-Molecular weight organic acids from source rocks[J].Geochimica, 1994,23(2):155-160.]
[34] Meredith W, Kelland S J, Jones D M. Influence of biodegradation on crude oil acidity and carboxylic acid composition[J]. Organic Geochemistry, 2000, 31(11):1059-1073.
[35] 刘静江,陈国红,黄成毅,等.塔里木盆地原油酸值特征及成因[J].石油勘探与开发,2009,36(6):718-724.
[LIU Jingjiang, CHEN Guohong, HUANG Chenyi, et al. Acidity features and origin of crude oil in Tarim Basin[J].Petroleum Exploration and Development, 2009,36(6):718-724.]
[36] Richard J Sizun J P Machhour l.Development and compartmentalization of chalky carbonate reservoirs:The Urgonian Jura-Bas Dauphiné platform model (Génissiat,southeastern France)[J].Sedimentary Geology,2007,198(3):195-207.
[37] 吴熙纯,王权锋,李培华,等.南海早中新世东沙台地流花生物礁-滩组合的白垩状结构化及白垩状孔隙储集层[J].古地理学报,2010,12(4):451-466.
[WU Xichun, WANG Qianfeng, LI Peihua,et al. Chalky texture formation and chalky porous reservoir of Liuhua reef-bank complex on the early Miocene Dongsha platform, South China Sea[J].Journal of Paleogeography,2010,12(4):451-466.]
[38] 岳大力,吴胜和,林承焰,等.流花11-1油田礁灰岩油藏沉积-成岩演化模式[J].石油与天然气地质,2005,26(4):518-523
,529.[YUE Dali, WU Shenghe, LIN Chenyan, et al. Sedimentary and diagenetic evolution pattern of reef limestone reservoirs in Liuhua 11-1 oilfield[J]. Oil & Gas Geology,2005,26(4):518-523,529.]
[39] 古莉,胡光义,罗文生,等.珠江口盆地流花油田新近系生物礁灰岩储层特征及成因分析[J].地学前缘,2012,19(2):49-58.
[GU Li, HU Guangyi, LUO Wensheng, et al. Characteristics and genesis of reservoir spaces in Neocene reef reservoir of Liuhua oilfield,Pearl River Mouth Basin[J].Earth Scienc Frontiers,2012,19(2):49-58.]
[40] 岳大力,吴胜和,林承焰,等.流花11-1油田礁灰岩油藏储层非均质性及剩余油分布规律[J].地质科技情报,2005,24(2):90-96.
[YUE Dali, WU Shenghe, LIN Chenyan, et al. Reservoir heterogeneity and remaining oil distribution pattern of reef limestone reservoir in Liuhua 11-1 Oilfield[J]. Geological Science and Technology Information, 2005,24(2):90-96.]
[41] 赵撼霆,吴时国,马玉波,等.南海珠江口盆地东沙隆起区生物礁演化模式[J].海洋地质与第四纪地质,2012,32(1):43-50.
[ZHAO Hanting, WU Shiguo, MA Yubo, et al. An evolution model of bio-reefs at the Dongsha uplift,Zhu Jiang Kou Basin,South China Sea[J]. Marine Geology and Quaternary Geology,2012,32(1):43-50.]
[42] Taylor T R.Petrographic and geochemical characteristics of dolomite types and the origin of ferroan dolomite in the Trenton Formation, Ordovician, Michigan Basin, USA[J].Sedimentology,1986,33(1):61-86.
-
