3500m钻机移摆管设计及动力学仿真研究

详细信息

刊出日期: 2014-04-10

Design of Pipe Racking for 3500m Hydraulic Core Drill Rig and the Dynamic Simulation Analysis

Publish Date: 10 April 2014

摘要: 随着我国探矿深度不断增加,钻探设备的尺寸不断加大,操作人员的劳动强度也在增加。基于此,3500 m液压岩心钻机需要适配一套移摆管装置,以实现快速、安全地运移钻杆,降低工人的劳动强度。对移摆管机构的设计进行了简单介绍,并利用ADAMS动力学仿真软件对移摆管机构进行运动仿真,找出设计的不足之处,给出优化建议。
- 液压钻机 /
- 移摆管 /
- ADAMS /
- 动力学仿真
Abstract: With the increasing depth of exploration,the size of drilling equipment becomes larger and larger, and the labor intensity of operators is also on the increase.Based on this situation, a set of pipe racking device is needed for 3500m hy-draulic core drill to realize fast and safe pipe arranging and reduce labor intensity of operating workers.The paper briefly in-troduces the design of the pipe racking device; motion simulation is conducted on pipe racking device by using dynamic simulation software ADAMS to identify the deficiencies in the design, and some optimization suggestions are put forward.
- hydraulic core drill /
- pipe racking /
- ADAMS /
- dynamic simulation
