全液压轻型岩心钻机主塔结构设计分析

详细信息

刊出日期: 2015-09-10

Analysis on Main Tower Structure Design of Light Full Hydraulic Core Drill

Publish Date: 10 September 2015

摘要: 主塔作为钻机中重要的组成部分,为钻机在给进过程中提供支撑、给进导轨、定位等,必须具有足够的承载能力、强度、刚度、整体稳定性和必要的操作使用空间。介绍了XDQ-1200型全液压轻型岩心钻机主塔采用铝合金结构的受力分析。
- 钻塔 /
- 有限元分析 /
- 全液压轻型岩心钻机
Abstract: As an important part of drilling rig, the main tower provides support, feeding guide rail and positioning in the feeding process, it must has sufficient bearing capacity, stiffness, strength, integral stability and necessary operation space.This paper introduces the mechanics analysis on aluminum alloy structure used for the main tower of XDQ-1200 light full hydraulic core drill.
- drill tower /
- finite element analysis /
- light full hydraulic core drill
