Development and Application of an Intelligent Hot-pressing Sintering Machine for Diamo nd Bit
-
摘要: 针对我国传统的金刚石钻头烧结机自动化程度低,难以灵活应对不同种类配方的金刚石钻头热压烧结工艺、温度、压力等要求的现状,研制了一种新型金刚石钻头智能烧结机。该智能烧结机集光、电、液压于一体,以单片机为控制系统的核心器件,利用模糊PID控制原理,实时监测、控制烧结温度和工作压力,实现了预存工艺自动运行,控制效果满足钻头烧结工艺要求。对金刚石钻头热压烧结机的工作原理、温度及压力参数对成品钻头质量的影响进行了分析,并介绍了与热压机配套的控制系统的设计。Abstract: Because of the low automation level of traditional diamond drill sintering machine in China, it is difficult to flexi-bly deal with the requirements of diamond bits of different formula in hot pressing process, temperature and pressure.A new hot-pressing intelligent sintering machine for diamond bit is developed.It integrates optical, electricity and hydraulic pressure, taking the microcontroller as the core device of the control system and using fuzzy PID control theory to monitor and control the sintering temperature and pressure in real time to achieve prestoring process automatic operation, the control effect meets the needing of bit sintering process.The paper analyzes the influence of the working principle, temperature and pressure parameters of this hot-pressing sintering machine on the quality of finished bits and introduces its control system design matched with hot press.
-
Key words:
- sintering machine /
- diamond bit /
- PID fuzzy theory /
- intelligent control
-
-
