Seismic Signal Characteristics of a New Source Based on Methane Gaseous Detonation in the Tibetan Plateau
-
摘要: 利用人工震源(又称主动震源)激发地震波是区域地下结构探测的主要方式之一。绿色环保和安全理念日渐盛行下, 寻找适用于生态脆弱和自然环境恶劣的青藏高原的人工震源需求迫切。本文介绍了新型甲烷气爆震源在高海拔低气压的青藏高原内部进行实验的相关过程及其效果。利用聚类分析、线性叠加、相位加权叠加等信号处理方法, 并与同期共线的炸药震源信号进行对比分析。结果显示:甲烷气爆震源(WB-76-1700, WB-70-2000及WB-60-500型震源当量分别为1.72 kg、1.72 kg和0.25 kg炸药)激发的地震波频率较高(频带范围1–50 Hz, 主频为5–30 Hz), 传播距离可达6.5 km; 同期炸药震源(48 kg)激发的地震波信号频率低于甲烷震源(主频低于20 Hz); 甲烷震源信号波形与实验所用甲烷震源型号无关, 与台站到震源的距离有关, 并推测可能与随机爆轰激发过程也相关; 甲烷震源适合于浅层速度结构探测, 特别是适合在波传播路径更加复杂的金属矿集区环境条件, 且施工效率更高。总之, 通过本次在青藏高原实验并与同期共线的炸药震源对比, 甲烷震源是一种有效的新型绿色环保型人工震源。鉴于此次实验甲烷气爆当量较小, 较炸药震源激发的地震波传输距离近。未来继续拓展实验, 进一步提高甲烷气爆震源当量并获得较大炮检偏移距的高信噪比地震波信号。Abstract: Artificial seismic source, which is also known as active source and is used to excite seismic wave, is an important way to detect underground structures.With the increasing popularity of the environmental protection and safety, it is urgent to find the new artificial source which is suitable for the fragile ecology and harsh natural environment of the Tibetan Plateau.This paper introduces the data processing and preliminary result of the experiment with a Methane Gaseous Source (MGS) under the special environment of high altitude and low pressure in the Tibetan Plateau, which includes such methos as cluster analysis, linear stacking, and phase weighted stacking, in comparison with the signals from traditional dynamite sources (TDS) during the same period in the same area.The results show the following phenomena:(1) The frequency range of the seismic wave excited by MGS is much higher (the frequency band range is 1–50 Hz, the dominant frequency is 5–30 Hz) than that by TDS.The power from MGS of WB-76-1700, WB-70-2000 and WB-60-500 type are equivalent to 1.72 kg, 1.72 kg and 0.25 kg TDS respectively.The wave propagation distance is up to 6.5 km.The frequency range of seismic wave excited by TDS of 48 kg is lower than that by MGS within the dominant seismic frequencies band of lower than 20 Hz; (2) the signal waveform of MGS is irrelevant to the device type of MGS, but depends on the epicenter distance and random detonation process; (3) it is much more suitable for shallow exploration and is especially effective in polymetallic ore concentration area with more complex wave propagation path.The efficiency in field work of MGS is higher than that of TDS.In brief, MGS is a new effective green and environmental artificial source.It is due to the small equivalent of MGS in this experiment that the travel distance of seismic waves excited by source is shorter than TDS of 48 kg.In the future experiment, higher signal-to-noise ratio seismic signal with larger distance would be recorded by enhancement of the equivalent of MGS.
-
Key words:
- methane detonation source /
- Tibetan Plateau /
- green and environmental
-
-
常旭, 李林新, 刘伊克, 王红落.2008.北京断陷黄庄-高丽营断层伪随机可控震源地震剖面[J].地球物理学报, 51(5):1503-1510.
陈颙, 李宜晋.2007.地震波雷达研究展望:用人工震源探测大陆地壳结构[J].中国科学技术大学学报, 37(8):813-819.
陈颙, 徐逸鹤, 蔡辉腾, 李稳.2018.关于地震科学实验场的一些思考--地下云图[J].中国地震, 34(2):165-171.
陈颙, 朱日祥.2005.设立“地下明灯研究计划”的建议[J].地球科学进展, 20(3):485-489.
高荣庆.1994.从气体分子运动论分析火药力的物理含义[J].火炸药, (2):40-44.
哈广浩.2019.藏南亚东-谷露裂谷中-南段晚新生代正断层作用[D].北京:中国地质科学院.
贺日政, 高锐.2003.西藏高原南北向裂谷研究意义[J].地球物理学进展, 18(01):35-43.
李光明, 潘桂棠, 王高明, 黄志英, 高大发.2004.西藏冈底斯成矿带矿产资源远景评价与展望[J].成都理工大学学报(自然科学版), 31(01):22-27.
苏金波, 王海涛, 王琼, 张文来, 冀战波, 魏芸芸, 陈昊, 张文秀.2017.利用聚类分析方法研究新疆呼图壁大容量气枪震源重复性[J].地震研究, 40(04):613-618, 678.
王宝善, 葛洪魁, 王彬, 王海涛, 张元生, 蔡辉腾, 陈颙.2016.利用人工重复震源进行地下介质结构及其变化研究的探索和进展[J].中国地震, 32(2):168-179.
王洪体, 庄灿涛, 薛兵, 赵翠萍, 朱祖杨.2009.精密主动地震监测[J].地球物理学报, 52(7):1808-1815.
王伟涛, 王宝善.2012.基于聚类分析的多尺度相似地震快速识别方法及其在汶川地震东北端余震序列分析中的应用[J].地球物理学报, 55(6):1952-1962.
王永哲, 陈石, 陈鲲.2021.InSAR数据约束的2020年西藏定日MW5.7地震源模型及构造意义[J].地震, 41(1):116-128.
吴章明, 曹忠权, 申屠炳明, 邓起东.1990.西藏申扎南发现地震地表破裂[J].地震地质, 12(4):317-318, 389.
徐善辉, 王伟涛, 王力伟, 杨微, 许卫卫.2020a.基于甲烷气爆震源的城市地区断层结构探测[C]//2020年中国地球科学联合学术年会论文集--专题51:城市地下介质成像和探测.北京:中国和平音像电子出版社:3343.
徐善辉, 王伟涛, 张云鹏, 许卫卫.2020b.基于甲烷气爆震源的区域尺度三维地震走时层析成像[C]//2020年中国地球科学联合学术年会论文集--专题 49:浅地表地球物理进展.北京:中国和平音像电子出版社:3296.
徐泰然, 卢占武, 王海燕, 李洪强, 李文辉.2018.深地震反射剖面揭示的西藏娘热矿集区上地壳结构[J].吉林大学学报(地球科学版), 48(02):556-565.
徐泰然.2018.深地震反射剖面揭示的西藏娘热矿集区深部结构[D].北京:中国地质科学院.
徐心悦.2019.藏南申扎-定结断裂系卡达正断裂晚第四纪活动性及其环境效应[D].北京:中国地震局地质研究所.
张超, 姚华建, 童平, 刘沁雅, 雷霆.2020.基于伴随方法的线性台阵背景噪声面波和远震体波联合成像研究[J].地球物理学报, 63(11):4065-4079.
张进江, 郭磊, 丁林.2002.申扎-定结正断层体系中、南段构造特征及其与藏南拆离系的关系[J].科学通报, 47(10):738-743.
张小涛, 姜祥华, 薛艳, 姚琪, 解孟雨, 臧阳, 宋金, 卢显, 于晨, 苑争一, 田雷.2020.2020年3月20日西藏定日MS 5.9地震总结[J].地震地磁观测与研究, 41(04):193-203.
AKI K.1957.Space and time spectra of stationary stochastic waves, with special reference to microtremors[J].Bull.Earthq.Res.Inst., 35:415-456.
CAMPILLO M, PAUL A.2003.Long-range correlations in the diffuse seismic coda[J].Science, 299(5606):547-549.
CHANG Xu, LI Lin-xin, LIU Yi-ke, WANG Hong-luo.2008.Seismic profile of Huangzhuang-Gaoliying fault in Beijing by Mini-sosie method[J].Chinese Journal of Geophysics, 51(5):1503-1510(in Chinese with English abstract).
CHEN Yong, LI Yi-jin.2007.Seismic wave radar research:using active source to detect continental crust structure[J].Journal of University of Science and Technology of China, 37(8):813-819(in Chinese with English abstract).
CHEN Yong, XU Yi-he, CAI Hui-teng.LI Wen.2018.Some thoughts on the earthquake science experiment site-the underground cloud map[J].Earthquake Research in China, 34(2):165-171(in Chinese with English abstract).
CHEN Yong, ZHU Ri-xiang.2005.Proposed project of “underground bright lump”[J].Advances in Earth Science, 20(3):485-489(in Chinese with English abstract).
CLAERBOUT J F.1968.Synthesis of a layered medium from its acoustic transmission response[J].Geophysics, 33(2):264-269.
GAO Rong-qing.1994.Analysis of the physical meaning of gunpowder force from the theory of gas molecule motion[J].Explosive Material, (2):40-44(in Chinese).
HA Guang-hao.2019.Normal Faulting of Central-Southern Yadong-Gulu rift Since Late Cenozoic, Southern Tibet[D].Beijing:Chinese Academy of Geological Sciences(in Chinese with English abstract).
HE Ri-zheng, GAO Rui.2003.Some significances of studying north-southern rift in Tibet plateau[J].Progress in Geophysics, 18(01):35-43(in Chinese with English abstract).
KALI E, LELOUP P H, ARNAUD N, MAHÉO G, LIU D Y, BOUTONNET E, VAN DER WOERD J, LIU X H, JING L Z, LI H B.2010.Exhumation history of the deepest central Himalayan rocks, Ama Drime range:Key pressure-temperature-deformation-time constraints on orogenic models[J].Tectonics, 29(2):1-31.
LASKE G, MASTERS G.1996.Constraints on global phase velocity maps from long-period polarization data[J].Journal of Geophysical Research:Solid Earth, 101(B7):16059-16075.
LI Guang-ming, PAN Gui-tang, WANG Gao-ming, HUANG Zhi-ying, GAO Da-fa.2004.Evaluation and prospecting value of mineral resources in Gangdise metallogenic belt, Tibet, China[J].Journal of Chengdu University of Technology (Science & Technology Edition), 31(01):22-27(in Chinese with English abstract).
LUTTER W J, FUIS G S, THURBER C H, MURPHY J.1999.Tomographic images of the upper crust from the Los Angeles basin to the Mojave Desert, California:Results from the Los Angeles Region Seismic Experiment[J].Journal of Geophysical Research:Solid Earth, 104(B11):25543-25565.
MO X X, HOU Z Q, NIU Y L, DONG G C, QU X M, ZHAO Z D, YANG Z M.2007.Mantle contributions to crustal thickening during continental collision:evidence from Cenozoic igneous rocks in southern Tibet[J].Lithos, 96(1-2):225-242.
MONIGLE P W, NABELEK J, BRAUNMILLER J, CARPENTER N S.2012.Evidence for low-angle normal faulting in the Pumqu-Xianza Rift, Tibet[J].Geophysical Journal International, 190(3):1335-1340.
MOONEY W D, PRODEHL C, PAVLENKOVA N I.2002.Seismic velocity structure of the continental lithosphere from controlled source data[J].International Geophysics Series, 81(A):887-910.
SU Jin-bo, WANG Hai-tao, WANG Qiong, ZHANG Wen-lai, JI Zhan-bo, WEI Yun-yun, CHEN Hao, ZHANG Wen-xiu.2017.A study on the repeatability of large volume arigun seismic source in Hutubi, Xinjiang using cluster analysis method[J].Journal of Seismological Research, 40(04):613-618(in Chinese with English abstract).
WANG B S, TIAN X F, ZHANG Y P, LI Y L, YANG W, ZHANG B, WANG W T, YANG J, LI X B.2018.Seismic signature of an untuned large-volume airgun array fired in a water reservoir[J].Seismological Research Letters, 89(3):983-991.
WANG B S, YANG W, WANG W T, YANG J, LI X B, YE B.2020.Diurnal and Semidiurnal P- and S-wave Velocity Changes Measured Using an Airgun Source[J].Journal of Geophysical Research:Solid Earth, 125(1):e2019JB018218.
WANG Bao-shan, GE Hong-kui, WANG Bin, WANG Hai-tao, ZHANG Yuan-sheng, CAI Hui-teng, CHEN Yong.2016.Practices and advances in exploring the subsurface structure and its temporal evolution with repeatable artificial sources[J].Earthquake Research in China, 32(2):168-179(in Chinese with English abstract).
WANG Hong-ti, ZHUANG Can-tao, XUE Bing, ZHAO Cui-ping, ZHU Zu-yang.2009.Precisely and actively seismic monitoring[J].Chinese Journal of Geophysics, 52(7):1808-1815(in Chinese with English abstract).
WANG W T, WANG X, MENG C M, DONG S, WANG Z G, XIE J J, WANG B S, YANG W, XU S H, WANG T.2019.Characteristics of the seismic waves from a new active source based on methane gaseous detonation[J].Earthquake Research in China, 33:354-366.
WANG Wei-tao, WANG Bao-shan.2012.Quick identification of multilevel similar earthquakes using hierarchical clustering method and its application to Wenchuan northeast aftershock sequence[J].Chinese Journal of Geophysics, 55(6):1952-1962(in Chinese with English abstract).
WANG Yong-zhe, CHEN Shi, CHEN Kun.2021.Source Model and Tectonic Implications of the 2020 Dingri MW5.7 Earthquake Constrained by InSAR Data[J].Earthquake, 41(1):116-128(in Chinese with English abstract).
WU Zhang-ming, CAO Zhong-quan, SHENTU Bin-ming, DENG Qi-dong.1990.Surface ruptures by earthquakes found in Xainza, central Xizang[J].Seismology and Geology, 12(4):317-318(in Chinese with English abstract).
XU Shan-hui, WANG Wei-tao, WANG Li-wei, YANG Wei, XU Wei-wei.2020a.Fault structure detection in urban area based on methane explosion source[C]//Proceedings of the annual meeting of China Earth Science Association in 2020.Topic 51:Imaging and detection of urban underground media.Beijing:China Peace Audio Visual Electronic Publishing House:3343(in Chinese).
XU Shan-hui, WANG Wei-tao, ZHANG Yun-peng, XU Wei-wei.2020b.Regional scale 3D seismic travel time tomography based on methane explosion source[C]//Proceedings of the annual meeting of China Earth Science Association in 2020.Topic 49:progress in shallow geophysics.Beijing:China Peace Audio Visual Electronic Publishing House:3296(in Chinese).
XU Tai-ran, LU Zhan-wu, WANG Hai-yan, LI Hong-qiang, LI Wen-hui.2018.Upper crustal structure of Tibetan Niangre ore concentration area revealed by deep seismic reflection profile[J].Journal of Jilin University (Earth Science Edition), 48(02):556-565 (in Chinese with English abstract).
XU Tai-ran.2018.Deep structure of Tibetan Niaggre ore concentration area revealed by deep seismic reflection profile[D].Beijing:Chinese Academy of Geological Sciences(in Chinese with English abstract).
XU Xin-yue.2019.Late Quaternary activity and its environmental effects of the N-S trend Kharta fault in Xainza-Dinggye rift, Southern Tibet[D].Beijing:Institute of Geology, China Earthquake Administration(in Chinese with English abstract).
YAMAOKA K, KUNITOMO T, MIYAKAWA K, KOBAYASHI K, KUMAZAWA M.2001.A trial for monitoring temporal variation of seismic velocity using an across system[J].Island Arc, 10(3-4):336-347.
YIN A, HARRISON T M.2000.Geologic evolution of the Himalayan-Tibetan orogen[J].Annual Review of Earth and Planetary Sciences, 28(1):211-280.
ZENG X, THURBER C H.2016.A graphics processing unit implementation for time-frequency phase-weighted stacking[J].Seism Res Lett, 87(2A):358-362.
ZHANG Chao, YAO Hua-jian, TONG Ping, LIU Qin-ya, LEI Ting.2020.Joint inversion of linear array ambient noise surface-wave and teleseismic body-wave data based on an adjoint-state method[J].Chinese Journal of Geophysics, 63(11):4065-4079(in Chinese with English abstract).
ZHANG Jin-jiang, GUO Lei, DING Lin.2002.Structural characteristics of the middle and South segments of the Shenzha-Dingjie normal fault system and its relationship with the southern Tibet detachment system[J].Science in China, 47(10):738-743(in Chinese with English abstract).
ZHANG Xiao-tao, JIANG Xiang-hua, XUE Yan, YAO Qi, XIE Meng-yu, ZANG Yang, SONG Jin, LU Xian, YU Chen, YUAN Zheng-yi, TIAN Lei.2020.Summary of the Dingri MS 5.9 earthquake in Tibet on March 20, 2020[J].Seismological and Geomagnetic Observation and Research, 41(4):193-203(in Chinese with English abstract).
ZHANG Y P, WANG B S, LIN G Q, OUYANG Y P, WANG T, XU S H, SONG L L, WANG R C.2020.Three-dimensional p-wave velocity structure of the Zhuxi ore deposit, south China revealed by control-source first-arrival tomography[J].Minerals, 10(2):148.
-
