Deep Geothermal Reservoir Structure Detection and Geothermal Well Optimization Technology in Xiongan New Area
-
摘要: 为了给雄安新区下步高温、高产地热井的探测提供借鉴, 需要归纳总结雄安新区高阳地热田雁翎潜山高温、高产地热井的成热地质规律。本文系统分析了雁翎潜山地热田地热地质条件与地温场背景, 通过对莫霍面上隆、深大断裂、凹凸相间构造格局、深浅断裂系统的控热、导热作用的综合研究, 总结归纳了地球物理场、区域水动力场、水化学场与温度场的多场耦合指示等探测评价技术对地温场的指示作用。在此基础上, 确定了研究区高温、高产地热井的主要优选布设依据: ①雁翎潜山是距饶阳、霸县深凹陷较近的低凸起, 深凹陷的莫霍面相对上隆使其底部形成相对较高的温度, 热流自深凹陷底部向与凹陷相邻的低凸起汇聚, 有利于形成深部高温异常; (2)雁翎潜山距区域深大走滑断裂——马西断层较近, 马西断层河间段气藏为R/Ra> 1的幔源氦异常区, 指示马西断层有可能导通深部幔源热; 潜山东侧的出岸断裂等断裂岩溶发育, 利于碳酸盐岩地下水的深循环对流加热后上涌; (3)雁翎潜山距太行山相对较远, 且未处于与太行山补给区水力联系较密切的安新—文安构造变换带, 受补给区冷水影响较小; 距区域深部岩溶地下水汇流区较近, 有利于热流的集聚。雁翎潜山井口水温 123.4°C、109.2°C地热井的成功实施, 说明了深部碳酸盐岩地热井位优选探测技术的科学有效性, 对雄安新区乃至华北盆地深部高温、高产地热井位的优选具有很好的示范意义。Abstract: This study aimed to summarize the geothermal formation law of high-temperature and high-yield geothermal wells in Yanling buried hill in Gaoyang geothermal field of Xiongan New Area, and provide reference for the detection of high-temperature and high-yield geothermal wells in the lower part of Xiongan New Area.In this study, the geothermal geological conditions and geothermal field background of Yanling buried hill geothermal field were systematically analyzed.Through the thermal control and thermal conductivity of Moho uplift, deep-large faults, inter-concave-convex structural pattern, and deep-shallow fault system, the indicative effects of geophysical field, regional hydrodynamic field, hydrochemical field and temperature field on geothermal field were summarized.On this basis, the main optimal layout basis of high temperature and high yield geothermal wells in the study area were determined: (1)Yanling buried hill is a low uplift near the deep depressions of Raoyang and Baxian.The Moho surface of the deep depression is relatively uplifted to form a relatively high temperature at the bottom.The heat flow converges from the bottom of the deep depression to the low uplift adjacent to the depression, which is beneficial to the formation of deep high temperature anomalies.(2)Yanling buried hill is close to the regional deep strike-slip fault-Maxi fault, and the gas reservoir in the inter-river section of Maxi fault is the mantle-derived helium anomaly area with R/Ra> 1, indicating that Maxi fault may lead to deep mantle-derived heat ; faults and karst development on the east side of the buried hill, such as the outgoing faults, are conducive to the uprising of carbonate groundwater after deep circulation convection heating; (3)Yanling buried hill is relatively far from Taihang Mountain, and is not in the Anxin-Wen’an structural transformation zone which is closely related to Taihang Mountains recharge area, and is less affected by the cold water in the recharge area.It is close to the deep karst groundwater confluence area, which is conducive to the accumulation of heat flow.The successful implementation of geothermal wells with water temperatures of 123.4°C and 109.2°C at the wellhead of Yanling buried hill shows the scientific validity of deep carbonate geothermal well location optimization detection technology, demonstrating the optimization of deep high temperature and high yield geothermal wells in Xiongan New Area and North China Basin.
-
-
陈墨香, 黄歌山, 张文仁, 张容燕, 刘炳义.1982.冀中牛驼镇凸起地温场的特点及地下热水的开发利用[J].地质科学, (3): 239-252.
陈墨香.1988.华北地热[M].北京: 科学出版社.
戴金星, 宋岩, 戴春森, 陈安福, 孙明良, 廖永胜.1995.中国东部无机成因气及其气藏形成条件[M].北京: 科学出版社.
戴明刚, 雷海飞, 胡甲国, 郭新锋, 马鹏鹏, 张家云.2019.雄安新区顶面埋深在3500m以浅的中元古界热储可采地热资源量和开发参数评估[J].地质学报, 93(11): 2874-2888.
李飞.2018.陆相断陷盆地典型凹陷流体活动差异性及其对油气成藏影响研究[D].北京: 中国石油大学.
刘国栋, 史书林, 王宝钧.1984.华北地区壳内高导层及其与地壳构造活动性的关系[J].中国科学B辑, 14(9): 839-848.
陆晨明, 刘春雷, 李亚松, 郝奇琛, 曹胜伟, 董岩.2021.泉州官桥地区地热勘探靶区及成因模式探讨[J].地质论评, 67(5):1345-1356.
马兵山, 漆家福, 高强, 王利爽, 杨克基.2017.霸县凹陷构造特征及新生代构造演化[J].地质科学, 52(2): 343-358.
马峰, 孙红丽, 蔺文静, 甘浩男, 王贵玲.2015.中国 EGS示范工程靶区选址与指标矩阵评价[J].科技导报, 33(8): 41-47.
漆家福.2004.渤海湾新生代盆地的两种构造系统及其成因解释[J].中国地质, 31(1): 15-22.
宋永东.2010.饶阳凹陷中北部构造特征及有利勘探方向研究[D].青岛: 中国石油大学.
王贵玲, 李郡, 吴爱民, 张薇, 胡秋韵.2018.河北容城凸起区热储层新层系--高于庄组热储特征研究[J].地球学报, 39(5): 533-541.
王贵玲, 张薇, 蔺文静, 刘峰, 朱喜, 刘彦广, 李郡.2017.京津冀地区地热资源成藏模式与潜力研究[J].中国地质, 44(6):1074-1085.
王思琪, 张保建, 李燕燕, 邢一飞, 袁文真, 李郡, 高俊, 赵甜.2021.雄安新区高阳地热田东北部深部古潜山聚热机制[J].地质科技通报, 40(3): 12-21.
吴爱民, 马峰, 王贵玲, 刘金侠, 胡秋韵, 苗青壮.2018.雄安新区深部岩溶热储探测与高产能地热井参数研究[J].地球学报, 39(5): 523-532.
肖尚斌, 高喜龙, 姜在兴, 谯汉生.2000.渤海湾盆地新生代的走滑活动及其石油地质意义[J].大地构造与成矿学, 24(4):321-328.
熊亮萍, 高维安.1982.隆起与拗陷地区地温场的特点[J].地球物理学报, 25(5): 448-456.
熊亮萍, 张菊明.1984.热流的折射和再分配的数学模拟[J].地质科学, (4): 445-454.
徐常芳.2003.中国大陆岩石圈结构、盆地构造和油气运移探讨[J].地学前缘, 10(3): 115-127.
阎敦实, 于英太.2000.京津冀油区地热资源评价与利用[M].武汉: 中国地质大学出版社.
曾昭发, 陈雄, 李静, 李桐林, 张良怀.2012.地热地球物理勘探新进展[J].地球物理学进展, 27(1): 168-178.
张保建, 高宗军, 张凤禹, 郝栓虎, 刘福义, 臧建军.2015.华北盆地地下热水的水动力条件及水化学响应[J].地学前缘, 22(6): 217-226.
周瑞良, 刘琦胜, 张晶, 杨力强.1989.华北断陷盆地牛驼镇基岩高凸起型热田地质特征及其开发前景[J].中国地质科学院562综合大队集刊, (7-8): 21-36.
CHEN Mo-xiang, HUANG Ge-shan, ZHANG Wen-ren, ZHANG Rong-yan, LIU Bing-yi.1982.The temperature distribution pattern and the utilization of geothermal water at Niutuozhen basement protrusion of central Hebei Province[J].Scientia Geologica Sinica, (3): 239-252(in Chinese with English abstract).
CHEN Mo-xiang.1988.Geothermics of North China[M].Beijing:Science Press(in Chinese).
DAI Jin-xing, SONG Yan, DAI Chun-sen, CHEN An-fu, SUN Ming-liang, LIAO Yong-sheng.1995.Inorganic gas and its reservoir forming conditions in eastern China[M].Beijing:Science Press(in Chinese).
DAI Ming-gang, LEI Hai-fei, HU Jia-guo, GUO Xin-feng, MA Peng-peng, ZHANG Jia-yun.2019.Evaluation of recoverable geothermal resources and development parameters of Mesoproterozoic thermal reservoir with the top surface depth of 3500 m and shallow in Xiong’an New Area[J].Acta Geologica Sinica, 93(11): 2874-2888(in Chinese with English abstract).
LI Fei.2018.Differences of fluid activities and their influences on the hydrocarbon migration and accumulation between typical sags in continental rift basin[D].Beijing: China University of Petroleum(in Chinese with English abstract).
LIU Guo-dong, SHI Shu-lin, WANG Bao-jun.1984.The high conductive layer in the crust of North China and its relationship with crustal tectonic activity[J].Science in China Series B, 14(9): 839-848(in Chinese).
LU Chen-ming, LIU Chun-lei, LI Ya-song, HAO Qi-cheng, CAO Sheng-wei, DONG Yan.2021.Exploration target area of geothermal resources in Guanqiao area, Quanzhou, and its genetic model[J].Geological Review, 67(5): 1345-1356(in Chinese with English abstract).
MA Bing-shan, QI Jia-fu, GAO Qiang, WANG Li-shuang, YANG Ke-ji.2017.Structural characteristic and Cenozoic tectonic evolution in Baxian sag[J].Chinese Journal of Geology, 52(2):343-358(in Chinese with English abstract).
MA Feng, SUN Hong-li, LIN Wen-jing, GAN Hao-nan, WANG Gui-ling.2015.Target site selection and index matrix evaluation of EGS trial project in China[J].Science & Technology Review, 33(8): 41-47(in Chinese with English abstract).
PANG Ju-mei, PANG Zhong-he, LÜ Min, TIAN Jiao, KONG Yan-long. 2018.Geochemical and isotopic characteristics of fluids in the Niutuozhen geothermal field, North China[J].Environmental Earth Sciences, 77: 12.
QI Jia-fu, YANG Qiao.2010.Cenozoic structural deformation and dynamic processes of the Bohai Bay basin province, China[J].Marine and Petroleum Geology, 27(4): 757-771.
QI Jia-fu.2004.Two tectonic systems in the Cenozoic Bohai Bay basin and their genetic interpretation[J].Geology in China, 31(1): 15-22(in Chinese with English abstract).
SONG Yong-dong.2010.Study on structural characteristics and the favorable exploration zones of the middle-northern area in Raoyang sag[D].Qingdao: China University of Petroleum(East China)(in Chinese with English abstract).
WANG Gui-ling, LI Jun, WU Ai-min, ZHANG Wei, HU Qiu-yun.2018.A Study of the thermal storage characteristics of Gaoyuzhuang Formation, a new layer system of thermal reservoir in Rongcheng uplift area, Hebei Province[J].Acta Geoscientica Sinica, 39(5): 533-541(in Chinese with English abstract).
WANG Gui-ling, ZHANG Wei, LIN Wen-jing, LIU Feng, ZHU Xi, LIU Yan-guang, LI Jun.2017.Research on formation mode and development potential of geothermal resources in Beijing-Tianjin-Hebei region[J].Geology in China, 44(6):1074-1085(in Chinese with English abstract).
WANG Si-qi, ZHANG Bao-jian, LI Yan-yan, XING Yi-fei, YUAN Wen-zhen, LI Jun, GAO Jun, ZHAO Tian.2021.Heat accumulation mechanism of deep ancient buried hill in the northeast of Gaoyang geothermal field, Xiong'an New Area[J].Bulletin of Geological Science and Technology, 40(3):12-21(in Chinese with English abstract).
WANG Zhu-ting, GAO Peng, JIANG Guang-zheng, WANG Yi-bo, HU Sheng-biao.2021.Heat flow correction for the high-permeability formation: A case study for Xiong’an New Area[J].Lithosphere, (Special 5): 9171191.
WU Ai-min, MA Feng, WANG Gui-ling, LIU Jin-xia, HU Qiu-yun, MIAO Qing-zhuang.2018.A study of deep-seated karst geothermal reservoir exploration and huge capacity geothermal well parameters in Xiongan New Area[J].Acta Geoscientica Sinica, 39(5): 523-532(in Chinese with English abstract).
XIAO Shang-bin, GAO Xi-long, JIANG Zai-xing, QIAO Han-sheng.2000.Cenozoic dextral strike-slip motion in Bohai Bay Basin and its meaning to petroleum geology[J].Geotectonica et Metallogenia, 24(4): 321-328(in Chinese with English abstract).
XIONG Liang-ping, GAO Wei-an.1982.Characteristics of geotherm in uplift and depression[J].Acta Geophysica Sinica, 25(5): 448-456(in Chinese with English abstract).
XIONG Liang-ping, ZHANG Ju-ming.1984.Mathematical simulation of refract and redistribution of heat flow[J].Scientia Geologica Sinica, (4): 445-454(in Chinese with English abstract).
XU Chang-fang.2003.The study of lithospheric tectonics and basin formation of Chinese mainland and migration of oil and gas[J].Earth Science Frontiers, 10(3): 115-127(in Chinese with English abstract).
YAN Dun-shi, YU Ying-tai.2000.Evaluation and utilization of geothermal resources in Beijing Tianjin Hebei Oil Region[M].Wuhan: China University of Geosciences Press(in Chinese).
ZENG Zhao-fa, CHEN Xiong, LI Jing, LI Tong-lin, ZHANG Liang-huai.2012.Advancement of geothermal geophysics exploration[J].Progress in Geophysics, 27(1): 168-178(in Chinese with English abstract).
ZHANG Bao-jian, GAO Zong-jun, ZHANG Feng-yu, HAO Shuan-hu, LIU Fu-yi, ZANG Jian-jun.2015.Hydrodynamic condition and response of formation water chemical fields of geothermal water in North China Basin[J].Earth Science Frontiers, 22(6): 217-226(in Chinese with English abstract).
ZHANG Bao-jian, WANG Si-qi, KANG Feng-xin, LI Yan-yan, ZHUO Lin-yang, GAO Jun, YUAN Wen-zhen, XING Yi-fei.2022.Flow path of the carbonate geothermal water in Xiong’an New Area, North China: Constraints from 14C dating and H-O isotopes[J].Frontiers in Earth Science, 10: 782273.
ZHOU Rui-liang, LIU Qi-sheng, ZHANG Jing, YANG Li-qiang.1989.The Geological geological features and exploitive prospects of the geothermal field of salient type of bed rock of Niutuozhen in the fault basin of North China[J].Bulletin of The 562 Comprehensive Geological Brigade Chinese Academy of Geological Sciences, (7-8): 21-36(in Chinese with English abstract).
-
