Geological Safety and Risk Analysis of Yinchuan Urban Underground Space Development
-
摘要: 城市地下空间受地质环境的影响和制约, 评价地质环境的安全成为地下空间开发的先导问题。结合银川市地下空间资源调查和区划, 选择了地震(活动断裂和场地地震效应)、砂土液化、富水砂卵石层、地基承载力和地表载荷等因素作为评价因子, 在分别确定各要素空间分布的基础上, 进行了单因素的地质风险分析; 采用层次分析和乘积标度相结合的方法, 进行银川市地下空间开发的多因素地质安全风险综合评价。结果表明: 银川市地下空间开发的最主要制约因素是地震和砂土液化; 地质风险的强风险区面积最小, 占总面积的4.10%, 中风险区面积占19.69%, 弱风险区面积最大, 占41.07%, 低风险区占35.13%。这为银川市地下空间开发建设等提供地质参考。Abstract: The use of urban underground space is affected and restricted by the geological environment.Evaluation of the safety of the geological environment is the foremost issue for the development of underground space.We conducted a geological resource investigation and regionalization of the Yinchuan urban area, and selected the evaluating factors namely, earthquakes (including active faults and site seismic effect), sand liquefaction, rich water sandy aquifer, soil-bearing capacity and surface building load.The geological risk of each factor was analyzed.Subsequently, a comprehensive evaluation of the factors of geological safety and risk in underground space development was conducted using the analytic hierarchy process and a more flexible multiplication scale method.The results showed that in the Yinchuan urban area, the main controlling factors are earthquake and sand liquefaction for the underground space development.The high-, moderate-, and low-risk areas comprised 4.10%, 19.69%, and 41.07% of the urban area.The very low-risk area comprised approximately 35.13% of the urban area.This study provides an important geological reference for underground space development and construction in the Yinchuan urban area.
-
-
董英, 张茂省, 李宁, 等, 2020.城市地下空间开发利用的地质安全评价内容与方法[J].水文地质工程地质, 47(5):161-168.
河南省地质矿产勘查开发局, 2021.河南省地方标准(DB 41/T 2120-2021): 城市地下空间开发地质环境适宜性评价技术规范[S].郑州: 河南省市场监督管理局.
蒋杰, 葛伟亚, 马青山, 等, 2021.南昌市中心城区地下空间开发地质适宜性评价[J].地质通报, 40(5): 734-744.
李晓昭, 王睿, 顾倩, 等, 2019.城市地下空间开发的战略需求[J].地学前缘, 26(3): 32-38.
钱七虎, 1998.城市可持续发展与地下空间开发利用[J].地下空间, 18(2): 69-74.
苏培东, 廖宸宇, 黎俊麟, 等, 2020.成都市城市地下空间开发中的环境工程地质问题[J].山地学报, 38(6): 861-872.
王成善, 周成虎, 彭建兵, 等, 2019.论新时代我国城市地下空间高质量开发和可持续利用[J].地学前缘, 26(3): 1-8.
王初生, 袁芬, 陈宝, 2005.上海城市地下工程环境地质效应的几个关键问题[J].地质灾害与环境保护, 16(2): 161-164.
吴文博, 曹亮, 刘健, 等, 2013.苏州地下空间开发地质环境因素的分析评价[J].防灾减灾工程学报, 33(2): 131-139.
张茂省, 李同录, 程秀娟, 等, 2019.山区城市地下空间资源评价与开发利用模式--以延安市为例[J].山地学报, 37(3):303-315.
张晓彤, 2016.成都市地下地质空间开发利用地质环境适宜性评价[D].北京: 中国地质大学(北京).
BIRKLE P, RODRÍGUEZ V T, PARTIDA E G, 1998.The water balance for the Basin of the Valley of Mexico and implications for future water consumption[J].Hydrogeology Journal, 6(4): 500-517.
GOLANY G S, OJIMA T, 1996.Geo-Space Urban Design[M].Hoboken: John Wiley & Sons.
GONZÁLEZ-MORÁN T, RODRÍGUEZ R, CORTES S A, 1999.The Basin of Mexico and its metropolitan area: water abstraction and related environmental problems[J].Journal of South American Earth Sciences, 12(6): 607-613.
Henan Bureau of Geology and Mineral Explorationt, 2021.Standard of Henan Province (DB 41/T 2120-2021): Technical specification for evaluation of geological environment suitability for urban underground space development [S].Zhengzhou: Administration for Market Regulation of Henan Province (in Chinese).
HOU Weisheng, YANG Liang, DENG Dongcheng, et al., 2016.Assessing quality of urban underground spaces by coupling 3D geological models: The case study of Foshan city, South China[J].Computers and Geosciences, 89: 1-11.
JIANG Jie, GE Weijie, MA Qingshan, et al., 2021.Geological environment suitability assessment of underground space development in Nanchang City[J].Geological Bulletin of China, 40(5): 734-744(in Chinese with English abstract).
LI Xiaozhao, WANG Rui, GU Qian, et al., 2019.Prediction of strategic demand of urban underground space development[J].Earth Science Frontiers, 26(3): 32-38(in Chinese with English abstract).
LU Zhongle, WU Li, ZHUANG Xiaoying, et al., 2016.Quantitative assessment of engineering geological suitability for multilayer Urban Underground Space[J].Tunnelling and Underground Space Technology, 59: 65-76.
PENG Jian, PENG Fangle, 2018.A GIS-based evaluation method of underground space resources for urban spatial planning:Part 1 methodology[J].Tunnelling and Underground Space Technology, 74: 82-95.
QIAN Qihu, 1998.Sustainable development of the cities and the development and utilization of underground space[J].Underground Space, 18(2): 69-74(in Chinese with English abstract).
SU Peidong, LIAO Chenyu, LI Junlin, et al., 2020.Problems of Environmental Engineering Geology for Exploitation of Urban Underground Space in Chengdu, China[J].Mountain Research, 38(06): 861-872(in Chinese with English abstract).
TONG Ying, ZHANG Maosheng, LI Ning, 2020.Methods and contents of geological safety evaluation for urban underground space development and utilization[J].Hydrogeology and Engineering Geology, 47(5): 161-168(in Chinese with English abstract).
WANG Chengshan, ZHOU Chenghu, PENG Jianbing, et al., 2019.A discussion on high-quality development and sustainable utilization of China’s urban underground space in the new era[J].Earth Science Frontiers, 26(3): 1-8(in Chinese with English abstract).
WANG Chusheng, YUAN Fen, CHEN Bao, 2005.Urban geo-environmental effect on underground engineering in Shanghai City[J].Journal of Geological Hazards and Environment Preservation, 16(2): 161-164(in Chinese with English abstract).
WANG Xia, ZHEN Feng, HUANG Xianjin, et al., 2013.Factors influencing the development potential of urban underground space: Structural equation model approach[J].Tunnelling and Underground Space Technology, 38: 235-243.
WU Wenbo, CAO Liang, LIU Jian, et al., 2013.Evaluation and analysis of geological environment for the development of underground space in Suzhou[J].Journal of Disaster Prevention and Mitigation Engineering, 33(2): 131-139(in Chinese with English abstract).
XI Yue, LI Xiaojun, ZHU Hehua, et al., 2022.Three-dimensional high-precision assessment of mountainous urban underground space resources: A case study in Chongqing, China[J].Tunnelling and Underground Space Technology, 123: 104439.
ZHANG Maosheng, LI Tonglu, CHENG Xiujuan, et al., 2019.Evaluation of underground space resources in mountain cities and their development models: taking Yan'an City as an example[J].Mountain Research, 37(3): 303-315(in Chinese with English abstract).
ZHANG Xiaotong, 2016.Suitability evaluation of geological environment for the development and utilization of underground geological space in Chengdu City[D].Beijing: China University of Geosciences(Beijing)(in Chinese with English abstract).
-
