基于模糊数学的北京城区地下空间地质适宜性评价

,  ,  ,

文章导航 > 地球学报 > 2024 > 45(1): 73-79

上一篇

下一篇

孙文洁, 杨文凯, 邓岳飞, 李文杰. 2024. 基于模糊数学的北京城区地下空间地质适宜性评价[J]. 地球学报, 45(1): 73-79. doi: 10.3975/cagsb.2023.051001
引用本文: 孙文洁, 杨文凯, 邓岳飞, 李文杰. 2024. 基于模糊数学的北京城区地下空间地质适宜性评价[J]. 地球学报, 45(1): 73-79. doi: 10.3975/cagsb.2023.051001
shu
SUN Wenjie, YANG Wenkai, DENG Yuefei, LI Wenjie. 2024. Geological Suitability Evaluation of Underground Space in Beijing Urban Area Based on Fuzzy Mathematics. Acta Geoscientica Sinica, 45(1): 73-79. doi: 10.3975/cagsb.2023.051001
Citation: SUN Wenjie, YANG Wenkai, DENG Yuefei, LI Wenjie. 2024. Geological Suitability Evaluation of Underground Space in Beijing Urban Area Based on Fuzzy Mathematics. Acta Geoscientica Sinica, 45(1): 73-79. doi: 10.3975/cagsb.2023.051001
shu

基于模糊数学的北京城区地下空间地质适宜性评价

  • 1. 中国矿业大学(北京)国家煤矿水害防治工程技术研究中心, 北京 100083;

  • 2. 中国矿业大学(北京)机电与信息工程学院, 北京 100083;

  • 3. 建设综合勘察研究设计院有限公司, 北京 100007

  • 基金项目:

    本文由国家自然科学基金项目(编号: 42172282

    42372285)、煤炭资源与安全开采国家重点实验室开放基金项目(编号: SKLCRSM22KFA16)和华北科技学院应急管理部工业安全事故分析与监测预警重点实验室开放基金项目(编号: OF2301)联合资助

详细信息
    作者简介: 孙文洁, 女, 1979年生。博士, 副教授。主要从事矿山环境及煤矿防治水方面的研究。E-mail: swj@cumtb.edu.cn
    通讯作者: 杨文凯, 男, 1994年生。硕士, 讲师。研究方向为矿井水害防治与矿山环境。E-mail: kevinyoung_nuli@163.com

  • 中图分类号: TU42

Geological Suitability Evaluation of Underground Space in Beijing Urban Area Based on Fuzzy Mathematics

  • 1. National Coal Mine Water Hazard Prevention Engineering Technology Research Center, China University of Mining and Technology (Beijing ), Beijing 100083;

  • 2. School of Mechanical Electronic and Information Engineering, China University of Mining and Technology (Beijing ), Beijing 100083;

  • 3. China Institute of Geotechnical Investigation and Surveying Limited, Beijing 100007

More Information
    Corresponding author: YANG Wenkai

    摘要
  • 以北京六环以内的核心城区为例, 在系统分析研究区地质条件的基础上, 综合考虑敏感因素对地下空间开发地质适宜性的影响, 从而构建地下空间适宜性评价指标体系, 并利用层次分析法确定评价指标权重, 最后采用模糊数学综合评判法对研究区地下空间开发适宜性进行了评价。结果表明: 研究区地下空间开发适宜性以适宜性好和较好为主, 占比60.11%, 地质环境条件较好, 总体比较适宜地下空间开发, 活动断裂、水源地分布和古河道分布3个敏感因素是制约研究区地下空间开发的主要地质因素。
    Taking the core urban area within the sixth ring road of Beijing as the study area, this study examined the influence of sensitive factors on the development of underground space, based on a system analysis of regional geological conditions.An appropriate suitability assessment index system for the exploitation and use of the underground space was established.The weights of indexes were determined using the analytic hierarchy process, and a fuzzy mathematics comprehensive evaluation method was used to evaluate the suitability of underground space as a resource in this region.The results show that 60.11% of the underground space in the study area is suitable for development; therefore, the geological conditions are relatively favorable for underground space development.Three sensitive factors-active fault, distribution of water source and distribution of palaeochannel-were found to be the main geological factors restricting the development of underground space in the study area.
    • HTML全文
  • 加载中
    • 参考文献(36)

  • 北京市地质矿产局, 1991.北京市区域地质志[M].北京: 地质出版社.

    鲍亦冈, 刘振锋, 王世发, 等, 2001.北京地质百年研究--北京地区基础地质研究的历史与最新成果[M].北京: 地质出版社.

    蔡向民, 张磊, 郭高轩, 等, 2016.北京平原地区第四纪地质研究新进展[J].中国地质, 43(3): 1055-1066.

    范剑才, 赵坚, 赵志业, 2016.新加坡NTU深层地下空间规划探讨[J].地下空间与工程学报, 12(3): 600-606.

    黄栋, 2009.北京市平原区地下水脆弱性研究[D].北京: 首都师范大学.

    刘森, 董志良, 2019.雄安新区城市地下空间资源开发适宜性评价[J].河北地质大学学报, 42(6): 57-62.

    李世君, 孙少游, 于洋, 2014.水文地质测绘报告[R].北京: 北京市地质工程勘察院.

    雷升祥, 申艳军, 肖清华, 等, 2019.城市地下空间开发利用现状及未来发展理念[J].地下空间与工程学报, 15(4):965-979.

    潘朝, 吴立, 左清军, 等, 2013.基于模糊数学的武汉市地下空间开发地质适宜性评价[J].安全与环境工程, 20(2): 19-23.

    宋迎昌, 2016.治理大城市病需要新思维[J].中国党政干部论坛, (7): 76-78.

    童林旭, 2005.地下空间与未来城市[J].地下空间与工程学报, (3): 323-328.

    王桂新, 2011.中国“大城市病”预防及其治理[J].南京社会科学, (12): 55-60.

    王丽亚, 2014.北京平原区地下水可持续利用模型研究[D].北京: 中国地质大学(北京).

    王新娟, 李志萍, 刘凯, 2015.基于新水情下的北京地下水资源可持续利用调查评价及保护规划建议成果报告[R].北京:北京市水文地质工程地质大队.

    王迎迎, 2011.北京市平原区地下水回灌数值模拟研究[D].北京: 清华大学.

    谢和平, 高明忠, 张茹, 2017.地下生态城市与深地生态圈战略构想及其关键技术展望[J].岩石力学与工程学报, 36(6):1301-1313.

    夏友, 马传明, 2014.郑州市地下空间资源开发利用地质适宜性评价[J].地下空间与工程学报, 10(3): 493-497.

    谢振华, 李志萍, 刘凯, 2011.地下水防污性能及环境容量评价成果报告[R].北京: 北京市水文地质工程地质大队.

    Beijing Municipal Bureau of Geology and Mineral Resources, 1991.Regional Geology of Beijing[M].Beijing: Geological Publishing House(in Chinese).

    BAO Yigang, LIU Zhenfeng, WANG Shifa, et al., 2001.Centennial study of beijing geology: History and Latest Achievements of Basic Geological Research in Beijing Area[M].Beijing: Geological Publishing House(in Chinese).

    CAI Xiangmin, ZHANG Lei, GUO Gaoxuan, et al., 2016.New Progress in the study of Quaternary geology in Beijing Plain[J].Geology in China, 43(3): 1055-1066(in Chinese with English abstract).

    FAN Jiancai, ZHAO Jian, ZHAO Zhiye, 2016.Planning of Deep Underground Space in NTU Campus[J].Chinese Journal of Underground Space and Engineering, 12(3): 600-606(in Chinese with English abstract).

    HUANG Dong, 2009.Study on groundwater vulnerability in beijing plain[D].Beijing: Capital Normal University(in Chinese with English abstract).

    LIU Sen, DONG Zhiliang, 2019.Suitability Evaluation of Urban Underground Space Resources Development in Xiongan New Area[J].Journal of Hebei GEO University, 42(6): 57-62(in Chinese with English abstract).

    LI Shijun, SUN Shaoyou, YU Yang, 2014.Hydrogeological mapping report[R].Beijing: Beijing Institute of Geological Engineering Investigation(in Chinese).

    LEI Shengxiang, SHEN Yanjun, XIAO Qinghua, et al., 2019.Present Situations of Development and Utilization for Underground Space in Cities and New Viewpoints for Future Development[J].Chinese Journal of Underground Space and Engineering, 15(4): 965-979(in Chinese with English abstract).

    PAN Chao, WU Li, ZUO Qingjun, et al., 2013.Geological Suitability Evaluation of the Development of Underground Space in Wuhan City Based on Fuzzy Mathematics[J].Safety and Environmental Engineering, 20(2): 19-23(in Chinese with English abstract).

    SONG Yingchang, 2016.New thinking is needed to cure diseases in big cities[J].Chinese Cadres Tribune, (7): 76-78(in Chinese).

    TONG Linxu, 2005.Underground Space and Future City[J].Chinese Journal of Underground Space and Engineering, (3):323-328(in Chinese with English abstract).

    WANG Guixin, 2011.China's Megacity Problems and Preventions[J].Nanjing Journal of Social Sciences, (12): 55-60(in Chinese with English abstract).

    WANG Liya, 2014.A model study of groundwater sustainability in beijing plain[D].Beijing: China University of Geosciences(in Chinese with English abstract).

    WANG Xinjuan, LI Zhiping, LIU Kai, 2015.Report on the results of the investigation and evaluation of the sustainable utilization of groundwater resources in Beijing based on the new water regime and the recommendations for protection planning[R].Beijing: Beijing Hydrogeology Engineering Geology Brigade(in Chinese).

    WANG Yingying, 2011.Study on numerical simulation of groundwater recharge in plain area of Beijing[D].Beijing:Tsinghua University(in Chinese with English abstract).

    XIE Heping, GAO Mingzhong, ZHANG Ru, et al., 2017.The subversive idea and its key technical prospect on underground ecological city and ecosystem[J].Chinese Journal of Rock Mechanics and Engineering, 36(6): 1301-1313(in Chinese with English abstract).

    XIA You, MA Chuanming, 2014.Geo-environmental Suitability Assessment of Underground Space Resources Exploitation and Utilization in Zhengzhou City[J].Chinese Journal of Underground Space and Engineering, 10(3): 493-497(in Chinese with English abstract).

    XIE Zhenhua, LI Zhiping, LIU Kai, 2011.Report on Assessment Results of Groundwater Anti pollution Performance and Environmental Capacity[R].Beijing: Beijing Hydrogeology Engineering Geology Brigade(in Chinese).
