Mechanism of Generation and Prediction of Distribution of Overpressure within the Permian Strata in the Jimusar Depression, Junggar Basin
-
摘要: 准噶尔盆地吉木萨尔凹陷二叠系普遍发育异常高压, 被认为是影响钻井工程高效安全和油气成藏动力条件评价的关键因素。但其成因机制目前缺乏研究, 目的层埋藏较深, 现有超压计算方法精度不高, 超压分布特征也不够明确。本文基于钻井、测井和测试资料对研究区目的层现今实测地层压力进行分析, 结合泥岩压实特征、源岩有机地球化学特征以及现今构造背景探讨了超压成因机制, 同时利用岩石静力平衡原理改进了压力预测模型, 以成因为导向, 形成适用于研究区的压力预测方法, 并对目的层进行了压力分布预测。研究表明: (1)吉木萨尔凹陷二叠系局部发育高幅超压, 其中芦草沟组压力系数最高可达1.8; (2)研究区二叠系超压形成机制主要包括沉积成因的非均衡压实和特殊成因的生烃增压, 可能存在水热增压; (3)现有压力预测模型假设过强且精度较低, 本文基于岩石静力平衡原理构建的颗粒应力法计算模型, 不仅消除特察模型缺陷, 且预测精度明显高于传统方法; (4)异常高压主要发育在凹陷西部深洼区及中西部斜坡带, 以J36 井区为最高, 该分布规律揭示局部高幅超压受到生烃凹陷控制。上述成果及认识对吉木萨尔凹陷二叠系钻探和油气勘探评价有比较重要的指导意义。Abstract: Abnormal pore pressure, developed in Permian strata throughout the Jimusar Depression, eastern Junggar Basin, is recognized as the key factor affecting the safety and efficiency of the drilling process and evaluation of the dynamic conditions of hydrocarbon accumulation. However, the causes of overpressure have still not been studied systematically, the accuracy of traditional overpressure calculation methods remains insufficient due to its deep burial, and the distribution law requires improvement. In this study, the current measured pore pressure features of the target layer were analyzed based on drilling, logging, and formation testing data, in combination with the compaction characteristics of the mudstone, organic geochemical characteristics, and present tectonic setting. Then, the mechanisms of overpressure generation were evaluated.Furthermore, based on the static equilibrium principle of formation, the pore pressure prediction model was improved theoretically. In addition, a new method suitable for the study area was developed considering the overpressure generation mechanism, and the pressure distribution in the study area was predicted. The study produced several interesting results: (1) High-amplitude overpressure is generally developed in the Permian of the Jimusar Depression, and the pressure coefficient of the Lucaogou Formation is as high as 1.8. (2) The overpressure of the Permian in the study area is caused mainly by disequilibrium compaction and hydrocarbon-generating supercharging, but a hydrothermal mechanism may also exist. (3) Traditional pressure prediction models have extremely strict assumptions and low accuracy. Therefore, based on the principle of the static equilibrium equation, grain stress parameters were introduced to eliminate the defects of the Terzaghi model, and a new pressure calculation model with significantly improved accuracy was proposed. (4) The overpressure is mainly developed in the western deep sag and the central-western slope zone, the high-pressure coefficient is mainly located in the J36 well area, which is controlled by the hydrocarbon-generating depression. The aforementioned results and implications have important guiding significance for drilling in the Permian and evaluating hydrocarbon exploration in the Jimusar Depression.
-
-
陈景阳, 2007. 准噶尔盆地异常压力演化及成藏机制研究[D].武汉: 中国地质大学(武汉).
陈雪, 2018. 准噶尔盆地莫西庄-永进地区中生界压力系统特征及演化研究[D]. 青岛: 中国石油大学(华东).
褚庆忠, 李耀华, 2001. 异常压力形成机制研究综述[J]. 天然气勘探与开发, 24(4): 38-46.
但顺华, 陈春勇, 向辉, 等, 2018. 吉木萨尔凹陷二叠系梧桐沟组沉积演化规律[J]. 新疆石油天然气, 14(2): 17-22, 27, 2.
杜栩, 郑洪印, 焦秀琼, 1995. 异常压力与油气分布[J]. 地学前缘, 2(3-4): 137-148.
段谟东, 叶加仁, 吴景富, 等, 2020. 低勘探程度区域压力分布预测及超压形成机制: 以东海盆地西湖凹陷为例[J]. 地质科技通报, 39(3): 129-139.
方世虎, 宋岩, 徐怀民, 等, 2007. 构造演化与含油气系统的形成--以准噶尔盆地东部吉木萨尔凹陷为例[J]. 石油实验地质, 29(2): 149-153, 161.
龚再升, 1991. 异常压力油气田[J]. 中国海上油气, 5(5): 30.
韩宏伟, 刘震, 马昕箬, 等, 2022. 基于颗粒应力的深层超压预测方法研究: 以准噶尔盆地腹部地区为例[J]. 现代地质, 36(4): 1074-1086, 1130.
郝芳, 2005.超压盆地生烃作用动力学与油气成藏机理[M]. 北京: 科学出版社.
何惠生, 叶加仁, 陈景阳, 2009. 准噶尔盆地腹部超压演化及成因[J]. 石油天然气学报, 31(1): 87-91, 392.
何生, 何治亮, 杨智, 等, 2009. 准噶尔盆地腹部侏罗系超压特征和测井响应以及成因[J]. 地球科学(中国地质大学学报), 34(3): 457-470.
贾婉婷, 2021. 吉木萨尔凹陷芦草沟组混积岩源储结构类型及含油性特征[D]. 北京: 中国石油大学(北京).
匡立春, 王霞田, 郭旭光, 等, 2015. 吉木萨尔凹陷芦草沟组致密油地质特征与勘探实践[J]. 新疆石油地质, 36(6):629-634.
赖仁, 2017. 吉木萨尔凹陷芦草沟组超压演化及其对致密油富集的影响[D]. 青岛: 中国石油大学(华东).
赖仁, 查明, 高长海, 等, 2016. 吉木萨尔凹陷芦草沟组超高压形成机制及演化特征[J]. 新疆石油地质, 37(6): 637-643.
李明诚, 2013.石油与天然气运移[M]. 北京: 石油工业出版社.
李培, 刘成林, 冯德浩, 等, 2021. 咸化湖盆地层超压特征及成因机制--以柴达木盆地英西地区渐新统为例[J]. 中国矿业大学学报, 50(5): 864-876.
李书琴, 印森林, 高阳, 等, 2020. 准噶尔盆地吉木萨尔凹陷芦草沟组混合细粒岩沉积微相[J]. 天然气地球科学, 31(2):235-249.
廉欢, 2016. 准噶尔盆地吉木萨尔凹陷芦草沟组致密油聚集机理研究[D]. 青岛: 中国石油大学(华东).
林一鹏, 韩登林, 邓远, 等, 2023. 成藏动力对页岩油气聚集的影响--以准噶尔盆地吉木萨尔凹陷芦草沟组为例[J]. 沉积学报, https://doi.org/10.14027/j.issn.1000-0550.2023.068.
刘震, 金博, 贺维英, 等, 2002. 准噶尔盆地东部地区异常压力分布特征及成因分析[J]. 地质科学, 37(S1): 91-104.
刘震, 张万选, 曾宪斌, 1997. 特察模型在孔隙性岩石中应用的局限性浅析[J]. 地质科学, 32(1): 116-121.
LUO Xiaorong, 1993. 压实和水热增压对地压的作用以及环境条件的影响[J]. 地质科学译丛, 10(4): 75-81.
马启富, 陈斯忠, 张启明, 等, 2000.超压盆地与油气分布[M].北京: 地质出版社.
平英奇, 2017. 柴达木盆地南翼山构造地层异常压力特征与成因机制研究[D]. 北京: 中国石油大学(北京).
邱桂强, 凌云, 樊洪海, 2003. 东营凹陷古近系烃源岩超压特征及分布规律[J]. 石油勘探与开发, 30(3): 71-75.
曲江秀, 查明, 2003. 准噶尔盆地异常压力类型及成因探讨[J].石油实验地质, 25(4): 333-336.
苏阳, 2019. 准噶尔盆地吉木萨尔凹陷芦草沟组致密油运聚过程及主控因素[D]. 青岛: 中国石油大学(华东).
王冰洁, 何生, 宋国奇, 等, 2012. 东营凹陷不同超压成因的有效应力特征[J]. 地质科技情报, 31(2): 72-79.
王雪柯, 李伟, 张本健, 等, 2019. 四川盆地西北部上三叠统须三段储层超致密与气藏超压成因[J]. 天然气工业, 39(11):25-35.
王子安, 2020. 玛湖凹陷百口泉组地层压力计算方法及其分布规律研究[D]. 北京: 中国石油大学(北京).
夏新宇, 宋岩, 2001. 沉降及抬升过程中温度对流体压力的影响[J]. 石油勘探与开发, 28(3): 8-11.
杨智, 何生, 何治亮, 等, 2008. 准噶尔盆地腹部超压层分布与油气成藏[J]. 石油学报, 29(2): 199-205, 212.
张力升, 张向涛, 彭光荣, 等, 2023. 白云凹陷超压模拟及成藏研究[J]. 西安石油大学学报(自然科学版), 38(4): 30-37.
赵靖舟, 李军, 徐泽阳, 2017. 沉积盆地超压成因研究进展[J].石油学报, 38(9): 973-998.
郑孟林, 田爱军, 杨彤远, 等, 2018. 准噶尔盆地东部地区构造演化与油气聚集[J]. 石油与天然气地质, 39(5): 907-917.
支东明, 李建忠, 张伟, 等, 2022. 准噶尔盆地吉木萨尔凹陷双吉构造带井井子沟组勘探突破及意义[J]. 石油学报, 43(10):1383-1394.
支东明, 唐勇, 杨智峰, 等, 2019. 准噶尔盆地吉木萨尔凹陷陆相页岩油地质特征与聚集机理[J]. 石油与天然气地质, 40(3): 524-534.
BARKER C, 1972. Aqathermal pressuring-role of temperature in development of abnormal-pressure zones: Geological notes[J].AAPG Bulletin, 56(10): 2068-2071.
BELLOTTI P, GIACCA D, 1978. AGIP deep drilling technology.Part 3. Pressure evaluation improves drilling programs[J]. Oil Gas Journal, 76: 6304549.
BERRY F A F, 1973. High Fluid Potentials in California Coast Ranges and Their Tectonic Significance[J]. AAPG Bulletin, 57(7): 1219-1249.
BOWERS G L, 1995. Pore Pressure Estimation from Velocity Data:Accounting for Overpressure Mechanisms Besides Undercompaction[J]. SPE Drilling & Completion, 31: 89-95.
BRUCE C H, 1984. Smectite dehydration-its relation to structural development and hydrocarbon accumulation in northern Gulf of Mexico Basin[J]. AAPG Bulletin, 68(6): 673-683.
CHEN Jingyang, 2007. Study on Abnormal Formation Pressure Evolution and Petroleum Accumulation Mechanism in Junggar Basin[D]. Wuhan: China University of Geosciences(Wuhan)(in Chinese with English abstract).
CHEN Xue, 2018. Characteristics and Evolution of Overpressures Within Mesozoic in Moxizhuan-yongjin area[D]. Qingdao:China University of Petroleum(East China)(in Chinese with English abstract).
CHU Qingzhong, LI Yaohua, 2001. Review on the Formation Mechanism of Abnormal Pressure[J]. Natural Gas Exploration and Development, 24(4): 38-46(in Chinese).
DAN Shunhua, CHEN Chunyong, XIANG Hui, et al., 2018.Sedimentary Evolution of the Permian Wutonggou Formation in Jimusaer Sag, Junggar Basin[J]. Xinjiang Oil & Gas, 14(2):17-22, 27, 2(in Chinese with English abstract).
DU Xu, ZHENG Hongyin, JIAO Xiuqiong, 1995. Abnormal Pressure and Hydrocarbon Accumulation[J]. Earth Science Frontiers, 2(3-4): 137-148(in Chinese with English abstract).
DUAN Modong, YE Jiaren, WU Jingfu, et al., 2020. Prediction of pressure distribution and formation mechanism in low exploration area: A case study of Xihu Depression, East China Sea Basin[J]. Bulletin of Geological Science and Technology, 39(3): 129-139(in Chinese with English abstract).
DUTTA N C, 1997. Pressure prediction from seismic data:implications for seal distribution and hydrocarbon exploration and exploitation in the deepwater Gulf of Mexico[J].Norwegian Petroleum Society Special Publications, 7:187-199.
EATON B A, 1972. The Effect of Overburden Stress on Geopressure Prediction from Well Logs[J]. Journal of Petroleum Technology, 24(8): 929-934.
FANG Shihu, SONG Yan, XU Huaimin, et al., 2007. Relationship between tectonic evolution and petroleum system formation-Taking the Jimusar Sag of Eastern Junggar Basin as an example[J]. Petroleum Geology and Experiment, 29(2):149-153, 161(in Chinese with English abstract).
FERTL W H, 1976.Abnormal formation pressure, implication to exploration, drilling, and production of oil and gas reservoirs[M]. Amsterdam: Elsevier: 382.
FILLIPPONE W R, 1979. On the Prediction of Abnormally Pressured Sedimentary Rocks from Seismic Data[J]. Journal of Petroleum Technology, (4): 212-234.
FOSTER J B, 1987. Estimation of Formation Pressures from Electrical Surveys-Offshore Louisiana[J]. Journal of Petroleum Technology, 18(2): 165-171.
GONG Zaisheng, 1991. Abnormal pressure oil and gas field[J].China Offshore Oil and Gas, 5(5): 30(in Chinese).
HAN Hongwei, LIU Zhen, MA Xinruo, et al., 2022. Distribution Prediction of High Overpressure in Jurassic Moxizhuang-Yongjin Area, Central Junggar Basin[J].Geoscience, 36(4): 1074-1086, 1130(in Chinese with English abstract).
HAO Fang, 2005.Hydrocarbon generation kinetics and hydrocarbon accumulation mechanism of overpressured basin[M]. Beijing: Science Press(in Chinese).
HE Huisheng, YE Jiaren, CHEN Jingyang, 2009. Overpressure Evolution and Genesis in Central Junggar Basin[J]. Journal of Oil and Gas Technology, 31(1): 87-91, 392(in Chinese with English abstract).
HE Sheng, HE Zhiliang, YANG Zhi, et al., 2009. Characteristics, Well-Log Responses and Mechanisms of Overpressure within the Jurassic Formation in the Central Part of Junggar Basin[J].Earth Science(Journal of China University of Geosciences), 34(3): 457-470(in Chinese with English abstract).
HOTTMANN C E, JOHNSON R K, 1965. Estimation of Formation Pressures from Log-Derived Shale Properties[J]. Journal of Petroleum Technology, 17(6): 717-722.
HUBBERT M K, RUBEY W W, 1959. Role of fluid pressure in the mechanics of overthrust fault[J]. Geological Society of America Bulletin, 70(5): 115-166.
JIA Wanting, 2021. The source-reservoir structure and oiliness of Lucaogou Formation, Jimsar Depression[D]. Beijing: China University of Petroleum(Beijing)(in Chinese with English abstract).
KUANG Lichun, WANG Xiatian, GUO Xuguang, et al., 2015.Geological characteristics and exploration practice of tight oil in Lucaogou Formation in Jimsar Sag[J]. Xinjiang Petroleum Geology, 36(6): 629-634(in Chinese with English abstract).
LAI Ren, 2017. Evolution of Overpressure and Its Influence on Enrichment of Tight Oil of Lucaogou Formation in Jimsar Depression[D]. Qingdao: China University of Petroleum(East China)(in Chinese with English abstract).
LAI Ren, ZHA Ming, GAO Changhai, et al., 2016. Formation mechanism and evolution characteristics of ultra-high pressure in Lusaogou Formation of Jimsar Sag, Junggar Basin[J]. Xinjiang Petroleum Geology, 37(6): 637-643(in Chinese with English abstract).
LI Mingcheng, 2013.Oil and Gas migration[M]. Beijing:Petroleum Industry Press(in Chinese).
LI Pei, LIU Chenglin, FENG Dehao, et al., 2021. Characteristics and origin mechanism of foramtion overpressure in the saline lacustrine basin: A case study from the Oligocene in the west of Yingxiong ridge, Qaidam Basin[J]. Journal of China University of Mining and Technology, 50(5): 864-876(in Chinese with English abstract).
LI Shuqin, YIN Senlin, GAO Yang, et al., 2020. Study on sedimentary microfacies of mixed fine-grained rocks in Lucaogou Formation, Jimsar Sag, Junggar Basin[J]. Natural Gas Geoscience, 31(2): 235-249(in Chinese with English abstract).
LIAN Huan, 2016. The Accumulation Mechanism of Tight Oil of Lucaogou Formation in Jimsar Depression, Junggar Basin[D].Qingdao: China University of Petroleum(East China)(in Chinese with English abstract).
LIN Yipeng, HAN Denglin, DENG Yuan, et al., 2023. Influence of reservoir forming dynamics on shale oil and gas accumulation:A case study form the Lucaogou Formation in Jimusar Sag, Junggar Basin[J]. Acta Sedimentologica Sinica, https://doi.org/10.14027/j.issn.1000-0550.2023.068(in Chinese with English abstract).
LIU Libin, SHEN Guoqiang, WANG Zhentao, et al., 2018. Abnormal formation velocities and applications to pore pressure prediction[J]. Journal of Applied Geophysics, 165: 1-6.
LIU Zhen, JIN Bo, HE Weiying, et al., 2002. Generation and Distribution of Abnormal Formation Pressures in Eastern Part of the Junggar Basin[J]. Chinese Journal of Geology, 37(S1):91-104(in Chinese with English abstract).
LIU Zhen, ZHANG Wanxuan, ZENG Xianbin, 1997. Stady on static equilibrium equation of porous rocks in compaction processes[J]. Scientia Geologica Sinica, 32(1): 116-121(in Chinese with English abstract).
LUO Xiaorong, 1993. Effects of compaction and hydrothermal pressurization on ground pressure and environmental conditions[J]. Journal of Geoscience Translations, 10(4):75-81(in Chinese).
MA Qifu, CHEN Sizhong, ZHANG Qiming, et al., 2000.Overpressure basin and hydrocarbon distribution[M]. Beijing:Geological Publishing House(in Chinese).
MAGARA K, 1968. Compaction and Migration of Fluids in Miocene Mudstone, Nagaoka Plain, Japan[J]. AAPG Bulletin, 52(12): 2466-2501.
MARTINEZ R D, 1985. Deterministic estimation of porosity and formation pressure from seismic data[J]. Seg Technical Program Expanded Abstracts, 4(1): 486-487.
MEISSNER F F, 1976. Abnormal Electric Resistivity and Fluid Pressure in Bakken Formation, Williston Basin, and Its Relation to Petroleum Generation, Migration, and Accumulation[J]. AAPG Bulletin, 60: 1403-1404.
MUDFORD B S, BEST M E, 1989. Venture Gas Field, Offshore Nova Scotia: Case Study of Overpressuring in Region of Low Sedimentation Rate[J]. AAPG Bulletin, 73(11): 1383-1396.
PENNEBAKER E S, 1968. Seismic data indicate depth, magnitude of abnormal pressure[J]. World Oil, 166(7): 73-78.
PING Yingqi, 2021. Study on abnormal pressure characteritics and genetic mechanism of the Nanyishan tectonics in the Qaidam Basin[D]. Beijing: China University of Petroleum(Beijing)(in Chinese with English abstract).
POWERS M C, 1967. Fluid-release mechanisms in compacting marine and their importance in oil exploration[J]. AAPG Bulletin, 51(1): 1240-1254.
QIU Guiqiang, LING Yun, FAN Honghai, 2003. The characteristics and distribution abnormal pressure in the Paleogene source rocks in Dongying Sag[J]. Petroleum Exploration and Development, 30(3): 71-75(in Chinese with English abstract).
QU Jiangxiu, ZHA Ming, 2003. Origin and characteristics of abnormal pressure in the Junggar Basin[J]. Petroleum Geology and Experiment, 25(4): 333-336(in Chinese with English abstract).
SU Yang, 2019. Processes and contolling factors of oil migration and accumulation in the tight reservoirs of the Lucaogou Formation in the Jimsar Sag, Junggar Basin[D]. Qingdao:China University of Petroleum(East China)(in Chinese with English abstract).
TERZAGHI K, PECK R B, 1948.Soil mechanics in engineering practice[M]. New York: John Wiley: 566-729.
UNGERER P, BEHAR E, DISCAMPS D, 1981. Tentative calculation of the overall volume expansion of organic matter during hydrocarbon genesis from geochemistry data.Implications for primary migration[J]. Advances in Organic Geochemistry, 56(10): 2068-2071.
WALLACE W E, 1965. Abnormal Subsurface Pressures Measured from Conductivity or Resistivity Logs[C]//SPWLA 6th Annual Logging Symposium. Dallas: SPWLA-1965-21.
WANG Bingjie, HE Sheng, SONG Guoqi, et al., 2012. Effective stress characteristics of different overpressured origins in Dongying Depression of the Bohai Bay Basin, China[J].Geological Science and Technology Information, 31(2):72-79(in Chinese with English abstract).
WANG Xueke, LI Wei, ZHANG Benjian, et al., 2019. The formation mechanisms of ultra-tight and overpressured gas reservoir in the third Member of Upper Triassic Xujiahe Formation in the northwestern Sichuan Basin[J]. Natural Gas Industry, 39(11): 25-35(in Chinese with English abstract).
WANG Zian, 2020. Study on Prediction Method and Distribution Law of Formation Pressure of Baikouquan Formation in Mahu Sag[D]. Beijing: China University of Petroleum(Beijing)(in Chinese with English abstract).
XIA Xinyu, SONG Yan, 2001. Temperature effects on geopressure during deposition and erosion[J]. Petroleum Exploration and Development, 28(3): 8-11(in Chinese with English abstract).
YANG Zhi, HE Sheng, HE Zhiliang, et al., 2008. Distribution of overpressure stratum and its relationship with hydrocarbon accumulation in the central part of Junggar Basin[J]. Acta Petrolei Sinica, 29(2): 199-205, 212(in Chinese with English abstract).
ZHANG Jincai, 2011. Pore pressure prediction from well logs:Methods, modifications, and new approaches[J].Earth-Science Reviews, 108(1-2): 50-63.
ZHANG Lisheng, ZHANG Xiangtao, PENG Guangrong, et al., 2023. Simulation of Overpressure and Study of Hydrocarbon Accumulation in Baiyun Sag[J]. Journal of Xi'an Shiyou University(Natural Science Edition), 38(4): 30-37(in Chinese with English abstract).
ZHAO Jingzhou, LI Jun, XU Zeyang, 2017. Advances in the origin of overpressures in sedimentary basins[J]. Acta Petrolei Sinica, 38(9): 973-998(in Chinese with English abstract).
ZHENG Menglin, TIAN Aijun, YANG Tongyuan, et al., 2018.Structural evolution and hydrocarbon accumulation in the eastern Junggar Basin[J]. Oil and Gas Geology, 39(5):907-917(in Chinese with English abstract).
ZHI Dongming, LI Jianzhong, ZHANG Wei, et al., 2022.Exploration breakthrough and its significance of Jingjingzigou Formation in Shuangji tectonic zone of Jimsar Sag in Junggar Basin[J]. Acta Petrolei Sinica, 43(10):1383-1394(in Chinese with English abstract).
ZHI Dongming, TANG Yong, YANG Zhifeng, et al., 2019. Geological characteristics and accumulation mechanism of continental shale oil in Jimusaer Sag, Junggar Basin[J]. Oil and Gas Geology, 40(3): 524-534(in Chinese with English abstract).
-
