Study on Numerical Simulation and Development Strategies of the Keshen 5 Fractured Water-bearing Gas Reservoir in the Tarim Basin
-
摘要: 克深5 气藏是一个裂缝性异常高压特低渗层状边水干气气藏, 由于裂缝发育, 气藏在开发之后快速见水, 开展水侵数值模拟及开发对策研究是该气藏提高采收率的关键, 为了更好描述储层特征, 采用嵌入式离散裂缝模型进行数值模拟, 针对裂缝性气藏历史拟合难度大的问题, 采用敏感性分析-生产动态拟合相结合、手工调整-自动调整相结合的思路开展拟合工作, 充分结合气藏实际水侵动态, 通过调整大裂缝, 基质与裂缝网格属性场等关键参数, 最终实现了全区历史拟合符合率为91%, 单井历史拟合符合率为86%。基于历史拟合结果及开发主控因素分析, 综合考虑不同采气速度、排水方式、排水规模、新井挖潜等因素, 设计12套提采方案, 预测模拟15 年结果优选出气藏排水采气方案为: 气藏配产105 万m3/天, 边部老井克深505、502、503 井排水, 克深5-5 井堵水, 鞍部部署一口水平井, 克深5-3 井北部部署一口定向井, 最终采出程度为23.7%。Abstract: The Keshen 5 gas reservoir is a fractured, abnormally high-pressure, ultra-low permeability, layered-edge water dry-gas reservoir. Due to the development of fractures, the gas reservoir quickly waters out after development. Thus, performing numerical simulations of water invasion and research on development strategies is the key to improving the recovery rate of the gas reservoir. To describe the reservoir characteristics more thoroughly, an embedded discrete fracture model was used for numerical simulation. In response to the difficulty of historical fitting for fractured gas reservoirs, a combination of sensitivity analysis, production dynamic fitting, and manual and automatic adjustment was adopted to perform the fitting work. The actual water invasion performance of the gas reservoir was fully combined, and attribute fields of key parameters, such as large fractures, matrix, and fracture grid, were adjusted. Finally, the historical fitting conformity rate of the entire area was 91%, and the historical fitting conformity rate of a single well was 86%. Based on the historical fitting results and an analysis of development control factors and taking into account factors such as different gas production rates, drainage methods, drainage scales, and new well potential excavation, 12 sets of extraction plans were designed. The prediction simulation results for 15 years showed that the optimal drainage and gas production plan for the gas reservoir were as follows: The gas reservoir production allocation is 1.05 million cubic meters per day; the old wells at the edge, KeS505, 502, and 503, are used for drainage; KeS5-5 is blocked; and a horizontal well is deployed in the saddle. A directional well is deployed north of KeS5-3, and the final recovery rate is 23.7%.
-
-
陈庆轩, 2017. 有水气藏动态分析方法及应用研究[D]. 成都:西南石油大学.
黄朝琴, 姚军, 王月英, 等, 2011. 基于离散裂缝模型的裂缝性油藏注水开发数值模拟[J]. 计算物理, 28(1): 41-49.
刘念肖, 王作豪, 闵春荣, 等, 2022. 裂缝-孔隙型有水气藏开发数值模拟研究[J]. 天津化工, 36(1): 99-102.
罗涛, 王阳, 2002. 裂缝水窜气藏单井数值模拟研究[J]. 天然气工业, 22(S1): 95-97.
吕志凯, 唐海发, 刘群明, 等, 2022. 塔里木盆地库车坳陷超深层裂缝性致密气藏水封气动态评价方法[J]. 天然气地球科学, 33(11): 1874-1882.
孙致学, 姜传胤, 张凯, 等, 2020. 基于离散裂缝模型的CO2 增强型地热系统THM 耦合数值模拟[J]. 中国石油大学学报(自然科学版), 44(6): 79-87.
王振彪, 孙雄伟, 肖香姣, 2018. 超深超高压裂缝性致密砂岩气藏高效开发技术--以塔里木盆地克拉苏气田为例[J]. 天然气工业, 38(4): 87-95.
夏崇双, 2002. 不同类型有水气藏提高采收率的途径和方法[J].天然气工业, 22(S1): 73-77.
张世明, 严侠, 孙红霞, 等, 2014. 基于离散裂缝模型的裂缝性介质等效渗透率求解新方法[J]. 科学技术与工程, 14(16):34-40, 54.
张岩, 郑智君, 鲁改欣, 等, 2010. 三维地质建模与数值模拟技术在裂缝型有水气藏开发中的应用[J]. 天然气地球科学, 21(5): 863-867.
钟孚勋, 2002. 四川盆地天然气开发实践与认识[J]. 天然气工业, 5(S1): 8-10, 12.
CHEN Qingxuan, 2017. Research on Dynamic Analysis Method and Application of Water Drive Gas Reservoir[D]. Chengdu:Southwest University of Petroleum(in Chinese with English abstract).
HUANG Zhaoqin, YAO Jun, WANG Yueying, et al., 2011.Numerical simulation on water flooding development of fractured reservoirs in a discrete-fracture model[J]. Chinese Journal of Computational Physics, 28(1): 41-49(in Chinese with English abstract).
LEE S H, JENSEN C L, LOUGH M F, 2001. Hierarchical modeling of flow in naturally fractured formations with multiple length scales[J]. Water Resources Research, 37(3):443-455.
LI Liyong, LEE S H, 2008. Efficient field-scale simulation of black oil in a naturally fractured reservoir through discrete fracture networks and homogenized media[J]. SPE Reservoir Evaluation & .Engineering, 11(4): 750-758.
LIU Nianxiao, WANG Zuohao, MIN Chunrong, et al., 2022.Numerical simulation study on the development of fractured porous water-bearing gas reservoirs[J]. Tianjin Chemical Industry, 36(1): 99-102(in Chinese).
LÜ Zhikai, TANG Haifa, LIU Qunming, et al., 2022. Dynamic evaluation method of water sealed gas for ultra-deep fractured tight gas reservoir in Kuqa Depression, Tarim Basin[J].Natural Gas Geoscience, 33(11): 1874-1882(in Chinese with English abstract).
LUO Tao, WANG Yang, 2002. Research on individual well numerical simulation of fracture water breakthrough gas reservoir[J]. Natural Gas Industry, 22(S1): 95-97(in Chinese with English abstract).
MOINFAR A, VARAVEI A, SEPEHRNOORI K, et al., 2012.Development of a novel and computationally-efficient discrete-fracture model to study IOR processes in naturally fractured reservoirs[C]//SPE Improved Oil Recovery Symposium. Tulsa: SPE-154246-MS.
MOINFAR A, VARAVEI A, SEPEHRNOORI K, et al., 2014.Development of an efficient embedded discrete fracture model for 3D compositional reservoir simulation in fractured reservoirs[J]. SPE Journal, 19(2): 289-303.
NOORISHAD J, MEHRAN M, 1982. An upstream finite element method for solution of transient transport equation in fractured porous media[J]. Water Resources Research, 18(3):588-596.
SUN Zhixue, JIANG Chuanyin, ZHANG Kai, et al., 2020.Numerical simulation for heat extraction of CO2-EGS with thermal-hydraulic-mechanical coupling method based on discrete fracture models[J]. Journal of China University of Petroleum(Edition of Natural Science), 44(6): 79-87(in Chinese with English abstract).
WANG Zhenbiao, SUN Xiongwei, XIAO Xiangjiao, 2018.Efficient development technologies for ultradeep, overpressured and fractured sandstone gas reservoirs: A case study of the Kelasu Gas Field in the Tarim Basin[J]. Natural Gas Industry, 38(4): 87-95(in Chinese with English abstract).
XIA Chongshuang, 2002. Ways and methods of enhancing recovery in various water-carrying gas reservoirs[J]. Natural Gas Industry, 22(S1): 73-77(in Chinese with English abstract).
ZHANG Shiming, YAN Xia, SUN Hongxia, et al., 2014. An Efficient Calculation of Equivalent Permeability of Fractured Porous Media Based on Discrete Fracture Model[J]. Science Technology and Engineering, 14(16): 34-40, 54(in Chinese with English abstract).
ZHANG Yan, ZHENG Zhijun, LU Gaixin, et al., 2010. Application of Three-dinensional Geological Modeling and Numerical Simulation in Exploitation of Fractured Water-Gas Reservoir[J]. Natural Gas Geoscience, 21(5): 863-867(in Chinese with English abstract).
ZHONG Fuxun, 2002. Practice and knowledge of natural gas development in Sichuan Basin[J]. Natural Gas Industry, 5(S1):8-10, 12(in Chinese with English abstract).
-
