Monitoring of nighttime light pollution in Nanjing City based on Luojia 1-01 remote sensing data
-
摘要: 为获取城市内部精细的光污染分布特征,基于珞珈一号夜光遥感影像对南京市的夜间光污染进行监测。利用地表反射率与建筑覆盖度将珞珈一号的表观辐射亮度修正为地表入射亮度,结合实地观测照度构建多种经验模型计算南京市夜间照度,并基于计算得到的夜间照度分析南京市的夜间光污染分布状况。结果表明,三阶多项式模型精度最高,判定系数R2为0.87,平均绝对误差为4.71 lx。南京市夜间照度在0~55 lx之间,空间分布差异性明显。总体而言,照度高值区域主要集中在主城区,由主城区向四周呈递减趋势; 其中鼓楼区与秦淮区光污染最严重,超过70%的面积比例存在轻度以上光污染; 郊区的光污染程度较弱,光污染最弱的三个区依次是高淳区、溧水区与六合区,存在光污染的面积比例不足4%。南京市部分区域表现出极高的照度(30 lx以上),这些区域包括大型商场、大型工厂、交通枢纽、道路以及部分住宅区,需要注意的是,除了交通枢纽和大型工厂附近几乎无居民区外,其他区域附近都存在较多的居民区。文章探索了基于珞珈一号遥感影像监测城市夜间光污染的方法,为南京市的光污染整治工作提供了数据支撑,也为其他地区的光污染监测提供了科学参考。Abstract: To obtain the distribution of nighttime light pollution on a city scale, this study monitors the nighttime light pollution in Nanjing City based on Luojia 1-01 nighttime light remote sensing images. The apparent radiance of the remote sensing images was converted into the surface incident luminance according to surface reflectance and building coverage ratio. Based on this and the illuminance values observed in the field, various empirical models were established to calculate the nighttime illuminance of Nanjing City. Finally, the distribution of nighttime light pollution in Nanjing City was analyzed according to the calculated nighttime illuminance. The results show that the third-order polynomial regression model had the highest accuracy, with a determination coefficient of 0.87 and a mean absolute error (MAE) of 4.71 lx. The nighttime illuminance in Nanjing City varied in the range of 0~55 lx, with obvious spatial distribution differences. In general, the areas with high illuminance were mainly concentrated in the main urban area and the illuminance showed a decreasing trend from the main urban area to the surrounding area. Light pollution was the most serious in Gulou and Qinhuai districts, where light pollution covered more than 70% in terms of area. The light pollution in the suburb was relatively weak, and the three districts with the weakest light pollution included Gaochun, Lishui, and Liuhe districts successively, where light pollution covered less than 4% in terms of area. Some areas in Nanjing City showed extremely high illuminance (> 30 lx), including large shopping malls, large factories, traffic hubs, roads, and some residential areas. It should be noted that there are many residential areas near these places except for traffic hubs and large factories. This study explored a method of monitoring urban light pollution at night based on Luojia 1-01 remote sensing data. It will provide data support for the light pollution control and management in Nanjing City and a scientific reference for the light pollution monitoring in other areas.
-
Key words:
- Luojia 1-01data /
- nighttime light pollution /
- illuminance /
- Nanjing City
-
-
[1] Stevens R G, Blask E D, Brainard C G, et al. The role of environmental lighting and circadian disruption in cancer and other diseases[J]. Environmental Health Perspect, 2007, 115(9):1357-1362. [2] Jason J, Chalres M Francis. The effects of light characteristices on avian mortality at lighthouse[J]. Journal of Avian Biology, 2003, 34(4):328-333. [3] Stevens R G. Light-at-night,circadian disruption and breast cancer:Assessment of existing evidence[J]. International Journal of Epidemiology, 2009, 38(4):963-970. [4] Yurk H, Tirtes A W. Expeirmental attempts to reduce predation by hahtor seals on out-migrating juvenile salm-onids[J]. Transactions of the American Fisheries Society, 2000, 129(6):1360-1366. [5] Gallaway T, Olsen R N, Mitchell D M. The economics of global light pollution[J]. Ecological Economics, 2010, 69(3):685-665.[6] Kohyama J. A newly proposed disease condition produced by light exposure during night:Asynchronyza-tion[J]. Brain & Development, 2009, 31(4):255-273.[7] Pulgar Jose, Zeballos Danae, Vargas Juan, et al. Endogenous cycles,activity patterns and energy expenditure of an intertidal fish is modified by artificial light pollution at night (ALAN)[J]. Environmental Pollution (Barking,Essex:1987), 2019, 244:197-201.[8] Navara K J, Nelson R J. The dark side of light at night:Physiological,epidemiological,and ecological consequences[J]. Journal of Pineal Research, 2007, 43(3):215-224. [9] Lyytimaki J, Rinne J. Voices for the darkness:Online survey on public perceptions on light pollution as an environmental problem[J]. Journal of Integrative Environmental Sciences, 2013, 10(2):127-139. [10] Bedrosian T A, Nelson R J. Influence of the modern light environment on mood[J]. Molecular Psychiatry, 2013, 18(7):751-757. [11] Kooijman S, van den Berg R, Ramkisoensing A, et al. Prolonged daily light exposure increases body fat mass through attenuation of brown adipose tissue activity[J]. Proceedings of the National Academy of Sciences, 2015, 112(21):6748-6753. [12] 张悦, 徐永明, 熊文成, 等. 夜间光污染的遥感监测及防治措施浅析[J]. 环境监控与预警, 2019, 11(5):108-112.[12] Zhang Y, Xu Y M, Xiong W C, et al. Remote sensing monitoring and prevention measures of night light pollution[J]. Environmental Monitoring and Forewarning, 2019, 11(5):108-112.[13] 代学民, 张克明, 卢颖. 张家口市区夜间照明光污染现状分析及对策研究[J]. 河北建筑工程学院学报, 2018(2):88-93.[13] Dai X M, Zhang K M, Lu Y. Analysis on the current situation and countermeasures of light pollution in the urban area of Zhangjiakou[J]. Journal of Hebei Institute of Architecture and Civil Engineering, 2018(2):88-93.[14] Kyba C C M, Ruhtz T, Fischer J, et al. Cloud coverage acts as an amplifier for ecological light pollution in urban ecosystems[J]. PloS One, 2011, 6(3):e17307. [15] Pun C S J, So C W, Leung W Y, et al. Contributions of artificial lighting sources on light pollution in Hong Kong measured through a night sky brightness monitoring network[J]. Journal of Quantitative Spectroscopy and Radiative Transfer, 2014, 139:90-108. [16] Dobler G, Ghandehari M, Koonin S E, et al. Dynamics of the urban lightscape[J]. Information Systems, 2015, 54:115-126. [17] Katz Y, Levin N. Quantifying urban light pollution:A comparison between field measurements and EROS-B imagery[J]. Remote Sensing of Environment, 2016, 177:65-77. [18] Kollath Z. Measuring and modelling light pollution at the Zselic Starry Sky Park[J]. Journal of Physics:Conference Series, 2010, 218(1):012001. [19] 苏晓明, 郝占国, 张明宇. 呼和浩特城市夜空光污染特征研究[J]. 照明工程学报, 2015, 26(4):124-128.[19] Su X, Hao Z, Zhang M. Study on the characteristics of light pollution in the night sky of Hohhot City[J]. Journal of Lighting Engineering, 2015, 26(4):124-128.[20] Elvidge C D, Baugh K E, Zhizhin M, et al. Why VIIRS data are superior to DMSP for mapping nighttime lights[J]. Proceedings of the Asia-Pacific Advanced Network, 2013, 35:62. [21] Bennie J, Davies T W, Duffy J P, et al. Contrasting trends in light pollution across Europe based on satellite observed night time lights[J]. Scientific Reports, 2014, 4:3789. [22] 郭晗. 珞珈一号科学试验卫星[J]. 卫星应用, 2018(7):70.[22] Guo H. Luojia-1 scientific experiment satellite[J]. Satellite Application, 2018(7):70.[23] 王磊, 陈锐志, 李德仁, 等. 珞珈一号低轨卫星导航增强系统信号质量评估[J]. 武汉大学学报(信息科学版), 2018, 43(12):2191-2196.[23] Wang L, Chen R Z, Li D R, et al. Signal quality assessment of Luojia-1 LEO satellite navigation enhancement system[J]. Geomatics and Information Science of Wuhan University, 2018, 43(12):2191-2196.[24] Li J, Xu Y, Cui W, et al. Investigation of nighttime light pollution in Nanjing,China by mapping illuminance from field observations and Luojia 1-01 imagery[J]. Sustainability, 2020, 12(2):681. [25]Commission Internationale de Leclairage. Guide on the limitation of the effects of obtrusive light from outdoor lighting installations:Technical Report:CIE 150[R]. 2003.
-
