黑龙江老祚山金矿区片麻状花岗岩锆石U-Pb年龄、Hf同位素特征及其地质意义

,  ,  ,  ,  ,

文章导航 > 地质与资源 > 2020 > 29(3): 239-245

上一篇

下一篇

寇林林, 张朋, 陈江, 赵岩, 王筱筝, 毕中伟. 黑龙江老祚山金矿区片麻状花岗岩锆石U-Pb年龄、Hf同位素特征及其地质意义[J]. 地质与资源, 2020, 29(3): 239-245.
引用本文: 寇林林, 张朋, 陈江, 赵岩, 王筱筝, 毕中伟. 黑龙江老祚山金矿区片麻状花岗岩锆石U-Pb年龄、Hf同位素特征及其地质意义[J]. 地质与资源, 2020, 29(3): 239-245.
shu
KOU Lin-lin, ZHANG Peng, CHEN Jiang, ZHAO Yan, WANG Xiao-zheng, BI Zhong-wei. ZIRCON U-Pb AGE AND Hf ISOTOPIC CHARACTERISTICS OF THE GNEISSIC GRANITES IN LAOZUOSHAN GOLDFIELD OF HEILONGJIANG PROVINCE: Geological Implication[J]. Geology and Resources, 2020, 29(3): 239-245.
Citation: KOU Lin-lin, ZHANG Peng, CHEN Jiang, ZHAO Yan, WANG Xiao-zheng, BI Zhong-wei. ZIRCON U-Pb AGE AND Hf ISOTOPIC CHARACTERISTICS OF THE GNEISSIC GRANITES IN LAOZUOSHAN GOLDFIELD OF HEILONGJIANG PROVINCE: Geological Implication[J]. Geology and Resources, 2020, 29(3): 239-245.
shu

黑龙江老祚山金矿区片麻状花岗岩锆石U-Pb年龄、Hf同位素特征及其地质意义

  • 1.

    中国地质调查局 沈阳地质调查中心, 辽宁 沈阳 110034

  • 2.

    中国地质调查局 自然资源实物地质资料中心, 河北 三河 065201

  • 基金项目:
    国家自然科学基金"变质地体中内生金矿成矿模式研究——以辽东裂谷猫岭金矿为例"(41502093)；中国地质调查局项目"东北地区区域成矿规律与总结"(121201103000150020)
详细信息
    作者简介: 寇林林(1983-), 女, 硕士, 高级工程师, 主要从事区域地质和矿产调查工作, 通信地址辽宁省沈阳市皇姑区黄河北大街280号, E-mail//120526628@qq.com

  • 中图分类号: P588.12;P597;P618.51

ZIRCON U-Pb AGE AND Hf ISOTOPIC CHARACTERISTICS OF THE GNEISSIC GRANITES IN LAOZUOSHAN GOLDFIELD OF HEILONGJIANG PROVINCE: Geological Implication

  • 1.

    Shenyang Center of China Geological Survey, Shenyang 110034, China

  • 2.

    Core and Sample Center of Natural Resources, Sanhe 065201, Hebei Province, China

    摘要

  • 黑龙江老柞山金矿床是佳木斯地块中北部的大型热液叠加夕卡岩型矿床.对矿区东矿带赋矿片麻状花岗岩进行了LA-ICP-MS的U-Pb定年和Hf同位素分析，共获得3组年龄，分别为697.1±8.0、703.0±8.8和484.7±2.7 Ma.其中前2组为捕获的锆石年龄，暗示佳木斯地块南缘可能存在新元古代的结晶基底.第三组锆石年龄代表片麻状花岗岩结晶年龄.锆石原位Hf同位素测试显示，片麻状花岗岩的εHf(t)值为-2.4~+3.6，TDM2为1620~1390 Ma，指示片麻状花岗岩原岩可能是中元古代陆壳物质重熔.结合区域构造演化，认为片麻状花岗岩可能形成于晚泛非-早加里东期的碰撞造山作用，是麻山群深熔岩浆结晶作用的产物.

    The Laozuoshan gold deposit in Heilongjiang Province is a large hydrothermal superimposed skarn deposit in the north-central of Jiamusi block. Three groups of age, 697.1±8.0, 703.0±8.8, and 484.7±2.7 Ma respectively, are acquired through the LA-ICP-MS U-Pb dating and Hf isotope analysis of gneissic granites in the east ore belt of orefield, among which the former two are the age of captured zircons, suggesting that there might be Neoproterozoic crystalline basement in the south margin of Jiamusi block, and the latter represents the crystallization ages of gneissic granites. The zircon Hf isotope tests show that the εHf(t) ranges from -2.4 to +3.6, with TDM2 of 1620-1390 Ma, indicating that the protolith of gneissic granite may be the derived from the remelting of Mesoproterozoic continental crust material. Combined with the regional tectonic evolution, it is believed that the gneissic granite was possibly formed by the late Pan-African-early Caledonian collision-orogeny as the product of anatectic magma crystallization of Mashan Group.

    • HTML全文
  • 加载中

  • 图 1  老柞山金矿床矿区地质图(据文献[4]修编)

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  老柞山金矿片麻状花岗岩部分锆石阴极发光图像及测点

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  老柞山金矿片麻状花岗岩锆石U-Pb谐和年龄图和加权年龄图

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  老柞山金矿片麻状花岗岩锆石Lu-Hf同位素图解

    Figure 4.

    下载: 全尺寸图片 幻灯片

    表 1  老柞山金矿片麻状花岗岩的主量元素测试结果

    Table 1.  Contents of major elements in the gneissic granites of Laozuoshan gold deposit

    样品号Na2O MgO Al2O3 SiO2 P2O5 K2O CaO TiO2 MnO TFe2O3 FeO LOI
    LZS-1 3.80 4.60 11.94 56.32 0.39 2.82 5.07 0.84 0.037 5.94 5.12 2.58
    LZS-2 0.52 0.45 12.27 54.11 0.06 10.52 10.18 0.30 0.093 3.15 2.43 8.37
    LZS-3 2.54 1.70 14.19 63.74 0.24 3.83 5.40 0.60 0.035 3.89 3.50 3.25
    LZS-4 3.42 1.95 17.16 61.38 0.30 3.94 4.52 0.92 0.054 5.19 4.40 1.42
    LZS-5 1.70 0.82 13.30 68.50 0.19 7.22 2.43 0.56 0.047 3.89 3.39 1.47
    含量单位：%.
    下载: 导出CSV

    表 2  老柞山金矿片麻状花岗岩LA-MC-ICP-MS锆石U-Pb同位素分析结果

    Table 2.  LA-MC-ICP-MS zircon U-Pb isotopic compositions of the gneissic granites in Laozuoshan gold deposit

    样品号 Th/10-6 U/10-6 Th/U 同位素比值 表面年龄/Ma
    207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ 208Pb/232Th 1σ 207Pb/206Pb 1σ 207Pb/235U 1σ 206Pb/238U 1σ
    LZS-2-1 109.01 415.97 0.26 0.07826 0.0009 0.62851 0.01264 0.02409 0.0004 0.07826 0.0009 539 43.84 495.2 7.88 485.7 5.37
    LZS-2-2 270.96 720.67 0.38 0.07821 0.00086 0.63095 0.00901 0.02452 0.00024 0.07821 0.00086 549.4 29.92 496.7 5.61 485.4 5.12
    LZS-2-3. 109.14 540.61 0.20 0.07839 0.00087 0.62773 0.01003 0.02418 0.00033 0.07839 0.00087 532.7 34.4 494.7 6.26 486.5 5.19
    LZS-2-4 83.32 751.19 0.11 0.07812 0.00091 0.59695 0.01288 0.02508 0.00064 0.07812 0.00091 429.3 46.88 475.3 8.19 484.9 5.43
    LZS-2-5 84.62 881.61 0.10 0.07806 0.00087 0.6257 0.00995 0.02998 0.00051 0.07806 0.00087 534.8 34.28 493.4 6.22 484.5 5.17
    LZS-2-6 114.4 213.34 0.54 0.0783 0.00093 0.64509 0.01557 0.02681 0.00039 0.0783 0.00093 594.6 51.92 505.5 9.61 486 5.57
    LZS-2-7 157.76 505.57 0.31 0.11523 0.00152 1.18829 0.03381 0.04235 0.001 0.11523 0.00152 1063.3 56.91 795.2 15.69 703 8.76
    LZS-2-8 59.59 987.83 0.06 0.07759 0.00089 0.59325 0.01229 0.02991 0.0009 0.07759 0.00089 430.8 44.91 472.9 7.83 481.7 5.35
    LZS-2-9 58.32 1593 0.04 0.07736 0.00093 0.58852 0.01465 0.03057 0.00145 0.07736 0.00093 419.5 54.31 469.9 9.36 480.4 5.56
    LZS-2-10 255.56 478.25 0.53 0.07839 0.00087 0.64108 0.01044 0.02838 0.00028 0.07839 0.00087 579 34.3 503 6.46 486.5 5.2
    LZS-2-11 158.91 549.01 0.29 0.07828 0.00088 0.61534 0.01111 0.03126 0.0004 0.07828 0.00088 491.8 39 486.9 6.98 485.8 5.27
    LZS-2-12 70.01 924.55 0.08 0.07784 0.00085 0.63181 0.00924 0.03165 0.00051 0.07784 0.00085 562.6 30.86 497.2 5.75 483.2 5.11
    LZS-2-13 95.74 532.81 0.18 0.07776 0.00099 0.60816 0.01842 0.03003 0.00085 0.07776 0.00099 480.5 66.89 482.4 11.63 482.7 5.92
    LZS-2-14 79.67 496.06 0.16 0.07824 0.00092 0.62616 0.01451 0.03377 0.00072 0.07824 0.00092 531.3 50.45 493.7 9.06 485.6 5.52
    LZS-2-15 48.59 702.78 0.07 0.0785 0.00087 0.62085 0.01033 0.03211 0.00069 0.0785 0.00087 505.3 35.29 490.4 6.47 487.2 5.22
    LZS-2-16 142.49 317.16 0.45 0.1142 0.00139 1.09545 0.02643 0.05153 0.0008 0.1142 0.00139 916 49.06 751.1 12.81 697.1 8.04
    LZS-2-17 43.81 721.84 0.06 0.07781 0.00096 0.63374 0.01729 0.03733 0.00154 0.07781 0.00096 570.2 58.71 498.4 10.75 483 5.75
    下载: 导出CSV

    表 3  老柞山金矿片麻状花岗岩LA-MC-ICP-MS锆石Hf同位素分析结果

    Table 3.  LA-MC-ICP-MS zircon Hf isotopic compositions of the gneissic granites in Laozuoshan gold deposit

    样品号 t/Ma 176Yb/177Hf 2σ 176Lu/177Hf 2σ 176Hf/177Hf 2σ εHf(0) εHf(t) 2σ TDM1/Ma TDM2/Ma fLu/Hf TDM2 (镁铁质) TDM2 (长英质)
    LZS-2-1 485.7 0.017895 0.001385 0.000471 0.000039 0.282438 0.000011 -11.8 -1.3 0.4 1135 1536 -0.99 1973 1331
    LZS-2-2 485.4 0.017814 0.000334 0.000469 0.000009 0.282468 0.000013 -10.8 -0.2 0.5 1093 1469 -0.99 1878 1277
    LZS-2-3 486.5 0.028564 0.002643 0.000776 0.000073 0.282413 0.000013 -12.7 -2.2 0.5 1179 1597 -0.98 2060 1380
    LZS-2-4 484.9 0.007256 0.000166 0.000182 0.000004 0.282455 0.000012 -11.2 -0.6 0.4 1103 1492 -0.99 1912 1295
    LZS-2-5 484.5 0.029353 0.001744 0.000778 0.000049 0.282482 0.000013 -10.3 0.2 0.5 1082 1444 -0.98 1844 1257
    LZS-2-6 486.0 0.041257 0.00338 0.00112 0.000091 0.28249 0.000015 -10.0 0.4 0.5 1081 1432 -0.97 1826 1247
    LZS-2-7 481.7 0.011692 0.000101 0.000304 0.000003 0.282451 0.000011 -11.4 -0.8 0.4 1112 1506 -0.99 1932 1306
    LZS-2-8 480.4 0.004508 0.000017 0.000114 0.000001 0.282418 0.000012 -12.5 -2.0 0.4 1151 1577 -1.00 2033 1362
    LZS-2-9 486.5 0.004923 0.00025 0.000126 0.000007 0.28242 0.000013 -12.4 -1.8 0.5 1149 1569 -1.00 2019 1357
    LZS-2-10 485.8 0.032692 0.000503 0.000886 0.00001 0.282501 0.000015 -9.6 0.8 0.5 1059 1403 -0.97 1785 1224
    LZS-2-11 483.2 0.026504 0.000698 0.000698 0.000015 0.282473 0.000012 -10.6 -0.2 0.4 1093 1464 -0.98 1871 1272
    LZS-2-12 482.7 0.009875 0.000151 0.000255 0.000005 0.282407 0.000011 -12.9 -2.4 0.4 1171 1603 -0.99 2069 1384
    LZS-2-13 485.6 0.00573 0.000288 0.000123 0.000008 0.282431 0.000015 -12.1 -1.4 0.5 1134 1544 -1.00 1985 1338
    LZS-2-14 487.2 0.024292 0.000951 0.000649 0.000026 0.282498 0.000014 -9.7 0.8 0.5 1056 1404 -0.98 1786 1225
    LZS-2-15 505.0 0.021344 0.000134 0.000578 0.000004 0.282396 0.000013 -13.3 -2.4 0.5 1196 1620 -0.98 2084 1402
    LZS-2-16 697.0 0.012193 0.000611 0.000325 0.000017 0.282443 0.000012 -11.6 3.6 0.4 1123 1390 -0.99 1678 1254
    LZS-2-17 483.0 0.016992 0.000152 0.00045 0.000004 0.282502 0.000012 -9.5 0.9 0.4 1045 1394 -0.99 17731216
    下载: 导出CSV
    • 参考文献(20)
  • [1]

    陈行时, 聂喜涛, 孙景贵, 等.黑龙江宁安英城子热液金矿床与成矿伴生的辉绿玢岩的锆石U-Pb年龄及其地质意义[J].世界地质, 2010, 29(2):211-217. doi: 10.3969/j.issn.1004-5589.2010.02.005

    [2]

    邢树文, 孙景贵, 张增杰, 等.中国东北部陆缘金、有色金属多期成矿作用和勘查选区研究[M].北京:地质出版社, 2014:94-108.

    [3]

    张红军.老柞山金矿床地质特征及同位素地球化学特征[J].地质找矿论丛, 1999, 14(1):48-52, 87. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dzzklc199901006

    [4]

    李怡欣.黑龙江省老柞山金矿床的成因与成矿地质模式[D].长春: 吉林大学, 2014: 24-43.

    [5]

    周喜文, 李宪洲, 李晓敏.黑龙江省老柞山金矿成矿模式探讨[J].地质与勘探, 2002, 38(2):18-22. doi: 10.3969/j.issn.0495-5331.2002.02.005

    [6]

    刘蒙财, 毛永强.老柞山金矿成矿规律分析[J].黑龙江冶金, 2009, 29(4):27-29. http://d.old.wanfangdata.com.cn/Periodical/hljyj200904013

    [7]

    陈熠, 方小敏, 宋春晖, 等.准噶尔盆地南缘新生代沉积物碎屑锆石记录的天山隆升剥蚀过程[J].地学前缘, 2012, 19(5):225-233. http://d.old.wanfangdata.com.cn/Periodical/dxqy201205022

    [8]

    陈会军, 崔天日, 钱程, 等.大兴安岭北段巴升河岩体锆石U-Pb年代学及其地质意义[J].地质与资源, 2019, 28(5):405-412. doi: 10.3969/j.issn.1671-1947.2019.05.001 http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract8414.shtml

    [9]

    张朋, 陈冬, 寇林林, 等.辽东宽甸东北沟钼矿二长花岗岩年代学、地球化学及Hf同位素特征[J].中国地质, 2016, 43(6):2092-2103. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi201606020

    [10]

    Belousova E, Griffin W, O'Reilly S Y, et al. Igneous zircon:Trace element composition as an indicator of source rock type[J]. Contri butions to Mineralogy and Petrology, 2002, 143(5):602-622. doi: 10.1007/s00410-002-0364-7

    [11]

    曾振, 孙雷, 张兴洲, 等.饶河杂岩中枕状玄武岩的锆石U-Pb年代学、地球化学及其地质意义[J].地质与资源, 2019, 28(2):119-127. doi: 10.3969/j.issn.1671-1947.2019.02.002 http://manu25.magtech.com.cn/Jweb_dzyzy/CN/abstract/abstract8386.shtml

    [12]

    李怡欣, 聂喜涛, 张朋, 等.老柞山金矿床的成矿时代与成矿背景[J].矿物学报, 2011, 31(S1):612. http://d.old.wanfangdata.com.cn/Conference/7684872

    [13]

    Wu M, Li L, Sun J G, et al. Geology, geochemistry, and geochronology of the Laozuoshan gold deposit, Heilongjiang Province, Northeast China:Implications for multiple gold mineralization events and geodynamic setting[J]. Canadian Journal of Earth Sciences, 2018, 55(6):604-619. doi: 10.1139/cjes-2018-0038

    [14]

    Yang J H, Wu F Y, Shao J A, et al. Constraints on the timing of uplift of the Yanshan Fold and Thrust Belt, North China[J]. Earth and Planetary Science Letters, 2006, 246:336-352. doi: 10.1016/j.epsl.2006.04.029

    [15]

    Amelin Y, Lee D C, Halliday A N, et al. Nature of the Earth's earliest crust from hafnium isotopes in single detrital zircons[J]. Nature, 1999, 399(6733):252-255. doi: 10.1038/20426

    [16]

    Amelin Y, Lee D C, Halliday A N, et al. Early-middle Archaean crustal evolution deduced from Lu-Hf and U-Pb isotopic studies of single zircon grains[J]. Geochimica et Cosmochimica Acta, 2000, 64(24):4205-4225. doi: 10.1016/S0016-7037(00)00493-2

    [17]

    吴福元, 李献华, 郑永飞, 等. Lu-Hf同位素体系及其岩石学应用[J].岩石学报, 2007, 23(2):185-220. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200702001

    [18]

    宋彪, 李锦轶, 牛宝贵, 等.黑龙江省东部麻山群黑云斜长片麻岩中锆石的年龄及其地质意义[J].地球学报, 1997, 18(3):306-312.

    [19]

    李锦轶, 牛宝贵, 宋彪, 等.长白山北段地壳的形成与演化[M].北京:地质出版社, 1999:46-53.

    [20]

    Wilde S A, Dorsett-Bain H L, Lennon R G. Geological setting and controls on the development of graphite, sillimanite and phosphate mineralization within the Jiamusi Massif:An exotic fragment of Gondwanaland located in north-eastern China?[J]. Gondwana Research, 1999, 2(1):21-46. doi: 10.1016/S1342-937X(05)70125-8
