An experimental study of shear deformation and mineral composition changes of granite under the condition of high temperature and high pressure
-
摘要:
在构造变形过程中，流体控制成矿作用的机制是目前世界矿床界共同面临的问题之一。通过研究剪切变形过程中的力学-化学作用，理解剪切构造应力和流体在构造成岩成矿过程中的行为与作用是解决这一科学问题的关键环节。在花岗岩高温高压剪切变形实验的基础上，分析了实验变形的矿物反应特征及矿物反应引起的化学成分变化，讨论了矿物反应与变形的相互影响。实验结果表明，变形样品中斜长石、钾长石和辉石以脆性-塑性变形为主，石英和云母以塑性变形为主。同时流体与岩石的相互作用引起了矿物间的反应，其中钾长石、辉石发生水解作用最典型。实验变形整体受应变局部化控制，随着剪切变形加强，脆性破裂逐渐形成和发展为裂隙，应力不断释放，有金属元素沿裂隙充填，这些微观特征在实验样品中普遍存在，类似野外中的矿脉。本次实验为韧性剪切带的流变行为、化学行为和剪切作用过程提供了实验数据。
Abstract:The fluid-controlling mineralization mechanism during tectonic deformation is a worldwide research focus.In order to comprehend the behavior and role of shear tectonic stress and fluids in the process of tectonic diagenesis and mineralization, it is the key to study the mechanical-chemical effects in the shear deformation process.In this study, the authors analyzed the distribution of mineral reaction and the change of chemical composition caused by the mineral reaction in experimental deformed granite samples under the condition of high temperature and high pressure and discussed interaction between mineral reactions and deformation.The results indicate that plagioclase, k-feldspar and pyroxene can endure brittle-plastic deformation, while most of the quartz and mica display plastic deformation.The hydrolysis of K-feldspar and pyroxene due to the fluid-rock interaction is the most characteristic reaction in the minerals.The strain localization dominantly controls the overall deformation in the experiment.With the strengthening of shear deformation, the brittle fracture gradually forms and develops into cracks.Thus the stress is released, and metal elements are filled along the cracks.These microscopic characteristics are common in the experimental samples, similar to features of the vein in the field.This experiment provides experimental data for the rheological behavior, chemical behavior and shearing process of the ductile shear zone.
-
-
表 1 实验条件与力学参数
Table 1. Experimental conditions and mechanicaldata of samples
样品号 T1/℃ T2/℃ 压力/
MPa差应力
/MPa应变速
率/s-1实验
时间/h应变量
/%S17-1 800 800 800 243.19 1×10-6 85 14.5 S17-2 800 800 800 202.13 1×10-7 104 31.2 S17-3 800 800 800 164.53 1×10-6 98 33.1 S17-4 800 800 800 240.88 1×10-7 82 17.8 S17-5 800 800 1000 190.94 1×10-6 108 14.8 S17-7 800 720 1000 270.15 1×10-7 139 15.1 S17-9 850 850 1000 / 1×10-7 80 21.2 S17-10 700 705 1000 231.49 1×10-6 121 23.7 S17-11 800 800 1000 281.23 1×10-7 166 9.1 注：T1为主控热偶温度；T2为副控热偶温度；主控热偶是控制实验温度的热偶, 而副控热偶主要是监控温度。实验的最后温度是主控热偶所显示的温度
下载: 导出CSV
-
[1] 付山岭, 胡斌.从微观尺度探讨韧性剪切带型金矿的成矿模式[J].黄金科学技术, 2010, 18(2):31-34. http://www.cqvip.com/Main/Detail.aspx?id=33799423
[2] Zhong Z Q, You Z D.Compositional variation and volume loss of a shear zone-Hetai shear zone as a case history[J].Chinese Science Bulletin, 1995, 40(19):1638-1641. http://www.cnki.com.cn/Article/CJFDTotal-JXTW199519012.htm
[3] 王春增, 李晓峰, 易先奎.江西金山金矿控矿韧性剪切带的递进变形成矿机理:显微构造证据[J].桂林工学院学报, 2009, 29(2):169-182. http://www.cnki.com.cn/Article/CJFDTotal-GLGX200902004.htm
[4] Fyfe W S.Metamorphic fluids[J].Earth Science Review, 1992, 32(1/2):1-146.
[5] Fyfe W S, Kerrich R.Fluids and thrusting[J].Chemical Geology, 1985, 49(1/3):353-362. https://www.sciencedirect.com/science/article/abs/pii/0009254185901676
[6] Koons P O, Craw D, Cox S C, et al.Fluid flow during active oblique convergence:A Southern Alps model from mechanical and geochemical observations[J].Geology, 1998, 26(2):159-162. http://adsabs.harvard.edu/abs/1998Geo....26..159K
[7] Sibson R H, Scott J.Stress-fault controls on the containment and release of overpressured fluids:Examples from gold-quartz vein systems in Juneau, Alaska; Victoria, Australia and Otago, New Zealand[J].Ore Geology Reviews, 1998, 13(1/5):293-306. http://www.sciencedirect.com/science/article/pii/S0169136897000231
[8] Travé A, Calvet F, Sans M, et al.Fluid history related to the Alpine compression at the margin of the South-Pyrenean Foreland basin:the Eiguix anticline[J].Tectonophysics, 2000, 321(1):73-102. http://www.sciencedirect.com/science/article/pii/S0040195100000901
[9] Ghisetti F, Kirschner D, Vezzani L.Tectoniccontrols on large-scale fluid circulation in the Apennines(Italy)[J].Journal of Geochemical Exploration, 2000, 69:533-537. http://www.onacademic.com/detail/journal_1000035506707010_e471.html
[10] Craw D.Fluid flow at fault intersections in an activeoblique collision zone, Southern Alps, New Zealand[J].Journal of Geochemical Exploration, 2000, 69:523-526. http://www.sciencedirect.com/science/article/pii/S0375674200000947
[11] Craw D, Koons P O, Horton T, et al Tectonically driven fluid flow and gold mineralization in active collisional orogenic belts:Comparison between New Zealand and western Himalaya[J].Tectonophysics, 2002, 348(1):135-153. http://www.sciencedirect.com/science/article/pii/S0040195101002530
[12] Robl J, Fritz H, Stüwe K, et al.Cyclic fluid infiltration in structurally controlled Ag-Pb-Cu occurrences(Schladming, Eastern Alps)[J].Chemical Geology, 2004, 205(1/2):17-36. http://www.sciencedirect.com/science/article/pii/S000925410300384X
[13] Bellot J P.Extensional deformation assisted by mineralized fluids within the brittle-ductile transition:Insights from the southwestern Massif Central, France[J].Journal of Structural Geology, 2007, 29(2):225-240. http://www.sciencedirect.com/science/article/pii/S0191814106002148
[14] 万天丰.关于中国构造地质学研究中几个问题的探讨[J].地质通报, 2008, 27(9):1441-1450. http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20080906&flag=1
[15] Andrew H A, Geoffrey R C, Greg W.Synchronous advanced argillic alteration and deformation in a shear zone hosted magmatic hydrothermal Au-Ag deposit at the Temora Mine, new south Wales Australia[J].Economic Geology, 1995, 90(6):1570-1603. http://www.researchgate.net/publication/247862982_Synchronous_advanced_argillic_alteration_and_deformation_in_a_shear_zone-hosted_magmatic_hydrothermal_Au-Ag_deposit_at_the_Temora_Gidginburg_Mine_New_South_Wales_Australia
[16] Tullis J, Yund R, Farver J.Deformation enhanced fluid distribution in feldspar aggregates and implications for ductile shear zones[J].Geology, 1996, 24(1):63-66. http://adsabs.harvard.edu/abs/1996Geo....24...63T
[17] 许德如, 吴传军, 吕古贤, 等.岩石流变原理在构造成矿研究中的应用——以BIF型富铁矿床为例[J].大地构造与成矿学, 2015, 1:93-109. http://www.cnki.com.cn/Article/CJFDTotal-DGYK201501010.htm
[18] 吕古贤.构造物理化学的研究与应用[J].中国地质, 1997, (10):45-48. http://www.cnki.com.cn/Article/CJFDTotal-DIZI199710014.htm
[19] 吕古贤.构造物理化学的研究进展[J].科学通报, 2003, 48(2):101. http://www.ixueshu.com/document/c2ce2a60dbe1de5dae1629b7c7511f7b318947a18e7f9386.html
[20] 吕古贤.构造动力成岩成矿和构造物理化学研究[J].地质力学学报, 2019, 25(5):962-980. http://kns.cnki.net/KCMS/detail/detail.aspx?dbcode=CJFD&filename=DZLX201905025
[21] 吕古贤, 邓军, 李晓波, 等, 构造物理化学的思路、研究和问题[J].地质学报, 2006, 80(10):1616-1626. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dizhixb200610017
[22] 岳石, 马瑞, 王子潮.关于韧性变形与成矿作用的一些实验结果[J].地质找矿论丛, 1990, 5(4):30-35. http://www.cqvip.com/QK/90755X/19904/229967.html
[23] 陈先兵.花岗闪长斑岩高温高压实验及其成矿地质意义[J].地质科技情报, 1994, 13(1):63-69. http://www.cnki.com.cn/Article/CJFDTotal-DZKQ402.013.htm
[24] 肖化云, 吴学益.金山金矿田构造变形特征及其模拟实验[J].地质地球化学, 1997, (3):80-86. http://www.cnki.com.cn/Article/CJFDTotal-DZDQ199703012.htm
[25] 吴学益, 尚精华, 张开平.金山金矿构造控矿特征及其模拟实验[J].矿物学报, 2007, 27(2):143-152. http://d.wanfangdata.com.cn/Periodical/kwxb200702009
[26] 郑远川, 顾连兴, 汤晓茜, 等.2009.天然矿石中硫化物的同构造再活化实验研究[J].地质学报, 83(1):31-42. http://d.wanfangdata.com.cn/Periodical/dizhixb200901004
[27] 陈柏林, 董法先, 李中坚.矿物中元素迁移变化的高温高压实验研究[J].地质力学学报, 1998, 4(1):72-77. http://www.cqvip.com/QK/98414X/199801/3008620.html
[28] 陈正乐.高温高压下成矿元素运移聚集模拟实验[J].地质力学学报, 1999, 2(2):90-93. http://www.cnki.com.cn/Article/CJFDTotal-DZLX602.012.htm
[29] 刘贵, 周永胜, 姚文明, 等.组构对花岗片麻岩高温流变影响的实验研究[J].地球物理学报, 2013, 56(7):2332-2347. http://www.cnki.com.cn/Article/CJFDTotal-DQWX201307019.htm
[30] Liu G, Zhou Y S, He C R, et al.Experimental study on effect of pre-existing fabric to deformation of foliated mylonite under high temperature and pressure[J].Geological Journal, 2016, 51(1):92-112.
[31] Kohlstedt D L, Zimmerman M E, Mackwell S J.Stress-driven melt segregation in partially molten feldspathic rocks[J].Journal of Petrology, 2010, 51(1/2):9-19. http://petrology.oxfordjournals.org/content/51/1-2/9.full.pdf+html
[32] Pec M, Stünitz H, Heilbronner R.Semi-brittle deformation of granitoid gouges in shear experiments at elevated pressures and temperatures[J].Journal of Structural Geology, 2012, 38:200-221. http://www.sciencedirect.com/science/article/pii/S0191814111001441
[33] Pec M, Stünitz H, Heilbronner R, et al.Semi-brittle flow of granitoid fault rocks in experiments[J].Journal of Geophysical Research, Solid Earth, 2016, 121:1677-1705. http://dx.doi.org/10.1002/2015jb012513
[34] Holyoke C W, Tullis J.The interaction between reaction and deformation:an experimental study using abiotite, plagioclase, quartz gneiss[J].J.Geology, 2006, 24:743-762. http://onlinelibrary.wiley.com/doi/10.1111/j.1525-1314.2006.00666.x
[35] Etheridge M A, Hobbs B E.Chemical and deformational controls on recrystallization of mica[J].Contributions to Mineralogy and Petrology, 1974, 43:111-124. http://link.springer.com/article/10.1007/BF00572714
[36] Bell T H.Syntectonic nucleation of new grains in deformed mica[J].Tectonophysics, 1978, 51:31-37. http://www.sciencedirect.com/science/article/pii/0040195178902299
[37] Holyoke C W, Tullis J.Mechanisms of weak phase interconnection and the effects of phase strength contrast on fabric development[J].Journal of Structural Geology, 2006, 28:621-640. http://www.sciencedirect.com/science/article/pii/S0191814106000241
[38] Stunitz H, Tullis J.Weakening and strain localization produced by syn-deformational reaction of plagioclase[J].Tectonophysics, 2001, 90:136-148. http://link.springer.com/article/10.1007/s005310000148
[39] 刘铁兵, 曾庚栋.山东蒙阴常马走滑式韧性剪切带控矿研究[J].地质与矿产, 2001, 37(1):15-19. http://d.wanfangdata.com.cn/Periodical/dzykt200101004
-
