Geochemistry characteristics and indicative significance of rare earth elements in coal from Juhugeng coal district, the Muli coalfield in Qinghai Province
-
摘要:
运用高分辨电感耦合等离子质谱（ICP-MS）、X射线荧光光谱、光学显微镜及煤的工业分析对聚乎更矿区主采煤层下1煤层及其顶底板中的稀土元素、主量元素、显微组分及工业组分进行测定，分析稀土元素的含量、地球化学特征和分布模式对成煤环境的指示。结果表明：聚乎更矿区下1煤中稀土元素平均含量为23.01×10-6，相对不富集；LREE/HREE平均值为3.38；表明轻稀土元素较重稀土元素富集；下1煤层顶底板泥岩中，稀土元素相对富集，稀土元素总量远高于煤中，均值为煤中的8.6倍，轻稀土元素明显富集。顶底板与煤中稀土元素分配模式相似，受煤炭堆积沼泽水体变化和后期热液作用的影响，稀土元素含量有轻微的分异，煤中稀土元素与陆源岩关系密切。煤中δEu负异常明显，结构保存指数与凝胶化指数图解显示成煤环境主要为还原环境，与Eu异常指示的成煤环境一致。Ce呈现负异常，可能与其处于强的还原环境有关。煤中稀土元素与灰分呈中等正相关关系，与SiO2呈正相关关系，表明聚乎更矿区下1煤中稀土元素呈无机态赋存。煤层顶底板泥岩中稀土元素含量与粘土矿物呈明显的正相关关系，其中伊利石含量与稀土元素富集关系最密切。
Abstract:The rare earth elements, major elements, microcomponents and industrial components in the coal seam and its roof and floor were determined by ICP-MS, X-ray fluorescence spectrum, optical microscope and industrial analysis of coal.According to the results, the content, geochemical characteristics and distribution patterns of rare earth elements were comprehensively analyzed.The modes of occurrence and genesis of rare earth elements in coal were discussed.The results show that the average content of REE is 23.01×10-6 in the No.1 coal of the Juhugeng mining area.LREE/HREE mean value is 3.38, indicating that the light rare earth elements are more abundant than the heavy rare earth elements.In the top and bottom mudstone of the lower coal, rare earth elements are relatively enriched, and the total amount of rare earth elements is much higher than that of coal, with an average value of 8.6 times that of coal.The distribution mode of rare earth elements in the roof and floor is similar to that in the coal.With the influence of the change of water body in the coal accumulation swamp and the later hydrothermal action, the rare earth content is slightly different.The rare earth elements in the coal are closely related to the continental source rocks.In the coal, Eu negative anomaly is obvious, and the structure preservation index (TPI) versus gelation index (GI) diagram shows that the coal-forming environment is mainly a reducing environment, which is consistent with the coal-forming environment indicated by Eu anomaly.The negative Ce anomaly may be related to the strong reduction environment.In coal, rare earth element REE is positively correlated with ash content (R=0.481), and positively correlated with SiO2 (R=0.652), indicating that rare earth elements in the No.1 coal in the Juhugeng mining area coexist in inorganic state.The content of rare earth elements in the mudstone of roof and floor is positively correlated with clay minerals, among which the content of illite is most closely related to the enrichment of rare earth elements.
-
Key words:
- Juhugeng coal district /
- No.1 coal seam /
- rare earth element /
- geochemistry /
- Qinghai Province
-
-
表 1 聚乎更矿区下1煤中稀土元素含量
Table 1. The content of rare earth elements in the No.1 coal from Juhugeng coal district
10-6 采样位置 样品编号 岩性 La Ce Pr Nd Sm Eu Gd Tb Dy Ho Er Tm Yb Lu Y 一井田 1J-1 顶板泥岩 43.5 81.7 8.72 33.3 6.42 1.28 5.51 0.88 4.83 1.00 2.77 0.46 3.03 0.48 27.1 1J-2 原煤 2.17 2.99 0.51 1.66 0.24 0.025 0.25 0.042 0.17 0.040 0.12 0.042 0.12 0.027 2.21 1J-3 原煤 1.46 3.20 0.54 1.72 0.28 0.070 0.26 0.055 0.30 0.070 0.21 0.043 0.26 0.046 2.04 1J-4 原煤 2.70 4.51 0.60 1.77 0.26 0.10 0.28 0.054 0.30 0.061 0.18 0.035 0.19 0.035 1.50 1J-5 原煤 1.77 2.13 0.59 1.61 0.23 0.16 0.23 0.052 0.20 0.045 0.13 0.033 0.14 0.036 1.41 1J-6 原煤 2.32 4.06 0.58 1.84 0.30 0.053 0.28 0.054 0.27 0.057 0.17 0.035 0.18 0.034 1.58 1J-7 原煤 2.08 3.46 0.56 1.80 0.29 0.086 0.27 0.049 0.22 0.080 0.14 0.032 0.16 0.033 1.24 1J-8 原煤 1.62 2.89 0.51 1.61 0.26 0.069 0.24 0.047 0.23 0.053 0.15 0.034 0.17 0.035 1.47 1J-9 原煤 4.00 6.89 0.85 3.04 0.53 0.12 0.48 0.089 0.53 0.12 0.36 0.066 0.45 0.076 3.49 1J-10 原煤 14.1 19.7 2.16 6.24 0.91 0.21 1.02 0.19 0.92 0.19 0.56 0.11 0.61 0.11 5.39 1J-11 原煤 8.66 15.8 1.82 6.73 1.33 0.25 1.19 0.19 1.13 0.23 0.65 0.10 0.69 0.14 6.46 1J-12 原煤 12.2 18.9 1.87 6.83 1.33 0.36 1.24 0.22 1.46 0.33 1.00 0.21 1.20 0.18 8.50 1J-13 原煤 7.68 14.0 1.52 6.07 1.25 0.24 1.10 0.18 1.04 0.20 0.54 0.08 0.51 0.08 5.72 1J-14 底板泥岩 34.2 68.3 7.26 26.4 4.55 0.76 3.99 0.61 3.13 0.59 1.61 0.28 1.69 0.29 16.1 三井田 3J-1 顶板泥岩 51.2 97.2 11.4 41.1 8.04 1.61 6.70 1.04 5.84 1.20 3.42 0.54 3.69 0.56 32.1 3J-2 原煤 0.69 1.10 0.43 0.95 0.17 0.019 0.17 0.04 0.17 0.04 0.12 0.03 0.17 0.03 1.11 3J-3 底板泥岩 51.7 96.1 10.9 38.5 7.80 1.50 6.59 1.05 6.12 1.24 3.46 0.55 3.74 0.56 35.3 四井田 4J-1 顶板泥岩 33.2 63.9 7.18 27.1 5.04 1.09 4.30 0.66 3.44 0.68 1.94 0.32 1.92 0.33 19.1 4J-2 原煤 2.48 2.67 2.09 2.85 0.27 0.012 0.41 0.10 0.04 0.02 0.07 0.09 0.15 0.07 1.38 4J-3 底板泥岩 17.9 31.3 4.35 15.4 2.91 0.84 2.74 0.53 3.17 0.63 1.66 0.29 1.63 0.29 16.4
下载: 导出CSV
表 2 聚乎更矿区下1煤中稀土元素地球化学参数
Table 2. Geochemical parameters of rare earth elements in the No.1 coal from Juhugeng coal district
采样位置 样品编号 Ad/% REE LREE HREE L/H (La/Yb)N (La/Sm)N (La/Lu)N (Gd/Lu)N δEu δCe 一井田 1J-1 / 220.9 174.9 46.05 3.8 9.67 4.26 9.42 1.43 0.66 1.01 1J-2 1.20 10.61 7.59 3.02 2.51 12.69 5.675 8.45 1.147 0.31 0.688 1J-3 6.71 10.56 7.27 3.29 2.21 3.78 3.306 3.31 0.704 0.80 0.866 1J-4 4.71 12.57 9.93 2.63 3.77 9.63 6.51 7.92 0.995 1.17 0.855 1J-5 25.41 8.78 6.50 2.28 2.85 8.44 4.76 5.12 0.801 2.09 0.500 1J-6 3.09 11.81 9.15 2.65 3.45 8.50 4.934 7.06 1.003 0.57 0.839 1J-7 2.33 10.50 8.28 2.22 3.72 8.52 4.555 6.63 1.009 0.96 0.550 1J-8 3.31 9.39 6.96 2.43 2.86 6.26 3.950 4.82 0.842 0.86 0.766 1J-9 6.52 21.10 15.43 5.67 2.72 6.00 4.73 5.50 0.797 0.75 0.90 1J-10 35.14 52.4 43.3 9.10 4.76 15.53 9.70 12.93 1.12 0.67 0.86 1J-11 9.70 45.35 34.6 10.77 3.21 8.44 4.10 6.65 1.09 0.62 0.96 1J-12 18.53 55.8 41.4 14.36 2.89 6.81 5.73 6.99 0.86 0.85 0.95 1J-13 5.77 40.23 30.8 9.45 3.26 10.25 3.87 10.19 1.74 0.63 0.99 1J-14 / 169.8 141.5 28.29 5.0 13.63 4.73 12.45 1.74 0.54 1.04 三井田 3J-1 / 265.7 210.6 55.1 3.8 9.36 4.00 9.46 1.48 0.67 0.97 3J-2 17.82 5.23 3.35 1.88 1.78 2.80 2.559 2.28 0.68 0.34 0.48 3J-3 / 265.1 206.5 58.6 3.5 9.33 4.17 9.53 1.45 0.64 0.97 四井田 4J-1 / 170.3 137.6 32.71 4.2 11.70 4.15 10.56 1.63 0.71 1.00 4J-2 4.45 12.70 10.37 2.33 4.46 10.99 5.771 3.84 0.76 0.11 0.28 4J-3 / 100.0 72.7 27.30 2.7 7.42 3.87 6.43 1.18 0.91 0.85 注：陨石数据采用Boynton推荐的球粒陨石平均值[25]；∑LREE=La+Ce+Pr+Nd+Sm+Eu；∑HREE=Gd+Tb+Dy+Ho+Er+Tm+Yb+Lu；∑REE=∑LREE+∑HREE；(La/Yb)N、(La/Sm)N、(La/Lu)N、(Gd/Lu)N元素球粒陨石标准化值的比值；δEu=EuN/(SmN×GdN)1/2，δCe=CeN/(LaN×PrN)1/2，EuN、SmN、GdN、CeN、LaN、PrN为元素球粒陨石标准化值
下载: 导出CSV
表 3 下1煤层顶底板泥岩矿物组分与含量
Table 3. The mineral composition and content of mudstone in roof and floor of the No.1 coal
样品编号 矿物含量/% 黏土矿物/% 稀土元素含量/10-6 石英 钾长石 斜长石 菱铁矿 TCCM 高岭石 伊利石 蒙脱石 REE LREE HREE 1J-01 47.0 1.0 52.0 25 27 220.9 174.9 46.05 1J-14 46.0 54.0 24 28 2 169.8 141.5 28.29 3J-01 41.0 5.0 4.0 50.0 24 26 265.7 210.6 55.1 3J-03 42.0 58.0 24 34 1 265.1 206.5 58.6 4J-01 50.0 3.0 4.0 2.0 41.0 15 24 1 170.3 137.6 32.71 4J-03 63.0 3.0 2.0 1.0 31.0 16 14 1 100 72.7 27.3
下载: 导出CSV
表 4 灰分、主量元素与稀土元素相关关系
Table 4. The relationship between ash, major elements and rare earth elements
组分 Ad K2O Na2O SiO2 Al2O3 Fe2O3 CaO MgO SO3 MnO2 P2O5 TiO2 REE Ad 1.000 K2O -0.863** 1.000 Na2O -0.738** 0.190 1.000 SiO2 0.055 0.522* -0.049 1.000 Al2O3 -0.773** 0.236 0.474 -0.184 1.000 Fe2O3 0.245 -0.333 -0.101 -0.696** -0.311 1.000 CaO 0.318 -0.689** 0.071 -0.613** -0.311 0.640** 1.000 MgO 0.327 -0.467 -0.044 -0.632** -0.422 0.833** 0.880** 1.000 SO3 -0.347 -0.532* 0.245 -0.255 0.081 0.244 0.598* 0.430 1.000 MnO2 0.351 -0.052 -0.390 -0.343 -0.603* 0.754** 0.413 0.692** -0.256 1.000 P2O5 / 0.899* 0.257 -0.886* 0.371 0.886* 0.143 0.143 -0.821 0.486 1.000 TiO2 -0.136 -0.140 0.411 0.005 0.390 -0.017 0.025 -0.015 0.701** -0.446 0.657 1.000 REE 0.481 0.668** -0.278 0.652** -0.118 -0.392 -0.696** -0.547* -0.679** 0.048 0.829* -0.275 1.000 注：**在置信度(双测)为0.01时，相关性是显著的；*在置信度(双测)为0.05时，相关性显著
下载: 导出CSV
-
[1] 王中刚, 于学元, 赵振华.稀土元素地球化学[M].北京:科学出版社, 1989:279-289, 310-313.
[2] 任德贻.煤的微量元素地球化学[M].北京:科学出版社, 2006:321-322.
[3] 代世峰, 任德贻, 李生盛.煤及顶板中稀土元素赋存状态及逐级化学提取[J].中国矿业大学学报, 2002, 31(5):349-353. doi: 10.3321/j.issn:1000-1964.2002.05.003
[4] 代世峰, 任德贻, 李生盛.华北若干晚古生代煤中稀土元素的赋存特征[J].地球学报, 2003, 24(3):273-278. doi: 10.3321/j.issn:1006-3021.2003.03.013
[5] 代世峰, 任德贻, 周义平, 等.煤型稀有金属矿床:成因类型、赋存状态和利用评价[J].煤炭学报, 2014, 8:1707-1715. http://www.cnki.com.cn/Article/CJFDTotal-MTXB201408044.htm
[6] Seredin V V, Dai S F.Coal deposits as potential alterna-tive sources for lanthanides and yttrium[J].International Journal of Coal Geology, 2012, 94:67-93. https://www.sciencedirect.com/science/article/pii/S0166516211002448
[7] Seredin V V.Rare earth element-bearing coals from the Russian Far East deposits[J].International Journal of Coal Geology, 1996, 30:101-129. doi: 10.1016/0166-5162(95)00039-9
[8] 杜美霞, 庄新国.华南地区晚二叠世煤的稀土元素特征[J].地质科技情报, 2006, (2):52-56. doi: 10.3969/j.issn.1000-7849.2006.02.009
[9] 黄文辉, 杨起, 汤达祯, 等.华北晚古生代煤的稀土元素地球化学特征[J].地质学报, 1999, 73(4):360-369. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199900084719
[10] 李大华, 唐跃刚, 陈坤, 等.重庆煤中稀土元素的地球化学特征研究[J].中国矿业大学学报, 2005, 34(3):312-317. doi: 10.3321/j.issn:1000-1964.2005.03.011
[11] 吴艳艳, 秦勇, 易同生.贵州凯里梁山组高硫煤中稀土元素的富集及其地质成因[J].地质学报, 2010, 84(2):280-285. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dizhixb201002014
[12] 刘东娜, 周安朝, 常泽光.大同煤田8号原煤及风化煤中常量元素和稀土元素地球化学特征[J].煤炭学报, 2015, 40(2):422-430. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=mtxb201502026
[13] 刘贝, 黄文辉, 敖卫华, 等.沁水盆地晚古生代煤中稀土元素地球化学特征[J].煤炭学报, 2015, 40(12):2916-2926. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=mtxb201512023
[14] 刘大锰, 杨起, 汤达祯, 等.华北晚古生代煤中硫及微量元素分布赋存规律[J].煤炭科学技术, 2000, 28(9):39-42. doi: 10.3969/j.issn.0253-2336.2000.09.013
[15] 文怀军, 邵龙义, 李永红, 等.青海省天峻县木里煤田聚乎更矿区构造轮廓和地层格架[J].地质通报, 2011, 30(12):1823-1828. doi: 10.3969/j.issn.1671-2552.2011.12.003
[16] 杨德寿, 王青平, 童海奎.青海聚乎更矿区侏罗纪含煤岩系沉积相研究[J].中国煤炭地质, 2011, 23(12):15-17. doi: 10.3969/j.issn.1674-1803.2011.12.04
[17] 吕景高, 邵龙义, 张文龙, 等.青海木里聚乎更矿区木里组煤层发育特征及煤层对比[J].中国煤炭地质, 2016, 28(5):15-19. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgmtdz201605004
[18] 邵龙义, 杨致宇, 李永红, 等.青海木里聚乎更天然气水合物潜在区中侏罗世岩相古地理特征[J].现代地质, 2015, (5):1061-1072. doi: 10.3969/j.issn.1000-8527.2015.05.008
[19] Dai S F, Ren D Y, Chou C L, et al.Geochemistry of trace elements in Chinese coals:a review of abundances, genetic types, impacts on human health, and industrial utilization[J].International Journal of Coal Geology, 2012, 94:3-21. https://www.sciencedirect.com/science/article/abs/pii/S0166516211000346
[20] Ketris M P, Yudovich Y E.Estimations of Clarkes for carbonaceous biolithes World averages for trace element contents in black shales and coals[J].International Journal of Coal Geology, 2009, 78:135-148. doi: 10.1016/j.coal.2009.01.002
[21] Dai S F, Hower J C, Ward C R, et al.Elements and phosphorus minerals in the middle Jurassic inertinite-rich coals of the Muli Coal field on the Tibetan Plateau[J].International Journal of Coal Geology, 2015, 144:23-47. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=377ba8c8a9b3c087907f59382799baf5
[22] 崔晓南, 黄文辉, 敖卫华, 等.渭北煤田下峪口矿二叠纪煤中稀土元素地球化学研究[J].地学前缘, 2016, 23(03):90-96. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201603012
[23] 秦国红, 邓丽君, 刘亢, 等.鄂尔多斯盆地西缘煤中稀土元素特征[J].煤田地质与勘探, 2016, 44(6):8-14. doi: 10.3969/j.issn.1001-1986.2016.06.002
[24] 郭江峰, 姚多喜, 陈健, 等.重庆龙潭组煤中稀土元素地球化学及地质成因分析[J].地学前缘, 2016, 23(3):51-58. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy201603007
[25] Boynton W V.Cosmochemistry of the rare earth elements:Meteorites studies[J].Developments in Geochemistry, 1984, 2(2):63-114. https://www.sciencedirect.com/science/article/pii/B9780444421487500083
[26] 赵志根, 唐修义, 李宝芳.淮南矿区煤的稀土元素地球化学[J].沉积学报, 2000, 18(3):453-459. doi: 10.3969/j.issn.1000-0550.2000.03.022
[27] 王文峰, 秦勇, 宋党育, 等.晋北中高硫煤中稀土元素的地球化学特征[J].地球化学, 2002, 31(6):564-570. doi: 10.3321/j.issn:0379-1726.2002.06.008
[28] Zhao F H, Cong Z Y, Peng S, et al.Geochemical character-istics of REE in Jurassic coal of Yan'an Formation from Dong sheng coal field[J].Journal of China University of Mining & Technology, 2002, 12(2):138-142. http://www.cnki.com.cn/Article/CJFDTotal-ZHKD200202004.htm
[29] Dai S F, Luo Y B, Seredin V V, et al.Revisiting the late Permian coal from the Huayingshan, Sichuan, southwestern China:Enrichment and occurrence modes of minerals and trace elements[J].International Journal of Coal Geology, 2012, 122:110-128. doi: 10.1016/j.coal.2013.12.016
[30] Eskenazy G M.Rare earth elements in a sampledcoal from the Pirindeposit, Bulgaria[J].International Journal of Coal Geology, 1987, 7:301-314. doi: 10.1016/0166-5162(87)90041-3
[31] 王运泉, 任德贻, 雷加锦, 等.煤中微量元素分布特征初步研究[J].地质科学, 1997, 32(1):65-73. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=9808173
[32] 赵志根.含煤岩系稀土元素地球化学研究[M].北京:煤炭工业出版社, 2002, 67.
-
