Cenozoic tectonic units and their stratigraphic characteristics of southern west Pacific region: Implication for Himalayan orogeny
-
摘要:
系统梳理西太平洋南段（包括华南、日本、菲律宾及东印度尼西亚）部分地区的新生代构造-地层特征，并以区域性角度不整合为主要依据，对喜马拉雅运动期次、时代及其构造背景进行探讨。研究区受白垩纪末期晚燕山运动的影响，古新统乃至下始新统大都缺失，新生界高角度不整合于前新生界之上。根据不同构造单元内地层沉积-火山类型及接触关系对比，研究区新生界可分为3个构造层，即始新统—渐新统、中新统或上渐新统—中新统及上新统以上。上述3个构造层之间为2个穿时的区域性角度不整合分隔，分别对应早喜马拉雅造山运动（33~20 Ma）及晚喜马拉雅造山运动（5.3~2.6 Ma）界面，并以前者最强烈。区域2次构造运动均与岛弧或裂离微地块向欧亚板块边缘的碰撞拼贴有关，指示西太平洋南段喜马拉雅运动是发生于大陆边缘的增生造山过程，受控于太平洋板块和印度洋-澳大利亚板块运动方向与速率变化。在2次构造事件期间，始新世和中新世弧后的强烈伸展，导致华南大陆边缘古老山系的夷平及边缘海的产生，并最终形成现今的地质及地理格局。
Abstract:In this paper, based on the study of tectono-stratigraphic characteristics of some representative tectonic units of southern Western Pacific region which include South China, Southwest Japan, Philippines, and East Indonesia, the authors present a review of the age, periods and background of Himalayan orogeny.Within the study region, after the late Yanshanian orogeny, most of regions were uplifted with the absence of Paleocene to lower Eocene strata.Cenozoic strata generally cover the pre-Cenozoic basement in angular unconformity form.According to stratigraphic and volcano-sedimentary characteristics of different tectonic units, they can be divided into three structural layers, i.e., Eocene or Eocene-Lower Oligocene(E2 or E2-E31), Miocene or Upper Oligocene-lowest Miocene(N1/E3-N11)and Pliocene till now(N2-Q).The above three structural layers are in contact with two regional angular unconformities, and correspond to the early Himalayan orogeny(E3-N11, 33~20 Ma)and the late Himalayan orogeny(N2, 5.3~2.6 Ma), respectively, with he former being most intense.In different regions, both orogenic movements were usually related to the collision of arcs or detached micro-terranes towards the edge of the Eurasian plate.Obviously, Himalayan orogeny was accretionary orogenesis rather than collision between two continents, and was controlled by changes in the direction and rate of movement of the Pacific and Indian Ocean-Australian plates.Between the episodic tectonic events, it was an intensive extensional setting, which led to the flattening of the palaeocathysian mountain system and the opening of the marginal seas.
-
Key words:
- Cenozoic /
- Himalayan orogeny /
- tectono-stratigraphic /
- southern West Pacific /
-
-
表 1 华南邻区新生代大地构造单元划分
Table 1. Tectonic units of the adjacent regions of South China
一级构造单元 二级构造单元 三级构造单元 Ⅰ 西太平洋弧盆系 Ⅰ-1 日本岛弧 Ⅰ-1-1
Ⅰ-1-2
Ⅰ-1-3
Ⅰ-1-4西南日本外带
西南日本内带
东北日本岛弧
千岛岛弧Ⅰ-2 台湾-菲律宾岛弧 Ⅰ-2-1
Ⅰ-2-2奇美火山弧
菲律宾岛弧Ⅰ-3 巴拉望-三宝颜陆块 Ⅰ-3-1
Ⅰ-3-2巴拉望陆块
三宝颜陆块Ⅰ-4
Ⅰ-5
Ⅰ-6伊里安-新几内亚陆缘增生带
伊豆-小笠原岛弧
哈马黑拉岛弧Ⅱ 东印度尼西亚弧盆系 Ⅱ-1 爪哇-班达岛弧 Ⅱ-I-1
Ⅱ-I-2爪哇岛弧
班达岛弧Ⅱ-2 东苏拉威西造山带 Ⅱ-3 苏拉威西岛弧 Ⅱ-3-1
Ⅱ-3-2西苏拉威西岛弧
北苏拉威西岛弧Ⅱ-4 松巴地块 Ⅲ 澳大利亚陆缘造山带 Ⅲ-1
Ⅲ-2
Ⅲ-3帝汶-布鲁造山带
苏拉地块
新几内亚褶皱带
下载: 导出CSV
-
[1] 黄汲清.中国区域地质的特征[J].地质学报, 1954, 34(3):217-244. http://d.old.wanfangdata.com.cn/Periodical/zgdizhi201005028
[2] Ren J S, Chen T.Tectonic evolution of the continental lithosphere in eastern China and adjacent areas[J].Journal of.Southeast Asian Earth Science, 1989, 3:17-27. doi: 10.1016/0743-9547(89)90006-8
[3] 贾承造, 何登发, 陆洁民.中国喜马拉雅运动的期次及其动力学背景[J].石油与天然气地质, 2004, 25(2):121-125. doi: 10.3321/j.issn:0253-9985.2004.02.001
[4] Amante C, Eakins B W.ETOPO11 Arc-Minute Global Relief Model: Procedures, DataSources and Analysis.NOAA Technical Memorandum NESDIS NGDC-24.National Geophysical Data Center, NOAA[EB/OL](2009-08)[2020-02-09]doi: 10.7289/V5C8276M[access date].https://www.ngdc.noaa.gov/mgg/global/global.html.2009.
[5] 郑洪波, 魏晓椿, 王平, 等.长江的前世今生[J].中国科学:地球科学, 2017, 47:385-393. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgkx-cd201704001
[6] 任纪舜, 赵磊, 徐芹芹, 等.中国的全球构造位置和地球动力系统[J].地质学报, 2016, 9:2100-2108. doi: 10.3969/j.issn.0001-5717.2016.09.002
[7] 蔡周荣, 刘维亮, 万志峰, 等.南海北部新生代构造运动厘定及与油气成藏关系探讨[J].海洋通报, 2010, 29(2):161-165. doi: 10.3969/j.issn.1001-6392.2010.02.007
[8] 李楠, 李巍然, 龙海燕.南黄海盆地北部坳陷正反转构造[J].海洋地质与第四纪地质, 2013, 33(3):95-100. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201303009
[9] 索艳慧, 李三忠, 曹现志, 等.中国东部中新生代反转构造及其记录的大洋板块俯冲过程[J].地学前缘, 2017, 24(4):249-267. http://d.old.wanfangdata.com.cn/Periodical/dxqy201704023
[10] 李廷栋, 莫杰.中国滨太平洋构造域构造格架和东海地质演化[J].海洋地质与第四纪地质, 2002, 22(4):1-6. http://d.old.wanfangdata.com.cn/Periodical/hydzydsjdz200204001
[11] Hall R.Cenozoic geological and plate tectonic evolution of SE Asia and the SW Pacific:computer-based reconstructions, model andanimations[J].Journal of Asian Earth Sciences, 2002, 20(4):353-431. doi: 10.1016/S1367-9120(01)00069-4
[12] Hall R.Late Jurassic-Cenozoic reconstructions of the Indonesian region and the IndianOcean[J].Tectonophysics, 2012, 570:1-41. https://www.sciencedirect.com/science/article/pii/S0040195112002533
[13] 姚伯初, 万玲, 吴能友.大南海地区新生代板块构造活动[J].中国地质, 2004, 31(2):113-122. doi: 10.3969/j.issn.1000-3657.2004.02.001
[14] 李三忠, 余珊, 赵淑娟, 等.东亚大陆边缘的板块重建与构造转换[J].海洋地质与第四纪地质, 2013, 33(3):65-94. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201303008
[15] 李三忠, 臧艺博, 王鹏程, 等.华南中生代构造转换和古太平洋俯冲启动[J].地学前缘, 2017, 24(4):213-225. http://d.old.wanfangdata.com.cn/Periodical/dxqy201704020
[16] 李三忠, 索艳慧, 李玺瑶, 等.西太平洋中生代板块俯冲过程与东亚洋陆过渡带构造-岩浆响应[J].科学通报, 2018, 63:1550. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=kxtb201816006
[17] Lee T Y, Lawver L A.Cenozoic plate reconstruction of SoutheastAsia[J].Tectonophysics, 1995, 251(1/4):85-138. https://scholar.lib.ntnu.edu.tw/en/publications/cenozoic-plate-reconstruction-of-southeast-asia
[18] Monnier C, Girardeau J, Maury R C, et al.Back-arc basin origin for the East Sulawesi ophiolite(eastern Indonesia)[J].Geology, 1995, 23(9):851-854. doi: 10.1130/0091-7613(1995)023<0851:BABOFT>2.3.CO;2
[19] Hill K C, Lucas K, Bradey K.Structural styles in the Papuan Fold Belt, Papua New Guinea:constraints from analoguemodelling[J].Geological Society, London, Special Publications, 2010, 348(1):33-56 doi: 10.1144/SP348.3
[20] 马文璞, 陆松年, 王果胜.日本在亚洲前沿的构造定位及其对中国东部区域构造的含义[J].地质通报, 2003, 22(3):192-199. doi: 10.3969/j.issn.1671-2552.2003.03.008 http://dzhtb.cgs.cn/gbc/ch/reader/view_abstract.aspx?file_no=20030339&flag=1
[21] Wakita K.Geology of the Japanese Islands: an outline[C]//Natural Heritage of Japan.Springer, Cham., 2018: 9-17.
[22] Isozaki Y, Aoki K, Nakama T, et al.New insight into a subduction-related orogen:a reappraisal of the geotectonic framework and evolution of the JapaneseIslands[J].Gondwana Research, 2010, 18(1):82-105. doi: 10.1016/j.gr.2010.02.015
[23] Taira A.Tectonic evolution of the Japanese island arcsystem[J].Annual Review of Earth and Planetary Sciences, 2001, 29(1):109-134. doi: 10.1146/annurev.earth.29.1.109
[24] Wakita K.Geology and tectonics of Japanese islands:a review-the key to understanding the geology ofAsia[J].Journal of Asian Earth Sciences, 2013, 72:75-87. doi: 10.1016/j.jseaes.2012.04.014
[25] Imaoka T, Kiminami K, Nishida K, et al.K-Ar age and geochemistry of the SW Japan Paleogene cauldron cluster:Implications for Eocene-Oligocene thermo-tectonicreactivation[J].Journal of Asian Earth Sciences, 2011, 40(2):509-533. doi: 10.1016/j.jseaes.2010.10.002
[26] Uyeda S, Miyashiro A.Plate tectonics and the Japanese Islands:asynthesis[J].Geological Society of America Bulletin, 1974, 85(7):1159-1170. doi: 10.1130/0016-7606(1974)85<1159:PTATJI>2.0.CO;2
[27] Saito T, Okada Y, Fujisaki W, et al.Accreted Kula plate fragment at 94 Ma in the Yokonami-melange, Shimanto-belt, Shikoku, Japan[J].Tectonophysics, 2014, 623(2):136-146. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=681b838247e96ccad44b31ee370929c8
[28] Kimura G, Kitamura Y, Yamaguchi A, et al.Origin of the early Cenozoic belt boundary thrust and Izanagi-Pacific ridge subduction in the western Pacific margin[J].Island Arc, 2019, 28(5):e12320. https://onlinelibrary.wiley.com/doi/full/10.1111/iar.12320
[29] Aoki K, Itaya T, Shibuya T, et al.The youngest blueschist belt in SW Japan:implication for the exhumation of the Cretaceous Sanbagawa high-P/T metamorphicbelt[J].Journal of Metamorphic Geology, 2008, 26(5):583-602. doi: 10.1111/j.1525-1314.2008.00777.x
[30] Aoki K, Kitajima K, Masago H, et al.Metamorphic P-T-time history of the Sanbagawa belt in central Shikoku, Japan and implications for retrograde metamorphism during exhumation[J].Lithos, 2009, 113(3/4):393-407. https://www.sciencedirect.com/science/article/pii/S0024493709001807
[31] Aoki K, Maruyama S, Isozaki Y, et al.Recognition of the Shimanto HP metamorphic belt within the traditional Sanbagawa HP metamorphic belt:New perspectives of the Cretaceous-Paleogene tectonics in Japan[J].Journal of Asian Earth Sciences, 2011, 42(3):355-369. doi: 10.1016/j.jseaes.2011.05.001
[32] Hara H, Kimura K.Metamorphic and cooling history of the Shimanto accretionary complex, Kyushu, Southwest Japan:Implications for the timing of out of sequencethrusting[J].Island Arc, 2008, 17(4):546-559. doi: 10.1111/j.1440-1738.2008.00636.x
[33] Mahony S H, Wallace L M, Miyoshi M, et al.Volcano-tectonic interactions during rapid plate-boundary evolution in the Kyushu region, SW Japan[J].GSA Bulletin, 2011, 123(11/12):2201-2223. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=54ceab77bdfd1893146b28bf83018bf7
[34] Raimbourg H, Famin V, Palazzin G, et al.Tertiary evolution of the Shimanto belt(Japan):A large-scale collision in EarlyMiocene[J].Tectonics, 2017, 36(7):1317-1337. doi: 10.1002/2017TC004529
[35] Sdrolias M, Roest W R, Müller R D.An expression of Philippine Sea plate rotation:the Parece Vela and Shikokubasins[J].Tectonophysics, 2004, 394(1/2):69-86. https://ui.adsabs.harvard.edu/abs/2004Tectp.394...69S/abstract
[36] Jolivet L, Tamaki K, Fournier M.Japan Sea, opening history and mechanism:Asynthesis[J].Journal of Geophysical Research:Solid Earth, 1994, 99(B11):22237-22259. doi: 10.1029/93JB03463
[37] Kino Y.Geoglogy of the Obi district.With Geological Sheet Map at 1: 50000[J].Geological Survey of Japan, 1959: 1-5(in Japanese with English abstract).
[38] Yamauchi, Sawada, Y, Takasu, et al.Geology of the Saigo distrct.With geological sheet map 1: 50000, Saigo[J].Geological Survey of Japan, AIST, 2009(in Japanese with English abstract 5p).
[39] Furukawa Y, Tatsumi Y.Melting of a subducting slab and production of high-mg andesite magmas:Unusual magmatism in SW Japan at 13~15 Ma[J].Geophysical Research Letters, 1999, 26(15):2271-2274. doi: 10.1029/1999GL900512
[40] Tatsumi Y, Ishikawa N, Anno K, et al.Tectonic setting of high-Mg andesite magmatism in the SW Japan arc:K-Ar chronology of the Setouchi volcanicbelt[J].Geophysical Journal International, 2001, 144(3):625-631. doi: 10.1046/j.1365-246x.2001.01358.x
[41] Itoh Y, Nagasaki Y.Crustal shortening of southwest Japan in the lateMiocene[J].Island Arc, 1996, 5(3):337-353. doi: 10.1111/j.1440-1738.1996.tb00035.x
[42] Sato H.The relationship between late Cenozoic tectonic events and stress field and basin development in northeastJapan[J].Journal of Geophysical Research:Solid Earth, 1994, 99(B11):22261-22274. doi: 10.1029/94JB00854
[43] Taira A, Okada H, Whitaker J H, et al.The Shimanto Belt of Japan:cretaceous-lower Miocene active-marginsedimentation[J].Geological Society, London, Special Publications, 1982, 10(1):5-26. doi: 10.1144/GSL.SP.1982.010.01.01
[44] Xu S M, Ye Q, Li S, et al.Sequential patterns in Cenozoic marginal basins of the NorthwestPacific[J].Geological Journal, 2016, 51:387-415. https://www.researchgate.net/publication/304067705_Sequential_patterns_in_Cenozoic_marginal_basins_of_the_Northwest_Pacific_Sequential_Patterns_in_Cenozoic_Marginal_Basins_of_the_NW_Pacific
[45] Yumul Jr G P, Dimalanta C B, Tamayo Jr R A, et al.Collision, subduction and accretion events in the Philippines:a synthesis[J].Island Arc, 2003, 12(2):77-91. doi: 10.1046/j.1440-1738.2003.00382.x
[46] Gabo J A S, Dimalanta C B, Asio M G S, et al.Geology and geochemistry of the clastic sequences from Northwestern Panay(Philippines):Implications for provenance and geotectonic setting[J].Tectonophysics, 2009, 479(1/2):111-119. https://www.sciencedirect.com/science/article/abs/pii/S0040195109000754
[47] Yumul Jr G P, Dimalanta C B, Marquez E J, et al.Onland signatures of the Palawan micro continental block and Philippine mobile belt collision and crustal growth process:a review[J].Journal of Asian Earth Sciences, 2009, 34(5):610-623. doi: 10.1016/j.jseaes.2008.10.002
[48] Yumul Jr G P, Dimalanta C B, Maglambayan V B, et al.Tectonic setting of a composite terrane:A review of the Philippine island arc system[J].Geosciences Journal, 2008, 12(1):7. https://www.researchgate.net/profile/Edanjarlo_Marquez/publication/226705935_Tectonic_setting_of_a_composite_terrane_A_review_of_the_Philippine_island_arc_system/links/0deec527c88350a63a000000.pdf
[49] Canto A P B, Padrones J T, Concepcion R A B, et al.Geology of northwestern Mindoro and its offshore islands:Implications for terrane accretion in west Central Philippines[J].Journal of Asian Earth Sciences, 2012, 61:78-87. doi: 10.1016/j.jseaes.2012.08.006
[50] Concepcion R A B, Dimalanta C B, Yumul G P, et al.Petrography, geochemistry, and tectonics of a rifted fragment of Mainland Asia:evidence from the Lasala Formation, Mindoro Island, Philippines[J].International Journal of Earth Sciences, 2012, 101(1):273-290. doi: 10.1007/s00531-011-0643-5
[51] Walia M, Knittel U, Suzuki S, et al.No Paleozoic metamorphics in Palawan(the Philippines)?-Evidence from single grain U-Pb dating of detritalzircons[J].Journal of Asian Earth Sciences, 2012, 52:134-145. doi: 10.1016/j.jseaes.2012.03.005
[52] Aurelio M A, Peña R E.Geology and mineral resources of thePhilippines[J].Mines and Geosciences Bureau, Department of Environment and Natural Resources, Quezon City, 2004:391.
[53] Aurelio M A, Peña R E, Taguibao K J L.Sculpting the Philippine archipelago since the Cretaceous through rifting, oceanic spreading, subduction, obduction, collision and strike-slip faulting:Contribution to IGMA5000[J].Journal of Asian Earth Sciences, 2013, 72:102-107. doi: 10.1016/j.jseaes.2012.10.007
[54] Evans C A, Casteneda G, Franco H.Geochemical complexities preserved in the volcanic rocks of the Zambales ophiolite, Philippines[J].Journal of Geophysical Research:Solid Earth, 1991, 96(B10):16251-16262. doi: 10.1029/91JB01488
[55] Dimalanta C B, Yumul G P.Magmatic and amagmatic contributions to crustal growth in the Philippine island arc system:Comparison of the Cretaceous and post-Cretaceousperiods[J].Geosciences Journal, 2006, 10(3):321. doi: 10.1007/BF02910373
[56] Andal E S, Arai S, Yumul Jr G P.Complete mantle section of a slow-spreadingridge-derived ophiolite:An example from the Isabela ophiolite in the Philippines[J].Island Arc, 2005, 14(3):272-294. doi: 10.1111/j.1440-1738.2005.00471.x
[57] Guotana J M R, Payot B D, Dimalanta C B, et al.Arc and back arc geochemical signatures of the proto-Philippine Sea Plate:Insights from the petrography and geochemistry of the Samar Ophiolite volcanicsection[J].Journal of Asian Earth Sciences, 2017, 142:77-92. doi: 10.1016/j.jseaes.2016.07.031
[58] Encarnación J.Multiple ophiolite generation preserved in the northern Philippines and the growth of an island arccomplex[J].Tectonophysics, 2004, 392(1/4):103-130. https://ui.adsabs.harvard.edu/abs/2004Tectp.392..103E/abstract
[59] Ilao K A, Morley C K, Aurelio M A.3D seismic investigation of the structural and stratigraphic characteristics of the Pagasa Wedge, Southwest Palawan Basin, Philippines, and their tectonic implications[J].Journal of Asian Earth Sciences, 2018, 154:213-237. doi: 10.1016/j.jseaes.2017.12.017
[60] Dimalanta C B, Ramos E G L, Yumul Jr G P, et al.New features from the Romblon Island Group:Key to understanding the arc-continent collision in CentralPhilippines[J].Tectonophysics, 2009, 479(1/2):120-129. https://core.ac.uk/display/52856021
[61] Yumul G P, Dimalanta C B, Tamayo R A, et al.Geology of the Zamboanga Peninsula, Mindanao, Philippines:an enigmatic South China continental fragment?[J].Geological Society, London, Special Publications, 2004, 226(1):289-312. doi: 10.1144/GSL.SP.2004.226.01.16
[62] Aurelio M A, Forbes M T, Taguibao K J L, et al.Middle to Late Cenozoic tectonic events in south and central Palawan(Philippines)and their implications to the evolution of the south-eastern margin of South China Sea:Evidence from onshore structural and offshore seismicdata[J].Marine and Petroleum Geology, 2014, 58:658-673. doi: 10.1016/j.marpetgeo.2013.12.002
[63] Aurelio M A, Barrier E, Rangin C, et al.The Philippine Fault in the late Cenozoic tectonic evolution of the Bondoc-Masbate-N.Leyte area, centralPhilippines[J].Journal of Southeast Asian Earth Sciences, 1991, 6(3/4):221-238. https://www.sciencedirect.com/science/article/pii/074395479190069A
[64] 任纪舜, 王作勋, 陈炳蔚, 等.从全球看中国大地构造——中国及邻区大地构造图简要说明[M].北京:地质出版社, 1999.
[65] Hall R, Wilson M E J.Neogene sutures in easternIndonesia[J].Journal of Asian Earth Sciences, 2000, 18(6):781-808. doi: 10.1016/S1367-9120(00)00040-7
[66] Charlton T R.Tertiary evolution of the eastern Indonesia collisioncomplex[J].Journal of Asian Earth Sciences, 2000, 18(5):603-631. doi: 10.1016/S1367-9120(99)00049-8
[67] Metcalfe I.Gondwana dispersion and Asian accretion:Tectonic and palaeogeographic evolution of easternTethys[J].Journal of Asian Earth Sciences, 2013, 66:1-33. doi: 10.1016/j.jseaes.2012.12.020
[68] Pubellier M, Morley C K.The basins of Sundaland(SE Asia):Evolution and boundaryconditions[J].Marine and Petroleum Geology, 2014, 58:555-578. doi: 10.1016/j.marpetgeo.2013.11.019
[69] Bergman S C, Coffield D Q, Talbot J P, et al.Tertiary tectonic and magmatic evolution of western Sulawesi and the Makassar Strait, Indonesia:evidence for a Miocene continent-continentcollision[J].Geological Society, London, Special Publications, 1996, 106(1):391-429. doi: 10.1144/GSL.SP.1996.106.01.25
[70] Wakita K, Sopaheluwakan J, Miyazaki K, et al.Tectonic evolution of the Bantimala complex, south Sulawesi, Indonesia[J].Geological Society, London, Special Publications, 1996, 106(1):353-364. doi: 10.1144/GSL.SP.1996.106.01.23
[71] Parkinson C.An outline of the petrology, structure and age of the Pompangeo Schist Complex of central Sulawesi, Indonesia[J].Island Arc, 1998, 7(1/2):231-245. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=10.1046/j.1440-1738.1998.00171.x
[72] Kadarusman A, Massonne H J, van Roermund H, et al.PT evolution of eclogites andblueschists from the Luk Ulo Complex of central Java, Indonesia[J].International Geology Review, 2007, 49(4):329-356. doi: 10.2747/0020-6814.49.4.329
[73] Zahirovic S, Seton M, Müller R D.The Cretaceous and Cenozoic tectonic evolution of SoutheastAsia[J].Solid Earth, 2014, 5(1):227. doi: 10.5194/se-5-227-2014
[74] Smyth H, Hall R, Hamilton J, et al.East Java: Cenozoic basins, volcanoes and ancient basement[C]//Proceedings Indonesian Petroleum Association 31st Annual Convention, Jakarta, 2005: 251-226
[75] Clements B, Hall R.Cretaceous to Late Miocene stratigraphic and tectonic evolution of West Java[C]//Proceedings Indonesian Petroleum Association 31st Annual Convention, Jakarta, 2007: 1-18
[76] Ratman R, Suwarti T, Samodra H.Geologic map of Indonesia, Surabay Sheet; scale 1:1000000)[J].Geological Reseach and Development Centre, Indonesia, Bundung, 1998.
[77] Gafoer S, Samodra H.Geologic map of Indonesia, Jakarta Sheet(scale 1:1000000)[J].Geological Reseach and Development Centre, Indonesia, Bundung, 1993.
[78] Matthews S J, Bransden P J E.Late cretaceous and cenozoic tectono-stratigraphic development of the East Java Sea Basin, Indonesia[J].Marine and Petroleum Geology, 1995, 12(5):499-510. doi: 10.1016/0264-8172(95)91505-J
[79] Leterrier J, Yuwono Y S, Soeria-Atmadja R, et al.Potassic volcanism in central Java and south Sulawesi, Indonesia[J].Journal of Southeast Asian Earth Sciences, 1990, 4(3):171-187. doi: 10.1016/S0743-9547(05)80011-X
[80] Soeria-Atmadja R, Maury R C, Bellon H, et al.Tertiary magmatic belts in Java[J].Journal of Southeast Asian earth sciences, 1994, 9(1/2):13-27. https://www.sciencedirect.com/science/article/pii/0743954794900620
[81] Van Leeuwen T, Allen C M, Elburg M, et al.The Palu Metamorphic Complex, NW Sulawesi, Indonesia:Origin and evolution of a young metamorphic terrane with links to Gondwana and Sundaland[J].Journal of Asian Earth Sciences, 2016, 115:133-152. doi: 10.1016/j.jseaes.2015.09.025
[82] Hennig J, Hall R, Armstrong R A.U-Pb zircon geochronology of rocks from west Central Sulawesi, Indonesia:Extension-related metamorphism and magmatism during the early stages of mountainbuilding[J].Gondwana Research, 2016, 32:41-63. doi: 10.1016/j.gr.2014.12.012
[83] White L T, Hall R, Armstrong R A, et al.The geological history of the Latimojong region of western Sulawesi, Indonesia[J].Journal of Asian Earth Sciences, 2017, 138:72-91. doi: 10.1016/j.jseaes.2017.02.005
[84] Pigram C J, Supandjono S J B.Origin of the Sula platform, easternIndonesia[J].Geology, 1985, 13(4):246-248. doi: 10.1130/0091-7613(1985)13<246:OOTSPE>2.0.CO;2
[85] Villeneuve M, Gunawan W, Cornee J J, et al.Geology of the central Sulawesi belt(eastern Indonesia):constraints for geodynamicmodels[J].International Journal of Earth Sciences, 2002, 91(3):524-537. doi: 10.1007/s005310100228
[86] Sukamto, R, Samodra H, Santosa S.Geologic map of Indonesia, Manado Sheet(scale 1:1000000)[J].Geological Reseach and Development Centre, Indonesia, Bundung, 1994.
[87] Sukamto R A B.Geologic map of Indonesia, Ujung Pandang Sheet(scale 1:1000000)[J].Geological Reseach and Development Centre, Indonesia, Bundung, 1975.
[88] Parkinson C D, Miyazaki K, Wakita K, et al.An overview and tectonic synthesis of the pre-Tertiary very high-pressure metamorphic and associated rocks of Java, Sulawesi and Kalimantan, Indonesia[J].Island Arc, 1998, 7(1/2):184-200. https://onlinelibrary.wiley.com/doi/abs/10.1046/j.1440-1738.1998.00184.x
[89] Monnier C, Girardeau J, Maury R C, et al.Back-arc basin origin for the East Sulawesi ophiolite(eastern Indonesia)[J].Geology, 1995, 23(9):851-854. doi: 10.1130/0091-7613(1995)023<0851:BABOFT>2.3.CO;2
[90] Kadarusman A, Miyashita S, Maruyama S, et al.Petrology, geochemistry and paleogeographic reconstruction of the East Sulawesi Ophiolite, Indonesia[J].Tectonophysics, 2004, 392(1/4):55-83. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=33a68222b66a4917fe1581e4b5a28dd9
[91] Parkinson C.Emplacement of the East Sulawesi Ophiolite:evidence from subophiolite metamorphicrocks[J].Journal of Asian Earth Sciences, 1998, 16(1):13-28. https://www.sciencedirect.com/science/article/pii/S0743954797000391
[92] Wakita K, Sopaheluwakan J, Zulkarnain I, et al.Early Cretaceous tectonic events implied in the time-lag between the age of radiolarian chert and its metamorphic basement in the Bantimala area, South Sulawesi, Indonesia[J].Island Arc, 1994, 3(2):90-102. doi: 10.1111/j.1440-1738.1994.tb00097.x
[93] Priadi B, Polve M, Maury R C, et al.Tertiary and Quaternary magmatism in Central Sulawesi:chronological and petrological constraints[J].Journal of Southeast Asian Earth Sciences, 1994, 9(1/2):81-93. https://www.academia.edu/24640566/Tertiary_and_quaternary_magmatism_in_Central_Sulawesi_Chronological_and_petrological_constraints
[94] Van Leeuwen T M.Stratigraphy and tectonic setting of the Cretaceous and Paleogene volcanic-sedimentary successions in northwest Sulawesi, Indonesia:implications for the Cenozoic evolution of Western and Northern Sulawesi[J].Journal of Asian Earth Sciences, 2005, 25(3):481-511. doi: 10.1016/j.jseaes.2004.05.004
[95] van Leeuwen T, Allen C M, Elburg M, et al.The Palu Metamorphic Complex, NW Sulawesi, Indonesia:Origin and evolution of a young metamorphic terrane with links to Gondwana and Sundaland[J].Journal of Asian Earth Sciences, 2016, 115:133-152. doi: 10.1016/j.jseaes.2015.09.025
[96] Sasajima S, Nishimura S, Hirooka K, et al.Paleomagnetic studies combined with fission-track datings on the western arc of Sulawesi, East Indonesia[J].Tectonophysics, 1980, 64(1/2):163-172. https://www.sciencedirect.com/science/article/pii/004019518090267X
[97] Calvert S J, Hall R.Cenozoic evolution of the Lariang and Karama regions, North Makassar Basin, western Sulawesi, Indonesia[J].Petroleum Geoscience, 2007, 13(4):353-368. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=afe21f660cdc9f462424e9a825d1429a
[98] Advokaat E L, Hall R, White L T, et al.Miocene to recent extension in NW Sulawesi, Indonesia[J].Journal of Asian Earth Sciences, 2017, 147:378-401. doi: 10.1016/j.jseaes.2017.07.023
[99] 陈友飞, 严钦尚, 许世远.苏北盆地沉积环境演变及其构造背景[J].地质科学, 1993:1-25. http://www.cnki.com.cn/Article/CJFDTotal-DZKX199302006.htm
[100] 钱勤, 李坤英.苏北盆地玄武岩地质年龄及地层时代[J].火山地质与矿产, 1996, 17(1):86-93. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199600241808
[101] 李春昱.四川运动及其在中国之分布[J].地质论评, 1950, 15(Z2):135-156. http://d.old.wanfangdata.com.cn/Periodical/OA000006544
[102] 江苏省地质矿产局.江苏省及上海市区域地质志[M].北京:地质出版社, 1984:315-329.
[103] 徐田武, 王英民, 魏水建, 等.苏北盆地海安凹陷下白垩统层序地层和沉积相研究[J].天然气地球科学, 2008, 19(3):351-355. http://d.old.wanfangdata.com.cn/Periodical/trqdqkx200803010
[104] 四川省地质矿产局.四川省区域地质志[M].北京:地质出版社, 1991:282-310.
[105] 李楠, 李巍然, 龙海燕.南黄海盆地北部坳陷正反转构造[J].海洋地质与第四纪地质, 2013, 33(3):95-100. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=hydzydsjdz201303009
[106] 索艳慧, 李三忠, 曹现志, 等.中国东部中新生代反转构造及其记录的大洋板块俯冲过程[J].地学前缘, 2017, 24(4):249-267. http://d.old.wanfangdata.com.cn/Periodical/dxqy201704023
[107] 安徽省地质矿产局.安徽省区域地质志[M].北京:地质出版社, 1984:315-329.
[108] 邵家骥, 黄姜侬.南京地区生代玄武岩的期次、层序及时代[J].地质论评, 1989, 35(2):97-106. doi: 10.3321/j.issn:0371-5736.1989.02.001
[109] 许汉奎.南京泗洪炭兽的发现及六合组、雨花台组的时代[J].地质学刊, 2010, (1):1-5. doi: 10.3969/j.issn.1674-3636.2010.01.1
[110] 钱勤.苏北盆地三垛组新探[J].地层学杂志, 1997, 21(4):275-280. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=QK199700028616
[111] Encarnacion J P, Essene E J, Mukasa S B, et al.High-pressure and-temperature subophiolitic kyanite-garnet amphibolites generated during initiation of mid-Tertiary subduction, Palawan, Philippines[J].Journal of Petrology, 1995, 36(6):1481-1503. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=HighWire000002126487
[112] Steuer S, Franke D, Meresse F, et al.Oligocene-Miocene carbonates and their role for constraining the rifting and collision history of the Dangerous Grounds, South China Sea[J].Marine and Petroleum Geology, 2014, 58:644-657. doi: 10.1016/j.marpetgeo.2013.12.010
[113] Shao L, Cao L, Qiao P, et al.Cretaceous-Eocene provenance connections between the Palawan Continental Terrane and the northern South China Seamargin[J].Earth and Planetary Science Letters, 2017, 477:97-107. doi: 10.1016/j.epsl.2017.08.019
[114] Suggate S M, Cottam M A, Hall R, et al.South China continental margin signature for sandstones and granites from Palawan, Philippines[J].Gondwana Research, 2014, 26(2):699-718. doi: 10.1016/j.gr.2013.07.006
[115] Dimalanta C B, Ramos E G L, Yumul Jr G P, et al.New features from the Romblon Island Group:Key to understanding the arc-continent collision in Central Philippines[J].Tectonophysics, 2009, 479(1/2):120-129. https://www.sciencedirect.com/science/article/abs/pii/S0040195109000894
[116] Yumul Jr G P, Dimalanta C B, Marquez E J, et al.Onland signatures of the Palawan microcontinental block and Philippine mobile belt collision and crustal growth process:a review[J].Journal of Asian Earth Sciences, 2009, 34(5):610-623. doi: 10.1016/j.jseaes.2008.10.002
[117] Oda M, Chiyonobu S, Torii M, et al.Integrated magnet obiochronology of the Pliocene-Pleistocene Miyazaki succession, southern Kyushu, southwest Japan:Implications for an Early Pleistocene hiatus and defining the base of the Gelasian(P/P boundary type section)in Japan[J].Journal of Asian Earth Sciences, 2011, 40(1):84-97. doi: 10.1016/j.jseaes.2010.09.003
[118] Elburg M, van Leeuwen T, Foden J.Spatial and temporal isotopic domains of contrasting igneous suites in western and northern Sulawesi, Indonesia[J].Chemical Geology, 2003, 199(3/4):243-276. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=84feefbb048f234733f3232e99ae342d
[119] Soeria-Atmadja R, Maury R C, Bellon H, et al.Tertiary magmatic belts in Java[J].Journal of Southeast Asian Earth Sciences, 1994, 9(1/2):13-27. http://www.sciencedirect.com/science/article/pii/0743954794900620
[120] Lunt P, Burgon G, Baky A.The Pemali Formation of Central Java and equivalents:Indicators of sedimentation on an active platemargin[J].Journal of Asian Earth Sciences, 2009, 34(1):100-113. https://www.sciencedirect.com/science/article/abs/pii/S1367912008000424
[121] Sakakibara M, Ota T.Metamorphic evolution of the Kamuikotan high-pressure and low-temperature metamorphic rocks in central Hokkaido, Japan[J].Journal of Geophysical Research:Solid Earth, 1994, 99(B11):22221-22235. doi: 10.1029/94JB00958
[122] 黄奇瑜.台湾岛的年龄[J].中国科学:地球科学, 2017, 47:394-405. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgkx-cd201704002
[123] 刘景彦, 林畅松, 肖建新, 等.东海西湖凹陷第三系主要不整合面的特征、剥蚀量的分布及其意义[J].现代地质, 1999, (4):432-438. http://www.cnki.com.cn/Article/CJFDTotal-XDDZ199904012.htm
[124] 蔡周荣, 刘维亮, 万志峰, 等.南海北部新生代构造运动厘定及与油气成藏关系探讨[J].海洋通报, 2010, 29(2):161-165. doi: 10.3969/j.issn.1001-6392.2010.02.007
[125] Padrones J T, Tani K, Tsutsumi Y, et al.Imprints of late Mesozoic tectono-magmatic events on Palawan Continental Block in northern Palawan, Philippines[J].Journal of Asian Earth Sciences, 2017, 142:56-76. doi: 10.1016/j.jseaes.2017.01.027
[126] 董树文, 张岳桥, 李海龙, 等."燕山运动"与东亚大陆晚中生代多板块汇聚构造——纪念"燕山运动"90周年[J].中国科学:地球科学, 2019, 49:913-938. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgkx-cd201906002
[127] Sdrolias M, Müller R D.Controls on back-arc basinformation[J].Geochemistry, Geophysics, Geosystems, 2006, 7.Q04016, doi:10.1029/2005GC001090.
[128] Jurdy D M.Relative plate motions and the formation of marginalbasins[J].Journal of Geophysical Research:Solid Earth, 1979, 84(B12):6796-6802. doi: 10.1029/JB084iB12p06796
[129] Harris R.Geodynamic patterns of ophiolites and marginal basins in the Indonesian and New Guinearegions[J].Geological Society, London, Special Publications, 2003, 218(1):481-505. doi: 10.1144/GSL.SP.2003.218.01.25
[130] Baldwin S L, Fitzgerald P G, Webb L E.Tectonics of the New Guinearegion[J].Annual Review of Earth and Planetary Sciences, 2012, 40:495-520. doi: 10.1146/annurev-earth-040809-152540
[131] Warren P Q, Cloos M.Petrology and tectonics of the Derewo metamorphic belt, west NewGuinea[J].International Geology Review, 2007, 49(6):520-553. doi: 10.2747/0020-6814.49.6.520
[132] Harris R, Kaiser J, Hurford A, et al.Thermal history of Australian passive margin cover sequences accreted to Timor during Late Neogene arc-continent collision, Indonesia[J].Journal of Asian Earth Sciences, 2000, 18(1):47-69. https://www.sciencedirect.com/science/article/abs/pii/S136791209900036X
[133] Harris R.Rise and fall of the Eastern Great Indonesian arc recorded by the assembly, dispersion and accretion of the Banda Terrane, Timor[J].Gondwana Research, 2006, 10(3/4):207-231. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=97c205b361a6ccb0fd540558c085db22
[134] Standley C E, Harris R.Tectonic evolution of forearc nappes of the active Banda arc-continent collision:Origin, age, metamorphic history and structure of the Lolotoi Complex, EastTimor[J].Tectonophysics, 2009, 479(1/2):66-94. https://www.sciencedirect.com/science/article/abs/pii/S0040195109000602
[135] Buchanan P G, Warburton J.The Influence of Pre-Existing Basin Architecture in the Development of the Papuan Fold and Thrust Belt: Implications for Petroleum Prospective[C]//Papua New Guinea(PNG)Petroleum Convention Proceedings, 1996.
[136] Hill K C, Lucas K, Bradey K.Structural styles in the Papuan Fold Belt, Papua New Guinea:constraints from analoguemodelling[J].Geological Society, London, Special Publications, 2010, 348(1):33-56. doi: 10.1144/SP348.3
[137] 姚运生, 刘锁旺.从江汉洞庭盆地新生代以来的构造变形探讨华南地块与周缘板块的相互关系[J].地壳形变与地震, 2000, 20(4):41-49. doi: 10.3969/j.issn.1671-5942.2000.04.007
[138] Pubellier M, Morley C K.The basins of Sundaland(SE Asia):Evolution and boundaryconditions[J].Marine and Petroleum Geology, 2014, 58:555-578. doi: 10.1016/j.marpetgeo.2013.11.019
[139] Lunt P, Van Gorsel J T.Geohistory analysis of South Makassar[J].Berita Sedimentol, 2013, 28:14-24. https://www.researchgate.net/publication/313428802_Geohistory_analysis_of_South_Makassar
[140] Kano K, Uto K, Ohguchi T.Stratigraphic review of Eocene to Oligocene successions along the eastern Japan Sea:Implication for early opening of the Japan Sea[J].Journal of Asian Earth Sciences, 2007, 30(1):20-32. doi: 10.1016/j.jseaes.2006.07.003
[141] Zhu B Q, W H F, C Y W, et al.Geochronological and geochemical constraint on the Cenozoic extension of Cathaysian lithosphere and tectonic evolution of the border sea basins in East Asia[J].Journal of Asian Earth Sciences, 2004, 24(2):163-175. doi: 10.1016/j.jseaes.2003.10.006
[142] 李三忠, 曹现志, 王光增, 等.太平洋板块中-新生代构造演化及板块重建[J].地质力学学报, 2019, 25(5):642-677. http://kns.cnki.net/KCMS/detail/detail.aspx?dbcode=CJFD&filename=DZLX201905005
[143] 邱燕, 陈国能.华南大陆边缘新生代构造地貌演化机制研究[J].地学前缘, 2011, 18(1):32-38. http://d.old.wanfangdata.com.cn/Thesis/Y1014785
[144] Zheng H B, Clift P D, Wang P, et al.Pre-Miocene birth of the Yangtze River[J].Proceedings of the National Academy of Sciences, 2013, 110(19):7556-7561. doi: 10.1073/pnas.1216241110
① 洪文涛, 邢光福, 杨祝良, 等.太平洋构造域南段1: 250万地质图.中国地质调查局南京地质调查中心, 2018.
-
