LA-ICP-MS zircon U-Pb dating and genetic types of uranium-bearing granite porphyry in northern Xiangshan orefield, Jiangxi Province
-
摘要:
相山铀矿田是中国迄今为止发现的最大的火山岩型铀矿床，其北部主要铀矿类型为花岗斑岩型铀矿床，铀成矿在时空和成因上与超淺成侵入相的花岗斑岩有关。前人多针对某一具体矿床含矿主岩开展工作，获得的花岗斑岩成岩年龄数据相差较大，影响了对相山花岗斑岩型铀矿的深入研究。选择相山北部横涧、游坊、沙洲、云际等铀矿床的含矿主岩——花岗斑岩系统开展野外地质调查、地球化学特征和LA-ICP-MS锆石U-Pb定年研究，以期厘定相山花岗斑岩型铀矿床含矿主岩的成岩时代和成因类型。花岗斑岩LA-ICP-MS锆石U-Pb定年结果显示，横涧、游坊、沙洲、云际的花岗斑岩206Pb/238U年龄加权平均值分别为135.6±1.3Ma（MSWD=0.45，n=26）、136.2±1.3Ma（MSWD=1.2，n=21）、133.4±11Ma（MSWD=0.67，n=24）及134.3±1.1Ma（MSWD=0.88，n=25），集中在132~137Ma之间，属于早白垩世。研究认为，相山北部花岗斑岩成因类型界于A型花岗岩与S型花岗岩之间的过渡型，为A-S型花岗岩。花岗斑岩岩浆起源于中元古代地壳，地壳物质作为主要成分参与了花岗斑岩的形成，同时有少量地幔物质的加入。花岗斑岩为板内构造界境下伸展体制的产物，可能是由于太平洋板块俯冲后，因板块后撤导致岩浆侵入作用的结果。
Abstract:The Xiangshan uranium orefield is the largest volcanic rock type uranium deposit so far found in China. The main uraniumore type in the north is the granite porphyry type uranium deposit.The uranium mineralization is related to the ultra-hallow intrusion-phase granite porphyry in time and space.Most of the previous work was aimed at the main rocks in a single deposit, and the age date of granite porphyry obtained were quite different, which has affected the in-depth study of Xiangshang granite porphyry uranium orefield. In this paper, the main mineral-granitic porphyry system of the uranium deposits in the northern part of Xiangshan, including Hengian, Youfang, Shazhou and Yunji, was selected to carry out field geological survey, geochemical characteristics study and LA-IXP-MS zircon U-Pb dating, with the purpose of determining the petrogenetic age and genesis type of one-bearing main rocks in Xiangshan granite porphyry uranium deposit.The weighted mean 206Pb/238U ages of granite of Hengjian, Youfang, Shazhou and Yunji are 135.6±1.3Ma (MSWD=0.45, n=26), 136.2±1.3Ma(MSWD=1.2, n=21Ma(MSWD=0.67, n=24) and 134.3±1.1Ma(MSWD=0.88, n=25) respectively, concentrated on the range of 132~137Ma, suggesting the Early Cretaceous period. It is concluded that the original type of granitic porphyry in the north of Xianghan is bounded by the transition type between A-type granite and S-type granite, named A-S granite. Granite porphyry magma originated from the Middle Proterozoic crust. Crustal material, as the main component, was involved in the formation of porphyry, with the addition of a small amount of mantle materal.The granite porphyry was formed by the stretching system under the intraplate tectonic environment.It might have been the effect of magmatic intrusion due to plate retreat after the Pacific plate subduction.
-
Key words:
- uranium granite porphyry /
- zircon U-Pb dating /
- Early Cretaceous /
- A-S granite /
- northern Xiangshan
-
-
表 1 花岗斑岩样品采集位置与性质
Table 1. Collection location and lithology of granite porphyry samples
序号 样号 采集点 北纬 东经 岩石性质 1 XS15-03 横涧 27°36′31″ 115°55′34″ 花岗斑岩 2 XS15-05 游坊 27°35′46″ 115°57′58″ 花岗斑岩 3 XS15-07 沙洲 27°36′50″ 115°58′46″ 花岗斑岩 4 XS15-11 云际 27°34′55″ 116°00′54″ 花岗斑岩
下载: 导出CSV
表 2 相山北部地区花岗斑岩主量元素分析结果
Table 2. Analyses of main elements of granite porphyry in northern Xiangshan
% 样品号 岩性 产地 SiO2 TiO2 Al2O3 Fe2O3 FeO MnO MgO CaO Na2O K2O P2O5 烧失量 总计 资料来源 岩性 产地 DI SI A/CNK A/NK AR σ ALK K2O/Na2O C 资料来源 XS-15-01 花岗斑岩 横涧 69.79 0.23 14.15 1.92 1.52 0.07 0.37 2.23 2.42 5.80 0.06 2.88 99.76 本文 花岗斑岩 横涧 83.49 3.11 0.99 1.38 3.01 2.50 8.22 2.40 0.00 本文 XS-15-03 64.95 0.54 15.56 3.88 3.36 0.08 0.78 2.59 2.87 5.75 0.15 2.80 99.57 76.22 4.69 0.99 1.42 2.81 3.40 8.62 2.00 0.27 XS-9 73.43 0.19 12.82 0.64 0.95 0.07 0.33 1.51 2.46 5.21 0.05 2.33 99.99 [13] 88.81 3.44 1.03 1.32 3.30 1.92 7.67 2.12 0.52 [13] XS-12 75.05 0.07 12.41 1.65 0.60 0.02 0.17 1.11 2.74 4.25 0.06 0.96 99.09 89.77 1.82 1.12 1.36 3.14 1.52 6.99 1.55 1.46 XS-18 75.68 0.07 12.26 0.92 0.85 0.02 0.28 0.23 2.56 4.96 0.03 1.59 99.45 93.49 2.93 1.23 1.28 4.03 1.72 7.52 1.94 2.38 XS-21 74.23 0.08 12.17 1.24 0.35 0.07 0.27 1.07 3.57 5.34 0.08 1.50 99.97 94.14 2.52 0.90 1.04 5.12 2.53 8.91 1.50 0.00 XS-22 73.81 0.18 13.16 1.67 1.00 0.04 0.30 1.26 2.14 4.95 0.05 1.83 100.39 87.36 3.00 1.18 1.48 2.93 1.62 7.09 2.31 2.14 XS-24 72.32 0.09 14.32 1.61 0.75 0.04 0.18 1.90 2.18 5.28 0.71 0.99 100.37 86.67 1.81 1.12 1.54 2.70 1.89 7.46 2.42 3.29 XS-25 74.33 0.06 13.54 1.72 0.50 0.09 0.18 0.29 2.24 5.57 0.10 1.31 99.93 91.92 1.78 1.32 1.39 3.59 1.94 7.81 2.49 3.59 XS-15-05 花岗斑岩 游坊 66.19 0.53 15.30 3.65 3.10 0.08 0.75 2.22 2.70 5.97 0.14 2.36 99.54 本文 花岗斑岩 游坊 78.30 4.68 1.02 1.40 2.96 3.26 8.67 2.21 0.69 本文 XS-15-06 66.04 0.48 15.50 3.68 2.72 0.12 0.73 2.95 2.66 5.04 0.15 2.58 99.62 74.90 4.92 1.02 1.57 2.43 2.57 7.70 1.89 0.66 XS-15-07 花岗斑岩 沙洲 64.50 0.65 15.52 4.58 3.75 0.06 1.03 2.62 3.02 5.56 0.21 2.15 99.48 本文 花岗斑岩 沙洲 74.54 5.77 0.99 1.41 2.79 3.47 8.58 1.84 0.26 本文 XS-15-08 65.12 0.58 15.46 3.94 3.24 0.06 0.83 2.43 2.69 5.91 0.16 2.67 99.50 76.66 5.04 1.01 1.43 2.85 3.36 8.60 2.20 0.61 XS-15-09 66.80 0.53 15.01 4.05 3.41 0.06 0.79 2.40 2.84 5.73 0.16 1.54 99.53 77.34 4.69 0.99 1.38 2.94 3.13 8.57 2.02 0.15 XS-15-10 68.04 0.48 14.59 3.60 3.22 0.05 0.67 2.26 2.84 5.72 0.14 1.57 99.60 花岗斑岩 沙洲 79.24 4.16 0.97 1.34 3.07 2.96 8.56 2.01 0.00 本文 D6576-1 72.03 0.27 13.41 0.79 1.03 0.04 0.38 1.72 2.70 5.38 0.06 0.72 98.53 87.83 3.70 1.00 1.30 3.29 2.23 8.08 1.99 0.16 D6575-1 74.70 0.25 13.16 1.01 0.98 0.03 0.36 0.32 2.39 5.55 0.05 0.68 99.48 92.21 3.50 1.25 1.32 3.87 1.98 7.94 2.32 2.79 T326-1 72.39 0.25 13.73 0.45 1.48 0.05 0.30 1.88 2.90 5.20 0.10 0.95 99.68 86.88 2.90 0.99 1.32 3.16 2.22 8.10 1.79 0.15 T326-2 71.07 0.32 14.30 0.62 1.82 0.04 0.49 1.84 2.75 5.33 0.07 0.72 99.37 85.04 4.45 1.05 1.39 3.00 2.31 8.08 1.94 0.84 T68-1 69.17 0.43 13.29 0.75 2.70 0.05 0.54 2.38 2.69 5.28 0.10 2.00 99.38 82.68 4.52 0.92 1.31 3.07 2.39 7.97 1.96 0.00 XS-15-11 花岗斑岩 云际 66.37 0.51 15.12 3.67 3.04 0.06 0.69 2.49 2.92 5.43 0.14 2.51 99.57 本文 花岗斑岩 云际 77.55 4.42 0.99 1.41 2.80 2.99 8.35 1.86 0.24 本文 XS-15-12 65.39 0.50 15.47 3.58 3.17 0.06 0.69 2.56 2.96 5.75 0.14 2.83 99.57 77.36 4.29 0.98 1.39 2.87 3.39 8.71 1.94 0.05 XS-15-13 67.25 0.48 15.07 3.45 2.85 0.06 0.66 2.44 2.89 5.51 0.13 2.06 99.68 78.49 4.31 0.99 1.40 2.84 2.93 8.40 1.91 0.22 X19 67.16 0.38 13.88 0.53 2.25 0.05 0.48 2.28 2.54 5.25 0.10 4.64 99.54 [12] 82.25 4.34 0.99 1.41 2.86 2.43 7.79 2.07 0.12 [12] T67-1 70.05 0.33 13.46 0.90 2.60 0.05 0.46 1.94 2.74 5.64 0.10 1.28 99.55 本文 84.57 3.73 0.95 1.27 3.39 2.57 8.38 2.06 0.00 本文 注：分异指数DI=Qz+Or+Ab+Ne+Lc+Kp；固结指数SI=MgO×100/(MgO+FeO+Fe2O3+Na2O+K2O)(Wt%)；ALK=K2O+Na2O(wt%)；A/NK=Al2O3/(K2O+Na2O)(mol比)；A/CNK=Al2O3/(K2O+Na2O+CaO)(mol比)；Rittmanσ=(K2O+Na2O)^2/(SiO2-43)(wt%)；AR=[Al2O3+CaO+(Na2O+K2O)]/[Al2O3+CaO-(Na2O+K2O)](wt%)；C：刚玉
下载: 导出CSV
表 3 相山北部地区花岗斑岩微量元素分析结果
Table 3. Analyses of trace elements of granite porphyry in northern Xiangshan
10-6 样品号 岩性 产地 Li Be Sc V Cr Co Ni Ga Rb Sr Y Cs Ba Re Pb Th U Nb Ta Zr Hf 资料来源 岩性 产地 Rb/Sr Ba/Sr Rb/Nb Sr/Y Zr/Hf Rb/Ba 10000*Ga/Al Nb/Ta Ta/Hf Th/Hf 资料来源 XS-15-01 花岗斑岩 横涧 31.5 3.53 8.77 15.7 4.01 78.7 24.7 19.1 350 93.5 45.90 29.4 282 < 0.002 29.5 32.3 10.3 26.2 3.42 95.0 4.25 本文 花岗斑岩 横涧 3.74 3.02 13.36 2.04 22.35 1.24 2.55 7.66 0.80 7.60 本文 XS-15-03 33.0 3.67 8.36 39.6 8.04 76.8 24.3 22.0 229 235 43.90 9.08 675 < 0.002 33.9 24.9 5.70 26.1 2.06 70.9 2.90 0.97 2.87 8.77 5.35 24.45 0.34 2.67 12.67 0.71 8.59 XS-9 34.7 2.01 4.37 13.4 3.00 1.85 1.68 16.5 274 95.2 39.60 14.2 376 < 0.002 22.0 26.3 8.36 17.0 2.21 135 5.30 [13] 2.88 3.95 16.12 2.40 25.47 0.73 2.43 7.69 0.42 4.96 [13] XS-12 18.3 0.75 2.37 9.19 2.25 0.75 0.87 20.0 9.78 125 54.10 1.37 336 < 0.002 16.6 49.5 193 17.9 3.22 143 5.95 0.08 2.69 0.55 2.31 24.03 0.03 2.47 5.56 0.54 8.32 XS-18 47.8 2.65 2.85 8.74 2.77 0.52 0.53 19.9 127 43.8 45.70 14.6 39.4 < 0.002 4.97 24.8 13.3 18.1 3.17 134 5.86 2.90 0.90 7.02 0.96 22.87 3.22 2.40 5.71 0.54 4.23 XS-21 14.6 0.90 3.91 9.55 2.62 0.51 0.98 19.5 36.2 97.0 58.10 2.98 41.6 < 0.002 9.71 36.7 56.2 20.9 3.66 155 7.38 0.37 0.43 1.73 1.67 21.00 0.87 2.47 5.71 0.50 4.97 XS-22 41.4 3.88 4.89 20.2 4.52 1.81 1.42 17.5 298 110 47.00 14.2 230 < 0.002 15.8 30.6 8.05 19.8 2.80 147 6.16 2.71 2.09 15.05 2.34 23.86 1.30 2.51 7.07 0.45 4.97 XS-24 15.5 1.12 3.62 11.0 2.66 1.16 1.56 20.3 22.8 167 59.20 1.77 28.0 < 0.002 17.4 37.8 89.7 17.6 3.35 205 7.03 0.14 0.17 1.30 2.82 29.16 0.81 2.39 5.25 0.48 5.38 XS-25 23.2 1.05 2.18 9.88 2.63 0.58 0.52 21.2 41.1 164 68.70 6.67 187 < 0.002 34.1 63.7 146 15.5 3.45 168 6.74 0.25 1.14 2.65 2.39 24.93 0.22 2.86 4.49 0.51 9.45 XS-15-05 花岗斑岩 游坊 40.2 3.17 7.79 34.8 7.97 70.9 22.8 19.7 197 217 40.00 9.85 592 < 0.002 32.7 25.6 5.91 23.9 1.85 53.1 2.33 本文 花岗斑岩 游坊 0.91 2.73 8.24 5.43 22.79 0.33 2.43 12.92 0.79 10.99 本文 XS-15-06 28.0 3.65 8.33 35.9 7.30 70.9 23.0 21.1 120 189 37.10 9.69 386 < 0.002 19.6 24.8 10.1 23.9 2.02 61.8 2.76 0.63 2.04 5.02 5.09 22.39 0.31 2.57 11.83 0.73 8.99 XS-15-07 花岗斑岩 沙洲 48.1 3.24 10.2 47.9 10.0 82.6 23.9 22.7 200 288 49.00 14.4 861 < 0.002 40.4 25.7 4.85 28.7 2.19 73.0 3.03 本文 花岗斑岩 沙洲 0.69 2.99 6.97 5.88 24.09 0.23 2.76 13.11 0.72 8.48 本文 XS-15-08 53.5 4.07 8.93 37.2 7.54 81.3 22.9 22.0 242 204 61.10 11.8 589 < 0.002 30.7 30.2 9.84 34.0 2.88 74.0 3.33 1.19 2.89 7.12 3.34 22.22 0.41 2.69 11.81 0.86 9.07 XS-15-09 33.6 3.76 8.58 37.0 8.43 87.7 25.8 22.1 240 220 48.40 9.14 578 < 0.002 30.8 24.1 6.06 30.6 2.76 70.3 3.12 花岗斑岩 沙洲 1.09 2.63 7.84 4.55 22.53 0.42 2.78 11.09 0.88 7.72 本文 XS-15-10 43.4 3.81 8.19 33.1 7.74 102 29.4 21.9 245 199 47.40 7.56 550 < 0.002 38.0 24.8 6.34 28.7 2.73 85.6 3.68 1.23 2.76 8.54 4.20 23.26 0.45 2.84 10.51 0.74 6.74 D6576-1 24.6 2.50 5.67 21.5 2.50 2.60 3.89 14.7 135 59.2 25.40 6.03 373 < 0.002 11.1 24.0 3.21 4.49 0.85 215 8.30 2.28 6.30 30.07 2.33 25.90 0.36 2.07 5.28 0.10 2.89 D6575-1 36.1 4.08 5.70 16.3 5.62 2.68 3.96 15.4 173 114 40.00 7.78 398 < 0.002 25.0 29.0 4.53 10.2 1.02 197 10.3 1.52 3.49 16.96 2.85 19.13 0.43 2.21 10.00 0.10 2.82 T326-1 32.3 1.20 7.46 17.2 11.7 2.86 2.62 17.1 177 180 33.50 5.7 332 < 0.002 27.9 23.5 5.43 16.5 1.84 209 6.95 0.98 1.84 10.73 5.37 30.07 0.53 2.35 8.97 0.26 3.38 T326-2 38.4 2.66 7.06 16.3 8.08 3.59 4.37 16.5 188 188 30.40 5.47 484 < 0.002 26.6 26.9 5.05 15.9 1.38 223 7.24 1.00 2.57 11.82 6.18 30.80 0.39 2.18 11.52 0.19 3.72 T68-1 35.3 3.20 7.78 31.7 10.8 4.60 3.37 20.0 192 224 24.70 6.56 556 < 0.002 24.3 22.1 2.88 17.4 1.04 211 6.49 0.86 2.48 11.03 9.07 32.51 0.35 2.84 16.73 0.16 3.41 XS-15-11 花岗斑岩 云际 51.3 3.78 8.55 37.9 8.16 90.3 26.8 23.0 234 214 44.50 14.8 493 < 0.002 33.1 26.1 4.43 25.7 2.18 86.0 3.38 本文 花岗斑岩 云际 1.09 2.30 9.11 4.81 25.44 0.47 2.88 11.79 0.64 7.72 本文 XS-15-12 46.9 3.47 14.8 36.4 7.73 82.1 27.5 23.0 249 212 43.60 16.7 585 < 0.002 47.4 26.6 4.10 27.3 2.14 86.3 3.30 1.17 2.76 9.12 4.86 26.15 0.43 2.81 12.76 0.65 8.06 XS-15-13 39.9 3.47 13.1 35.8 7.51 85.2 25.7 21.4 236 209 40.90 11.6 492 < 0.002 33.1 24.6 4.06 23.8 1.91 73.2 2.84 [12] 1.13 2.35 9.92 5.11 25.77 0.48 2.68 12.46 0.67 8.66 [12] X19 35.2 2.85 7.78 27.1 6.92 3.44 2.36 17.9 181 179 23.60 6.92 513 < 0.002 30.5 18.5 2.21 15.3 1.04 100 3.16 1.01 2.87 11.83 7.58 31.65 0.35 2.44 14.71 0.33 5.85 T67-1 29.1 2.01 7.79 28.8 12.0 4.38 3.93 19.5 203 222 26.00 7.16 536 < 0.002 32.1 21.4 3.32 17.1 1.12 238 3.32 本文 0.91 2.41 11.87 8.54 71.69 0.38 2.74 15.27 0.34 6.45 本文
下载: 导出CSV
表 5 相山北部地区花岗斑岩Sr、Nd同位素分析结果
Table 5. Sr, Nd isotope analytical results of granite porphyry in northern Xiangshan
样品号 年龄/Ma Rb/10-6 Sr/10-6 87Rb/86Sr 87Sr/86Sr(2σ) ISr Sm/10-6 Nd/10-6 147Sm/144Nd 143Nd/144Nd(2σ) INd εNd(t) fSm/Nd TDM2/Ma XS-15-01 135.6 350 93.5 0.1083 0.735104±15 0.735 10.6 54.5 0.1176 0.512166±5 0.512062 -7.83 -0.40 1567 XS-15-03 135.6 229 235 0.0282 0.71835±13 0.718 11.6 67.0 0.1047 0.512134±9 0.512041 -8.24 -0.47 1599 XS-15-05 136.2 197 217 0.0263 0.717494±13 0.717 10.1 59.5 0.1026 0.512162±16 0.512071 -7.64 -0.48 1552 XS-15-06 136.2 120 189 0.0184 0.717052±13 0.717 11.2 65.9 0.1027 0.512137±6 0.512045 -8.15 -0.48 1592 XS-15-07 133.4 200 288 0.0201 0.715875±10 0.716 13.3 77.9 0.1032 0.512172±8 0.512082 -7.50 -0.48 1537 XS-15-09 133.4 240 220 0.0316 0.717714±11 0.718 11.2 60.9 0.1112 0.512189±7 0.512092 -7.30 -0.43 1522 XS-15-11 134.3 234 214 0.0316 0.717051±16 0.717 11.5 69.9 0.0995 0.512152±8 0.512065 -7.81 -0.49 1564 XS-15-13 134.3 236 209 0.0327 0.718046±16 0.718 11.3 68.6 0.0996 0.512158±6 0.512071 -7.69 -0.49 1554 注：计算所需的参数：λ(Nd)=6.54×10-12a-1，λ(Sr)=1.39×10-11a-1，143Nd/144Nd与87Sr/86Sr所示的2σ误差取其小数点后的最后位数，TDM2年龄采用二阶段模式计算，计算公式为:TDM2=(1/λSm)ln(1+A)，A={(143Nd/144Nd)m-(143Nd/144Nd)DM-[(147Sm/144Nd)m-147Sm/144Nd)c](eλt-1)}/[(147Sm/144Nd)c-(147Sm/144Nd)DM]，式中，下角标DM代表亏损地幔值，下角标m代表样品现今测定值，下角标CHUR代表球粒陨石值，下角标c代表大陆壳平均值，(147Sm/144Nd)c=0.118；(147Sm/144Nd)CHUR=0.1960;(143Nd/144Nd)CHUR=0.512630[17]；(147Sm/144Nd)DM=0.2136；(143Nd/144Nd)DM=0.513151；样品计算年龄采用本文所测试的锆石U-Pb年龄值；初始钕INd=(143Nd/144Nd)i；初始锶ISr=(87Sr/86Sr)i
下载: 导出CSV
表 6 相山北部地区花岗斑岩Pb同位素分析结果
Table 6. Pb isotope analytical results of granite porphyry in northern Xiangshan
样品号 年龄/Ma Th/ 10-6 U/ 10-6 Pb/ 10-6 208Pb/204Pb (2σ) 207Pb/204Pb (2σ) 206Pb/204Pb (2σ) (208Pb/204Pb)i (207Pb/204Pb)i (206Pb/204Pb)i 206Pb/207Pb Th/U XS-15-01 135.60 32.3 10.3 29.5 38.850±5 15.632±2 18.736±2 38.3615 15.6088 18.2600 1.19857 3.14 XS-15-03 135.60 24.9 5.70 33.9 38.884±4 15.629±2 18.489±2 38.5573 15.6179 18.2604 1.18300 4.37 XS-15-05 136.20 25.6 5.91 32.7 38.869±6 15.628±2 18.461±3 38.5194 15.6160 18.2144 1.18128 4.33 XS-15-06 136.20 24.8 10.1 19.6 39.044±5 15.645±2 18.832±2 38.4747 15.6104 18.1234 1.20371 2.46 XS-15-07 133.40 25.7 4.85 40.4 38.850±4 15.618±1 18.434±2 38.5720 15.6102 18.2737 1.18030 5.30 XS-15-09 133.40 24.1 6.06 30.8 38.870±4 15.631±1 18.516±2 38.5275 15.6182 18.2529 1.18457 3.98 XS-15-11 134.30 26.1 4.43 33.1 38.848±3 15.620±1 18.438±2 38.5011 15.6112 18.2581 1.18041 5.89 XS-15-13 134.30 24.6 4.06 33.1 38.921±3 15.639±1 18.485±1 38.5934 15.6309 18.3198 1.18198 6.06 注：(206Pb/204Pb)i=(206Pb/204Pb)实测-μ(eλt-1)；(207Pb/204Pb)i=(207Pb/204Pb)实测-μ/137.88(eλt-1)；(208Pb/204Pb)i=(208Pb/204Pb)实测-ω(eλt-1)；t为侵入岩结晶年龄或成矿年龄；计算所需的参数λ(232Th)=4.9475×10-11a-1；λ(235U)=9.8485×10-10a-1，λ(238U)=1.55125×10-10a-1；ω为现代测定的N(232Th)/N(204Pb)[18]；μ为现代测定的N(238U)/N(204Pb)
下载: 导出CSV
表 7 相山北部各个地区花岗斑岩LA-ICP-MS锆石U-Th-Pb年龄
Table 7. LA-ICP-MS zircon U-Th-Pb dating results of the granite porphyry in northern Xiangshan
测点 Th/10－6 U/10－6 Th/U 207Pb/235U 207Pb/235U 206Pb/238U 206Pb/238U rho 206Pb/238U 比值 1σ 比值 1σ 年龄/Ma 1σ XS-3-1 123.10 255.72 0.481 0.1464 0.0140 0.02114 0.00053 0.260 134.84 3.32 XS-3-2 80.01 178.05 0.449 0.1433 0.0148 0.02155 0.00070 0.315 137.43 4.43 XS-3-3 118.77 232.25 0.511 0.1441 0.0103 0.02212 0.00056 0.355 141.07 3.52 XS-3-4 297.61 363.81 0.818 0.1466 0.0111 0.02159 0.00046 0.281 137.69 2.91 XS-3-5 148.59 386.14 0.385 0.1445 0.0096 0.02131 0.00045 0.322 135.90 2.87 XS-3-7 151.25 270.37 0.559 0.1445 0.0113 0.02131 0.00047 0.280 135.93 2.95 XS-3-8 213.25 473.19 0.451 0.1405 0.0101 0.02111 0.00041 0.267 134.66 2.56 XS-3-9 210.80 427.03 0.494 0.1428 0.0130 0.02115 0.00051 0.266 134.94 3.22 XS-3-10 156.28 419.68 0.372 0.1420 0.0098 0.02109 0.00042 0.288 134.57 2.64 XS-3-11 256.70 401.14 0.640 0.1422 0.0105 0.02136 0.00044 0.281 136.24 2.79 XS-3-13 154.13 342.37 0.450 0.1440 0.0123 0.02139 0.00055 0.303 136.45 3.49 XS-3-14 84.97 193.52 0.439 0.1448 0.0118 0.02128 0.00062 0.360 135.75 3.95 XS-3-15 141.28 405.71 0.348 0.1433 0.0106 0.02056 0.00039 0.255 131.22 2.46 XS-3-16 107.39 268.23 0.400 0.1451 0.0135 0.02136 0.00045 0.227 136.23 2.84 XS-3-17 145.36 280.12 0.519 0.1388 0.0112 0.02060 0.00049 0.295 131.43 3.11 XS-3-18 56.13 108.47 0.517 0.1460 0.0126 0.02188 0.00078 0.411 139.50 4.91 XS-3-21 127.07 235.04 0.541 0.1444 0.0125 0.02155 0.00057 0.307 137.44 3.63 XS-3-22 94.96 213.61 0.445 0.1429 0.0140 0.02154 0.00074 0.350 137.40 4.68 XS-3-23 90.96 206.12 0.441 0.1427 0.0128 0.02165 0.00067 0.346 138.06 4.24 XS-3-24 134.64 308.47 0.436 0.1431 0.0132 0.02154 0.00060 0.302 137.39 3.80 XS-3-25 150.93 302.21 0.499 0.1440 0.0122 0.02160 0.00050 0.273 137.79 3.15 XS-3-26 142.00 269.40 0.527 0.1428 0.0205 0.02128 0.00087 0.265 135.77 5.11 XS-3-27 84.52 178.32 0.474 0.1432 0.0143 0.02139 0.00063 0.296 136.46 4.00 XS-3-28 221.99 505.29 0.439 0.1451 0.0083 0.02106 0.00040 0.333 134.38 2.54 XS-3-29 193.25 502.51 0.385 0.1410 0.0098 0.02111 0.00042 0.289 134.68 2.67 XS-3-30 99.03 211.31 0.469 0.1404 0.0110 0.02103 0.00046 0.277 134.14 2.89 XS-5-1 143.42 301.45 0.476 0.1462 0.0124 0.02190 0.00056 0.302 139.68 3.54 XS-5-2 140.54 309.19 0.455 0.1378 0.0112 0.02065 0.00044 0.261 131.79 2.78 XS-5-3 146.05 267.92 0.545 0.1442 0.0111 0.02160 0.00045 0.271 137.78 2.85 XS-5-4 86.22 192.90 0.447 0.1419 0.0126 0.02126 0.00057 0.303 135.60 3.60 XS-5-6 180.31 484.05 0.373 0.1443 0.0104 0.02163 0.00044 0.282 137.97 2.78 XS-5-7 147.44 273.68 0.539 0.1435 0.0128 0.02127 0.00057 0.302 135.69 3.63 XS-5-8 108.67 205.27 0.529 0.1437 0.0146 0.02149 0.00060 0.277 137.04 3.81 XS-5-9 149.90 354.58 0.423 0.1425 0.0097 0.02118 0.00039 0.270 135.10 2.45 XS-5-11 88.35 198.46 0.445 0.1427 0.0158 0.02132 0.00060 0.254 136.01 3.79 XS-5-13 102.32 230.63 0.444 0.1439 0.0134 0.02182 0.00048 0.235 139.17 3.00 XS-5-14 164.28 431.25 0.381 0.1411 0.0111 0.02184 0.00049 0.283 139.26 3.07 XS-5-15 89.30 165.36 0.540 0.1448 0.0112 0.02163 0.00065 0.387 137.95 4.08 XS-5-16 82.92 176.18 0.471 0.1379 0.0220 0.02180 0.00089 0.256 139.04 5.61 XS-5-17 139.66 342.21 0.408 0.1465 0.0114 0.02053 0.00046 0.289 130.97 2.90 XS-5-21 143.44 333.93 0.430 0.1476 0.0101 0.02180 0.00042 0.284 138.99 2.68 XS-5-22 148.07 463.84 0.319 0.1412 0.0117 0.02067 0.00039 0.224 131.91 2.43 XS-5-23 96.50 235.99 0.409 0.1432 0.0116 0.02141 0.00049 0.285 136.58 3.11 XS-5-24 153.55 380.75 0.403 0.1527 0.0106 0.02222 0.00044 0.282 141.70 2.74 XS-5-25 134.39 276.66 0.486 0.1431 0.0156 0.02132 0.00059 0.253 135.98 3.71 XS-5-27 83.67 284.15 0.294 0.1505 0.0149 0.02219 0.00066 0.302 141.51 4.19 XS-5-30 271.67 554.47 0.490 0.1378 0.0091 0.02053 0.00037 0.271 131.03 2.33 XS-7-1 285.69 932.42 0.306 0.1366 0.0074 0.02048 0.00032 0.288 130.70 2.01 XS-7-2 153.15 377.42 0.406 0.1386 0.0115 0.02074 0.00041 0.239 132.34 2.59 XS-7-3 263.36 851.29 0.309 0.1409 0.0074 0.02078 0.00034 0.310 132.58 2.14 XS-7-4 213.00 583.76 0.365 0.1397 0.0084 0.02064 0.00036 0.291 131.68 2.28 XS-7-5 82.62 157.95 0.523 0.1375 0.0106 0.02059 0.00049 0.311 131.41 3.12 XS-7-6 186.72 446.76 0.418 0.1396 0.0095 0.02060 0.00041 0.293 131.43 2.59 XS-7-7 69.51 198.49 0.350 0.1387 0.0163 0.02050 0.00078 0.323 130.82 4.91 XS-7-8 87.07 186.04 0.468 0.1415 0.0137 0.02102 0.00054 0.263 134.11 3.38 XS-7-9 178.60 466.97 0.382 0.1372 0.0100 0.02068 0.00049 0.328 131.93 3.10 XS-7-11 199.10 482.15 0.413 0.1398 0.0123 0.02038 0.00044 0.244 130.07 2.77 XS-7-12 210.39 483.53 0.435 0.1406 0.0092 0.02072 0.00033 0.241 132.21 2.06 XS-7-14 77.52 179.27 0.432 0.1414 0.0147 0.02125 0.00056 0.253 135.57 3.54 XS-7-16 85.93 223.37 0.385 0.1390 0.0136 0.02126 0.00061 0.295 135.61 3.86 XS-7-17 220.58 601.58 0.367 0.1418 0.0121 0.02108 0.00049 0.272 134.47 3.07 XS-7-18 125.13 265.45 0.471 0.1430 0.0136 0.02146 0.00055 0.268 136.88 3.46 XS-7-19 271.56 736.99 0.368 0.1454 0.0089 0.02167 0.00039 0.291 138.19 2.44 XS-7-20 81.027 147.01 0.551 0.1422 0.0186 0.02141 0.00087 0.312 136.54 5.51 XS-7-24 170.75 450.48 0.379 0.1379 0.0089 0.02141 0.00046 0.331 136.55 2.88 XS-7-25 205.56 577.50 0.356 0.1400 0.0086 0.02100 0.00036 0.281 133.96 2.30 XS-7-26 175.87 400.94 0.439 0.1369 0.0119 0.02103 0.00046 0.253 134.16 2.91 XS-7-27 184.21 424.57 0.434 0.1401 0.0090 0.02147 0.00043 0.316 136.93 2.74 XS-7-28 71.34 185.04 0.386 0.1402 0.0158 0.02068 0.00075 0.323 131.94 4.74 XS-7-29 182.87 478.34 0.382 0.1404 0.0101 0.02088 0.00039 0.261 133.20 2.49 XS-7-30 143.20 334.18 0.429 0.1418 0.0105 0.02121 0.00047 0.300 135.29 2.98 XS-11-1 134.14 323.47 0.415 0.1389 0.0105 0.02078 0.00039 0.248 132.57 2.47 XS-11-2 75.92 145.46 0.522 0.1402 0.0159 0.02091 0.00057 0.239 133.43 3.58 XS-11-4 94.01 188.64 0.498 0.1431 0.0132 0.02090 0.00059 0.309 133.34 3.76 XS-11-5 104.18 196.60 0.530 0.1380 0.0119 0.02037 0.00049 0.280 130.01 3.11 XS-11-6 82.16 165.37 0.497 0.1430 0.0201 0.02151 0.00080 0.264 137.17 5.04 XS-11-7 154.14 445.99 0.346 0.1388 0.0101 0.02041 0.00044 0.298 130.26 2.79 XS-11-8 234.80 606.39 0.387 0.1403 0.0083 0.02090 0.00034 0.277 133.33 2.16 XS-11-9 174.29 574.29 0.303 0.1427 0.0087 0.02131 0.00035 0.267 135.92 2.20 XS-11-10 146.28 370.30 0.395 0.1382 0.0095 0.02025 0.00039 0.276 129.21 2.43 XS-11-11 90.50 197.85 0.457 0.1423 0.0105 0.02125 0.00047 0.299 135.55 2.95 XS-11-13 212.30 651.66 0.326 0.1408 0.0076 0.02076 0.00034 0.299 132.45 2.13 XS-11-14 126.67 272.35 0.465 0.1403 0.0108 0.02110 0.00060 0.370 134.64 3.81 XS-11-15 112.48 270.68 0.416 0.1406 0.0156 0.02137 0.00078 0.330 136.29 4.94 XS-11-16 158.51 454.75 0.349 0.1409 0.0100 0.02141 0.00043 0.286 136.56 2.73 XS-11-17 266.53 841.45 0.317 0.1398 0.0076 0.02178 0.00032 0.267 138.92 2.00 XS-11-18 181.03 447.45 0.405 0.1405 0.0090 0.02105 0.00042 0.310 134.28 2.65 XS-11-19 181.77 521.59 0.348 0.1425 0.0082 0.02125 0.00037 0.302 135.52 2.35 XS-11-20 172.74 380.97 0.453 0.1402 0.0088 0.02065 0.00042 0.320 131.75 2.64 XS-11-22 92.07 170.02 0.542 0.1448 0.0162 0.02162 0.00078 0.325 137.86 4.95 XS-11-23 164.24 319.39 0.514 0.1409 0.0159 0.02116 0.00079 0.332 134.99 5.00 XS-11-24 107.36 211.74 0.507 0.1450 0.0125 0.02160 0.00049 0.265 137.76 3.12 XS-11-25 172.35 291.38 0.592 0.1411 0.0132 0.02124 0.00051 0.259 135.48 3.25 XS-11-27 110.17 195.20 0.564 0.1396 0.0109 0.02151 0.00061 0.359 137.21 3.82 XS-11-29 143.64 494.07 0.291 0.1400 0.0082 0.02103 0.00036 0.293 134.14 2.27 XS-11-30 194.96 433.83 0.449 0.1408 0.0094 0.02120 0.00040 0.283 135.26 2.52
下载: 导出CSV
-
[1] 余达淦, 吴仁贵, 陈培荣.铀资源地质学[M].哈尔滨:哈尔滨工程大学出版社, 2005.
[2] 薛振华, 尹宗烈, 曾长庚.横涧花岗斑岩成因探讨[J].东华理工大学学报(自然科学版), 1991, (1):28-36.
[3] 张鸿.横涧-岗上英矿床多期次热液活动与铀成矿关系的探讨[J].世界核地质科学, 2008, 25(2):68-72. doi: 10.3969/j.issn.1672-0636.2008.02.002
[4] 邵飞, 范衡, 夏菲, 等.相山矿田斑岩型铀矿床地球化学特征及成矿机制探讨[J].东华理工大学学报自然科学版, 2011, 34(4):308-314. http://d.old.wanfangdata.com.cn/Periodical/hddzxyxb201104002
[5] 曹小兵, 吕古贤, 胡宝群, 等.相山矿田沙洲铀矿床围岩蚀变地球化学特征[J].地质力学学报, 2012, 18(4):389-400. doi: 10.3969/j.issn.1006-6616.2012.04.004
[6] 张玉燕, 李子颖, 黄志章, 等.江西相山沙洲矿床铀的存在形式和迁移特征探讨:来自诱发裂变径迹的证据[J].高校地质学报, 2012, (4):639-646. doi: 10.3969/j.issn.1006-7493.2012.04.005
[7] 陈正乐, 王平安, 王永, 等.江西相山铀矿田山南矿区控矿构造解析与找矿预测[J].地球科学与环境学报, 2013, 35(2):8-18. doi: 10.3969/j.issn.1672-6561.2013.02.002
[8] 周玉龙, 刘云浪, 高琰.赣中相山矿田北部铀成矿地质条件分析[J].世界核地质科学, 2013, 30(1):1-6. doi: 10.3969/j.issn.1672-0636.2013.01.001
[9] 郭福生, 谢财富, 张树明, 等.江西相山-鹿冈区域地质及铀多金属成矿背景[M].北京:地质出版社, 2017.
[10] 杨水源.华南赣杭构造带含铀火山盆地岩浆岩的成因机制及动力学背景[D].南京大学博士学位论文, 2013.
[11] 陈正乐, 王永, 周永贵, 等.江西相山火山-侵入杂岩体锆石SHRIMP定年及其地质意义[J].中国地质, 2013, 40(1):217-231. doi: 10.3969/j.issn.1000-3657.2013.01.015
[12] 王勇剑.相山花岗斑岩和中基性脉岩特征及其与铀成矿关系[D].核工业北京地质研究院硕士学位论文, 2015.
[13] 陈雷, 赵元艺, 王宗起, 等.江西相山铀矿田山南矿区流纹英安岩和花岗斑岩的地球化学与Sr、Nd同位素特征[J].地质与勘探, 2013, 49(6):999-1016. http://d.old.wanfangdata.com.cn/Periodical/dzykt201306001
[14] 张万良, 李子颖.关于赣中相山矿田相山"碎斑熔岩"[J].地质论评, 2015, 61(2):367-375.
[15] 李冰; 杨红霞; 刘崴, 等.硅酸盐岩石化学分析方法(GB/T14506.1-GB/T14506.30—2010)[M].国家地质实验测试中心, 2010.
[16] 张桂存; 崔建勇; 高鼎顺, 等.岩石中锶、钕、铅同位素测定方法(GB/T17672—1999)[M].北京:核工业北京地质研究院, 1999.
[17] 刘亮, 邱检生, 杨泽黎.浙江临海猫狸岭岩体的成因:年代学、地球化学与Sr-Nd-Hf同位素制约[J].岩石学报, 2013, 29(12):4069-4086. http://d.old.wanfangdata.com.cn/Periodical/ysxb98201312003
[18] 周振华, 吕林素, 王挨顺.内蒙古黄岗锡铁矿床花岗岩深部源区特征与构造岩浆演化:Sr-Nd-Pb-Hf多元同位素制约[J].地质科技情报, 2011, 30(1):1-14. http://d.old.wanfangdata.com.cn/Periodical/dzkjqb201101001
[19] Sun S S, Mcdonough W F.Chemical and Isotopic Systematics of Oceanic Basalts:Implications for Mantle Composition and Processes[J]. Geological Society of London Special Publications, 1989, 42:313-345. doi: 10.1144/GSL.SP.1989.042.01.19
[20] Taylor S R, Mclennan S M.The Continental Crust:Its composition and Evolution[M]. Oxford:Blackwell Scientific Publications, 1985:1-312.
[21] 黎彤.化学元素的地球丰度[J].地球化学, 1976, (3):167-174. doi: 10.3321/j.issn:0379-1726.1976.03.004
[22] Faure G.Principles of Isotope Geology[M]. New York, Johnwiley and Sons, 1986: 1-589.
[23] Wiedenbeck M.Three Natural Zircon Standards for U-Th-Pb, Lu-Hf, Trace-Element and Ree Analyses[J]. Geostandards Newsletter, 1995, 19(1):1-23. doi: 10.1111/j.1751-908X.1995.tb00147.x
[24] Wiedenbeck M, Hanchar J M, Peck W H, et al.Further characterisation of the 91500 zircon crystal[J]. Geostandards and Geoanalytical Research, 2004, 28(1):9-39. doi: 10.1111/j.1751-908X.2004.tb01041.x
[25] Black L P, Gulson B L.The age of the Mud Tank carbonatite, Strangways Range, Northern Territory[J]. BMR Journal of Australian Geology and Geophysics, 1978, 3:227-232.
[26] Liu Y S, Hu Z C, Gao S, et al.In situ analysis of major and trace elements of anhydrous minerals by LA-ICP-MS without applying an internal standard[J]. Chemical Geology, 2008, 257(1/2):34-43. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=babd721ac13e2675d9485b52683be64c
[27] 吴仁贵, 余达淦, 张树明.相山铀矿田流纹英安斑岩的厘定及与铀矿化的关系[J].铀矿地质, 2003, 19(2):81-87. doi: 10.3969/j.issn.1000-0658.2003.02.003
[28] 范洪海, 王德滋, 沈渭洲, 等.江西相山火山-侵入杂岩及中基性脉岩形成时代研究[J].地质论评, 2005, 51(1):86-91. doi: 10.3321/j.issn:0371-5736.2005.01.011
[29] 张万良, 李子颖.相山"流纹英安岩"单颗粒锆石U-Pb年龄及地质意义[J].岩石矿物学杂志, 2007, 26(1):21-26. doi: 10.3969/j.issn.1000-6524.2007.01.004
[30] Whalen J B.Geochemistry of an island-arc plutonic suite:the Uasilau-Yau Yau intrusive complex New Britain, PNG[J]. J. Petrol., 1985, 26:603-632. doi: 10.1093/petrology/26.3.603
[31] Whalen J B, Currie K L, Chappell B W.A-type granite:geochemical characteristics, discrimination and petrogenesis[J]. Contrib.Mineral.Petrol., 1987, 95(4):407-419. doi: 10.1007/BF00402202
[32] Eby G N.Chemical subdivision of the A-type granitoids[J]. Petrogenetic and Tectonic Implications Geology, 1992, 20:641-644. http://d.old.wanfangdata.com.cn/NSTLQK/10.1130-0091-7613(1992)020-0641-CSOTAT-2.3.CO%3b2/
[33] 张旗.A型花岗岩的标志和判别——兼答汪洋等对"A型花岗岩的实质是什么"的质疑[J].岩石矿物学杂志, 2013, 32(2):267-274. doi: 10.3969/j.issn.1000-6524.2013.02.014
[34] 王强, 赵振华, 熊小林.桐柏-大别造山带燕山晚期A型花岗岩的厘定[J].岩石矿物学杂志, 2000, 19(4):297-306 doi: 10.3969/j.issn.1000-6524.2000.04.002
[35] Collies W J, Beams S D, White A J R, et al.Nature and origin of A-type granites with particular reference to southeastern Australia[J]. Contributions to Mineralogy and Petrology, 1982, 80:189-200. doi: 10.1007/BF00374895
[36] 吴福元, 江博明.中国北方造山带造山后花岗岩的同位素特点与地壳生长意义[J].科学通报, 1997, (20):2188-2192. doi: 10.3321/j.issn:0023-074X.1997.20.017
[37] 沈渭洲.稳定同位素地质学教程[M].北京:原子能出版社, 1997.
[38] 肖庆辉, 邓晋福, 马大铨, 等.花岗岩研究思维与研究方法[M].北京:地质出版社, 2002.
[39] 毛景文, 陈懋弘, 袁顺达, 等.华南地区钦杭成矿带地质特征和矿床时空分布规律[J].地质学报, 2011, 85(5):636-658. http://d.old.wanfangdata.com.cn/Periodical/dizhixb201105004
[40] 邱检生, 王德滋.浙闽沿海地区I型-A型复合花岗岩体的地球化学及成因[J].岩石学报, 1999, 15(2):237-246. http://d.old.wanfangdata.com.cn/Periodical/ysxb98199902009
[41] 范洪海, 凌洪飞, 沈渭洲, 等.相山火山-侵入杂岩Nd-Sr-Pb同位素地球化学特征[J].岩石学报, 2001, 17(3):395-402. http://d.old.wanfangdata.com.cn/Periodical/ysxb98200103007
[42] 张金带.华东铀矿地质志[M].北京: 中国核工业地质局, 2005.
-
