北祁连造山带嘉峪关北大草滩地区早志留世碎屑锆石LA-ICP-MS U-Pb年龄及其地质意义

孟勇; 唐淑兰; 李向民; 李艳广; 卜涛

北祁连造山带嘉峪关北大草滩地区早志留世碎屑锆石LA-ICP-MS U-Pb年龄及其地质意义

1.
中国地质调查局西安地质调查中心, 陕西西安 710054

2.
西安财经学院, 陕西西安 710100

基金项目:
中国地质调查局项目《祁连成矿带肃南—大柴旦地区地质矿产调查》（编号：DD20160012）、《中国及邻区海陆大地构造研究和相关图件编制（西安中心）》（编号：121201232000167711）和西安财经学院项目《高分辩率遥感影像信息提取的多尺度分析方法研究》（编号：16FCJH05）

详细信息

作者简介: 孟勇(1979-), 男, 硕士, 高级工程师, 从事区域地质调查及综合研究工作。E-mail:16392800@qq.com

中图分类号: P534.43;P597⁺.3

收稿日期: 2017-07-07

修回日期: 2018-03-13

刊出日期: 2018-04-25

LA-ICP-MS zircon U-Pb dating of the Early Silurian clastic rocks in Dacaotan of Jiayuguan, North Qilian orogenic belt

1.
Xi'an Center of Geological Survey, CGS, Xi'an 710054, Shaanxi, China

2.
Xi'an University of Finance and Economics, Xi'an 710100, Shaanxi, China

Received Date: 07 July 2017

Revised Date: 13 March 2018

Publish Date: 25 April 2018

摘要

摘要:
以北祁连造山带嘉峪关北大草滩地区原划为中—下奥陶统的阴沟群碎屑岩为研究对象，进行碎屑锆石LA-ICP-MS UPb测年，探讨其形成时代、物源组成和构造背景。结果表明，碎屑岩沉积时代早于432.5Ma，为早志留世，该套沉积地层并不属于早—中奥陶世阴沟群。碎屑锆石U-Pb同位素年龄可明显分为4组：早古生代年龄组，434~521Ma，峰值为447Ma；新元古代年龄组，791~992Ma，峰值年龄966Ma；中古元古代年龄组，1017~1755Ma，并出现1120Ma、1278Ma、1427Ma和1648Ma多个峰值；古元古代早期—新太古代晚期年龄组，1879~2663Ma，并出现2089Ma、2428Ma和2543Ma多个峰值。综合分析显示，碎屑岩沉积物质来源于祁连造山带和阿拉善地块，祁连造山带早古生代岛弧型岩浆岩和新元古代岩浆岩，以及造山带结晶基底岩系为该套碎屑岩沉积提供了更重要的物源。
- 早志留世 /
- 碎屑锆石 /
- LA-ICP-MSU-Pb测年 /
- 沉积物源 /
- 北祁连造山带
Abstract:
The detrital rocks distributed in Dacaotan, northern Jiayuguan in the North Qilian orogenic belt were chosen as the study object, which was originally considered to be of the Yingou Group of Middle-Lower Ordovician. LA-ICP-MS zircon U-Pb iso-tope chronology was investigated to study the formation age, material source composition and tectonic background of the Yingou Group. The results show that the sedimentary age of the Yingou Group is earlier than 432.5Ma, and hence its age should be Early Si-lurian and it does not belong to the Yingou Group of Middle-Lower Ordovician. The zircon age spectrum can be evidently divided into four groups:Early Paleozoic age group from 434~521Ma, with the peak value being 447Ma; Neoproterozoic age group from 791~992Ma, with the peak value being 966Ma; Mesoproterozoic age group from 1017~1755Ma, with the peak value varying from 1120Ma, 1278Ma, 1427Ma to 1648Ma; Paleoproterozoic-Neoarchaean age group from 1879~2663Ma, with the peak value varying from 2089Ma, 2428Ma to 2543Ma. Comprehensive analyses show that the material source was derived form Qilian tectonic zone and Alashan block. The Early Paleozoic island-type magmatic rock in Qilian tectonic zone, Neoproterozoic magmatic rock and tectonic zone crystalline basement rock series contributed much to the sedimentation of the detrital rocks.
- Early Silurian /
- detrital zircon /
- LA-ICP-MS U-Pb dating /
- provenance /
- North Qilian orogenic belt

HTML全文

图 1 北祁连造山带地质简图

Figure 1.

下载: 全尺寸图片幻灯片

图 2 嘉峪关北大草滩地质剖面

Figure 2.

下载: 全尺寸图片幻灯片

图 3 长石岩屑杂砂岩野外露头（a）及显微照片（b）

Figure 3.

下载: 全尺寸图片幻灯片

图 4 代表性碎屑锆石CL图像及²⁰⁷Pb/²⁰⁶Pb或²⁰⁶Pb/²³⁸U年龄

Figure 4.

下载: 全尺寸图片幻灯片

图 5 二长花岗岩锆石CL图像及²⁰⁷Pb/²⁰⁶Pb或²⁰⁶Pb/²³⁸U年龄

Figure 5.

下载: 全尺寸图片幻灯片

图 6 单颗粒碎屑锆石LA-ICP-MS U-Pb年龄谐和图

Figure 6.

下载: 全尺寸图片幻灯片

图 7 单颗粒碎屑锆石LA-ICP-MS U-Pb年龄频谱图

Figure 7.

下载: 全尺寸图片幻灯片

图 8 二长花岗岩锆石U-Pb谐和图（a）及加权平均年龄图（b）

Figure 8.

下载: 全尺寸图片幻灯片

表 1 碎屑锆石LA-ICP-MS U-Th-Pb同位素分析结果

Table 1. LA-ICP-MS U-Th-Pb data of detrital zircons

样点编号	同位素比值								年龄/Ma								Th/10^-6	U/10^-6	Th/U
样点编号	Pb²⁰⁷/Pb²⁰⁶	±σ	Pb²⁰⁷/U²³⁵	±σ	Pb²⁰⁶/U²³⁸	±σ	Pb²⁰⁸/Th²³²	±σ	Pb²⁰⁷/Pb²⁰⁶	±σ	Pb²⁰⁷/U²³⁵	±σ	Pb²⁰⁶/U²³⁸	±σ	Pb²⁰⁸/Th²³²	±σ	Th/10^-6	U/10^-6	Th/U
样品P02
P02-01	0.15799	0.00409	10.34628	0.26549	0.47518	0.0072	0.1266	0.00238	2434.2	43.17	2466.3	23.76	2506.2	31.48	2409.3	42.68	66.37	57.07	1.16
P02-02	0.15751	0.00249	10.47264	0.17211	0.48246	0.00597	0.12256	0.00172	2429.1	26.51	2477.5	15.23	2538	25.97	2336.8	31.06	120.21	176.28	0.68
P02-03	0.07125	0.00159	1.60106	0.03611	0.16305	0.00203	0.04973	0.00075	964.6	44.92	970.6	14.1	973.7	11.28	981	14.47	246.96	419.21	0.59
P02-04	0.09731	0.00163	2.33904	0.04051	0.17442	0.0021	0.06728	0.00086	1573.1	31.05	1224.2	12.32	1036.4	11.51	1316.1	16.27	397.97	771.01	0.52
P02-05	0.33967	0.00566	5.20137	0.08597	0.11111	0.00146	0.10694	0.00126	3661.3	25.25	1852.8	14.08	679.2	8.45	2053.6	23.07	299.83	375.99	0.80
P02-06	0.06579	0.00177	1.2206	0.03282	0.13461	0.00174	0.03779	0.00062	799.8	55.36	810	15.01	814.1	9.9	749.7	12.1	221.12	304	0.73
P02-07	0.14006	0.00504	7.74859	0.27259	0.40143	0.00708	0.09773	0.0027	2227.9	60.99	2202.3	31.64	2175.6	32.56	1884.7	49.66	27.65	29.79	0.93
P02-08	0.17984	0.00319	12.78025	0.23225	0.51563	0.00674	0.12547	0.00174	2651.4	29.15	2663.6	17.11	2680.6	28.65	2389.1	31.28	182.45	143.07	1.28
P02-09	0.08155	0.00249	2.11199	0.06391	0.18792	0.00263	0.05909	0.00128	1234.7	58.68	1152.7	20.85	1110.1	14.26	1160.3	24.37	81.36	154.53	0.53
P02-10	0.19841	0.00327	5.14635	0.08645	0.1882	0.00236	0.06897	0.00084	2813.2	26.7	1843.8	14.28	1111.6	12.8	1348.1	15.94	443.49	389.1	1.14
P02-11	0.08374	0.00263	0.85213	0.02643	0.07383	0.00103	0.03095	0.00061	1286.5	60.19	625.8	14.49	459.2	6.19	616	11.91	198.77	376.86	0.53
P02-12	0.07136	0.00208	1.68881	0.04903	0.17172	0.00231	0.04559	0.00093	967.7	58.43	1004.3	18.51	1021.6	12.72	901.2	17.99	135.67	249.12	0.54
P02-13	0.06931	0.00243	1.25788	0.04354	0.13169	0.00188	0.03851	0.00076	907.9	70.52	827	19.58	797.5	10.68	763.8	14.71	201.09	234.36	0.86
P02-14	0.06444	0.00207	0.64928	0.02072	0.07311	0.00099	0.02232	0.00036	756.2	66.5	508	12.76	454.8	5.95	446.1	7.07	584.44	556.9	1.05
P02-15	0.0588	0.00402	0.63247	0.04238	0.07805	0.0015	0.0247	0.00095	559.6	142.41	497.6	26.36	484.5	8.99	493.1	18.75	74.22	129.85	0.57
P02-16	0.40839	0.00513	11.89931	0.15882	0.21141	0.00252	0.40718	0.00428	3940.3	18.7	2596.5	12.5	1236.3	13.42	6904.2	61.43	667.32	1504.76	0.44
P02-17	0.07184	0.00193	0.72433	0.01937	0.07315	0.00095	0.03052	0.00059	981.5	53.71	553.2	11.4	455.1	5.7	607.7	11.53	214.06	636.09	0.34
P02-18	0.14595	0.00273	7.37217	0.14017	0.36649	0.00472	0.09836	0.00154	2299	31.82	2157.6	17	2012.9	22.26	1896.3	28.31	126.09	162.42	0.78
P02-19	0.0537	0.00325	0.52414	0.03117	0.07082	0.00123	0.01988	0.0007	358.5	130.52	427.9	20.77	441.1	7.38	398	13.78	79.91	149.33	0.54
P02-20	0.05858	0.00552	0.66521	0.06145	0.08239	0.00194	0.02096	0.00127	551.5	193.37	517.8	37.47	510.4	11.58	419.3	25.23	27.18	49.53	0.55
P02-21	0.07528	0.00168	1.91246	0.0431	0.18432	0.00231	0.05036	0.00124	1076.1	44.2	1085.4	15.03	1090.6	12.58	993.1	23.83	71.48	349.58	0.20
P02-22	0.16192	0.00286	10.23195	0.18519	0.45849	0.00589	0.12146	0.0017	2475.8	29.55	2456	16.74	2432.9	26.01	2316.9	30.64	143.25	131.82	1.09
P02-23	0.05447	0.00214	0.53445	0.02073	0.07119	0.001	0.0213	0.00057	390.5	84.97	434.8	13.71	443.3	6.04	425.9	11.29	124.88	327.23	0.38
P02-24	0.06783	0.00321	1.35221	0.06282	0.14465	0.00237	0.04534	0.00121	863.2	95.14	868.5	27.12	870.9	13.34	896.3	23.44	67.45	93.35	0.72
P02-25	0.05788	0.00245	0.57397	0.02396	0.07195	0.00106	0.02148	0.00057	525	90.46	460.6	15.45	447.9	6.37	429.6	11.31	128.12	268.66	0.48
P02-26	0.07484	0.00189	1.64827	0.04166	0.15979	0.00206	0.04283	0.00069	1064.3	49.99	988.9	15.97	955.6	11.46	847.8	13.32	236.93	290.7	0.82
P02-27	0.05707	0.00286	0.62748	0.03095	0.07977	0.00127	0.02277	0.00085	493.7	107.42	494.5	19.31	494.8	7.59	455.1	16.86	73.25	202.47	0.36
P02-28	0.07211	0.00258	1.72293	0.06092	0.17336	0.00253	0.05002	0.00087	989	71.2	1017.1	22.72	1030.6	13.88	986.4	16.74	232.71	178.41	1.30
P02-29	0.07158	0.00203	1.64245	0.04638	0.16647	0.00222	0.04706	0.00084	974.2	56.79	986.7	17.82	992.7	12.25	929.5	16.27	206.97	284.79	0.73
P02-30	0.0644	0.00252	1.18124	0.04553	0.13309	0.00196	0.03614	0.00063	754.7	80.37	791.9	21.2	805.5	11.14	717.6	12.29	275.47	187.37	1.47
P02-31	0.05612	0.00214	0.56852	0.02143	0.0735	0.00104	0.02238	0.00055	456.7	82.16	457.1	13.87	457.2	6.22	447.3	10.93	179.37	397.33	0.45
P02-32	0.0525	0.00297	0.50887	0.02834	0.07032	0.00116	0.02026	0.00054	307.4	123.7	417.7	19.07	438.1	7	405.5	10.64	159.46	188.5	0.85
P02-33	0.31284	0.00437	8.36895	0.12117	0.1941	0.00237	0.1655	0.00185	3535	21.38	2271.8	13.13	1143.5	12.79	3095.6	32.07	638.26	746.45	0.86
P02-34	0.06888	0.00168	1.44563	0.03544	0.15229	0.00193	0.04031	0.00131	895	49.63	908.1	14.72	913.8	10.8	798.9	25.54	47.72	372.85	0.13
P02-35	0.10637	0.00232	2.37668	0.05185	0.16211	0.00208	0.15129	0.00309	1738.2	39.35	1235.6	15.59	968.5	11.54	2847.6	54.22	41.07	317.24	0.13
P02-36	0.0669	0.00389	1.28019	0.07303	0.13884	0.00255	0.03943	0.00175	834.7	116.83	836.9	32.52	838.1	14.43	781.7	33.98	27.03	67.33	0.40
P02-37	0.14177	0.00226	2.8049	0.046	0.14355	0.00173	0.08494	0.00105	2248.9	27.28	1356.8	12.28	864.7	9.77	1647.8	19.48	408.73	728.25	0.56
P02-38	0.5079	0.00641	8.50243	0.11265	0.12146	0.00145	0.16187	0.0017	4264.3	18.45	2286.2	12.04	739	8.35	3032.4	29.57	1526.05	1649.57	0.93
P02-39	0.09851	0.00194	2.47174	0.04937	0.18205	0.00226	0.08104	0.00137	1596.1	36.4	1263.8	14.44	1078.2	12.33	1575	25.58	137.13	436.02	0.31
P02-40	0.1796	0.00265	5.45002	0.08351	0.22017	0.00265	0.23988	0.00304	2649.2	24.27	1892.8	13.15	1282.8	14.01	4346	49.62	181.38	674.88	0.27
P02-41	0.05962	0.00331	0.62213	0.0339	0.07571	0.00128	0.02495	0.00065	589.8	116.02	491.2	21.22	470.5	7.7	498.1	12.78	120.77	142.38	0.85
P02-42	0.19944	0.00322	5.09426	0.08368	0.18532	0.0023	0.10876	0.00133	2821.6	26.09	1835.2	13.94	1096	12.5	2086.8	24.18	455.64	525.75	0.87
P02-43	0.07113	0.00206	1.58536	0.04562	0.16171	0.00216	0.04897	0.00105	961.1	58.03	964.5	17.92	966.3	11.99	966.3	20.15	94.61	209.27	0.45
P02-44	0.07025	0.00187	1.55411	0.04125	0.1605	0.00209	0.0477	0.0009	935.8	53.6	952.1	16.4	959.5	11.59	941.9	17.42	150.81	292.11	0.52
P02-45	0.06935	0.00239	1.52091	0.05175	0.15911	0.00226	0.04694	0.00078	909.3	69.31	938.8	20.84	951.8	12.55	927.2	14.98	245.54	181.43	1.35
P02-46	0.06888	0.00336	1.35435	0.06481	0.14266	0.00238	0.03792	0.00126	895.1	97.54	869.4	27.95	859.7	13.43	752.3	24.5	49.27	89.44	0.55
P02-47	0.09134	0.00361	2.83393	0.10969	0.22509	0.00366	0.0673	0.00207	1453.7	73.47	1364.6	29.05	1308.7	19.24	1316.5	39.23	61.17	121.67	0.50
P02-48	0.0711	0.00183	1.58469	0.04068	0.1617	0.00208	0.04738	0.00089	960.4	51.61	964.2	15.98	966.2	11.56	935.7	17.26	170.01	351.28	0.48
P02-49	0.09709	0.00194	3.30763	0.06687	0.24716	0.00309	0.06926	0.00111	1569	36.96	1482.9	15.76	1423.8	15.95	1353.5	20.95	192.28	305.32	0.63
P02-50	0.11084	0.00203	3.84872	0.07184	0.25192	0.00311	0.18705	0.00516	1813.2	32.94	1603	15.04	1448.4	16.02	3465.8	87.91	21.54	413.9	0.05
P02-51	0.05527	0.00267	0.53356	0.02543	0.07004	0.00108	0.02068	0.00062	423.1	104.33	434.2	16.84	436.4	6.51	413.8	12.36	94.51	203.59	0.46
P02-52	0.47185	0.00718	7.23518	0.10911	0.11125	0.00143	0.09408	0.00108	4155.6	22.34	2140.8	13.45	680	8.32	1817.3	20.04	624.7	440.6	1.42
P02-53	0.10629	0.00225	4.29936	0.09146	0.29346	0.00376	0.08808	0.00156	1736.8	38.18	1693.2	17.52	1658.8	18.76	1706.2	29.02	88.32	162.99	0.54
P02-54	0.05806	0.00224	0.54659	0.02086	0.0683	0.00097	0.01986	0.00045	531.6	82.92	442.8	13.69	425.9	5.84	397.4	8.83	194.84	293.03	0.66
P02-55	0.07672	0.00164	1.87927	0.04055	0.17772	0.0022	0.0522	0.00094	1113.9	42.09	1073.8	14.3	1054.5	12.04	1028.5	18.02	146	370.75	0.39
P02-56	0.10099	0.0026	4.0051	0.10263	0.28772	0.00392	0.08072	0.00177	1642.4	47.06	1635.2	20.82	1630.1	19.64	1569	33.13	57.47	114.13	0.50
P02-57	0.12692	0.00173	6.66283	0.09645	0.38087	0.00445	0.10439	0.00124	2055.7	23.91	2067.7	12.78	2080.4	20.79	2007	22.62	428.4	519.56	0.82
P02-58	0.38344	0.00546	6.20777	0.08992	0.11746	0.00145	0.12393	0.00141	3845.4	21.32	2005.5	12.67	715.9	8.36	2361.4	25.39	528.64	602.11	0.88
P02-59	0.05372	0.00239	0.52979	0.02327	0.07155	0.00106	0.02075	0.00049	359.2	97.26	431.7	15.45	445.5	6.38	415	9.76	181.38	243.03	0.75
P02-60	0.07246	0.00153	1.64189	0.03495	0.1644	0.00202	0.0461	0.00108	998.8	42.17	986.4	13.43	981.2	11.16	910.9	20.86	75.32	401.48	0.19
P02-61	0.07174	0.00168	1.61962	0.03816	0.16379	0.00206	0.04853	0.00101	978.6	47.1	977.8	14.79	977.8	11.4	957.9	19.51	100.08	320.02	0.31
P02-62	0.06896	0.00157	1.48545	0.03394	0.15628	0.00194	0.04781	0.00082	897.5	46.14	924.5	13.86	936.1	10.82	943.9	15.86	173.51	373.52	0.46
P02-63	0.06003	0.00242	0.61281	0.02431	0.07406	0.00107	0.02359	0.00044	604.6	84.76	485.3	15.31	460.6	6.44	471.3	8.74	269.3	239.4	1.12
P02-64	0.07175	0.00164	1.59449	0.03665	0.16123	0.00201	0.0457	0.00082	978.8	45.91	968.1	14.34	963.6	11.17	903.3	15.9	161.82	349.85	0.46
P02-65	0.27553	0.00327	23.3198	0.30027	0.61402	0.00711	0.15699	0.00175	3337.8	18.43	3240.4	12.54	3086.1	28.4	2947.3	30.58	523.68	456.04	1.15
P02-66	0.30082	0.00491	3.96406	0.06436	0.0956	0.00122	0.10395	0.00129	3474.4	25.06	1626.9	13.16	588.6	7.17	1998.8	23.69	397.31	555.13	0.72
P02-67	0.05468	0.00333	0.56783	0.03406	0.07533	0.00128	0.02768	0.00078	400.1	129.87	456.6	22.06	468.2	7.65	551.9	15.42	107.74	151.79	0.71
P02-68	0.05571	0.00212	0.5535	0.02081	0.07208	0.00101	0.0229	0.00038	440.5	82.54	447.3	13.6	448.7	6.04	457.6	7.57	393.05	302.94	1.30
P02-69	0.14495	0.00205	3.56322	0.05277	0.17834	0.00209	0.10288	0.00121	2287.2	24.17	1541.4	11.74	1057.9	11.46	1979.2	22.2	473.94	812.67	0.58
P02-70	0.234	0.00306	5.69926	0.07847	0.17669	0.00207	0.25705	0.00296	3079.6	20.71	1931.3	11.89	1048.9	11.35	4624	47.65	327.61	956.44	0.34
P02-71	0.07571	0.0022	1.91633	0.05534	0.18362	0.00248	0.05539	0.00086	1087.5	57.25	1086.8	19.27	1086.7	13.49	1089.7	16.51	232.07	172.08	1.35
P02-72	0.06944	0.00169	1.50487	0.03677	0.15721	0.00198	0.04623	0.00092	912	49.42	932.4	14.9	941.3	11.05	913.5	17.74	111.37	283.76	0.39
P02-73	0.22706	0.00396	4.59976	0.07993	0.14697	0.00188	0.16999	0.00238	3031.4	27.67	1749.2	14.49	883.9	10.56	3173.2	41.15	126.57	318.92	0.40
P02-74	0.15906	0.00221	7.5249	0.10989	0.34322	0.00405	0.1127	0.00149	2445.7	23.35	2176	13.09	1902.1	19.42	2158.5	27.08	231.39	422.71	0.55
P02-75	0.40951	0.00516	9.14282	0.12112	0.16197	0.00191	0.21823	0.00241	3944.4	18.77	2352.4	12.13	967.7	10.6	3989.9	40.02	894.6	1175.09	0.76
P02-76	0.05529	0.00283	0.5326	0.02678	0.06988	0.0011	0.02077	0.00064	423.7	109.83	433.5	17.74	435.5	6.64	415.5	12.6	87.53	164.31	0.53
P02-77	0.09668	0.00193	2.10024	0.04227	0.1576	0.00195	0.05797	0.00084	1561	36.99	1148.9	13.84	943.4	10.84	1138.9	16.08	280.86	393.96	0.71
P02-78	0.05661	0.00236	0.57747	0.02371	0.074	0.00107	0.02302	0.00049	475.7	90.19	462.8	15.26	460.2	6.42	460	9.6	188.41	224.29	0.84
P02-79	0.22573	0.00365	2.80186	0.04556	0.09005	0.00111	0.0836	0.00105	3022	25.7	1356	12.17	555.8	6.59	1622.9	19.5	354	549.23	0.64
P02-80	0.06984	0.00182	1.59423	0.04149	0.1656	0.00213	0.04995	0.00092	923.7	52.69	968	16.24	987.8	11.77	985.2	17.71	122.58	218.28	0.56
P02-81	0.10292	0.00232	4.31159	0.09737	0.3039	0.00396	0.09954	0.00177	1677.5	41.11	1695.6	18.61	1710.6	19.57	1917.9	32.51	70.57	116.09	0.61
P02-82	0.05631	0.00222	0.56051	0.02179	0.07221	0.00102	0.0237	0.00045	463.8	85.71	451.9	14.18	449.5	6.14	473.5	8.92	222.45	239.28	0.93
P02-83	0.07026	0.00197	0.77851	0.02166	0.08039	0.00105	0.02872	0.00056	935.9	56.44	584.6	12.36	498.4	6.24	572.3	10.91	187.17	369.54	0.51
P02-84	0.07057	0.00201	1.53235	0.04329	0.15752	0.00208	0.04703	0.0008	945.1	57.16	943.4	17.36	943	11.57	928.9	15.46	178.8	192.51	0.93
样品P57
P57-01	0.09249	0.00208	3.12084	0.06993	0.24481	0.00306	0.06957	0.00117	1477.4	42.11	1437.8	17.23	1411.7	15.83	1359.5	22.07	175.95	276.33	0.64
P57-02	0.05932	0.00251	0.57317	0.02384	0.0701	0.00102	0.02033	0.00042	578.9	89.31	460.1	15.38	436.8	6.12	406.8	8.27	335.45	352.45	0.95
P57-03	0.05705	0.00271	0.55937	0.02616	0.07114	0.00108	0.02115	0.00048	492.7	101.87	451.1	17.03	443	6.5	423.1	9.44	297.7	310.03	0.96
P57-04	0.05672	0.00208	0.54988	0.0199	0.07034	0.00095	0.02153	0.00045	480.1	79.73	444.9	13.04	438.2	5.73	430.6	8.86	312.82	502.67	0.62
P57-05	0.07461	0.00411	0.7389	0.03966	0.07185	0.00128	0.02335	0.00058	1057.8	107.35	561.8	23.16	447.3	7.68	466.5	11.39	224.72	196.66	1.14
P57-06	0.07561	0.00205	2.02619	0.05443	0.19443	0.00251	0.05793	0.00116	1084.8	53.35	1124.3	18.26	1145.3	13.53	1138.3	22.12	129.7	262.75	0.49
P57-07	0.07526	0.00276	1.70528	0.06143	0.16441	0.00238	0.04228	0.00094	1075.4	71.89	1010.5	23.06	981.2	13.18	837	18.3	171.99	199.63	0.86
P57-08	0.07108	0.00168	1.52446	0.03591	0.15562	0.00191	0.04756	0.00096	959.6	47.47	940.3	14.44	932.4	10.63	939.2	18.61	166.34	557.53	0.30
P57-09	0.16946	0.00232	8.48064	0.12097	0.36312	0.00417	0.15132	0.00219	2552.3	22.79	2283.9	12.96	1996.9	19.72	2848.2	38.5	292.95	1298.03	0.23
P57-10	0.05737	0.00302	0.57433	0.02963	0.07263	0.00117	0.02156	0.00057	505.5	112.07	460.8	19.11	452	7.02	431.2	11.2	209.61	260.47	0.80
P57-11	0.07191	0.0016	1.5362	0.03415	0.155	0.00187	0.04315	0.00074	983.4	44.54	945	13.67	929	10.45	853.8	14.41	313.88	687.77	0.46
P57-12	0.0758	0.003	1.99707	0.07772	0.19115	0.00289	0.05396	0.00128	1089.9	77.41	1114.5	26.33	1127.6	15.67	1062.2	24.58	94.81	122.12	0.78
P57-13	0.06999	0.00232	1.58743	0.05194	0.16457	0.00226	0.04785	0.00107	928.1	66.64	965.3	20.38	982.1	12.49	944.7	20.66	123.88	227.56	0.54
P57-14	0.1581	0.00284	9.29854	0.16873	0.42674	0.00533	0.10238	0.00182	2435.5	30.16	2367.9	16.64	2291	24.09	1970.1	33.33	105.12	184.17	0.57
P57-15	0.14186	0.00245	7.33406	0.12846	0.37513	0.00456	0.09925	0.00177	2250	29.55	2153	15.65	2053.5	21.38	1912.6	32.62	121.5	277.12	0.44
P57-16	0.07598	0.00284	1.9343	0.07096	0.18471	0.00272	0.05569	0.00208	1094.6	72.97	1093	24.56	1092.7	14.81	1095.5	39.83	37.38	162.07	0.23
P57-17	0.06992	0.0021	1.5488	0.04608	0.16073	0.00212	0.04515	0.00173	925.9	60.57	950	18.36	960.8	11.79	892.6	33.48	42.36	292.74	0.14
P57-18	0.0539	0.00448	0.54478	0.04444	0.07334	0.00155	0.02512	0.00116	366.6	177.44	441.6	29.21	456.3	9.32	501.4	22.84	58.83	114.02	0.52
P57-19	0.05624	0.00493	0.59532	0.05116	0.0768	0.00171	0.02112	0.0009	461.2	184.23	474.3	32.56	477	10.26	422.3	17.87	80.97	94.85	0.85
P57-20	0.11412	0.0022	4.87805	0.09475	0.31015	0.00381	0.0848	0.00118	1866.1	34.45	1798.5	16.37	1741.5	18.77	1645.2	21.99	241.68	247.85	0.98
P57-21	0.05584	0.00469	0.5653	0.0466	0.07346	0.00157	0.02783	0.00116	445.5	177.05	455	30.23	457	9.41	554.8	22.85	46.44	83.58	0.56
P57-22	0.11298	0.00235	5.36676	0.11191	0.34469	0.00435	0.0896	0.00173	1847.9	37.19	1879.6	17.85	1909.2	20.85	1734.5	32.16	85.89	179.84	0.48
P57-23	0.05594	0.00271	0.54118	0.02579	0.07019	0.00107	0.02133	0.00053	449.8	104.51	439.2	16.99	437.3	6.45	426.6	10.54	165.34	235.25	0.70
P57-24	0.07035	0.00175	1.48333	0.03679	0.153	0.0019	0.04586	0.00133	938.6	50.2	923.6	15.04	917.7	10.64	906.2	25.71	59.2	376.69	0.16
P57-25	0.07049	0.0025	1.5741	0.05509	0.16204	0.00229	0.04499	0.00117	942.7	71.13	960	21.73	968.1	12.71	889.4	22.69	82.67	173.92	0.48
P57-26	0.16108	0.00287	10.15387	0.18295	0.45741	0.00574	0.11601	0.00184	2467.1	29.79	2448.9	16.65	2428.1	25.37	2218.5	33.41	106.4	146.34	0.73
P57-27	0.07236	0.00212	1.64267	0.04773	0.16473	0.00217	0.03619	0.00079	996.1	58.22	986.7	18.34	983	12.01	718.6	15.44	141.52	237.08	0.60
P57-28	0.05816	0.00183	0.60752	0.01891	0.0758	0.00098	0.02323	0.00053	535.1	67.89	482	11.94	471	5.88	464.2	10.48	182.95	508	0.36
P57-29	0.07241	0.00307	1.6065	0.06682	0.161	0.00248	0.04588	0.00098	997.4	83.77	972.7	26.03	962.3	13.78	906.7	18.91	103.5	97.8	1.06
P57-30	0.07075	0.00182	1.53721	0.03939	0.15768	0.00199	0.05893	0.00104	950.1	51.81	945.4	15.76	943.9	11.06	1157.3	19.85	128.68	321.4	0.40
P57-31	0.07064	0.00154	1.53973	0.03364	0.15818	0.00191	0.04593	0.00074	947	43.94	946.4	13.45	946.6	10.62	907.7	14.39	213.81	451.43	0.47
P57-32	0.06043	0.00163	0.80866	0.02171	0.09711	0.00121	0.02618	0.00052	619.1	57.18	601.7	12.19	597.4	7.12	522.3	10.32	202.83	496.24	0.41
P57-33	0.06803	0.00156	1.45085	0.03322	0.15476	0.00188	0.04193	0.00124	869.5	46.66	910.2	13.76	927.6	10.51	830.2	24.04	52.64	433.19	0.12
P57-34	0.08341	0.00144	2.50951	0.04413	0.21833	0.00255	0.06329	0.001	1278.6	33.34	1274.8	12.77	1273.1	13.48	1240.5	18.99	181.44	617.25	0.29
P57-35	0.06696	0.00175	1.45653	0.03787	0.15786	0.00199	0.0374	0.00086	836.4	53.47	912.6	15.65	944.9	11.05	742.2	16.7	113.22	318.57	0.36
P57-36	0.07235	0.00211	1.75702	0.05065	0.17625	0.00232	0.04886	0.00108	995.7	57.69	1029.8	18.65	1046.4	12.72	964.2	20.8	90.56	196.66	0.46
P57-37	0.10721	0.00295	4.6345	0.12584	0.3137	0.00438	0.09119	0.0021	1752.6	49.47	1755.5	22.68	1758.9	21.48	1763.9	38.95	49.54	95.09	0.52
P57-38	0.05706	0.00227	0.5724	0.02246	0.07281	0.00102	0.02076	0.00052	493.1	86	459.6	14.5	453	6.15	415.4	10.26	195.71	377.37	0.52
P57-39	0.16361	0.00381	10.20119	0.23532	0.45249	0.00641	0.12011	0.00177	2493.3	38.72	2453.2	21.33	2406.3	28.45	2292.7	31.86	153.62	81.33	1.89
P57-40	0.07089	0.00295	1.58944	0.06495	0.16272	0.00249	0.04671	0.00128	954.2	82.83	966.1	25.47	971.9	13.79	922.8	24.73	81.42	134.75	0.60
P57-41	0.08057	0.00766	2.14065	0.19835	0.19281	0.00544	0.06329	0.00314	1211	176.51	1162	64.13	1136.6	29.42	1240.3	59.69	17.76	20.1	0.88
P57-42	0.05424	0.00406	0.54026	0.03961	0.07228	0.00144	0.02034	0.00089	381	159.42	438.6	26.11	449.9	8.68	407	17.71	71.9	130.96	0.55
P57-43	0.05645	0.00216	0.60682	0.02293	0.07801	0.00109	0.0217	0.0005	469.5	83.4	481.6	14.49	484.2	6.49	433.8	9.9	292.33	498.4	0.59
P57-44	0.05913	0.0025	0.5918	0.02465	0.07264	0.00106	0.01762	0.00045	571.7	89.55	472	15.72	452.1	6.38	353.1	8.88	188.08	289.63	0.65
P57-45	0.06374	0.00245	1.14716	0.0435	0.13061	0.00187	0.03783	0.0008	733.1	79.49	775.9	20.57	791.4	10.68	750.5	15.59	150.77	191.12	0.79
P57-46	0.05972	0.00372	0.6937	0.04238	0.0843	0.00152	0.0266	0.00075	593.7	129.48	535	25.41	521.7	9.03	530.7	14.84	97.26	109.21	0.89
P57-47	0.08413	0.00266	2.53082	0.07891	0.21833	0.00307	0.06131	0.00106	1295.5	60.39	1280.9	22.69	1273	16.25	1202.6	20.18	128.57	109	1.18
P57-48	0.2586	0.00395	23.04171	0.36147	0.6467	0.00811	0.15951	0.00317	3238.2	23.85	3228.7	15.27	3215.3	31.75	2991.4	55.18	40.53	110.32	0.37
P57-49	0.0598	0.0038	0.58097	0.03614	0.07052	0.00128	0.02061	0.00054	596.2	131.91	465.1	23.21	439.3	7.73	412.3	10.64	155.3	131.23	1.18
P57-50	0.28356	0.00567	23.62074	0.47	0.60461	0.00884	0.30756	0.00517	3382.6	30.84	3252.9	19.38	3048.4	35.52	5420.1	79.85	49.18	61.04	0.81
P57-51	0.07918	0.00165	1.75864	0.03677	0.16121	0.00195	0.04519	0.00066	1176.6	40.62	1030.3	13.53	963.5	10.84	893.3	12.73	255.2	385.29	0.66
P57-52	0.05359	0.00644	0.50309	0.05932	0.06814	0.00186	0.01945	0.00124	353.6	250.83	413.8	40.08	425	11.2	389.3	24.52	31.04	56.2	0.55
P57-53	0.06784	0.00317	0.71719	0.03282	0.07673	0.00122	0.01922	0.00054	863.7	94.1	549	19.41	476.6	7.32	384.8	10.68	233.46	351.4	0.66
P57-54	0.07046	0.00344	0.65053	0.03104	0.06702	0.0011	0.01994	0.00051	941.7	96.99	508.8	19.09	418.2	6.66	399	10.17	319.97	367.01	0.87
P57-55	0.07384	0.00501	1.78534	0.11821	0.1755	0.00372	0.04904	0.00241	1037	131.21	1040.1	43.09	1042.4	20.41	967.6	46.35	26.96	55.28	0.49
P57-56	0.0531	0.00315	0.4883	0.02846	0.06675	0.00114	0.01924	0.00073	333.1	128.53	403.7	19.42	416.5	6.87	385.2	14.54	102.79	247.28	0.42
P57-57	0.09298	0.00719	0.88585	0.0665	0.06916	0.00161	0.01461	0.00106	1487.5	139.85	644.1	35.8	431.1	9.73	293.1	21.21	71.75	97.85	0.73
P57-58	0.04226	0.00324	0.41167	0.03136	0.07071	0.0011	0.01926	0.00046	0.1	0	350.1	22.56	440.4	6.64	385.6	9.09	229.3	260.93	0.88
P57-59	0.23522	0.01065	9.53609	0.40981	0.29429	0.00627	0.25893	0.0056	3087.9	70.49	2391	39.49	1662.9	31.22	4654.2	89.92	32.75	42.16	0.78
P57-60	-0.27587	0.0161	-2.61591	0.1454	0.06883	0.00155	0.0165	0.0007	0.1	0	-NaN	-91.36	429.1	9.32	330.8	14	88.49	88.28	1.00
P57-61	0.13118	0.00259	7.21019	0.14318	0.399	0.0051	0.09873	0.00177	2113.8	34.25	2137.8	17.71	2164.4	23.49	1903	32.61	106.25	179.28	0.59
P57-62	0.05311	0.00331	0.51102	0.03131	0.06985	0.00122	0.01958	0.00057	333.3	134.87	419.1	21.04	435.3	7.34	392	11.37	127.82	152.82	0.84
P57-63	0.09118	0.00349	3.11869	0.11694	0.24828	0.00394	0.07323	0.00237	1450.3	71.26	1437.3	28.83	1429.6	20.34	1428.4	44.64	33.08	78.94	0.42
P57-64	0.08823	0.00205	3.08939	0.07155	0.25419	0.00324	0.07718	0.0015	1387.5	43.8	1430.1	17.76	1460.1	16.64	1502.7	28.2	92.56	234.36	0.39
P57-65	0.06923	0.00191	1.42959	0.0391	0.14991	0.00194	0.04792	0.00371	905.6	55.76	901.4	16.34	900.4	10.87	946.1	71.58	8.14	357.83	0.02
P57-66	0.05642	0.00535	0.54184	0.05031	0.06972	0.00166	0.02222	0.00115	468	197.94	439.6	33.13	434.5	9.99	444.1	22.7	47.23	87.85	0.54
P57-67	0.07898	0.00261	2.11651	0.06879	0.19455	0.00276	0.05317	0.00091	1171.6	63.96	1154.2	22.41	1146	14.9	1047.1	17.53	212.11	169.85	1.25
P57-68	0.06069	0.00556	0.70145	0.06284	0.0839	0.002	0.02115	0.0007	628.4	185.93	539.7	37.5	519.4	11.88	422.9	13.82	117.65	68.1	1.73
P57-69	0.15831	0.00446	9.88901	0.27361	0.45349	0.00712	0.12223	0.00237	2437.7	46.96	2424.5	25.51	2410.7	31.56	2330.9	42.71	70.14	53.78	1.30
P57-70	0.06139	0.00362	0.67718	0.03911	0.08008	0.00142	0.02529	0.00075	653	121.78	525.1	23.68	496.6	8.49	504.9	14.79	93.08	126.96	0.73
P57-71	0.06986	0.00196	1.53612	0.04271	0.15963	0.00208	0.04549	0.00087	924.4	56.54	945	17.1	954.7	11.57	899.1	16.87	168.94	312.65	0.54
P57-72	0.06786	0.00162	0.91865	0.02187	0.09828	0.00121	0.03068	0.0008	864.3	48.69	661.6	11.58	604.3	7.12	610.7	15.64	106.43	702.49	0.15
P57-73	0.07288	0.00174	1.65866	0.03959	0.16523	0.00207	0.0459	0.00127	1010.7	47.4	992.9	15.12	985.8	11.43	907.2	24.55	55.75	328.39	0.17
P57-74	0.0681	0.00322	1.50852	0.07008	0.16083	0.0026	0.04299	0.00219	871.7	95.07	933.8	28.37	961.4	14.45	850.7	42.36	16.91	81.04	0.21
P57-75	0.05338	0.00265	0.54157	0.02649	0.07366	0.00113	0.02363	0.00058	345	108.37	439.5	17.45	458.2	6.79	472.1	11.42	146.33	207.4	0.71
P57-76	0.05498	0.00178	0.56211	0.01805	0.07423	0.00097	0.02021	0.00029	411.5	70.23	452.9	11.73	461.6	5.84	404.4	5.66	746.92	479.42	1.56
P57-77	0.07105	0.0025	1.49111	0.05162	0.15238	0.00216	0.04094	0.0011	958.9	70.19	926.8	21.04	914.3	12.09	811	21.31	63.99	151.59	0.42
P57-78	0.07744	0.00164	1.89675	0.04041	0.17784	0.00217	0.02724	0.00061	1132.6	41.65	1079.9	14.16	1055.2	11.9	543.2	12.08	141.35	387.93	0.36
P57-79	0.05444	0.00243	0.53559	0.02352	0.07143	0.00105	0.01843	0.00059	389.4	96.5	435.5	15.55	444.8	6.35	369.1	11.67	101.65	241.95	0.42
P57-80	0.05665	0.002	0.71193	0.02482	0.09125	0.00124	0.02359	0.00049	477.2	76.85	545.9	14.72	562.9	7.33	471.3	9.74	206.99	320.04	0.65
P57-81	0.07639	0.00387	2.04591	0.1014	0.19447	0.0034	0.05427	0.00161	1105.3	97.98	1130.9	33.8	1145.6	18.35	1068.1	30.83	41.51	55.92	0.74
P57-82	0.07313	0.00452	1.83446	0.11095	0.18215	0.00357	0.05021	0.00226	1017.6	120.41	1057.9	39.74	1078.7	19.49	990.3	43.41	21.05	45.42	0.46
P57-83	0.05516	0.00208	0.54551	0.02031	0.07181	0.001	0.02036	0.00035	418.5	81.74	442.1	13.34	447.1	5.98	407.4	6.95	458.43	414.81	1.11
P57-84	0.07766	0.00253	2.17624	0.06986	0.2035	0.00287	0.05157	0.00112	1138.1	63.43	1173.5	22.33	1194.1	15.39	1016.4	21.56	96.15	136.56	0.70

下载: 导出CSV

表 2 花岗岩LA-ICP-MS锆石U-Th-Pb同位素分析结果

Table 2. LA-ICP-MS U-Th-Pb data of granite zircons

样点编号	同位素比值								年龄/Ma								Th/10^-6	U/10^-6	Th/U
样点编号	Pb²⁰⁷/Pb²⁰⁶	±σ	Pb²⁰⁷/U²³⁵	±σ	Pb²⁰⁶/U²³⁸	±σ	Pb²⁰⁸/Th²³²	±σ	Pb²⁰⁷/Pb²⁰⁶	±σ	Pb²⁰⁷/U²³⁵	±σ	Pb²⁰⁶/U²³⁸	±σ	Pb²⁰⁸/Th²³²	±σ	Th/10^-6	U/10^-6	Th/U
样品P34
P3401	0.0581	0.00382	0.58718	0.03796	0.07322	0.00129	0.02038	0.00085	532.9	138.44	469.1	24.28	455.5	7.74	407.8	16.83	33.66	76.1	0.44
P3402	0.0525	0.0043	0.50038	0.04041	0.06905	0.0013	0.02528	0.00102	307.1	175.94	412	27.35	430.4	7.84	504.6	20.01	32.9	73.57	0.45
P3403	0.05491	0.00356	0.51168	0.03258	0.06751	0.00116	0.02048	0.00075	408.4	138.82	419.6	21.89	421.2	7.03	409.7	14.85	52.22	107.2	0.49
P3404	0.05536	0.00464	0.51046	0.0421	0.06681	0.00133	0.018	0.00121	426.4	177.14	418.8	28.3	416.9	8.05	360.5	23.98	32.98	76.73	0.43
P3405	0.05518	0.00378	0.52967	0.03562	0.06955	0.00124	0.01978	0.00083	419.2	146.13	431.6	23.64	433.5	7.49	395.9	16.52	51.89	104.38	0.50
P3406	0.05316	0.00372	0.51828	0.03563	0.07065	0.00126	0.02041	0.00085	335.5	150.47	424	23.83	440.1	7.56	408.5	16.91	46.84	105.42	0.44
P3407	0.05363	0.00265	0.50368	0.02451	0.06806	0.00102	0.02003	0.00053	355.5	107.27	414.2	16.55	424.5	6.14	400.9	10.42	131.3	208.79	0.63
P3408	0.05594	0.00354	0.54019	0.03359	0.06999	0.0012	0.02131	0.00077	449.5	135.08	438.6	22.15	436.1	7.23	426.3	15.33	61.48	126.45	0.49
P3409	0.05328	0.00366	0.49245	0.03321	0.06699	0.00119	0.01867	0.00084	340.7	147.69	406.6	22.59	418	7.21	373.8	16.73	51.42	112.57	0.46
P3410	0.05357	0.00326	0.52209	0.03127	0.07064	0.00117	0.02269	0.00073	352.8	131.42	426.5	20.86	440	7.04	453.4	14.35	75.69	141.25	0.54
P3411	0.06199	0.00573	0.62033	0.05628	0.07254	0.0016	0.02509	0.00151	673.7	186.13	490.1	35.27	451.4	9.6	500.8	29.68	23.54	61.03	0.39
P3412	0.05553	0.00496	0.56036	0.04918	0.07315	0.00157	0.019	0.00115	433.4	187.87	451.8	32	455.1	9.41	380.5	22.83	32.33	66.9	0.48
P3413	0.05465	0.00346	0.49943	0.03105	0.06626	0.00115	0.01716	0.00055	398.1	135.46	411.3	21.03	413.6	6.94	343.8	11.01	114.08	146.09	0.78
P3414	0.05725	0.00335	0.53409	0.03066	0.06764	0.00114	0.0186	0.00062	500.8	124.33	434.5	20.29	421.9	6.86	372.5	12.36	84.25	137.61	0.61
P3415	0.0585	0.00513	0.55786	0.04803	0.06915	0.00148	0.02095	0.00122	548.6	180.85	450.1	31.31	431.1	8.93	419	24.17	35.86	77.26	0.46
P3416	0.0555	0.00371	0.52282	0.03436	0.06832	0.00122	0.02041	0.00079	432	142.83	427	22.91	426	7.38	408.4	15.63	69.19	136.84	0.51
P3417	0.05604	0.00455	0.54808	0.04372	0.07093	0.00142	0.0258	0.00132	453.6	171.1	443.7	28.67	441.8	8.57	514.8	26.04	31.19	88.37	0.35
P3418	0.05341	0.00449	0.49098	0.04061	0.06668	0.00134	0.01854	0.00092	346.1	179.61	405.6	27.66	416.1	8.12	371.4	18.33	39.86	93.52	0.43
P3419	0.05235	0.00379	0.53161	0.03781	0.07367	0.00139	0.02189	0.00108	300.7	156.87	432.9	25.07	458.2	8.33	437.8	21.42	45.67	104.02	0.44
P3420	0.05377	0.00469	0.51365	0.04397	0.0693	0.00148	0.01704	0.00126	361.2	185.68	420.9	29.5	432	8.91	341.6	25.07	29.53	75.88	0.39
P3421	0.05765	0.00408	0.54497	0.03787	0.06858	0.00129	0.02115	0.00112	516.2	148.69	441.7	24.89	427.6	7.8	423.1	22.11	36.33	109.21	0.33
P3422	0.07024	0.00415	0.71372	0.04119	0.07372	0.00134	0.02535	0.00103	935.4	116.71	547	24.41	458.6	8.02	505.9	20.32	47.18	107.67	0.44
P3423	0.05258	0.00424	0.51217	0.0407	0.07068	0.00136	0.02256	0.00101	310.6	173.31	419.9	27.33	440.3	8.19	450.8	19.97	46.21	92.9	0.50
P3424	0.06331	0.00486	0.59008	0.04439	0.06764	0.00137	0.02676	0.00118	718.5	155.12	470.9	28.35	421.9	8.3	533.7	23.22	35.56	80.97	0.44

下载: 导出CSV

参考文献(66)

[1]	Wu H Q, Feng Y M, Song S G. Metamorphism and deformation of blueschist belts and their tectonic implications, north Qilian Mountains, China[J]. Journal of Metamorphic Geology, 1993, 11(4):523-536.
[2]	冯益民, 何世平.祁连山大地构造与造山作用[M].北京:地质出版社, 1996:1-135.
[3]	左国朝, 吴汉泉.北祁连中段早古生代双向俯冲-碰撞造山模式剖析[J].地球科学进展, 1997, 12(4):315-323. http://www.adearth.ac.cn/CN/10.11867/j.issn.1001-8166.1997.04.0315
[4]	葛肖虹, 刘俊来.北祁连造山带的形成与背景[J].地学前缘, 1999, 6(4):223-230. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy199904004
[5]	张旗, 王焰, 钱青.北祁连早古生代洋盆是裂陷槽还是大洋盆——与葛肖虹讨论[J].地质科学, 2000, 35(1):121-128. https://www.wenkuxiazai.com/doc/3fd5b366700abb68a882fb77-3.html
[6]	杜远生, 张哲, 周道华, 等.北祁连-河西走廊志留纪和泥盆纪古地理及其同造山过程的沉积响应[J].古地理学报, 2002, 4(4):1-8. http://edu.wanfangdata.com.cn/Periodical/Detail/gdlxb200204001
[7]	杜远生, 朱杰, 韩欣, 等.从弧后盆地到前陆盆地-北祁连造山带奥陶纪-泥盆纪的沉积盆地和构造演化[J].地质通报, 2004, 23(9/10):911-917. http://dzhtb.cgs.cn/ch/reader/view_abstract.aspx?file_no=200409163&flag=1
[8]	Xia L Q, Xia Z C, Xu X. Magmagenesis in the Ordovician Backarc Basins of the North Qilian Mountains, China[J]. Geological Society of America Bulletin, 2003, 115(12):1510-1522. doi: 10.1130/B25269.1
[9]	Zhang J X, Meng F C, Wan Y S. A cold early Palaeozoic subduction zone in the North Qilian Mountains, NW China:Petrological and U-Pb geochronological constraints[J]. Journal Metamorphic Geology, 2007, 25(3):285-304. doi: 10.1111/jmg.2007.25.issue-3
[10]	Song S G, Zhang L F, Niu Y L, et al. Zircon U-Pb SHRIMP ages of eclogites from the North Qilian Mountains in NW China and their tectonic implication[J]. Chinese Science Bulletin, 2004, 49(8):848-852. doi: 10.1007/BF02889759
[11]	Song S G, Zhang L F, Niu Y L, et al. Eclogite and carpholitebearing metasedimentary rocks in the North Qilian suture zone, NW China:Implications for Early Palaeozoic cold oceanic subduction and water transport into mantle[J]. Journal of Metamorphic Geology, 2007, 25(5):547-563. doi: 10.1111/jmg.2007.25.issue-5
[12]	Song S G, Niu Y, Zhang L F, et al. Tectonic evolution of Early Paleozoic HP metamorphic rocks in the North Qilian Mountains, NW China:New perspectives[J]. Journal of Asian Earth Sciences, 2009, 35(3/4):334-353. https://www.sciencedirect.com/science/article/pii/S136791200800182X
[13]	Song S G, Niu Y L, Su L, et al. Tectonics of the North Qilian orogen, NW China[J]. Gondwana Research, 2013, 23:1378-1401. doi: 10.1016/j.gr.2012.02.004
[14]	Song S G, Niu Y, Su Li, et al. Continental orogenesis from ocean subduction, continent collision/subduction, to orogen collapse, and orogen recycling:The example of the North Qaidam UHPM belt, NW China[J]. Earth-Science Reviews, 2014, 129:59-84. doi: 10.1016/j.earscirev.2013.11.010
[15]	Yang J H, Du Y S, Cawood P A, et al. Silurian collisional suturing onto the southern margin of the North China Craton:Detrital zircon geochronology constraints from the Qilian orogen[J]. Sedimentary Geology, 2009, 220(1/2):95-104.
[16]	Xu Y J, Du Y S, Cawood P A, et al. Detrital zircon record of continental collision:Assembly of the Qilian Orogen, China[J]. Sedi-mentary Geology, 2010, 230(1/2):35-45. https://www.sciencedirect.com/science/article/pii/S0037073810001636
[17]	徐亚军, 杜远生, 杨江海.北祁连造山带晚奥陶世-泥盆纪构造演化:碎屑锆石年代学证据[J].地球科学——中国地质大学学报, 2013, 38(5):934-946. http://www.earth-science.net/PDF/20131224103440.pdf
[18]	解广轰, 汪缉安.祁连山的下古生代地质[J].地质科学, 1959, 2(4):104-108. http://www.cqvip.com/QK/90050X/201604/669848882.html
[19]	青海省地质矿产局.青海省岩石地层[M].武汉:中国地质大学出版社, 1997:1-340.
[20]	夏林圻, 李向民, 余吉远, 等.祁连山新元古代中-晚期至早古生代火山作用与构造演化[J].中国地质, 2016, 43(4):1087-1138. http://www.cqvip.com/QK/90050X/201604/669848882.html
[21]	Van Achterbergh E, Ryan et al. Data reduction software for LAICP-MS[C]//Sylvester P J. Laser-Ablation-ICPMS in the Earth Sciences. Principles and Applications. Mineralogical Society of Can-ada Short Course Series 29, 2011: 239-243.
[22]	李艳广, 汪双双, 刘民武, 等.斜锆石LA-ICP-MS U-Pb定年方法及应用[J].地质学报, 2015, 89(12):2400-2418. doi: 10.3969/j.issn.0001-5717.2015.12.015
[23]	Ludwig, K R. ISOPLOT 3.00:A Geochronological Toolkit for Microsoft Excel[J]. Berkeley Geochronology Center, California. 2003. https://searchworks.stanford.edu/view/6739593
[24]	吴元保, 郑永飞.锆石成因矿物学研究及其对U-Pb年龄解释的制约[J].科学通报, 2004, 49(16):1589-1604. doi: 10.3321/j.issn:0023-074X.2004.16.002
[25]	Cawood P A, Nemchin A A. Provenance record of a rift basin:U/Pb ages of detrital zircons from the Perth basin, Western Australia[J]. Sedimentary Geology, 2000, 134:209-234. doi: 10.1016/S0037-0738(00)00044-0
[26]	Cawood P A, Nemchin A A. Paleogeographic development of the east Laurentian margin:Constraints from U-Pb dating of detrital zircons in the Newfoundland Appalachians[J]. Geological Society of Americal Bulletin, 2001, 113:1234-1246. doi: 10.1130/0016-7606(2001)113<1234:PDOTEL>2.0.CO;2
[27]	Cawood P A, Nemchin A A, Smith M, et al. Source of the Dalradian Supergroup constrained by U-Pb dating of detrital zircons and implications for the East Laurentian margin[J]. Journal of the Geo-logical Society, London, 2003, 160:231-246. doi: 10.1144/0016-764902-039
[28]	Cawood P A, Nemchin A A, Strachan R A, et al. Laurentian provenance and an intracratonic setting for the Moine Supergroup, Scotland, constrained by detrital zircons from the Loch Eil and Glen Urquhart successions[J]. Journal of the Geological Society, 2004, 161(5):861-874. doi: 10.1144/16-764903-117
[29]	修群业, 于海峰, 李铨, 等.龙首山岩群成岩时代探讨[J].地质学报, 2004, 78:366-373. doi: 10.3321/j.issn:0001-5717.2004.03.010
[30]	宁夏地质矿产局.宁夏区域地质志[M].北京:地质出版社, 1990.
[31]	夏林圻, 夏祖春, 彭礼贵, 等.北祁连山石灰沟奥陶纪岛弧火山岩系岩浆性质的确定[J].岩石矿物学杂志, 1991, 10(1):1-10. http://www.oalib.com/paper/4338956
[32]	夏林圻, 夏祖春, 徐学义.北祁连山构造-火山岩浆演化动力学[J].西北地质科学, 1995, 16(1):1-28. http://www.cqvip.com/QK/95212A/199501/1916616.html
[33]	夏林圻, 夏祖春, 徐学义.北祁连山海相火山岩岩石成因[M].北京:地质出版社, 1996.
[34]	夏林圻, 夏祖春, 任有祥, 等.祁连山及邻区火山作用与成矿[M].北京:地质出版社, 1998.
[35]	夏林圻, 夏祖春, 徐学义.北祁连山早古生代洋脊洋岛和弧后盆地火山作用[J].地质学报, 1998, 72(4):301-312. http://www.oalib.com/paper/4877497
[36]	李猛, 王超, 李荣社, 等.北祁连肃南地区阴沟群形成时代及沉积源区讨论——碎屑锆石U-Pb年龄证据[J].中国地质, 2015, 42(3):601-615. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=zgdizhi201503015
[37]	Xia L Q, Xia Z C, Xu X Y. Magmagenesis in the Ordovician backarc basins of the Northern Qilian Mountains, China[J]. Geol. Soc. Am. Bull., 2003, 115, 1510-1522. doi: 10.1130/B25269.1
[38]	夏林圻, 夏祖春, 任有祥, 等.北祁连山构造-火山岩浆-成矿动力学[M].北京:中国大地出版社, 2001.
[39]	李怀坤, 陆松年, 王惠初, 等.青海柴北缘新元古代超大陆裂解的地质记录——全吉群[J].地质调查与研究, 2003, 26(1):27-37. http://www.docin.com/p-25259683.html
[40]	徐学义, 王洪亮, 陈隽璐, 等.中祁连东段兴隆山群基性火山岩错石U-Pb定年及岩石成因研究[J].岩石学报, 2008, 24(4):827-840. http://www.cnki.com.cn/Article/CJFDTOTAL-XBDI201104004.htm
[41]	Mao J W, Zhang Z C, Yang J M. Dating of single-grain zircon for Precambrican strata in western part of from North Qilian Mountains[J]. Chinese Science Bulletin, 1997, 42:1414-1417. https://link.springer.com/article/10.1007/BF02884144
[42]	夏小洪, 孙楠, 宋述光, 等.北祁连西段熬油沟二只哈拉达坂蛇绿岩的形成环境和时代[J].北京大学学报(自然科学版), 2012, 48(5):757-769. http://d.wanfangdata.com.cn/Periodical_bjdxxb201205009.aspx
[43]	Xia L Q, Xia Z C, Zhao J T, et al. Determination of properties of Proterozoic continental flood basalts of western part from North Qilian Mountains[J]. Science in China:Earth Sciences, 1999, 42:506-514. https://link.springer.com/article/10.1007/BF02875244
[44]	万渝生, 许志琴, 杨经绥.祁连山带及邻区前寒武纪深变质基底的时代和组成[J].地质学报, 2001, 75:375-384. http://www.oalib.com/paper/4876805
[45]	郭进京, 赵凤清, 李怀坤.中祁连东段晋宁期碰撞型花岗岩及其地质意义[J].地球学报, 1999, 20:10-15. doi: 10.3321/j.issn:1006-3021.1999.01.002
[46]	李兆, 陈岳龙, 刘长征, 等.北祁连的形成与演化历史:来自河流沉积物地球化学及其碎屑锆石U-Pb年龄、Hf同位素组成的证据[J].地质学报, 2016, 90(2):267-283. http://www.oalib.com/paper/4875049
[47]	Gehrels G E, Yin A, Wang X F. Detrital zircon geochronology of the northeastern Tibetan Plateau[J]. GSA Bulletin, 2003, 115(7):881-896. doi: 10.1130/0016-7606(2003)115<0881:DGOTNT>2.0.CO;2
[48]	Tseng C Y, Hong Y Y, Wan Y S, et al. Finding of Neoproterozoic (~775Ma) magmatism recorded in metamorphic complexes from the North Qilian Orogen:Evidence from SHRIMP zircon U-Pb dating[J]. Chinese Science Bulletin, 2006, 51(8):963-970. doi: 10.1007/s11434-006-0963-1
[49]	Tung K A, Yang H J, Yang H Y, et al. SHRIMP U-Pbgeochronology of the zircons from the Precambrian basement of the Qilian Block and its geological significances[J]. Chinese Science Bulletin, 2007, 52(19):2687-2701. doi: 10.1007/s11434-007-0356-0
[50]	Xu W C, Zhang H F, Liu X M. U-Pb zircon dating constraints on formation time of Qilian high-grade metamorphic rock and its tectonic implications[J]. Chinese Science Bulletin, 2007, 52(4):531-538. doi: 10.1007/s11434-007-0082-7
[51]	李怀坤, 陆松年, 相振群, 等.北祁连山西段北大河岩群碎屑锆石SHRIMP U-Pb年代学研究[J].地质论评, 2007, 53(1):132-140. http://www.cnki.com.cn/Article/CJFDTOTAL-XBDI201404021.htm
[52]	王洪亮, 何世平, 陈隽璐, 等.甘肃马衔山花岗岩杂岩体LA-ICPMS锆石U-Pb测年及其构造意义[J].地质学报, 2007, 1(1):72-78. http://www.oalib.com/paper/4874042
[53]	Lu S N, Yang C L, Li H K, et al. A group of rifting events in the terminal Paleoproterozoic in the North China Craton[J]. Gondwana Research, 2002, 5(1):123-131. doi: 10.1016/S1342-937X(05)70896-0
[54]	陆松年, 杨春亮, 李怀坤, 等.华北古大陆与哥伦比亚超大陆[J].地学前缘, 2002, 9(4):225-233. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=dxqy200204002
[55]	赵国春, 孙敏, Wilde S A.早-中元古代Columbia超级大陆研究进展[J].科学通报, 2002, 47(18):1361-1364. doi: 10.3321/j.issn:0023-074X.2002.18.001
[56]	赵国春.华北克拉通基底主要构造单元变质作用演化及其若干问题讨论[J].岩石学报, 2009, 25(8):1772-1792. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=ysxb98200908004
[57]	翟明国, 彭澎.华北克拉通古元古代构造事件[J].岩石学报, 2007, 23(11):2665-2682. doi: 10.3969/j.issn.1000-0569.2007.11.001
[58]	Guo J H, Sun M, Chen F K, et al. Sm-Nd and SHRIMP U-Pb zircon geochronology of high-pressure granulite in the anggan area, North China Craton:Timing of Paleoproterozoic continental collision[J]. Journal of Asian Earth Science, 2005, 24(5):629-642. doi: 10.1016/j.jseaes.2004.01.017
[59]	张招崇, 毛景文, 左国朝, 等.北祁连山西段早元古代变质火山岩的地球化学特征及其构造背景[J].矿物岩石, 1998, 18(4):22-30. http://www.cqvip.com/QK/94361X/199804/3290885.html
[60]	刘建栋, 王春涛, 李五福, 等.北祁连浪士当地区元古代基底地质特征及时代讨论[J].甘肃冶金, 2015, 37(4):96-102. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=gsyj201504025
[61]	Hou G T, Liu Y, Li J. Evidence for~1.8 extension of the eastern block of the North China Craton from SHRIMP U-Pb dating of mafic dyke swarms in Shandong Province[J]. Journal of Asian Earth Science, 2006, 27(4):392-401. doi: 10.1016/j.jseaes.2005.05.001
[62]	Wan Y S, Song B, Liu D Y, et al. SHRIMP U-Pb zircon geochronology of Palaeoproterozoic metasedimentary rocks in the North China Craton:Evidence for a major late Palaeoproterozoic tectonothermal event[J]. Precambrian Research, 2006, 149(3/4):249-271. https://www.sciencedirect.com/science/article/pii/S0301926806001471
[63]	Wan Y S, Wilde S A, Liu D Y, et al. Further evidence for~1.85 Ga metamorphism in the central zone of the North China Craton:SHRIMP U-Pb dating of zircon from metamorphic rocks in the Lushan Area, Henan Province[J]. Gondwana Research, 2006, 9(1/2):189-197. https://www.sciencedirect.com/science/article/pii/S1342937X05000171
[64]	Tung K A, Yang H Y, Liu D Y, et al. SHRIMP U-Pb geochronology of the detrital zircons from the Longshoushan Group and its tectonic significance[J]. Chinese Science Bulletin, 2007, 52(10):1414-1425. doi: 10.1007/s11434-007-0189-x
[65]	Zhao G C, Kroner A, Wilde S A, et al. Lithotectonic elements and geological events in the Hengshan-Wutai-Fuping Belt:A synthesis and implications for the evolution of the trans-North China Orogen[J]. Geological Magazine, 2007, 144(5):753-775.
[66]	Zhao G C, Wilde S A, Sun M, et al. SHRIMP U-Pb zircon ages of granitoid rocks in the Lüliang Complex:Implication for the accrection and evolution of the transnorth China orogen[J]. Precambrian Research, 2008, 160(3/4):213-226. https://www.sciencedirect.com/science/article/pii/S0301926811001410
