围压下裂隙对地震波速度影响的物理实验研究

赵卫华; 王红才; 魏建新; 孙东生; 李阿伟

围压下裂隙对地震波速度影响的物理实验研究

1.
中国地质科学院地质力学研究所, 北京 100081

2.
国土资源部新构造与地质灾害重点实验室, 北京 100081

3.
中国石油大学(北京)CNPC重点实验室, 北京 102249

基金项目:
中国地质调查局地质调查项目“特殊地质地貌区填图试点”（DD20160060）

详细信息

作者简介: 赵卫华(1984-), 男, 硕士, 主要从事岩石物理学、岩石力学及地应力等研究工作。E-mail:weihuazhao@163.com

中图分类号: P315.3

收稿日期: 2016-06-20

刊出日期: 2016-12-25

STUDY ON SEISMIC PROPERTY OF CRACK-INCLUDED PHYSICAL MODEL

1.
Institute of Geomechanics, CAGS, Beijing 100081, China

2.
Key Laboratory of Neotectonic Movement and Geohazard, Ministry of Land and Resources, Beijing 100081, China

3.
CNPC Key Lab of Geophysical Prospecting, China University of Petroleum, Changping District, Beijing, 102249, China

Received Date: 20 June 2016

Publish Date: 25 December 2016

摘要

摘要:
构建了等直径不同裂隙密度和等裂隙密度不同裂隙直径两组物理模型，进行不同围压条件下多方向的超声波速度测试，并运用Hudson理论进行了理论模型计算。结果显示，计算与实测结果吻合较好。随围压的增大，纵、横波速度均近线性增加，纵、横波各向异性基本保持不变；裂隙密度从2%增大到6%，纵波速度不同程度降低，其中慢纵波降低幅度相对较大，快横波变化不明显，而慢横波则大幅降低。随着裂隙密度的增大，纵、横波各向异性均增大，且横波各向异性增加速率大于纵波；裂隙直径从2 mm增大到3 mm，快纵波速度增加很小，慢纵波增加明显，横波速度均不发生改变。随着裂隙直径的增大，纵波各向异性逐渐降低，横波各向异性保持不变。最后结合试验结果分析了Hudson理论在不同深度进行参数预测的必要条件。研究结果有助于油气生产、地下水的开采与控制、污染处理等。
- 裂隙 /
- Hudson理论 /
- 物理模型 /
- 波速 /
- 围压
Abstract:
It is very helpful in petroleum production, groundwater exploration and to disposal of pollution to investigate the seismic property of the crustal rocks included cracks or fractures. Two group physical models with the same diameter varying crack density and the same density varying diameters were constructed. The seismic velocities were measured under different confining pressure and calculated by numerical simulation based on Hudson theory. The calculated and measured results show that the V_p and V_s nearly increase linearity and there anisotropy keep nearly stable constant with confining pressure. V_p circles decrease with the crack density varying from 2% to 6%. Moreover, the slow V_p decrease more amplitude than the fast V_p which maintains nearly stable, the V_p and V_s anisotropy all increase with the crack density ranging from 2% to 6%.With the crack diameter varying from 2 mm to 3 mm, the V_p increases, but the V_p anisotropy decreases, V_s and the V_s anisotropy nearly remain constant. Comparing the experimental and the theoretical calculated results, new conclusion of Hudson theory used in different depth was discussed, and the primary constraint of its application were analyzed. It is very helpful in petroleum production, exploration of groundwater and disposal of pollution to investigaste the seismic property of the crustal rocks with cracks or fractures.
- crack /
- Hudson theory /
- rock physical model /
- velocity /
- confining pressure

HTML全文

图 1 样品裂隙分布与XYZ分布示意图

Figure 1.

下载: 全尺寸图片幻灯片

图 2 样品Z04实测纵、横波速度随围压的变化

Figure 2.

下载: 全尺寸图片幻灯片

图 3 样品Z02实测与计算纵、横波速度随围压的变化

Figure 3.

下载: 全尺寸图片幻灯片

图 4 直径2 mm的3种裂隙密度模型纵、横波速度随围压的变化

Figure 4.

下载: 全尺寸图片幻灯片

图 5 直径2 mm的3种裂隙密度模型纵、横波各向异性随围压的变化

Figure 5.

下载: 全尺寸图片幻灯片

图 6 围压25 MPa直径2 mm的3种模型纵、横波各向异性随裂隙密度的变化

Figure 6.

下载: 全尺寸图片幻灯片

图 7 裂隙密度4%的3种直径模型纵、横波速度随围压的变化

Figure 7.

下载: 全尺寸图片幻灯片

图 8 裂隙密度4%的3种直径模型纵、横波各向异性随围压的变化

Figure 8.

下载: 全尺寸图片幻灯片

图 9 围压25 MPa裂隙密度4%的3种模型纵、横波各向异性随裂隙直径的变化

Figure 9.

下载: 全尺寸图片幻灯片

表 1 样品参数信息

Table 1. Sample parameters

样品编号	直径/mm	高度/mm	裂隙密度/%	裂隙直径/mm	密度/(g·cm^-3)
M0	25.40	37.12	-	-	1.109
M1-1	25.38	47.48	0	-	1.174
Z02X	25.32	43.26	2	2	1.168
Z02Y	25.42	48.82	2	2	1.180
Z02Z	25.42	43.46	2	2	1.174
Z04X	25.42	47.84	4	2	1.176
Z04Y	25.44	47.66	4	2	1.176
Z04Z	25.42	47.52	4	2	1.175
Z06X	25.40	49.42	6	2	1.166
Z06Y	25.42	49.56	6	2	1.178
Z06Z	25.42	47.36	6	2	1.177
Z08X	25.42	45.74	4	2.5	1.169
Z08Y	25.40	47.02	4	2.5	1.176
Z08Z	25.42	48.82	4	2.5	1.171
Z10X	25.42	49.02	4	3	1.173
Z10Y	25.42	48.16	4	3	1.176
Z10Z	25.40	47.74	4	3	1.175

下载: 导出CSV

参考文献(25)

[1]	Crampin S, Evans R, Üçer B, et al. Observations of dilatancy-induced polarization anomalies and earthquake prediction[J]. Nature, 1980, 286:874~877. doi: 10.1038/286874a0
[2]	Crampin S. A review of wave motion in anisotropic and cracked elastic-media[J]. Wave Motion, 1981, (3):343~391.
[3]	Crampin S, Sheila P. A review of shear-wave splitting in the compliant crack-critical anisotropic Earth[J]. Wave Motion, 2005, 41:59~77. doi: 10.1016/j.wavemoti.2004.05.006
[4]	刘恩儒, 曾新吾.裂缝介质的有效弹性常数[J].石油地球物理勘探, 2001, 36(1):37~44. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ200101006.htm LIU En-ru, ZENG Xin-wu. Effective elastic constant of fractured medium[J]. Oil Geophysical Prospecting, 2001, 36(1):37~44. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ200101006.htm
[5]	韩开锋, 曾新吾. Hudson理论中裂隙参数的适用性研究[J].石油物探, 2006, 45(5):435~440. http://www.cnki.com.cn/Article/CJFDTOTAL-SYWT200605001.htm HAN Kai-feng, ZENG Xin-wu. Study of the boundary element method on applicability of fracture parameters in Hudson theory[J]. Geophysical Prospecting for Petroleum, 2006, 45(5):435~440. http://www.cnki.com.cn/Article/CJFDTOTAL-SYWT200605001.htm
[6]	魏建新, 狄帮让.裂隙密度对纵波传播特性影响的实验观测[J].石油地球物理勘探, 2007, 42(5):554~559. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ200705013.htm WEI Jian-xin, DI Bang-rang. Experimentally surveying influence of fractural density on P-wave propagating characters[J]. Oil Geophysical Prospecting, 2007, 42(5):554~559. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ200705013.htm
[7]	魏建新, 狄帮让.裂隙张开度对地震波特性影响的模型研究[J].中国科学(D辑), 2008, (增刊Ⅰ):211~218. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2008S1028.htm WEI Jian-xin, DI Bang-rang. Study on the impact of seismic wave characteristics of crack aspect ratio[J]. Science in China (Series D), 2008, (Supp. I):211~218. http://www.cnki.com.cn/Article/CJFDTOTAL-JDXK2008S1028.htm
[8]	齐宇, 魏建新, 狄帮让, 等.横向各向同性介质纵波方位各向异性物理模型研究[J].石油地球物理勘探, 2009, 44(6):671~674, 689. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ200906005.htm QI Yu, WEI Jian-xin, DI Bang-rang, et al. Compressional wave (P-wave) azimuthal anisotropyphysical model studies in transversally isotropic me-dium[J]. Oil Geophysical Prospecting, 2009, 44(6):671~674, 689. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ200906005.htm
[9]	魏建新, 狄帮让.岩石柱塞样品超声横波速度测试精度分析[J].石油地球物理勘探, 2012, 47(6):918~925. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ201206010.htm WEI Jian-xin, DI Bang-rang. Test accuracy analysis of S-wave velocity on rock core sample[J]. Oil Geophysical Prospecting, 2012, 47(6):918~925. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ201206010.htm
[10]	魏建新, 狄帮让.周期层状介质对纵波速度影响的实验研究[J].石油地球物理勘探, 2010, 45(5):661~666. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ201005010.htm WEI Jian-xin, DI Bang-rang. Experimental research on P-wave velocity of periodic layered media[J]. Oil Geophysical Prospecting, 2010, 45(5):661~666. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ201005010.htm
[11]	尹志恒, 狄帮让, 魏建新, 等.裂缝参数对纵波能量衰减影响的物理模型研究[J].石油地球物理勘探, 2012, 47(5):728~734, 753. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ201205009.htm YIN Zhi-heng, DI Bang-rang, WEI Jian-xin, et al. P-wave attenuation by fracture parameter in physical models[J]. Oil Geophysical Prospecting, 2012, 47(5):728~734, 753. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ201205009.htm
[12]	Hudson J A. Overall properties of a cracked solid[J]. Mathematical Proceedings of the Cambridge Philosophical Society, 1980, 88:371~384. doi: 10.1017/S0305004100057674
[13]	Hudson J A. Wave speeds and attenuation of elastic waves in material containing cracks[J]. Geophysical Journal International, 1981, 64(1):133~150. doi: 10.1111/j.1365-246X.1981.tb02662.x
[14]	Hudson J A. A higher order approximation to the wave propagation constants forcracked solid[J]. Geophysical Journal International, 1986, 87(1):265~274. doi: 10.1111/gji.1986.87.issue-1
[15]	Hudson J A, Liu E, Crampin S. The mechanical properties of materials with interconnected cracks and pores[J]. Geophysical Journal International, 1996, 124(1):105~112. doi: 10.1111/gji.1996.124.issue-1
[16]	Hudson J A, Pointer T, Liu E. Effective medium theories for fluid saturated materials with aligned cracks[J]. Geophysical Prospecting, 2001, 49(5):509~522. doi: 10.1046/j.1365-2478.2001.00272.x
[17]	Hess H. Seismic anisotropy of the uppermost mantle under oceans[J]. Nature, 1964, 203:629~631. doi: 10.1038/203629a0
[18]	Ji S C, Saruwatari K, Mainprice D, et al. Microstructures, petrofabrics and seismic properties of ultrahigh-pressure eclogites from Sulu region, China:Implications for rheology of subducted continental crust and origin of mantle reflections[J]. Tectonophysics, 2003, 370:49~76. doi: 10.1016/S0040-1951(03)00177-X
[19]	杨顶辉, 张中杰, 滕吉文, 等.双相各向异性研究、问题与应用前景[J].地球物理学进展, 2000, 15:7~21. doi: 10.3969/j.issn.1004-2903.2000.02.002 YANG Ding-hui, ZHANG Zhong-jie, TENG Ji-wen, et al. The study of two-phase anisotropy questions and applied prospects[J]. Progress in Geophysics, 2000, 15:7~21. doi: 10.3969/j.issn.1004-2903.2000.02.002
[20]	张中杰, 滕吉文, 陈运泰.地球物理学的回顾与展望[J].地球物理学进展, 2001, (5):345~352. http://www.cnki.com.cn/Article/CJFDTOTAL-DXJZ200105006.htm ZHANG Zhong-jie, TENG Ji-wen, CHEN Yun-tai. Geophysics:The 20^th Century in retrospect and the 21^st Century in prospect[J]. Progress in Geophysics, 2001, (5):345~352. http://www.cnki.com.cn/Article/CJFDTOTAL-DXJZ200105006.htm
[21]	曲寿利, 季玉新, 王鑫, 等.全方位P波属性裂缝检测方法[J].石油地球物理勘探, 2001, 36(4):390~397. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ200104001.htm QU Shou-li, JI Yu-xin, WANG Xin, et al. Seismic method for using full-azimuth P wave attribution to detect fracture[J]. Oil Geophysical Prospecting, 2001, 36(4):390~397. http://www.cnki.com.cn/Article/CJFDTOTAL-SYDQ200104001.htm
[22]	滕吉文, 王光杰, 杨顶辉, 等, 地球各向异性介质中地震波动理论、检测与应用研究[J].地学前缘, 1998, 5(1):83~90. http://www.cnki.com.cn/Article/CJFDTOTAL-DXQY801.012.htm TENG Ji-wen, WANG Guang-jie, YANG Ding-hui, et al. The study for propagation theory of seismic waves, detection technique and application on anisotropic media in the earth's interior[J]. Earth Science Frontiers, 1998, 5(1):83~90. http://www.cnki.com.cn/Article/CJFDTOTAL-DXQY801.012.htm
[23]	Thomsen L. Weak elastic anisotropy[J].Geophysics, 1986, 51:1954~1966. doi: 10.1190/1.1442051
[24]	Thomsen L. Weak anisotropic reflections[C]//Castagna J P, Backus M M. Offset dependent eflectivity. SEG, 1993.
[25]	Thomsen L. Elastic anisotropy due to aligned cracks in porous rock[J]. Geophysical Prospecting, 1995, 43:805~829. doi: 10.1111/gpr.1995.43.issue-6
