COMPLEX FLAC3D THREE DIMENSIONAL GEOLOGICAL MODELING BASED ON MOVING LEAST SQUARES METHOD
-
摘要:
针对岩土力学分析软件FLAC3D建模效率较低的不足之处，在分析FLAC3D建模命令以及网格模型*.FLAC3D文件格式特点的基础上，介绍了空间坐标变换、MLS插值的方法与意义，并提出了新的建模方法，开发了相应的计算机辅助建模程序。该程序直接读取原始数据点，无需借助第三方软件，通过坐标变换、MLS插值，可快速生成具有复杂边界的地质模型，且便于材料参数和应力边界条件参数的赋值，可有效地提高工作效率。
Abstract:FLAC3D is an excellent computer code for rock-soil mechanics numerical simulation, but it performs poor in modeling complex geological body. The features of modeling commands and *FLAC3D type file were elaborated, the space coordinate transformation and MLS interpolation method were introduced in detailed and a new modeling method was proposed and a computer aided modeling program was developed. The input of the program is just original data and does not need the aid of other commercial software. Through coordinate transformation and MLS interpolation, our method can quickly build complex geological model and is convenient to set material parameters and apply the stress boundary conditions, thereby can effectively improve the work efficiency.
-
