LATE CENOZOIC NORMAL FAULTING OF THE QUNGDO'GYANG GRABEN IN THE CENTRAL SEGMENT OF THE CONA-OIGA RIFT, SOUTHEASTERN TIBET
-
摘要:
遥感解译和地表调查结果显示, 位于西藏曲松县境内的邛多江盆地构成了藏南近南北向裂谷带最东端的错那-沃卡裂谷的中段。它是在该区近东西向逆冲构造带停止活动之后, 上地壳沿N108～115°E方向发生引张作用所形成的第四纪半地堑式断陷盆地。控制晚第四纪盆地发育的主边界正断裂带位于盆地西缘, 总体呈NNE走向, 向东倾, 长40 km左右。断裂活动位移测量和年代学测试结果表明, 该边界正断层带在5Ma左右就已开始活动, 总累计垂直位移量至少为2.6～2.8 km, 最小长期平均垂直活动速率约0.5mm/a。末次冰期盛冰期以来, 该断裂平均活动速率的最合理的估计值为1.2 ±0.6 mm/a。
Abstract:The Qungdo'gyang graben in Qusum County, Tibet, belongs to the central segment of the NNE-trending Cona-Oiga (or Cona-Sangri)rift zone, which is the only rift located at the easternmost end of the nearly N-S-trending Yadong-Gulu rift zone in southern Tibet.It is a Quaternary semi-graben downfaulted basin formed by extension of the upper crust occurring in the N108-115°E direction after the nearly E-W-trending thrust zone in the study area ceased its activity.The main boundary normal fault controlling the development of the late Quaternary basin is located at the western margin of the basin.It generally strikes NNE and dips E with a length of ～40 km.Displacement measurements and isotopic dating indicate that:this boundary normal fault began activity at ～5 Ma BP; the total cumulative vertical displacement ranged from 2.6 to 2.8 km; and the minimum long-term average throw rate was ～0.5 mm/a.The most rational estimate of the average throw rate since the last maximum glaciation (MIS2)of the fault is 1.2±0.6 mm/a.
-
Key words:
- Tibet /
- Quaternary /
- Cona-Oiga rift /
- Qungdo'gyang graben /
- normal faulting
-
-
表 1 邛多江盆地晚第四纪沉积物、断层岩的年代学测试结果和断裂带垂直活动速率估算值
Table 1. TL dating of late Quaternary deposits and fault rock in the Qungdo'gyang basin and estimated vertical throw rates of the fault zone
下载: 导出CSV
-
[1] Molnar P, Tapponnier P.Active tectonics of Tibet[J].Journal of Geophysical Research, 1978, 83:5361～ 5375. doi: 10.1029/JB083iB11p05361
[2] Armijo R, Tapponier P, Mercier JL.Quaternary extension in southern Tibet:Field observations and tectonic implications[J]. Journal of Geophysical Research, 1986, 91:13803～ 13872. doi: 10.1029/JB091iB14p13803
[3] Rothery DA and Drury SA.The neotectonics of the Tibetan plateau[J].Tectonics, 1984, 3 (1), 19～ 26. doi: 10.1029/TC003i001p00019
[4] Ni J, York JE.Late Cenozoic tectonics of the Tibetan plateau[J].Journal of Geophysical Research, 1978, 83 (B11), 5377 ～ 5384. doi: 10.1029/JB083iB11p05377
[5] Molnar P, England P, Martinod J.Mantle dynamics, uplift of the Tibet plateau, and the Indian monsoon[J].Review of Geophysics.1993, 31, 357～ 396. doi: 10.1029/93RG02030
[6] Yin A.Mode of Cenozoic east-west extension in Tibet suggesting a common origin of rifts in Asia during the Indo-Asia collision[J].Journal of Geophysical Research, 2000, 105 (B9):21745～ 21759. doi: 10.1029/2000JB900168
[7] Harrison TM, Copeland P, Kidd WS F et al.Raising Tibet[J].Science, 1992, 225:1663～ 1670. http://d.old.wanfangdata.com.cn/Periodical/cdxb201401035
[8] 钟大赉, 丁林.青藏高原的隆起过程及其机制探讨[J].中国科学(D辑), 1996, 26 (4):289～ 295. doi: 10.3321/j.issn:1006-9267.1996.04.001
[9] 李吉均, 文世宣, 张青松, 等.青藏高原隆升的时代、幅度和形式探讨[J].中国科学(B辑), 1979, 9 (6): 608～ 616.
[10] Dewey JF, Shackleton RM, Chang Chengfa et al.The tectonic evolution of the Tibetan Plateau[J].Philosophical Transaction of Royal Society of London, 1988, Series A, 327:379～ 413. http://d.old.wanfangdata.com.cn/Periodical/dxqy200906024
[11] Mercier JL, Armijo R, Tapponier P et al.Change from late Tertiary compression to Quaternary extension in southern Tibet during India-Asia collision[J].Tectonics, 1987:6 (3), 275～ 304. doi: 10.1029/TC006i003p00275
[12] England P, Houseman G.Extension during continental convergence, with application to the Tibetan Plateau[J].Journal of Geophysical Research, 1989, 94:17561～ 17569. doi: 10.1029/JB094iB12p17561
[13] Royden LH, Burchfiel C, King RW et al.Surface deformation and lower crustal flow in eastern Tibet[J].Science, 1997, 276, 788～ 790. doi: 10.1126/science.276.5313.788
[14] 韩同林.西藏活动构造[M].北京:地质出版社, 1987.
[15] 中国科学院青藏高原综合科学考察队(李炳元, 王富葆, 张青松. 等). 西藏第四纪地质[M]. 北京: 科学出版社, 1983.
[16] 尹安.喜马拉雅-青藏高原造山带地质演化[J].地球学报, 2001, 22 (3):193～ 230. doi: 10.3321/j.issn:1006-3021.2001.03.001
[17] Masek, JG., Isacks BL, Fielding EJ, Browaeys J.Rift-flank uplift in Tibet:Evidence for a viscous lower crust[J]. Tectonics, 1994, 13, 659～ 667. doi: 10.1029/94TC00452
[18] Lee J, Whitehouse M J.Onset of mid-crustal extensional flow in southern Tibet:Evidence from U Pb zircon ages[J].Geology, 2007, 35 (1), 45～ 48. doi: 10.1130/G22842A.1
[19] Thiede RC, Arrowsmith JR, Bookhagen B.Dome formation and extension in the Tethyan Himalaya, Leo Pargil, northwest India[J].GSA Bulletin, 2006;118 (5 6) 635～ 650. http://www.wanfangdata.com.cn/details/detail.do?_type=perio&id=JJ027449639
[20] Mahéo G, Leloup PH, Valli F et al.Post 4 M a initiation of normal faulting in southern Tibet[J].Earth and Planetary Science Letters, 2007, 256, 233～ 243. doi: 10.1016/j.epsl.2007.01.029
[21] 吴中海, 吴珍汉, 胡道功.等.青藏铁路唐古拉山-拉萨段全新世控震断裂研究[J].地质通报, 2006, 25 (12):1387～ 1401. doi: 10.3969/j.issn.1671-2552.2006.12.006
[22] 吴中海, 吴珍汉, 胡道功, 等, 西藏当雄-羊八井盆地的第四纪地质与断裂活动研究[J].地质力学学报, 2006, 12(3):305～ 316. doi: 10.3969/j.issn.1006-6616.2006.03.004 http://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20060343&journal_id=dzlxxb
[23] Molnar P, Deng Q.Faulting associated with large earthquakes and the average rate of deformation in Asia[J].J Geophys Res, 1984, 89:6203～ 6228. doi: 10.1029/JB089iB07p06203
[24] Wang Qi, Zheng Pei-zhen, Freymueller J et al.Present-day crustal deformation in China constrained by global positioning system measurements[J].Science, 2001, 294, 574～ 577. doi: 10.1126/science.1063647
[25] Chen, Q, Freymueller JT, Yang Z, et al.Spatially variable extension in southern Tibet based on GPS measurements[J].J. Geophys Res, 2004, 109, B09401. http://cn.bing.com/academic/profile?id=7214fa19d26e7d1d12a1dc093169633a&encoded=0&v=paper_preview&mkt=zh-cn
[26] 西藏自治区科学技术委员会.西藏地震史料汇编[M].拉萨:西藏人民出版社, 1982.
-
