MECHANIC RESPONSE OF A SHALLOW-EMBEDDED AND DOUBLE-ARCH TUNNEL UNDER PARTIAL PRESSURES DURING CONSTRUCTION
-
摘要:
以江西某高速公路一浅埋偏压连拱隧道为背景, 用MARC有限元程序对其出口段进行了动态施工的三维数值模拟。系统研究了塑性区分布和发展、拱顶下沉、正应力与剪应力的集中和转移、中隔墙竖向应力随施工过程的变化规律。研究表明:1.非对称开挖是引起中墙偏压的最关键因素, 初衬和二衬的施作对改善中墙偏压作用不大, 对称开挖才是最有效途径; 2.在浅埋条件下, 拱顶下沉有随埋深增大而增大的趋势, 位移释放在开挖完成、支护之前就已经大部分完成。3.左右洞上台阶开挖后拱顶出现拉应力区, 是易坍方部位, 应超前或及时支护; 4.由于偏压作用, 山脊一侧边墙和中墙墙踵处塑性区更发育, 该侧更易失稳; 5.施工完毕, 隧道两侧边墙附近集中的压应力转移到二衬和仰拱上, 使二者成为应力集中部位, 从而改善了隧道围岩的受力状况。
Abstract:Taking an expressway in Jiangxi province as the engineering background, the behavior of a shallow-embedded and double-arch tunnel with partial-pressure during construction is simulated.Several aspects, such as stress concentration and transfer, plastic zone distribution, vault displacement and change of vertical stress, (σy)of the mid-leading wall with construction are studied systemtically. The study indicates that :1) asymmetrical excavation is the key cause of partial pressure in the mid-leading wall and the construction of the first and second lining can not ameliorate the conditions greatly; 2) under conditions of shallow embedment, vault displacement increases with embedment depth and displacement mainly happens during excavation of tunnel before lining construction; 3)after excavation of the up-bench tunnel, pulling stress concentrates around the top arch and lining should be constructed promptly or beforehand; 4)as a result of partial pressure, when plastic zones around the side-wall and mid-leading wall heel, which are near the mountain ridge, are better developed; and 5) when construction finished, compressive stresses at tunnel side-walls disappear and are transferred to the inverse arch and second lining, making them concentrated by shear stress and normal stress and improving the stability of the tunnel.
-
Key words:
- 3D numerical simulation /
- partial pressure /
- vault displacement /
- plastic zone /
- stress concentration
-
-
[1] 蒋树屏, 胡学兵.云南扁平状大断面公路隧道施工力学响应数值模拟[J].岩土工程学报, 2004, 26 (2):178~182. doi: 10.3321/j.issn:1000-4548.2004.02.004
[2] 杜彬.长梁山隧道水平软弱围岩地段施工效应分析[J].岩石力学与工程学报, 2005, 24 (13):2357~2361. doi: 10.3321/j.issn:1000-6915.2005.13.026
[3] 金丰年, 钱七虎.隧洞开挖的三维有限元计算[J].岩石力学与工程学报, 1996, 15 (3):193~200. doi: 10.3321/j.issn:1000-6915.1996.03.001
[4] 邓建, 朱合华, 丁文其.不等跨连拱隧道施工全过程的有限元模拟[J].岩土力学, 2004, 25 (3):477~480. doi: 10.3969/j.issn.1000-7598.2004.03.031
[5] 丁文其, 王晓形, 李志刚, 等.龙山浅埋大跨度连拱隧道施工方案优化[J].岩石力学与工程学报, 24 (22):4042~4047. doi: 10.3321/j.issn:1000-6915.2005.22.007
[6] 赵玉光, 张焕新, 林志远, 等.双连拱隧道施工力学数值模拟与施工方法比选[J].广西交通科技, 2003, 28(4):25~30. http://d.old.wanfangdata.com.cn/Periodical/gxjtkj200304007
[7] 林刚, 何川.连拱隧道施工全过程地层沉降三维数值模拟[J].公路, 2004 (3):136~140. http://d.old.wanfangdata.com.cn/Periodical/gl200403034
[8] 吴俊强, 刘永华, 李围.浅埋偏压连拱公路隧道施工数值模拟分析[J].公路交通技术, 2005, (4):137~141. doi: 10.3969/j.issn.1009-6477.2005.04.044
[9] 申玉生, 赵玉光.高速公路双连拱隧道的中墙力学特性分析[J].地下空间与工程学报, 2005, 1 (2):200~204. http://d.old.wanfangdata.com.cn/Periodical/dxkj200502009
[10] 申玉生, 赵玉光, 张焕新, 等.双连拱隧道施工过程弹塑性有限元数值分析[J].岩石力学与工程学报, 2004, 23 (增2):4946~4951. http://d.old.wanfangdata.com.cn/Periodical/yslxygcxb2004z2049
[11] 赵阳, 王伟笔, 杨昌能.偏压浅埋连拱隧道施工过程的三维数值模拟[J].中南公路工程, 2005, 30 (2):181~184. doi: 10.3969/j.issn.1674-0610.2005.02.054
[12] 陈火红.MARC有限元实例分析教程[M].北京:机械工业出版社, 2002.
[13] 陈建勋, 欧阳院平, 王明年.公路隧道复合式衬砌结构数值计算及分析[J].中国公路学报, 2006, 19 (2):74~79. doi: 10.3321/j.issn:1001-7372.2006.02.013
[14] 吴波, 高波, 索晓明, 等.城市地铁小间距隧道施工性态的力学模拟与分析[J].中国公路学报, 2005, 18 (3):84~89. doi: 10.3321/j.issn:1001-7372.2005.03.017
[15] 吴满路, 廖椿庭.大茅隧道地应力测量及围岩体稳定性研究[J].地质力学学报, 2000, 6 (2):71~76. doi: 10.3969/j.issn.1006-6616.2000.02.011 http://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20000226&journal_id=dzlxxb
[16] 马秀敏, 彭华, 李金锁.新疆西部地应力测量在隧道工程中的应用[J].地质力学学报, 2005, 11 (4):386~393. doi: 10.3969/j.issn.1006-6616.2005.04.013 http://journal.geomech.ac.cn/ch/reader/view_abstract.aspx?flag=1&file_no=20050455&journal_id=dzlxxb
-
