基于机载LiDAR技术的泥石流物源侵蚀量定量评价研究

,  ,

文章导航 > 沉积与特提斯地质 > 2023 > 43(4): 808-816

上一篇

下一篇

赵聪, 铁永波, 梁京涛. 2023. 基于机载LiDAR技术的泥石流物源侵蚀量定量评价研究. 沉积与特提斯地质, 43(4): 808-816. doi: 10.19826/j.cnki.1009-3850.2021.09004
引用本文: 赵聪, 铁永波, 梁京涛. 2023. 基于机载LiDAR技术的泥石流物源侵蚀量定量评价研究. 沉积与特提斯地质, 43(4): 808-816. doi: 10.19826/j.cnki.1009-3850.2021.09004
shu
ZHAO Cong, TIE Yongbo, LIANG Jingtao. 2023. Quantitative evaluation of debris flow provenance erosion based on Airborne Lidar Technology. Sedimentary Geology and Tethyan Geology, 43(4): 808-816. doi: 10.19826/j.cnki.1009-3850.2021.09004
Citation: ZHAO Cong, TIE Yongbo, LIANG Jingtao. 2023. Quantitative evaluation of debris flow provenance erosion based on Airborne Lidar Technology. Sedimentary Geology and Tethyan Geology, 43(4): 808-816. doi: 10.19826/j.cnki.1009-3850.2021.09004
shu

基于机载LiDAR技术的泥石流物源侵蚀量定量评价研究

  • 1.

    四川省地质调查院 稀有稀土战略资源评价与利用四川省重点实验室，四川　成都　610081

  • 2.

    中国地质调查局成都地质调查中心（西南地质科技创新中心），四川　成都　610218

  • 基金项目: 国家自然科学基金面上项目（41772324）；中国地质调查局地质调查项目（DD20190640）；四川省地质灾害隐患遥感识别监测（2020年）项目（510201202076888）
详细信息
    作者简介: 赵聪（1994—），男，助理工程师，硕士，主要从事地质灾害遥感调查监测相关研究。E-mail：735069327@qq.com
    通讯作者: 梁京涛（1982—），男，高级工程师，主要从事遥感地质、水工环地质研究工作。E-mail：550124235@qq.com

  • 中图分类号: P237；P642.23

Quantitative evaluation of debris flow provenance erosion based on Airborne Lidar Technology

  • 1.

    Sichuan Geological Survey/Evaluation and Utilization of Strategic Rare Metals and Rare Earth Resource Key Laboratory of Sichuan Province, Chengdu 610081, China

  • 2.

    Chengdu Center, China Geological Survey (Geosciences Innovation Center of Southwest China), Chengdu 610218, China

More Information

    摘要

  • 泥石流物源是形成泥石流的三大基本条件之一，物源侵蚀堆积变化量则是衡量泥石流规模和频率的重要指标，然而目前采用常规技术手段仍难以实现对物源侵蚀堆积变化的定量研究。针对这一问题，本文以西昌市邛海水厂后山冲沟泥石流为例，采用机载LiDAR技术建立了该流域雨季前后的高精度数字高程模型（DEM），并基于此开展了泥石流物源侵蚀量定量评价研究。结果表明：邛海水厂后山冲沟流域总体过火面积达65%，流域内主要发育坡面堆积物源、崩滑堆积物源以及沟道堆积物源；两期次高精度DEM数据差分叠加可实现泥石流物源侵蚀量的估算，该沟雨季前后泥石流物源侵蚀减少量为12209 m3，物源侵蚀变化呈分布区域广、数量多、散状发育的特点；泥石流物源的启动以坡面堆积物源侵蚀为主，侵蚀厚度多在0.5 m以内；邛海水厂后山冲沟泥石流在今后一段时间内将以高频泥石流为主。

    The material source is one of the three basic conditions for the formation of debris flow, and the change in erosion accumulation of the material source is an important index to measure the scale and frequency of debris flow. Currently, conventional techniques are still unable to achieve quantitative research on the change in source erosion accumulation. To solve this problem, this paper takes the gully debris flow at the back of the Qionghai water plant in Xichang City as an example, based on two periods of optical images and high-precision DEM (Digital Elevation Model) by LiDAR before and after the rainy season, carries out quantitative evaluation of debris flow provenance erosion. The results show that: the fire area of the basin is 65%, and there are slope erosion provenance, landslide provenance and gully accumulation sources in the basin. According to the superposition analysis of two high-precision DEM datasets, the source erosion amount of debris flow before and after the rainy season is 12209 cubic metres. The source erosion area is characterized by wide distribution, large number and scattered development. The debris flow is mainly caused by slope material source erosion, and the majority of the erosion thickness is within 0.5 m. Therefore, there will be high frequency debris flow in the future.

    • HTML全文
  • 加载中

  • 图 1  研究区无人机光学影像（2020年6月）

    Figure 1.

    下载: 全尺寸图片 幻灯片

    图 2  邛海水厂后山冲沟两期次DSM与DEM

    Figure 2.

    下载: 全尺寸图片 幻灯片

    图 3  过火区分布解译图

    Figure 3.

    下载: 全尺寸图片 幻灯片

    图 4  过火区分布野外验证照片

    Figure 4.

    下载: 全尺寸图片 幻灯片

    图 5  泥石流物源分布及分区解译图

    Figure 5.

    下载: 全尺寸图片 幻灯片

    图 6  泥石流物源侵蚀堆积变化图

    Figure 6.

    下载: 全尺寸图片 幻灯片

    图 7  A-A'剖面示意图

    Figure 7.

    下载: 全尺寸图片 幻灯片

    图 8  沟口物源变化野外验证照片

    Figure 8.

    下载: 全尺寸图片 幻灯片

    图 9  B-B’剖面示意图

    Figure 9.

    下载: 全尺寸图片 幻灯片

    图 10  C-C’剖面示意图

    Figure 10.

    下载: 全尺寸图片 幻灯片

    图 11  流域中下游物源变化野外验证照片

    Figure 11.

    下载: 全尺寸图片 幻灯片

    表 1  两次无人机作业检查点误差统计表

    Table 1.  Error statistics of checkpoints during two UAV operations

    检查点编号检查点实测坐标值第一次飞行点云坐标误差（m）第二次飞行点云坐标误差（m）
    XYZXYZXYZ
    CHK01526477.3693078813.7601772.339－0.012－0.0190.0850.0230.0330.031
    CHK02526280.7293078734.2701830.9690.0410.0260.0630.047－0.0310.009
    CHK03526372.0603078500.4401848.9380.018－0.0090.021－0.0370.025－0.033
    下载: 导出CSV
    • 参考文献(25)
  • [1]

    Alexander D, 1989. Progress in physical geography[J]. Urban Landslides, 13（2）: 157-191.

    [2]

    Axelsson P, 1999. Processing of laser scanner data-algorithms and applications[J]. ISPRS J Photogramm Remote Sens, 54（2-3）: 138-147. doi: 10.1016/S0924-2716(99)00008-8

    [3]

    Chigira M, Duan F, Yagi H, et al. , 2004. Using an airborne laser scanner for the identification of shallow landslides and susceptibility assessment in an area of ignimbrite overlain by permeable pyroclastics[J]. Landslides, （1）: 203-209.

    [4]

    Hanberg W C, Creighton A L, Medley E W, et al., 2005. Use of LiDAR to assess slope hazards at the Lihir Gold Mine, Papua New Guinea[R]. International Conference on Landslide Risk Management, Vancouver, British Columbia, Canada.

    [5]

    Glenn N F, Streutker D R, Chadwick D J, et al. , 2006. Analysis of LiDAR-Derived topographic information for characterizing and differentiating landslide morphology and activity[J]. Geomorphology, 73（1/2）: 131-148.

    [6]

    Schulz W H, 2007. Landslide susceptibility revealed by LiDAR imagery and historical records, Seattle, Washington[J]. Engineering Geology, 89（1/2）: 67-87.

    [7]

    Tang C, Zhu J, Ding J, et al. , 2011. Catastrophic debris flows triggered by a 14 August 2010 rainfall at the epicenter of the Wenchuan earthquake[J]. Landslides, 8（4）: 485-497. doi: 10.1007/s10346-011-0269-5

    [8]

    Varnes D J, 1978. Slope movement type and process[J]. Special Report, 176: 11-33.

    [9]

    常鸣, 唐川, 蒋志林, 等, 2014. 强震区都江堰市龙池镇泥石流物源的遥感动态演变[J]. 山地学报, 32（1）: 89-97 doi: 10.3969/j.issn.1008-2786.2014.01.012

    Chang M, Tang C, Jiang Z L, et al. , 2014. Dynamic Evolution Process of Sediment Supply for Debris Flow Occurrence in Longchi of Dujiangyan, Wenchuan Earthquake Area[J]. Mountain Research, 32 （1）: 89-97. doi: 10.3969/j.issn.1008-2786.2014.01.012

    [10]

    董秀军, 许强, 佘金星, 等, 2020. 九寨沟核心景区多源遥感数据地质灾害解译初探[J]. 武汉大学学报·信息科学版, 45（3）: 432-441

    Dong X J, Xu Q, She J X, et al. , 2020. Preliminary Study on Interpretation of Geological Hazards in Jiuzhaigou Based on Multi‐source Remote Sensing Data[J]. Geomatics and Information Science of Wuhan University, 45 （3）: 432-441.

    [11]

    方群生, 唐川, 王毅, 等, 2016. 汶川极震区泥石流动储量及总物源量计算方法研究[J]. 防灾减灾工程学报, 36（6）: 1008-1014

    Fang Q S, Tang C, Wang Y, et al. , 2016. A Calculation Method for Predicting Dynamic Reserve and the Total Amount of Material Source of the Debris Flows in the Wenchuan Meizoseismal Area[J]. Journal of Disaster Prevention and Mitigation Engineering, 36 （6）: 1008-1014.

    [12]

    冯增文, 2015. 基于多期DEM的地质灾害与环境动态监测[D]. 北京: 中国地质大学（北京）.

    Feng Z W, 2015. Multi-phase DSM for the Dynamic Monitoring of Geological Hazard and Environment[D]. Beijing: China University of Geosciences.

    [13]

    蒋忠信, 1994. 泥石流固体物质储量变化的定量预测[J]. 山地研究, 12（3）: 155-162

    Jiang Z X, 1994. Aquantitative Forecast to Reserves Change of Solid Loose Materials in Debris Flow Ravine[J]. Mountain Research, 12 （3）: 155-162.

    [14]

    李显巨, 2012. 基于LiDAR技术的复杂地质环境区滑坡识别研究[D]. 武汉: 中国地质大学（武汉）.

    Li X J, 2012. Research of the Landslide Recognition Based on LiDAR Technology in the Complex Geological Environment Area[D]. Wuhan: China University of Geosciences.

    [15]

    刘圣伟, 郭大海, 陈伟涛, 等, 2012. 机载激光雷达技术在长江三峡工程库区滑坡灾害调查和监测中的应用研究[J]. 中国地质, 39（2）: 507-517

    Liu S W, Guo D H, Chen W T, et al. , 2012. The application of airborne lidar technology in landslide investigation and monitoring of Three Gorges Reservoir Area[J]. Geology in China, 39 （2）: 507-517.

    [16]

    刘希林, 莫多闻, 2001. 论泥石流及其学科性质[J]. 自然灾害学报, 3（10）: 1-5

    Liu X L, Mo D W, 2002. Debris Flow and Its Subject Attribute[J]. Journal of Natural Disasters, 3 （10）: 1-5.

    [17]

    潘聪, 2015. 汶川县七盘沟泥石流斜坡物源启动模式及动储量预测研究[D]. 成都: 西南交通大学.

    Pan C, 2015. Study on Startup Mode of Slope Material Sources and Dynamic Reserves Prediction of Qipan Gully Debris Flow in Wenchuan County[D]. Chengdu: Southwest Jiaotong University

    [18]

    佘金星, 程多祥, 刘飞, 等, 2018. 机载激光雷达技术在地质灾害调查中的应用——以四川九寨沟7.0级地震为例[J]. 中国地震, 34（3）: 435 − 444

    She J X, Cheng D X, Liu F, et al., 2018. Application of Airborne LiDAR Technology in Geological Disaster Investigation—Taking the Jiuzhaigou Ms 7.0 Earthquake in Sichuan Province as an Example[J]. Earthquake Research in China, 34 （3）: 435 − 444.

    [19]

    王绚, 范宣梅, 杨帆, 等, 2020. 植被茂密山区地质灾害遥感解译方法研究[J]. 武汉大学学报·信息科学版, 45（11）: 1771-1781

    Wang X, Fan X M, Yang F, et al. , 2020. Remote Sensing Interpretation Method of Geological Hazards in Lush Mountainous Area[J]. Geomatics and Information Science of Wuhan University, 45 （11）: 1771-1781.

    [20]

    谢谟文, 刘翔宇, 王增福, 等, 2011. 基于三维遥感系统的泥石流土方量计算及影响范围模拟[J]. 水文地质工程地质, 38（03）: 115-119

    Xie M W, Liu X Y, Wang Z F, et al. , 2011. A 3-D remote sensing system based on assessment of debris flow and impact area simulation[J]. Hydrogeology and Engineering Geology, 38 （03）: 115-119.

    [21]

    徐弘, 1995. 泥石流松散固体物质临界集聚估算模型研究[J]. 西南交通大学学报, 30（2）: 212-217

    Xu H, 1995. An Estimation Model for Critical Accumulation of Porous Solid Mass in Debris Flow Study[J]. Journal of Southwest Jiaotong University, 30 （2）: 212-217.

    [22]

    杨顺, 2014. 水动力作用下泥石流源区固体物质可移动判别模型研究[D]. 北京: 中国科学院大学.

    Yang S, 2014. Study on the movable criticle model of solid material under hydro-dynamical condition in debris flow area[D]. Beijing: University of the Chinese Academy of Sciences.

    [23]

    张佳佳, 刘建康, 高波, 等, 2018. 藏东南嘎龙曲冰川泥石流的物源特征及其对扎墨公路的影响[J]. 地质力学学报, 24（1）: 106-115

    Zhang J J, Liu J K, Gao B, et al. , 2018. Characteristics of Material Sources of Galongqu Glacial Debris Flow and the Influence to ZhaMo Road[J]. Journal of Geomechanics, 24 （1）: 106-115.

    [24]

    张友谊, 袁亚东, 顾成壮, 2020. 震区泥石流物源储量评价方法综述[J]. 山地学报, 38（3）: 394-401 doi: 10.16089/j.cnki.1008-2786.000519

    Zhang Y Y, Yuan Y D, Gu C Z, et al. , 2020. Review of Evaluation Methods for Debris Flow Resource Reserves in Areas Affected by Earthquakes[J]. Mountain Research, 38 （3）: 394-401. doi: 10.16089/j.cnki.1008-2786.000519

    [25]

    周必凡, 李德基, 罗德富, 等, 1991. 泥石流防治指南[M]. 北京: 科学出版社.

    Zhou B F, Li D J, Luo D F, et al., 1991. Guidelines for Debris Flow Control[M]. Beijing: Science Press.
