摘要:
这是一篇地球科学领域的论文。踏卡穹隆与江浪穹隆位于松潘—甘孜地块南缘，地质特征显示其物质组成、变质-变形特征较为相似。江浪穹隆发现有里伍、黑牛洞、中咀等铜锌矿床，但踏卡穹隆同层位还未发现相似矿床。为查明踏卡穹隆中深部构造特征及成矿的关系，本次开展了不同时代地层的地球物理电性参数测定和音频大地电磁测深剖面，以获得地下中、深部电性特征。结果表明，穹隆总体显示为两侧低、中阻，核部高阻为主夹杂低阻的特征，整体电性特征与穹隆结构的时空规律相吻合。深部电性剖面中出现3条主要低阻异常带，推断为低阻岩性、断层或构造破碎带的反映；3条主要高阻异常带，推断为踏卡穹隆内完整的中、高阻特征的中元古界里伍群上段（Pt2l3）岩体反映。上述认识为探索踏卡穹隆中、深部地质空间结构提供了地球物理学上的证据。
Abstract:This is an article in the field of earth sciences. Taka dome and Jianglang dome are located in the southern margin of Songpan-Ganzi block, and their geological characteristics indicate similar composition and metamorphic-deformation characteristics. Liwu, Heiniudong and Zhongsui deposits have been found in Jianglang Dome, while no similar deposits have been found in the same horizon of Taka Dome. To investigate the medium-deep part structure characteristics and mineralization of the Taka Dome, the geophysical electrical parameters and audio magnetotelluric sounding profiles of different strata of different ages were measured to obtain the electrical characteristics of the middle and deep subsurface. The results show that the overall characteristics of the dome are low and medium resistance on both sides, and high resistance in the core is mainly mixed with low resistance. The overall electrical characteristics are consistent with the spatiotemporal law of the dome structure. There are three main low-resistivity anomaly zones in the deep electrical profile, which are inferred to reflect the low-resistivity lithology, fault or structural fracture zone. The three main high-resistivity anomaly belts are inferred to be reflected by the upper member of the Mesoproterozoic Liwu Group (Pt2l3) with complete medium-high resistivity characteristics in the Taka dome. The above understanding provides geophysical evidence for exploring the medium-deep geological spatial structure of the Taka Dome.
-
-
表 1 岩矿标本电性参数测定结果
Table 1. Statistical of electrical parameters of rock ore specimens
地层/年代 岩性 标本数量 电阻率ρ/（Ω.m） 电性特征 最小值 最大值 算术平均值 石炭系下统（C1b） 大理岩 33 291.3 45 937.73 8141.32 高阻 蚀变带矿化（矿点） 9 7.06 18 735.39 5360.69 高阻 古元古界里伍岩群上段（Pt2l3） 石英岩 31 294.9 7729.18 2679.47 中阻 黑云角闪斜长片岩 31 208.45 19 520.22 3020.36 中阻 奥陶系下统江浪岩组（Oj） 纯白石英岩 31 66.83 16 733.89 6223.08 高阻 志留系下统米黑沟组（S1m） 绿泥斜长片岩 31 17.3 2221.19 486.68 低阻
下载: 导出CSV
-
[1] 朱玉娣, 代堰锫, 王丽丽, 等. 松潘-甘孜造山带南缘二叠系变质玄武岩的成因与构造意义[J]. 地学前缘, 2017, 24(6): 98-109.ZHU Y D, DAI Y P, WANG L L, et al. Petrogenesis and tectonic significance of the Permian metabasalts in the southern margin of the Songpan-Garze orogenic belt[J]. Earth Science Frontiers. 2017, 24(6): 98-109.
ZHU Y D, DAI Y P, WANG L L, et al. Petrogenesis and tectonic significance of the Permian metabasalts in the southern margin of the Songpan-Garze orogenic belt[J]. Earth Science Frontiers. 2017, 24(6): 98-109. [2] 刘晓佳, 许志琴. 松潘-甘孜造山带南部江浪穹隆中侏罗世花岗岩及构造意义[J]. 地质学报, 2021, 95(6):1754-1773.LIU X J, XU Z Q. Tectonic significance of Middle Jurassic granites in the Jianglang dome, Southern Songpan-Ganzi orogen belt[J]. Acta Geologica Sinica, 2021, 95(6):1754-1773.
LIU X J, XU Z Q . Tectonic significance of Middle Jurassic granites in the Jianglang dome, Southern Songpan-Ganzi orogen belt[J]. Acta Geologica Sinica,2021 ,95 (6 ):1754 -1773 .[3] 周家云, 谭洪旗, 龚大兴, 等. 川西江浪穹隆核部新火山花岗岩LA-ICP-MS锆石U-Pb定年和Hf同位素研究[J]. 矿物岩石, 2013, 33(4): 42-52.ZHOU J Y, TAN H Q, GONG D X, et al. Zircon LA-ICP-MS U-Pb dating and Hf isotopic composition of Xinhuoshan granite in the core of Jianglang Dome, Western Sichuan, China. [J]. Mineral Petrol, 2013, 33(4): 42-52.
ZHOU J Y, TAN H Q, GONG D X, et al. Zircon LA-ICP-MS U-Pb dating and Hf isotopic composition of Xinhuoshan granite in the core of Jianglang Dome, Western Sichuan, China. [J]. Mineral Petrol, 2013, 33(4): 42-52. [4] 陈道前. 四川里伍铜锌矿田控矿构造特征与找矿预测研究[D]. 成都: 成都理工大学, 2015.CHEN D Q. Research on the ore-controlling structures and prospecting of Liwu Cu-Zn orefield in Sichuan Province[D]. Chengdu: Chengdu University of Technology, 2015.
CHEN D Q. Research on the ore-controlling structures and prospecting of Liwu Cu-Zn orefield in Sichuan Province[D]. Chengdu: Chengdu University of Technology, 2015. [5] 罗丽萍, 胡军亮, 谭洪旗, 等. 川西上基拱伟晶岩型铍矿绿柱石矿物化学特征[J]. 矿产综合利用, 2021(5): 113-119.LUO L P, HU J L, TAN H Q, et al. Mineralogical characteristics of the pegmatite type beryl in Shangjigong, Western Sichuan Province[J]. Multipurpose Utilization of Mineral Resources, 2021(5): 113-119.
LUO L P, HU J L, TAN H Q, et al. Mineralogical characteristics of the pegmatite type beryl in Shangjigong, Western Sichuan Province[J]. Multipurpose Utilization of Mineral Resources, 2021(5): 113-119. [6] 谭洪旗, 朱志敏, 周雄, 等. 川西九龙地区两期伟晶岩型稀有金属成矿作用[J]. 矿产综合利用, 2022(1):15-24.TAN H Q, ZHU Z M, ZHOU X, et al. Two periods rare metal mineralization of the pegmatite in Jiulong area, western Sichuan[J]. Multipurpose Utilization of Mineral Resources, 2022(1):15-24.
TAN H Q, ZHU Z M, ZHOU X, et al . Two periods rare metal mineralization of the pegmatite in Jiulong area, western Sichuan[J]. Multipurpose Utilization of Mineral Resources,2022 (1 ):15 -24 .[7] 谭洪旗, 朱志敏, 周家云, 等. 松潘-甘孜地块南缘燕山早期矽卡岩型钨钼矿床—来自大牛场成岩成矿年代学及锆石Hf同位素证据[J]. 矿床地质, 2022, 41(1):53-68.TAN H Q, ZHU Z M, ZHOU J Y, et al. Early Yanshanian skarn W-Mo deposit in the southern margin of Songpan-Ganze terrane: evidence from diagenetic and metallogenic chronology, zircon Hf isotopes in Daniuchang area[J]. Mineral Deposits, 2022, 41(1):53-68.
TAN H Q, ZHU Z M, ZHOU J Y, et al . Early Yanshanian skarn W-Mo deposit in the southern margin of Songpan-Ganze terrane: evidence from diagenetic and metallogenic chronology, zircon Hf isotopes in Daniuchang area[J]. Mineral Deposits,2022 ,41 (1 ):53 -68 .[8] 谭洪旗, 朱志敏, 罗林洪, 等. 川西洛莫地区燕山早期花岗岩对稀有金属成矿的制约[J]. 地质学报, 2023, 97(2):307-327.TAN H Q, ZHU Z M, LUO L H, et al. Distribution of early Yanshanian granite and its constraints on the mineralization of rare metals in Luomo area, western Sichuan[J]. Acta Geologica Sinica, 2023, 97(2):307-327.
TAN H Q, ZHU Z M, LUO L H, et al . Distribution of early Yanshanian granite and its constraints on the mineralization of rare metals in Luomo area, western Sichuan[J]. Acta Geologica Sinica,2023 ,97 (2 ):307 -327 .[9] 肖晓, 汤井田, 周聪, 等. 庐枞矿集区大地电磁探测及电性结构初探[J]. 地质学报, 2011, 85(5): 873-886.XIAO X, TANG J T, ZHOU C, et al. Magnetotelluric sounding in the Lujiang-Zongyang ore-district and preliminary study of electrical structure[J]. Acta Geologica Sinica. 2011, 85(5): 873-886.
XIAO X, TANG J T, ZHOU C, et al. Magnetotelluric sounding in the Lujiang-Zongyang ore-district and preliminary study of electrical structure[J]. Acta Geologica Sinica. 2011, 85(5): 873-886. [10] 杨炳南, 周琦, 杜远生, 等. 音频大地电磁法对深部隐伏构造的识别与应用: 贵州省松桃县李家湾锰矿为例[J]. 地质科技情报, 2015, 34(6):26-32.YANG B N, ZHOU Q, DU Y S, et al. Identification and application of audio magnetotellurics to the deep buried structere: A case study of Lijiawan manganese deposit at Songtao County in Guizhou Province[J]. Geological Science and Technology Information, 2015, 34(6):26-32.
YANG B N, ZHOU Q, DU Y S, et al . Identification and application of audio magnetotellurics to the deep buried structere: A case study of Lijiawan manganese deposit at Songtao County in Guizhou Province[J]. Geological Science and Technology Information,2015 ,34 (6 ):26 -32 .[11] 姚大为, 朱威, 王大勇, 等. 音频大地电磁法在武山外围深部勘查中的应用[J]. 物探与化探, 2015, 39(1):100-103.YAO D W, ZHU W, WANG D Y, et al. The effect of applying audio-frequency magnetotelluric method to the deep geological exploration: a case study of Wushan periphery in the Jiurui ore concentration area[J]. Geophysical& Geochemical Exploration, 2015, 39(1):100-103.
YAO D W, ZHU W, WANG D Y, et al . The effect of applying audio-frequency magnetotelluric method to the deep geological exploration: a case study of Wushan periphery in the Jiurui ore concentration area[J]. Geophysical& Geochemical Exploration,2015 ,39 (1 ):100 -103 .[12] 李冉, 汤吉, 董泽义, 等. 云南南部地区深部电性结构特征研究[J]. 地球物理学报, 57(4): 1111-1122.LI R, TANG J, DONG Z Y, et al. Deep electrical conductivity structure of the southern area in Yunnan Province[J]. Chinese Journal of Geophysics, 57(4): 1111-1122.
LI R, TANG J, DONG Z Y, et al. Deep electrical conductivity structure of the southern area in Yunnan Province[J]. Chinese Journal of Geophysics, 57(4): 1111-1122. [13] 王桥, 杨剑, 夏时斌, 等. 四川盆地新区新层系页岩气的音频大地电磁探测-以川西南乐山地区须家河组为例[J]. 地质学报, 2022, 96(2):699-711.WANG Q, YANG J, XIA S B, et al. Audio magnetotelluric detection of shale gas in the new horizon of the new area of Sichuan basin: a case study of the Xujiahe Formation in the Leshan area, southwest Sichuan[J]. Acta Geologica Sinica, 2022, 96(2):699-711.
WANG Q, YANG J, XIA S B, et al . Audio magnetotelluric detection of shale gas in the new horizon of the new area of Sichuan basin: a case study of the Xujiahe Formation in the Leshan area, southwest Sichuan[J]. Acta Geologica Sinica,2022 ,96 (2 ):699 -711 .[14] 周月, 官大维, 延海涛, 等. 基于先验信息约束的重磁电联合三维交互反演技术实践——以彭山穹隆构造为例[J]. 物探与化探, 2021, 45(2):308-315.ZHOU Y, GUAN D W, YAN H T, et al. 3D gravity magnetic and electrical inversion modeling based on prior information: a case study of the dome structure in Pengshan area, Jiangxi Province[J]. Geophysical and Geochemical Exploration, 2021, 45(2):308-315.
ZHOU Y, GUAN D W, YAN H T, et al . 3D gravity magnetic and electrical inversion modeling based on prior information: a case study of the dome structure in Pengshan area, Jiangxi Province[J]. Geophysical and Geochemical Exploration,2021 ,45 (2 ):308 -315 .[15] 何帅, 杨炳南, 李核良, 等. 音频大地电磁法对渝东南Ⅳ级地堑构造的识别及意义[J]. 地质科技情报, 2019, 38(1):270-276.HE S, YANG B N, LI H L, et al. Identification of IV graben tectonics of Southeast Chongqing by AMT method and its significance[J]. Geological Science and Technology Information, 2019, 38(1):270-276.
HE S, YANG B N, LI H L, et al . Identification of IV graben tectonics of Southeast Chongqing by AMT method and its significance[J]. Geological Science and Technology Information,2019 ,38 (1 ):270 -276 .[16] 杨剑, 王绪本, 王永华, 等. 电、磁综合方法在云南北衙铁金矿勘查中的应用[J]. 中国地质, 2014, 41(2):602-610.YANG J, WANG X B, WANG Y H, et al. The application of integrated geophysical methods of magnetic survey and AMT to the exploration of the Beiya gold deposit[J]. Geology In China, 2014, 41(2):602-610.
YANG J, WANG X B, WANG Y H, et al . The application of integrated geophysical methods of magnetic survey and AMT to the exploration of the Beiya gold deposit[J]. Geology In China,2014 ,41 (2 ):602 -610 .[17] 战启宁, 李鹏, 鹿琪, 等. 东北地区松辽盆地和大三江盆地群基底构造电性特征[J]. 世界地质, 2021, 40(3):703-710.ZHAN Q N, LI P, LU Q, et al. Electrical characteristics of basement structures of Songliao Basin and Dasanjiang Basin Group in Northeast China[J]. Global Geology, 2021, 40(3):703-710. doi: 10.3969/j.issn.1004-5589.2021.03.023
ZHAN Q N, LI P, LU Q, et al . Electrical characteristics of basement structures of Songliao Basin and Dasanjiang Basin Group in Northeast China[J]. Global Geology,2021 ,40 (3 ):703 -710 .[18] 刘畅往, 何梅兴, 杜炳锐. 东北漠河盆地北部电性特征及其地质意义[J]. 物探与化探, 2017, 41(6):1195-1203.LIU C W, HE M X, DU B R. Electrical property of Mohe Basin in Northeast China and its geological significance[J]. Geophysical and Geochemical Exploration, 2017, 41(6):1195-1203.
LIU C W, HE M X, DU B R . Electrical property of Mohe Basin in Northeast China and its geological significance[J]. Geophysical and Geochemical Exploration,2017 ,41 (6 ):1195 -1203 .[19] 曹创华, 徐定芳, 康方平, 等. 湖南省岳家桥典型岩溶发育区电性特征及构造格架研究[J]. 中国地质调查, 2018, 5(6):68-74.CAO C H, XU D F, KANG F P, et al. Electrical characteristics and tectonic framework of typical karst zone in Yuejiaqiao area of Hunan Province[J]. Geological survey of China, 2018, 5(6):68-74.
CAO C H, XU D F, KANG F P, et al . Electrical characteristics and tectonic framework of typical karst zone in Yuejiaqiao area of Hunan Province[J]. Geological survey of China,2018 ,5 (6 ):68 -74 .[20] 刘营, 徐义贤, 张胜业, 等. 华南地区岩石圈电性特征及其地球动力学意义[J]. 地球物理学报, 2013, 56(12):4234-4244.LIU Y, XU Y X, ZHANG S Y, et al. Lithospheric electrical characteristics in South China and its geodynamic implication[J]. Chinese J. Geophys, 2013, 56(12):4234-4244.
LIU Y, XU Y X, ZHANG S Y, et al . Lithospheric electrical characteristics in South China and its geodynamic implication[J]. Chinese J. Geophys,2013 ,56 (12 ):4234 -4244 .[21] 赵英凯. 基于地球物理电性特征的阿拉格忒赫特阿尔铜矿成矿规律研究[D]. 天津: 河北工业大学, 2009.ZHAO Y K. The study of the metallogenic law about copper deposit at Alagtaihert Al based on the electrical characteristics in geophysics [D]. Tianjin: Hebei University of Technology, 2009.
ZHAO Y K. The study of the metallogenic law about copper deposit at Alagtaihert Al based on the electrical characteristics in geophysics [D]. Tianjin: Hebei University of Technology, 2009. [22] 张惠华, 冯孝良, 唐高林, 等. 四川省九龙县中咀铜矿构造与成矿关系研究[J]. 高校地质学报, 2013, 19(1):95-108.ZHANG H H, FENG X L, TANG G L, el at. Structure types and mineralization in the Zhongzui copper deposit, Jiulong County, Sichuan Province[J]. Geological Journal of China Universities, 2013, 19(1):95-108.
ZHANG H H, FENG X L, TANG G L, el at . Structure types and mineralization in the Zhongzui copper deposit, Jiulong County, Sichuan Province[J]. Geological Journal of China Universities,2013 ,19 (1 ):95 -108 .[23] 刘俊来, 陈小宇, 张健, 等. 大陆地壳活动带片麻岩穹隆构造与分层流变[J]. 地质学报, 2022, 96(9):3158-3181.LIU J L, CHEN X Y, ZHANG J, et al. Gneiss domes and stratified middle to lower crustal flow in continental mobile belt[J]. Acta Geologica Sinica, 2022, 96(9):3158-3181.
LIU J L, CHEN X Y, ZHANG J, et al . Gneiss domes and stratified middle to lower crustal flow in continental mobile belt[J]. Acta Geologica Sinica,2022 ,96 (9 ):3158 -3181 .[24] 王继斌, 颜丹平, 邱亮, 等. 南盘江盆地赖子山穹隆构造样式及沙箱模拟研究[J]. 地学前缘, 2018, 25(1):47-64.WANG J B, YAN D P, QIU L, et al. Structural style and sandbox modelling of the Laizishan Dome in the Nanpanjiang Basin, South China[J]. Earth Science Frontiers, 2018, 25(1):47-64.
WANG J B, YAN D P, QIU L, et al . Structural style and sandbox modelling of the Laizishan Dome in the Nanpanjiang Basin, South China[J]. Earth Science Frontiers,2018 ,25 (1 ):47 -64 .[25] 谭洪旗. 松潘-甘孜地块南缘穹隆体物质组成、变形-变质特征及成矿响应[D]. 成都: 成都理工大学, 2019.TAN H Q. The composition, deformation-metamorphic characteristics and metallogenic response of the dome geological bodies on L2the South Margin of Songpan-Garze Block[D]. Chengdu: Chengdu University of Technology, 2019.
TAN H Q. The composition, deformation-metamorphic characteristics and metallogenic response of the dome geological bodies on L2the South Margin of Songpan-Garze Block[D]. Chengdu: Chengdu University of Technology, 2019. [26] Whitney D L, Teyssier C, Vanderhaeghe O V. Gneiss domes and crustal flow[J]. Geological Society of America Special Paper, 2004, 380:1-20.
-
