海原断裂干盐池探槽揭示非特征性古地震序列
Research on various magnitudes of paleoearthquakes: A case study of non-characteristic earthquakes from the Salt Lake site of Haiyuan fault
-
摘要: 海原断裂是青藏高原东北缘一条重要的陆内活动左旋走滑断裂,于1920年发生过里氏8(1/2)级特大地震,形成约230km的地表破裂带和高达10.2m的同震左旋位移。该断裂的大地震复发行为特征一直是地震地质学家关注的重点,然而现有的认识需要更多以精细沉积地层约束的古地震数据的验证。基于此,在海原断裂中段干盐池盆地成功开挖了数个大型三维探槽,揭露了清晰的韵律性、面状展布地层和丰富的古地震事件证据。在探槽上部2.5m厚的最新细粒沉积层序记录了AD 1500以来的3次地震事件。基于地层中14C样品的结果和历史地震史料的考证,限定这3次地震事件分别对应于AD 1920年、AD 1760年(或1709年)和AD 1638年的地震,但其震级差别很大。除了最新一次地震,即1920年海原大地震的震级为8(1/2)级,其他2次地震事件的震级较小,均小于7级,说明海原断裂上伴生有地表破裂的地震不全是特征型地震事件。结果表明,古地震探槽中揭示的地震强度不一定相同,而且中等震级地震也可以产生地表破裂,其地层证据在合适的条件下,如无沉积间断、沉积速率大等环境能在地层中得到保存。Abstract: The active left-lateral Haiyuan fault is one of the major continental strike-slip faults in the Tibetan Plateau. The last large earthquake that occurred on the fault was the great 1920 Ms 8(1/2) Haiyuan earthquake with a 230-km-long surface rupture and maximum left-lateral slip of 10.2m. Much less known is its earthquake recurrence behavior in spite of much focused studies. The current understanding is still preliminary and requires validation of paleoseismic data based on fine stratigraphy in trenching. In this study, the authors present results of a paleoseismic study at the Salt Lake site in a shortcut pull-apart basin within the section that broke in 1920. 3D excavation at the site exposed fine-grained and layered stratigraphy and ample evidence of multiple paleoseismic events. Charcoal fragments are abundant in the trenches. AMS dating of charcoal fragments shows that multiple events occurred during the past 3600 years. Of these, the youngest three and possibly four events were recorded in the top 2.5m section of distinctive thinly-layered stratigraphy. A comparison of paleoseismic with historical earthquake records suggests that these three events are correlative to the AD 1920, 1760 (or 1709) and 1638 earthquakes. Historical accounts of earthquake damage suggest that earthquakes exposed in the trenches are markedly different in magnitude. With the exception of the most recent M8 earthquake in AD 1920, two earlier events were considerably smaller, with magnitude M<7, and more likely M6 or less. Thus, the Haiyuan fault could produce surface-rupturing earthquakes with a variety of magnitudes, not just characteristic earthquakes. This study indicates that paleo-earthquakes exposed in trenches are not necessarily similar in size, and moderate magnitude events might produce surface ruptures, which can be preserved in stratigraphy and exposed in a paleoseismic trenching under some conditions, for instance, the sedimentation is fast enough and there exists no hiatus in deposition.
-
Key words:
- Haiyuan fault /
- Salt Lake /
- paleoearthquake /
- historical earthquake /
- non-characteristic earthquake
-
-
[1] McCalpin J P. Paleoseismology (2nd Edition)[M]. Elsevier Publishing, Oxford,2009.
[2] 冉勇康,邓起东.古地震学研究的历史、现状和发展趋势[J].科学通报, 1999,44(10):880-889.
[3] 刘静,徐锡伟, 李岩峰, 等. 以海原断裂甘肃老虎山段为例浅析走滑断裂古地震记录的完整性——兼论古地震研究中的若干问题[J]. 地质通报, 2007, 26(6):650-660.
[4] Richter F R. Elementary Seismology[M]. W. H. Freeman and Company, San Francisco, and Bailey Bros. & Swinfen Ltd., London, 1958.
[5] Zhang W Q, Jiao D C, Zhang P Z, et al. Displacement along the Haiyuan fault associated with the great 1920 Haiyuan China earthquake[J]. Bull. Seismol. Soc. Am., 1987, 77:117-131.
[6] Chen W P, Molnar P. Seismic moments of major earthquakes and average rate of slip in central Asia[J]. J. Geophys. Res., 1977,82:2954-2969.
[7] Zhang P Z, Molnar P, Burchfiel B C, et al. Bounds on the Holocene slip rate along the Haiyuan fault, north-central China[J]. Quaternary Research, 1988,30:151-164.
[8] Deng Q D, Chen S, Song F, et al. Variations in the geometry and amount of slip on the Haiyuan (Nanxihaushan) fault zone, China and the surface rupture of the 1920 Haiyuan earthquake[J]. Earthquake Source Mechanics, 1986:169-182.
[9] 国家地震局地质研究所, 宁夏省地震局.海原活动断裂带[M].北京:地震出版社,1990.
[10] Zhang P Z,Burchfiel B C,Molnar P, et al. Late Cenozoic tectonic evolution of the Ningxia-Hui Autonomous Region, China[J]. Geological Society of America Bulletin, 1990,102:1484-1498.
[11] 刘百篪,周俊喜.海原活断层上的史前大地震[J].地震地质, 1985,7(4):11-21.
[12] 何文贵,刘百篪,吕太乙,等.老虎山断裂带的分段性研究[J].西北地震学报. 1994,16(3):67-72.
[13] 何文贵,袁道阳,葛伟鹏,等.祁连山活动断裂带中东段冷龙岭断裂滑动速率的精确厘定[J].地震,2010,30(1):131-137.
[14] Gaudemer Y, Tapponnier P, Meyer B, et al. Partitioning of crustal slip between linked, active faults in the eastern Qilian Shan, and evidence for a major seismic gap, the 'Tianzhu gap', on the western Haiyuan Fault, Gansu(China)[J]. Geophysical Journal International, 1995,120(3):599-645.
[15] 袁道阳,刘百篪,吕太乙,等.毛毛山断裂带位移累积滑动亏损特征及其分段意义讨论[J].西北地震学报,1996,18(4):59-67.
[16] 袁道阳, 刘百篪, 吕太乙, 等.北祁连山东段活动断裂带的分段性研究[J].西北地震学报, 1998,20(4):27-33.
[17] Lasserre C, Morel P, Gaudemr Y, et al. Postglacial left slip rate and past occurrence of M ≥ 8 earthquakes on the western Haiyuan Fault, Gansu, China[J]. J. Geophys. Res.,1999,104:17633-17652.
[18] Lasserre C, Gaudemer Y, Tapponnier P, et al. Fast late Pleistocene slip rate on the Leng Long Ling segment of the Haiyuan Fault, Qinghai, China[J]. J. Geophys. Res., 2002,107:2276-2290.
[19] 张培震, 闵伟, 邓起东, 等. 海原活动断裂带的古地震与强震复发规律[J]. 中国科学(D辑),2003,33(8):705-713.
[20] Liu Z J, Klinger Y, Xu X W, et al. Millennial Recurrence of Large Earthquakes on the Haiyuan Fault near Songshan, Gansu Province, China[J]. Bull. Seis. Soc. Am., 2007,97:14-34.
[21] Li C Y, Zhang P Z, Yin J, et al. Late Quaternary left-lateral slip rate of the Haiyuan Fault, northeastern margin of the Tibetan plateau[J]. Tectonics, 2009,28:TC5010.
[22] Jolivet R, Lasserre C, Doin M P, et al. Shallow creep on the Haiyuan Fault (Gansu, China) revealed by SAR Interferometry[J]. J. Geophys. Res., 2012, 117:1-18.
[23] 张维歧, 焦德成. 海原古地震的一个剖面[J].地震地质,1984, 6(3):14.
[24] Deng Q D, Wang Y P, Song F M, et al.Principal Characteristics of the Nanxihuashan Fault Zone and the 1920 Haiyuan Earthquake Faultandthe Recurence of Strong Earthquakes[J]. EOS, Trans. Am. Geophys. Union, 1985, 6(46):169.
[25] Zhang P Z, Molnar P, Burchfiel B C, et al. Bounds on the average recurence interval of major earthquakes along the Haiyuan Fault in NorthCentral China[J]. Seismol. Res. Lett., 1988, 59(3):81-89.
[26] 冉勇康, 段瑞涛, 邓起东, 等. 海原断裂高湾子地点三维探槽的开挖与古地震研究[J]. 地震地质, 1997, 19(2):97-107.
[27] 冉勇康,邓起东.海原断裂的古地震及特征地震破裂的分级性讨论[J].第四纪研究,1998,(3):271-278.
[28] 冉勇康,段瑞涛,邓起东. 海原断裂主要活动段的古地震与强震分布特征探讨[J]. 活动断裂研究, 1998, 6:42-55.
[29] 闵伟, 张培震. 海原活动断裂带破裂行为特征研究[J].地质论评, 2001,47(1):75-81.
[30] Min W,Zhang P Z, Deng Q D,et al.ThedetailedstudyofHolocenepaleoearthquakes ofactiveHaiyuan Fault[J]. Continental Dynamics, 20016(2):59-66.
[31] Zhang P Z, Burchfield B C, Chen S, et al. Extinction of pull-apart basins[J]. Geology, 1989,17:814-817.
[32] 邓起东,刘百篪,张培震,等. 活动断裂工程安全评价和位错量的定量评估[C].活动断裂研究(2)北京:地震出版社, 1992:236-246.
[33] Ding G Y, Chen J, Tian Q J, et al. Active faults and magnitudes of left-lateral displacement along the northern margin of the Tibetan Plateau[J]. Tectonophysics, 2004,380:243-260.
[34] Scharer K M, Weldon R J Ⅱ, Fumal T E, et al. Paleoearthquakes on the southern San Andreas fault, Wrightwood, California, 3000 to 1500 B.C.:a new method for evaluating paleoseismic evidence and earthquake horizons[J]. Bull. Seismol. Soc. Am., 2007,97:1054-1093.
[35] Weldon R J Ⅱ, Fumal T E, Powers T J, et al. Structure and earthquake offsets on the San Andreas fault at the Wrightwood, California, paleoseismic site[J]. Bull. Seis. Soc. Am., 2002,92(7):2704-2725.
[36] Allen C R, Brune J N. A low-stress-drop, low-magnitude earthquake with surface faulting:The Imperial, California, earthquake of March 4, 1966[J]. Bull. Seis. Soc.Am., 1967,57:501-514.
[37] Marco S, Stein M, Agnon A, et al. Long term earthquake clustering:a 50000 year paleoseismic record in the Dead Sea Graben[J]. J. Geophys. Res., 1996,101:6179-6192.
[38] Bronk R C. OxCal 4.2 Manual. Available from Oxford Radiocarbon Accelerator Unit[EB/OL] [2015-11-26] https://c14.arch.ox.ac.uk/oxcalhelp/hlp_contents.html. 2013.
[39] 中国科学院地震工作委员会历史组编.中国地震年表[M].北京:科学出版社,1956.
[40] 李善邦.中国地震目录[M].北京:地震出版社,1960.
[41] 中央地震工作小组办公室主编.1971.中国地震目录[M]. 北京:科学出版社,1971.
[42] 顾功叙. 中国地震目录[M]. 北京:科学出版社,1983.
[43] 谢毓寿,蔡美彪.中国地震历史资料汇编:第一卷-第四卷[M].北京:科学出版社,1983,1985,1987.
[44] 国家地震局兰州地震研究所.甘肃省历史地震资料汇编[M]. 北京:地震出版,社1989.
[45] 国家地震局地球物理研究所等. 明时期中国历史地震图集[M]. 北京:地图出版社,1986.
[46] 国家地震局震害防御司主编.中国历史强震目录(公元前23世纪-公元1911年)[M]. 北京:地震出版社,1995.
[47] Hudnut K, Beavan J. Vertical deformation (1952-1987) in the Salton Trough, California, from water level recordings[J]. J. Geophys. Res., 1989, 94:9463-9476.
[48] Wei M, Sandwell D, Fialko Y, et al. Slip on faults in the Imperial Valley triggered by the 4 April 2010 Mw 7.2 El Mayor-Cucapah earthquake revealed by InSAR[J]. Geophys. Res. Lett., 2011,38(L01308):1-6.
[49] 袁道阳, 雷中生, 何文贵, 等. 公元前186年武都地震考证与发震构造分析[J]. 地震学报, 2007,29(6):654-663.
[50] 刘兴旺, 袁道阳, 何文贵. 祁连山北缘佛洞庙-红崖子断裂古地震特征初步研究[J]. 震灾防御技术, 2014,9(3):411-419.
[51] Wesnousky S G. Predicting the endpoints of earthquake ruptures[J]. Nature, 2006,444:358-360.
[52] Klinger Y. Relation between continental strike-slip earthquake segmentation and thickness of the crust[J]. J. Geophys. Res., 2010,115(B07306):1-19.
[53] Wells D L, Coppersmith K J. New empirical relationships among magnitude, rupture length, rupture width, rupture area, and surface displacement[J]. Bull. Seismol. Soc. Am., 1994,84, 974-1002.
[54] Streig A R, Dawson T E, Weldon R J Ⅱ. Paleoseismic evidence of the 1890 and 1838 earthquakes on the Santa Cruz Mountains section of the San Andreas fault, near Corralitos, California[J]. Bull. Seismol. Soc. Am., 2014, 104(1):285-300.
[55] Bakun W H, Wentworth C M. Estimating earthquake location and magnitude from seismic intensity data[J]. Bull. Seismol. Soc. Am., 1997, 87:1502-1521.
[56] Wells D L, Coppersmith K J. Likelihood of Surface Rupture as a function of Magnitude[J]. Seismol. Res. Lett., 1993,64(1):54.
[57] Weldon R J Ⅱ, Biasi G. Probability of detection of ground rupture at paleoseismic sites[M]. Appendix I of Uniform California Earthquake Rupture Forecast, Version 3(UCERF3),2015:1-26.
[58] Sieh K E, Natawidjaja D H, Meltzner A J, et al. Earthquake supercycles inferred from sea-level changes recorded in the corals of west Sumatra[J]. Science, 2008,322(5908):1674-1678.
[59] Grant-Ludwig L, Akçiz S O, Noriega G R, et al. Climate-modulated channel incision and rupture history of the San Andreas fault in the Carrizo Plain[J]. Science, 2010,27:1117-1119.
[60] Akciz S, Ludwig L, Arrowsmith J, et al. Century-long average time intervals between earthquake ruptures of the San Andreas fault in the Carrizo Plain, California[J]. Geology, 2010,38:787-790.
[61] Weldon R J Ⅱ, Scharer K, Fumal T, et al. Wrightwood and the earthquake cycle:What a long recurrence record tells us about how faults work[J]. GSA Today,2004,14(9):4-10.
[62] Stein S, Newman A. Characteristic and uncharacteristic earthquakes as possible artifacts:Applications to the New Madrid and Wabash seismic zones[J].Seismol. Res. Lett., 2004, 75:173-187.
-
