滇西哀牢山构造带变质岩系LA-ICP-MS锆石U-Pb年龄及其地质意义
LA-ICP-MS zircon U-Pb dating of the metamorphic rocks in the Ailaoshan tectonic belt, western Yunnan, and its geological implications
-
摘要: 为厘定哀牢山岩群的时代和大地构造归属,选取哀牢山岩群中的花岗质片麻岩(SM-15)、花岗闪长质片麻岩(SM-22)、同变形的花岗质岩脉(SM-18)及紧邻哀牢山岩群的变质砂岩(NO-1)为研究对象,运用LA-ICP-MS锆石U-Pb定年法对其进行定年。结果显示,样品SM-15中有岩浆锆石和变质锆石2类,岩浆锆石的年龄集中于722~740Ma之间,变质锆石的206Pb/238U年龄加权平均值为29.9±0.5Ma。样品SM-22中2组206Pb/238U年龄加权平均值,原岩年龄为232.3±4.3Ma;后期变质重结晶年龄为29.2±0.4Ma。样品SM-18中锆石206Pb/238U年龄加权平均值为27.19±0.36Ma,代表变质年龄。样品NO-1中的碎屑锆石年龄分4组:246~276Ma、600~800Ma、800~1000Ma和1000Ma以上。以上年龄数据表明,哀牢山岩群中至少包括元古宙岩浆岩(722~740Ma)、二叠纪末-三叠纪初岩浆岩或地层(235~255Ma),以及新近纪岩浆岩(27~32Ma),是一个复杂的变质岩带,而不是以往认为的全部属于元古宙扬子地台的结晶基底。哀牢山岩群的主变质时代集中在27~32Ma之间,哀牢山岩群现今的面貌主要在这一时期成型。Abstract: In order to determine the age of Ailaoshan Group and its tectonic affinity, the authors chose granodioritic gneiss (SM-15 and SM-22), its synchronic deformational granite vein intrusion (SM-18) in the high-grade metamorphic rock series and its proximate meta-sandstone (NO-1) in the low-grade metamorphic rock series as research objects and present new results of zircon U-Pb dating of four samples so as to do the accurate chronology tests. Two groups of ages were identified in sample SM-15 and SM-22. In sample SM-15, the older magmatic group yielded an age of 722~740Ma and the metamorphic younger group yielded an age of 29.9±0.5Ma. In sample SM-22, the older is 232.3±4.3Ma and the younger is 29.2±0.4Ma. In addition, the zircons from sample SM-18 yielded a concordant U-Pb ages of 27.19±0.36Ma. A total of 30 spots analyses of sample NO-1 defined four age groups at 246~276Ma, 600~800Ma, 800~1000Ma and >1000Ma respectively. From these data, the authors have drawn some conclusions: Firstly, the Ailaoshan Group consists of at least three stages of tectonic and magmatic activities, i.e., the 722-740Ma and 235±10Ma igneous rocks and sedimentary rocks, and the 27-32Ma igneous rocks. The metamorphic rocks in the study area are unlikely to be of the Yangtze Plate; Secondly, the peak metamorphism deformation time of Ailaoshan Group was about 27-32Ma.
-
-
[1] 刘俊来,唐渊,宋志杰,等.滇西哀牢山构造带:结构与演化[J].吉林大学学报(地球版),2011,41(5):1295-1303.
[2] 张建国.中越红河断裂带活动性研究[D]. 中国科学技术大学博士学位论文, 2009:1-3.
[3] 钟大赉.滇川西部古特提斯造山带[M].北京:科学出版社,1998:1-231.
[4] 云南省地质矿产局.云南省区域地质志[M].北京:地质出版社. 1990:1-658.
[5] 虢顺民,计凤桔,向宏发,等.红河活动断裂带[M].北京:海洋出版社,2001:1-20.
[6] 王冬兵,唐渊,廖世勇,等.滇西哀牢山变质岩系锆石U-Pb定年及其地质意义[J].岩石学报,2013,29(4):1261-1278.
[7] 李宝龙,季建清,付孝悦,等.滇西点苍山-哀牢山变质岩系变质时限研究[J].岩石学报,2009,25(3):595-608.
[8] 戚学祥,朱路华,李化启,等.青藏高原东缘哀牢山-金沙江构造带糜棱状花岗岩的LA-ICP-MS U-Pb定年及其构造意义[J].地质学报,2010,84(3):357-369.
[9] 段新华,赵鸿.论哀牢山一藤条河断裂古板块俯冲带[J].地质学报, 1981,55(4):258-266.
[10] 吴海威,张连生,嵇少丞.红河-哀牢山断裂带——喜山期陆内大型左行走滑剪切带[J].地质科学,1989,1:1-8.
[11] 王义昭,丁俊.云南哀牢山中深变质岩系构造变形特征及演变[J]. 特提斯地质,1996,20:52-70.
[12] 范晨子,胡明月,赵令浩,等.锆石铀-铅定年激光剥蚀-电感耦合等离子体质谱原位微区分析进展[J].岩矿测试,2012,31(1):29-46.
[13] Ludwing K R. User's manual for Isoplot 3.00:a geochronological toolkit for Microsoft Excel[J]. Berkeley Geochronology Center Special Publication,2003, 4:1-70.
[14] Compston W,Williams I S,Kirschvink J L,et al.Zircon U-Pb ages for the Early Cambrian time-scale[J]. Geol. Sci. London.,1992,149:171-184.
[15] Rubatto D,Gebauer D.Use of cathodoluminescence for U-Pb zircon dating by IOM Microprobe:Some examples from the western Alps[C]//Cathodoluminescence in Geoscience. Springer-Verlag Berlin Heidelberg,Germany, 2000:373-400.
[16] 黄汲清.中国主要地质构造单位[M].北京:地质出版社,1954:101-103.
[17] 范承钧.云南哀牢山构造变质带[J].云南地质,1986,5(4):281-290.
[18] 翟明国,从柏林,乔广生,等.中国滇西南造山带变质岩的Sm-Nd和Rb-Sr同位素年代学[J].岩石学报,1990,4:1-11.
[19] 王凯元.论哀牢山构造变质带的几个主要问题[J].云南地质, 1993,12(1):130-135.
[20] 刘翠,邓晋福,刘俊来,等.哀牢山构造岩浆带晚二叠世-早三叠世火山岩特征及其构造环境[J].岩石学报,2011,27(11):3590-3602.
[21] 李龚健,王庆飞,禹丽,等.哀牢山古特提斯洋缝合时限:晚二叠世花岗岩类锆石U-Pb年代学与地球化学制约[J].岩石学报, 2013,29(11):3883-3900.
[22] 刘汇川,王岳军,蔡永丰,等.哀牢山构造带新安寨晚二叠世末期过铝质花岗岩锆石U-Pb年代学及Hf同位素组成研究[J].大地构造与成矿学,2013,37(1):87-98.
[23] 李宝龙,季建清,付孝悦,等.滇西点苍山-哀牢山变质岩系锆石SHRIMP定年及其地质意义[J].岩石学报,2008,24(10):2322-2330.
[24] Scharer U,Tapponnier P,Lacassin R,et al. Intraplate tectonics in Asia:A precise age for large-scale Miocene movement along the Ailao Shan-Red River shear zone,China[J]. Earth and Planetary Science Letters,1990,97(1/2):65-77.
[25] Harrison T M, Leloup P H, Ryerson F J, et al. Diachronous initiation of transtension along the Ailao Shan-Red River shear zone, Yunnan and Vietnam[C]//Yin A, Harrison T M.The Tectonic Evolution of Asia.New York:Cambridge University Press,1996:208-226.
[26] Tapponnier P,Lacassin R,Leloup P H,et al.The Ailao Shan-Red River metamorphic belt:Tertiary left-lateral shear between Indochina and South China[J].Nature,1990,343:431-437.
-
