西藏聂荣变质杂岩及邻区逆冲推覆与构造隆升时代
Thrust structures and uplift periods of the Nyainrong metamorphic complex and its neighboring areas
-
摘要: 通过详细的野外观测结合地质填图资料，在聂荣变质杂岩及邻区厘定大规模逆冲推覆构造，不同时代的逆冲岩席自北-北东向南-南西逆冲推覆于上白垩统红层及下伏岩石地层之上，形成大量逆冲断层、滑脱构造、飞来峰、构造窗和褶皱构造。逆冲推覆构造运动导致侏罗纪蛇绿混杂岩、石炭系-二叠系构造层、古生界浅变质岩、变质基底之间发生拆离滑脱，在聂荣变质杂岩内部形成韧性剪切带和高角度斜冲断层。在唐古拉山口南侧形成北西-南东向土门-托纠-杂色右旋走滑断裂，走滑断裂末端转换为近东西向逆冲推覆构造。聂荣变质杂岩顶部逆冲推覆叠加滑覆，导致侏罗系混杂堆积和古生界沉积盖层向南西-西向运移86～110km，在那曲-巴尔达-班戈北形成近东西向长透镜状懂错蛇绿混杂岩逆冲岩席，沿缓倾斜断层发育向西倾斜的构造片理、摩擦镜面和近东西走向的矿物线理。裂变径迹测年表明，聂荣变质杂岩及邻区逆冲推覆及构造隆升时代主要为早白垩世晚期-晚白垩世早期（111±5～91±5Ma）、晚白垩世晚期（89±6～69±5Ma）、古新世晚期-始新世早期（55±4～44±2Ma），估算构造隆升视速率为0.10～0.69mm/a，部分断层逆冲推覆及构造隆升延续至古近纪晚期。综合各类观测资料，建立不同时期构造模式，探讨聂荣变质杂岩及邻区逆冲推覆构造演化过程及形成机理。Abstract: Regional thrust systems consisting of thrust faults, tectonic slices and sheets, nappes, structural windows and accompanied folds were discovered in the Nyainrong metamorphic complex and its neighboring areas on the basis of field studies and geological mapping. Tectonic slices and thrust sheets surrounding the Nyainrong metamorphic complex were thrust southwest-westward over the Upper Cretaceous red beds and the Jurassic-Lower Cretaceous marine sedimentary rocks. Regional intensive thrust led to detach-ments among the ophiolite and Jurasssic mélanges, the Carboniferous-Permian clastic-carbonate, the Paleozoic low-grade metamor-phic rocks and the high-grade metamorphic basement, accompanied by ductile shear zones and oblique thrust faults in the Nyainrong metamorphic complex. Dextral-slip fault trending in northwest-southeast direction along the Tumen-Tuojiu-Zase zone trans-formed to regional thrust systems trending in east-west direction in southern Tanggula Range. Regional thrust and gravitational slide resulted in 86~120km southwest-westward movement of the Jurassic mélange and the Paleozoic covering layers, forming the Dong Co tectonic sheets of ophiolite mélanges along the Naqu-Baerda-North Baingoin in the west-southwest of the Nyainrong meta-morphic complex. Tectonic schist, slikensides and linear minerals trending in east-west direction were formed along the detachment faults beneath the Dong Co thrust slices of ophiolite mélanges. Fission-track dating indicates that thrust uplift mainly occurred at the late stage of the Early Cretaceous-the early stage of the Late Cretaceous (111±5~91±5Ma), late stage of the Late Cretaceous (89±6~69±5Ma) and Late Paleocene-Early Eocene (55±4~44±2Ma), and the corresponding rates of thrust uplift range from 0.10mm/a to 0.69mm/a in the Nyainrong metamorphic complex and its neighboring areas. Thrust uplift also occurred in Late Eocene and Oligo-cene in some areas. The process and mechanism of regional thrust in the Nyainrong metamorphic complex and its neighboring areas are discussed on the basis of the data available.
-
-
[1] 王明, 李才, 谢明超, 等. 聂荣微陆块胡刚片麻岩锆石LA-ICPMS U-Pb定年——新元古代基底岩石的发现及其意义[J]. 岩石学报, 2012, 28(12):4101-4108.
[2] 陆露. 西藏聂荣微陆块构造演化与隆升过程[D]. 中国地质科学院博士学位论文, 2014:1-114.
[3] 解超明, 李才, 苏犁, 等. 藏北聂荣微陆块泛非-早古生代构造热事件:年代学与地球化学制约[J]. 中国科学:地球科学, 2014, 44(3):414-428.
[4] 赖绍聪, 刘池阳. 青藏高原安多岛弧型蛇绿岩地球化学及成因[J]. 岩石学报, 2003, 19(4):675-682.
[5] 叶培盛, 吴珍汉, 胡道功, 等. 西藏东巧蛇绿岩的地球化学特征及其形成的构造环境[J].现代地质, 2004, 18(3):309-315.
[6] 夏斌, 徐力峰, 韦振权, 等. 西藏东巧蛇绿岩中辉长岩锆石SHRIMP丁定年及其地质意义[J]. 地质学报, 2008, 82(4):528-531.
[7] 孙立新, 白志达, 徐德斌, 等. 西藏安多蛇绿岩中斜长花岗岩地球化学特征及锆石U-Pb SHRIMP年龄[J]. 地质调查与研究, 2011, 34(1):10-15.
[8] 黄强太, 夏斌, 李强, 等. 西藏东巧地区玄武岩地球化学特征及构造环境分析[J]. 沉积与特提斯地质, 2015, 35(2):97-103.
[9] 白志达, 徐德斌, 陈梦军, 等. 西藏安多地区粗面岩的特征及其锆石SHRIMP U-Pb定年[J]. 地质通报, 2009, 28(9):1229-1235.
[10] 刘敏, 朱弟成, 赵志丹, 等. 藏北聂荣地区早侏罗世的岩浆混合作用及构造意义[J]. 岩石学报, 2010, 26(10):3117-3130.
[11] 彭智敏, 耿全如, 张璋, 等. 西藏那曲地区流纹岩LA-ICP-MS锆石U-Pb年龄和地球化学特征[J]. 地质通报, 2011, 30(7):1050-1059.
[12] 费光春, 赵发明, 许家斌, 等. 藏北安多县白垩纪马登火山岩地球化学特征及地质意义[J]. 矿物岩石, 2014, 34(1):46-51.
[13] 肖序常, 李廷栋. 青藏高原的构造演化与隆升机制[M]. 广州:广东科学出版社, 2000.
[14] 吴珍汉, 吴中海, 胡道功, 等. 青藏高原新生代构造演化与隆升过程[M]. 北京:地质出版社, 2009:1-331.
[15] 解超明, 李才, 王明, 等. 藏北聂荣微陆块的构造亲缘性——来自LA-ICP-MS锆石U-Pb年龄及Hf同位素的制约[J]. 地质通报, 2014, 33(11):1778-1792.
[16] Pan G T, Wang L Q, Li R S, et al. Tectonic evolution of the Ti-betan Plateau[J]. Journal of Asian Earth Sciences, 2012, 53(2012):3-14.
[17] Lu L, Zhao Z, Wu Z H, et al. Fission track thermochronology evi-dence for the Cretaceous and Paleogene tectonic events of the Nyainrong microcontinent, Tibet[J]. Acta Geologica Sinica, 2015, 89(1):133-144.
[18] 潘桂棠, 丁俊. 青藏高原及邻区地质图及说明书(1:1500000)[M]. 成都:成都地图出版社, 2004:1-140.
[19] 张晓冉, 史仁灯, 黄启帅, 等. 青藏高原安多高压麻粒岩的发现及其地质意义[J]. 科学通报, 2010, 55(27/28):2701-2711.
[20] Wu Z H, Barosh P J, Ye P S, et al. Late Cretaceous tectonic frame-work of the Tibetan Plateau[J]. Journal of Asian Earth Sciences, 2015, 114(2105):693-703.
[21] Wu Z H, Hu D G, Ye P S, et al. Early Cenozoic Tectonics of the Tibetan Plateau[J]. Acta Geologica Sinica, 2013, 87(2):289-303.
[22] Wu Z H, Ye P S, Barosh P J, et al. Early Cenozoic Multiple Thrusts in the Tibetan Plateau[J]. Journal of Geological Research, 2013:1-12.
[23] Wu Z H, Yang Y, Barosh P J, et al. Tectonics and Topography of the Tibetan Plateau in Early Miocene[J]. Acta Geologica Sinica, 2014, 88(2):410-424.
[24] 吴珍汉, 叶培盛, 杨艳. 西藏阿里推覆构造与蛇绿岩构造侵位[J]. 中国地质, 2013, 40(1):182-189.
[25] 吴珍汉, 高锐, 卢占武, 等. 羌塘盆地结构构造与油气勘探方向[J]. 地质学报, 2014, 88(6):1130-1144.
[26] Wu Z H, Ye P S, Barosh P J, et al. Early Cenozoic mega thrusting in the Qiangtang block of the Northern Tibetan Plateau[J]. ACTA Geologica Sinica, 2012, 86(4):799-809.
[27] Ren Z L, Cui J P, Liu C Y, et al. Apatite fission track evidence for uplift cooling in the Qiangtang basin and constrains for the Tibetan Plateau uplift[J]. Acta Geologica Sinica, 2015, 89(2):467-484.
[28] Hurford A J, Hunziker J C, Stockhert B. Constraints on the late thermotectonic evolution of western Alps:evidence for episodic rapid uplift[J]. Tectonics, 1991, 10(4):758-769.
[29] Naeser C W, Izett G A, Obradovich J D. Fission-track and K-Ar ages of natural glasses[M]. United States Government Printing Of-fice, Washington, 1980.
[30] Stock J, Molnar P. Uncertainties and implications of the late Creta-ceous and Tertiary position of North America relative to the Faral-lon, Kula and Pacific Plates[J]. Tectonics, 1988, 7:1339-1284.
[31] Lee T Y, Lawver A L. Cenozoic plate reconstruction of southeast Asia[J]. Tectonophysics, 1995, 251:85-138.
-
