基于SVI方法的折射波信噪比改善效果研究

邵宇蓝; 李唐律; 廖仪; 童思友; 吴志强

基于SVI方法的折射波信噪比改善效果研究

1 中国海洋大学海底科学与探测技术教育部重点实验室, 青岛 266100;

2 青岛海洋地质研究所, 青岛 266071

基金项目:
国土资源部地质调查专项(GZH200800503,GZH201200509)

国家自然科学基金重点项目(41230318,41210005)

详细信息

作者简介: 邵宇蓝(1987-),男,在读硕士,主要从事地震资料处理方法研究工作.E-mail:sean_880618@hotmail.com

通讯作者: 童思友(1969—),男,博士,教授,主要从事海洋地球物理方法研究工作.E-mail:tsy@ouc.edu.cn

中图分类号: P631.4

收稿日期: 2014-02-27

REFRACTION WAVE SNR IMPROVEMENT BASED ON SVI METHOD

1 Key Lab of Submarine Geosciences and Prospecting Techniques, Ministry of Education, Ocean University of China, Qingdao 266100, China;

2 Qingdao Institute of Marine Geology, Qingdao 266071, China

More Information

Corresponding author: TONG Siyou, tsy@ouc.edu.cn

Received Date: 27 February 2014

摘要

摘要: 折射波在地震勘探中有非常重要的作用,但由于近地表噪声等因素影响,折射波在地震记录上往往能量较弱,信噪比较低。因此,Bharadwaj、Mallinson等提出了超虚拟折射干涉法(Supervirtual refraction interferometry-SVI),用于提高折射波的信噪比。在此基础上,结合正演模拟数据和实际资料,对该方法的抗噪性以及相关叠加道数、褶积叠加道数等因素对处理效果的影响进行了研究,结果表明,对于信噪比>0.2的资料,在满足一定相关叠加道数和褶积叠加道数时,使用本方法后能使信噪比得到显著增强。
- 超虚拟折射干涉法 /
- 初至折射波 /
- 信噪比 /
- 互易方程
Abstract: The refraction wave plays an important role in the seismic exploration. However, the amplitude and the signal-to-noise ratio(SNR) of refraction are always low because of many factors, such as near-surface noise and attenuation. Supervirtual refraction interferometry(SVI) was proposed by Bharadwaj, Mallinson, etc (2011) to improve the SNR of refraction. In this article, some experiments were conducted to analyzing the resistance of SVI method to noise and the influence of the numbers of correlation and convolution traces on processing effect. It illustrates that for the data which contain a SNR greater than 0.2, the SNR can be improved a lot after implementing the SVI method as long as the requirement for number of correlation and convolution traces was met.
- supervirtual refraction interferometry /
- head-wave refraction /
- signal-to-noise ratio /
- reciprocal equation
