HEAT FLOW MEASUREMENTS IN THE XISHA TROUGH OF THE SOUTH CHINA SEA
-
摘要: 为了解南海西沙海槽区的地热特征,利用Ewing型地热探针在该区开展了地热测量,并利用TK04热导率仪测量了相关站位表层沉积物样品的热导率,获得了7个站位的热流数据。结果表明,研究区7个站位的热导率变化范围为0.88~1.06 W/m·K,平均为0.96 W/m·K,地温梯度变化范围为85~120℃/km,热流值变化范围为83~112 mW/m2,平均达到95 mW/m2。分析表明测量结果与20世纪80年代中美合作在西沙海槽的地热测量结果一致性较好,说明研究区仍具有高热流特征,推测高热流特征可能与本区高热背景、莫霍面埋深较浅、断裂发育、晚期岩浆活动和基底起伏等有关。Abstract: To investigate the geothermal characteristics in the Xisha Trough of the South China Sea, geothermal measurements were done in the area with a Ewing type heat probe, and thermal conductivities of the samples, collected from the heat flow sites, were measured with a thermal conductivity meter of TK04, and a heat flow profile with 7 heat flow stations was successfully obtained. The results show that the thermal conductivity of the top sediment ranges from 0.88 to 1.06 W/m·K, with an average of 0.96 W/m·K, and geothermal gradient ranges from 85 to 120℃/km, and heat flow ranges from 83 to 112 mW/m2, with an average of 95 mW/m2, which is according with the results of the geothermal measurement in the Xisha Trough area jointly conducted by the scientists of China and USA in 1980s. The accordance of two different measurements suggests that heat flow in the area is really quite high. The character of high heat flow is thought to be related with both regional and local factors, such as high heat flow background, the uplifted Moho surface, faulting activities, latest magmatism, and the undulation of the basement.
-
Key words:
- heat probe /
- geothermal gradient /
- thermal conductivity /
- marine heat flow /
- Xisha Trough
-
-
[1] 何廉声,王光宇,石效超. 西沙海槽——新生代裂谷[J].地质论评,1980,26(6):486-489.
[HE Lian-sheng, WANG Guang-yu, SHI Xiao-chao. Xisha Trough-a Cenozoic rift[J]. Geological Review, 1980, 26(6):486-489.]
[2] Taylor B, Hayes D E. Origin and history of the South China Sea Basin[C]//Hayes D E,Ed. The Tectonic and Geologic Evolution of Southeast Asian Seas and Islands.Am. Geophys. Union Geophys. Monogr., 1983, 27:23-56.
[3] 姚伯初,曾维军,陈艺中,等. 南海西沙海槽——一条古缝合线[J]. 海洋地质与第四纪地质,1994,14(1):1-10.
[YAO Bo-chu, ZENG Wei-jun, CHEN Yi-zhong,et al. Xisha Trough of South China Sea-An ancient suture[J]. Marine Geology and Quaternary Geology, 1994, 14(1):1-10.]
[4] 徐行,陆敬安,罗贤虎,等.南海北部海底热流测量及分析[J].地球物理学进展,2005, 20(2):562-565.
[XU Xing, LU Jing-an,LUO Xian-hu, et al. The marine heat flow survey and the result discussion in the northern part of South China Sea[J]. Progress in Geophysics, 2005, 20(2):562-565.]
[5] 饶春涛.珠江口盆地地热特征[J].南海东部石油,1994,1:10-18.[RAO Chun-tao. Geothermal characters of Pearl River Mouth Basin[J]. Eastern Petroleum of South China Sea, 1994
, 1:10-18.]
[6] 胡圣标,张容燕,罗毓晖,等. 渤海盆地地热历史及构造-热演化特征[J]. 地球物理学报,1999,42(6):748-755.
[HU Sheng-biao, ZHANG Rong-yan, LUO Yu-hui,et al. Thermal history and tectonic-thermal evolution of Bohai Basin, East China[J]. Chinese Journal of Geophysics, 1999, 42(6):748-755.]
[7] 王良书,刘绍文,肖卫勇,等.渤海盆地大地热流分布特征[J].科学通报,2002, 47(2):151-155.
[WANG Liang-shu, LIU Shao-wen, XIAO Wei-yong, et al. Distribution characteristics of heat flow in Bohai Basin[J]. Chinese Science Bulletin, 2002, 47(2):151-155.]
[8] HE Li-juan, XIONG Liang-ping, WANG Ji-yang. Heat flow and thermal modeling of the Yinggehai Basin, South China Sea[J]. Tectonophysics, 2002,351:245-253.
[9] 杨树春,胡圣标,蔡东升,等. 南黄海南部盆地地温场特征及热-构造演化[J]. 科学通报,2003,48(14):1564-1569.
[YANG Shu-chun,HU Sheng-biao,CAI Dong-sheng,et al. Geothermal field and thermotectonic evolution in Southern South Yellow Sea Basin[J]. Chinese Science Bulletin, 2003, 48(22):2466-2471.]
[10] 喻普之,李乃胜.东海地壳热流[M].北京:海洋出版社,1992.[YU Pu-zhi,LI Nai-sheng.Heat Flow in Crust of the East China Sea[M].Beijing:China Ocean Press,1992.]
[11] 李乃胜.冲绳海槽地热[M].青岛:青岛出版社,1995.[LI Nai-sheng.Heat Flow in the Okinawa Trough[M].Qingdao:Qingdao Press,1995.]
[12] QIAN Yi-peng, NIU Xiao-ping, YAO Bo-chu,et al. Geothermal Pattern Beneath the continental margin in the northern part of the South China Sea[C]. CCOP/TB,1995,25:89-104.
[13] Nissen S S, Hayes D E, YAO Bo-Chu.Gravity heat flow, and seismic constraints on the processes of crustal extension:Northern margin of the South China Sea[J]. Journal of Geophysical Research, 1995,100(B11):22447-22483.
[14] 夏戡原. 南沙群岛及其邻近海区地质地球物理与油气资源[M]. 北京:科学出版社,1996:93-97.[XIA Kan-yuan. The Geological and Geophysical Characteristics and Oil and Gas Resources in the Nansha Islands and Its Neighboring Sea Waters[M]. Beijing:Science Press,1996:93
-97.]
[15] 徐行,罗贤虎,肖波.海洋地热流测量技术及其方法研究[J].海洋技术,2005,24(1):77-81.
[XU Xing,LUO Xian-hu,XIAO Bo. Research on the methods&technique of marine heat flow measurement[J].Ocean Technology, 2005, 24(1):77-81.]
[16] 徐行,施小斌,罗贤虎,等.南海北部海底地热测量的数据处理方法[J].现代地质,2006.[XU Xing, SHI Xiao-bin, LUO Xian-hu, et al. Data processing of geothermal measurements in the northern margin of the South China Sea[J]. Geoscience, 2006.]
[17] Pfender M, Villinger H. Miniaturized data loggers for deep sea sediment temperature gradient measurements[J]. Marine Geology, 2002, 186:557-570.
[18] TEXAS A&M University. Initial Report Proceedings of the Ocean Drilling Program, 184[C]. 2000.
[19] Ratcliffe E H. The thermal conductivities of ocean sediments[J]. Journal of Geophysical Research, 1960, 65(5):1535-1541.
[20] Hyndman R D,Erickson A J,von Herzen R P. Geothermal measurement on DSDP Leg 26[C]//Davies T A,Luyendyk B P,et al. Proc. DSDP, Init. Repts. 1974, 26:451-463.
[21] Shyu C, Liu C. Heat flow of the Southwestern end of the Okinawa Trough[J]. TAO, 2001(Sup.):205-317.
[22] Shi X, Qiu X, Xia K, et al. Characteristics of the surface heat flow in the South China Sea[J]. Journal of Asian Earth Sciences, 2003, 22(3):265-277.
[23] 姚伯初, 曾维军, Hayes D E,等. 中美合作调研南海地质专报[C]. 武汉:中国地质大学出版社, 1994:34-140.[YAO Bo-chu,ZENG Wei-jun,Hayes D E,et al.Report on Sino-America Survey of the South China Sea Geology[C].Wuhan:China University of Geosciences Press,1994:34
-140.]
[24] Qiu X, Ye S, Wu S, et al. Crustal structure across the Xisha Trough, Southwest South China Sea[J]. Tectonophysics,2001,341:179-193.
[25] 丘学林,施小斌,阎贫,等.南海北部地壳结构的深地震探测和研究进展[J].自然科学进展, 2003,13(3):231-236.
[QIU Xue-lin, SHI Xiao-bin, YAN Pin, et al. Recent progress of deep seismic experiments and studies of crustal structure in northern South China Sea[J]. Progress in Natural Science, 2003, 13(7):481-488.]
[26] 刘祖惠,王启玲,袁恒涌,等. 南海海域布格重力异常图及莫霍面等深图[J]. 热带海洋,1983,2(2):167-171.
[LIU Zu-hui, WANG Qi-ling, YUAN Heng-yong, et al. Contours of Bouguer's gravity anomalies and depths of mohorovicic discontinuity in South China Sea[J]. Tropic Oceanology, 1983, 2(2):167-171.]
[27] 施小斌,周蒂,张毅祥,等.南海西沙海槽岩石圈的密度结构与热流变结构[J]. 热带海洋学报, 2002,21(2):23-31.
[SHI Xiao-bin, ZHOU Di, ZHANG Yi-xiang, et al. Density, thermal and rheological structures of Xisha Trough, South China Sea[J]. Journal of Tropical Oceanography, 2002, 21(2):23-31.]
[28] McKenzie D. Some remarks on the development of sedimentary basins[J]. Earth and Planetary Science Letters, 1978, 40:24-32.
[29] 张健, 汪集旸.南海北部大陆边缘深部地热特征[J].科学通报,2000,45(10):1095-1100.
[ZHANG Jian, WANG Ji-yang. The deep thermal characteristic of continental margin of the northern South China Sea[J]. Chinese Science Bulletin, 2000, 45(18):1717-1722.]
-
