陕北富县探区延长组长3储层特征及评价
Characteristic and Evaluation of Chang 3 Member Reservoir of the Yanchang Formation in the Fuxian Area, North Shaanxi
-
摘要: 陕北富县探区延长组长3油层为该区的主力产层之一。长3油层属于三角洲前缘亚相沉积环境,其储层的主要成因类型为水下分流河道砂体、河口坝砂体,次为前缘席状砂和远砂坝。通过对80个样品的统计及分析,储层的矿物成分成熟度低,结构成熟度中等—好。储层的成岩作用类型繁多,但主要以压实及压溶作用、胶结作用和溶解作用为主,且主要处于晚成岩阶段的A期,成岩演化阶段分为3个:压实作用及粘土矿物胶结孔隙缩小期、胶结充填孔隙缩小期及溶解作用孔隙扩大期。通过对18口井1 683块样品的物性分析资料的分析,长3油层属于低孔—特低渗储层,孔隙类型以剩余粒间孔、粒内溶蚀孔为主。储层主要受沉积作用和成岩作用的影响。根据以上资料,把长3油层划分为好、中、差三类储层,长32的物性较好;长31、长33的物性较差。Abstract: The oil-bearing Chang-3 member of the Yanchang Formation is one of the major oil producing formations in the Fuxian area,north Shaanxi. Chang-3 member belongs to an environment of delta frontal subfacies. The primary types of the reservoirs include distributary channel sandbodies,river mouth bar sandbodies. The secondary types are front-mat sand and distal bars. Statistics and analysis for 80 simples indicate that mineral maturity of Chang 3 reservoir is low,and textural maturity is medium-low. Reservoir diagensis types are relatively comlex and mainly consist of compaction, cementation and dissolution in the A period of the late stage. Diagenesis evolution can be divided into three stages:compaction and cementation to pore reduction,cementation,infilling and pore reduction and corrosion to pore enlargement. Petrophysical property analyses of 1747 simples from 18 wells show that the physical property of the Chang-3 member reservoir is of low porosity and very low permeable reservoir. Pore types are characterized by residual protozoal intergranular porosity and dissolution porosity. The reservoir is closely controlled by sedimentation and diagenesis. It is suggested that the Chang-3 reservoir can be divided into the high quality excellent,the intermediate quality and the low quality reservoirs. The physical property of the Chang 32 reservoir is bettern that Chang 31 and Chang 33.
-
Key words:
- characteristic of reservoir /
- evaluation of reservoir /
- diagenesis /
- structure of pore
-
-
陕北富县探区延长组储层精细评价研究.
文玲,胡书毅,田海芹.靖安油田延长组长6段低孔低渗透储层特征及评价[J].西北地质,2001,34(4):52-61.
孙东胜,李文山,罗记虹,等.陕北新庄地区延长组长2油层组储层特征[J].西北地质,2003,36(1):59-61.
武刚.低渗透砂岩储层成岩作用研究及有利储集区预测[J].新疆石油学院学报,2004,16(4):1-9.
李凤杰,王多云,徐旭辉.鄂尔多斯盆地陇东地区三叠系延长组储层特征及影响因素分析[J].石油试验地质,2005,27(4):364-369.
杨琦.查干凹陷下白垩统碎屑岩储集层特征研究[J].西北地质,2000,33(3):13-17.
李春玉,谢渊,刘绍光,等.陕北富县延长组特低孔渗砂岩储层控制因素分析[J].成都理工学院学报,2002,29(3):284-290.
庞雯,郭德运,赵靖舟,等.鄂尔多斯盆地甘谷驿油田东区长6油层储层特征及储层评价[J].兰州大学学报,2004,40(5):94-100.
史基安,王金鹏,毛明陆,等.鄂尔多斯盆地西峰油田三叠系延长组长6-8段储层砂岩成岩作用研究[J].沉积学报,2003,21(3):371-378.
谢庆邦,贺静.陕甘宁盆地南部延长组低渗砂岩储层评价[J].天然气工业,1994,14(3):16-19.
张金亮,司学强,梁杰,等.陕甘宁盆地庆阳地区长8油层砂岩成岩作用及其对储层性质的影响[J].沉积学报,2004,22(2):225-232.
张金亮,梁杰,杜桂林.安塞油田长2油层成岩作用及其对储层物性的影响[J].西北地质,2004,37(4):50-58.
武富礼,李文厚,李玉宏,等.鄂尔多斯盆地上三叠统延长组三角洲沉积及演化[J].古地理学报,2004,6(3):307-315.
夏青松,田景春,张锦泉,等.鄂尔多斯盆地陇东地区三叠系延长组长6-长8储层评价及有利区带预测[J].油气地质与采收率,2003,10(4):10-16.
牟泽辉.鄂尔多斯盆地庆阳以南三叠系延长组长5、长6、长7储层成岩作用[J].天然气工业,2001,21(2):10-18.
罗静兰,张晓莉,张云翔,等.成岩作用对河流-三角洲相砂岩储层物性演化的影响[J].沉积学报,2001,19(4):541-548.
杨晓萍,裘怿楠.鄂尔多斯盆地上三叠统延长组浊沸石的形成机理、分布规律与油气关系[J].沉积学报,2002,20(4):628-632.
Li Chunyu,Xie Yuan,Liu Shaoguang,et al.Factors controlling the very low-porosity and permeability sandstone reservoir of the Yanchang formation in Fuxian area,north shaanxi[J].Journal of Chengdu University of Tecnology,2002,29(3):284-290.
Li Fengjie,Wang Duoyun,Xu Xuhui.The influential factors and characteristics of Triassic Yangchang formation reservoir in Longdong area,Ordos basin[J].Petroleum Geology and Experiment,2005,27(4):364-369.
Luo Jinglan,Zhang Xiaoli,Zhang Yunxiang,et al.The diagenetic impact on reservoir quality evolution of fluvial deltaic sandstones[J].Acta Sedimentologica Sinica,2001,19(4):541-548.
Mou Zehui.Diageneses of the reservoirs Chang 5,Chang 6 and Chang 7 of Yangchang formation of Triassic to the south of Qingyang in Ordos basin[J].Nature Gas Industry,2001,21(2):10-18.
Pang Wen,Guo Deyun,Zhao Jingzhou,et al.Reservoir feature and evaluation of oil-bearing Chang2 bed in the east of Ganguyi oil field in Ordos basin[J].Journal of Lanzhou University,2004,40(5):94-100.
Shi Ji'an,Wang Jinpeng,Mao Minglu,et al.Reservoir sandstone diagenesis of Chang 6 to 8 in Yanchang formation (Triassic),Xifeng oil field,Ordos basin[J].Acta Sedimentologica Sinica,2003,21(3):371-378.
Sun Dongsheng,Li Wenshan,Luo Jihong,et al.The reservoir characteristics of the Chang2 oil-bearing strata group of Yanchang formation in Xinzhuang area in the north of Shaanxi province[J].Northwestern Geology,2003,36(1):59-61.
Wen Ling,Hu Shuyi,Tian Haiqin.The characteristic and evaluation of reservoir of low porous and low permeable from Chang 6,the Yanchang Formation in Jing'an oil field[J].Northwestern Geology,2001,34(4):52-61.
Wu Gang.Study on low-permeability sandstone reservoir diagenesis and predicat ion of the advantageous reserve[J].Journal of Xinjiang Petroleum Institute,2004,16(4):1-9.
Wu Fuli,Li Wenhou,Li Yuhong,et al.Delta sediments and evolution of the Yanchang Formation of Upper Triassic in Ordos basin[J].Journal of Palaeogeography,2004,6(3):307-315.
Xia Qingsong,Tian Jingchun,Zhang Jinquan,et al.Reservoir evaluation and favorable area prospecting in Chang 6 to Chang 8 of the Triassic period in Longdong region,Ordos basin[J].Petroleum Geology and Recovery Efficiency,2003,10(4):10-16.
Xie Qingbang,He Jing.Reservoir evaluation on low permeability sandstone of Yanchang Formation in south part of Shanganning basin[J].Nature Gas Industry,1994,14(3):16-19.
Yang Qi.On features of lower Cretaceous clastic reservoir in Qagan Sag[J].Northwestern Geology,2000,33(3):13-17.
Yang Xiaoping,Qiu Yinan.Formation process and distribution of laumontite in Yangchang formation (Upper Triassic) of Ordos basin[J].Acta Sedimentologica Sinica,2002,20(4):628-632.
Zhang Jinliang,Si Xueqiang,Liang Jie,et al.Diagenesis of lacustrine deltaic sandstones and its impact on reservoir quality[J].Acta Sedimentologica Sinica,2004,22(2):225-232.
Zhang Jinliang,Liang Jie,Du Guilin.Diagenesis and its effect on reservoir quality in Chang2 reservoir of Ansai oil field[J].Northwestern Geology,2004,37(4):50-58.
-
