辽北地区中生代石英闪长岩的形成时代
Formation Age of Mesozoic Quartz-Diorite in Northern Liaoning
-
摘要: 辽北地区位于华北陆块和华北北缘古生代坳陷带2个Ⅱ级大地构造单元上，后期构造岩浆作用强烈，尤以侏罗纪岩浆活动最为强烈，广泛发育不同类型的花岗岩。关于研究区内中生代石英闪长岩的形成时代，一直缺乏深入的年代学研究。笔者在区内进行1：5万区域地质调查中，对石英闪长岩采样并作LA-ICP-MS测年，获得锆石U-Pb年龄为（173±0.88）Ma（MSWD=5.8），在一定误差范围内，综合所测锆石的CL图像特征，准确约束了区内中生代石英闪长岩的形成时代。结合前人资料将区内中生代石英闪长岩的形成时代确定为中侏罗世。这一成果为研究辽北地区岩浆作用及其构造演化提供了新的年代学证据。
-
关键词:
- 中生代 /
- 石英闪长岩 /
- LA-ICP-MS锆石U-Pb测年 /
- 形成时代 /
- 辽北地区
Abstract: The northern Liaoning is located in two secondary tectonic units of North China Craton and Paleozoic depression zone in northern margin of North China, with strong late tectonic magmatic activities, especially Jurassic magmatic activity is most intense, when different types of granites were widely developed.However, the formation times of the Mesozoic tonalite in this area is lack of depth research.When carrying out the 1:50 000 regional geological survey, the quartz diorite samples have been collected to carry out the LA-ICP-MS dating. The obtained U-Pb ages of zircons are (173+0.88) Ma (MSWD=5.8), which is in a certain error range. Based on the CL images of these zircons, the formation age of Mesozoic quartz diorite in this area has been restrained precisely. According to the previous results, the formation age of this quartz diorite has been defined as Middle Jurassic. This achievement provides a new chronology evidence for studying the magmatism and tectonic evolution of northern Liaoning.-
Key words:
- Mesozoic /
- quartz-diorite /
- LA-ICP-MS zircon U-Pbdating /
- formation age /
- northern Liaoning
-
-
王忠江,翟富荣,王岐,等.辽宁西丰大岩体的解体及其地质意义[J].地质与资源,2013,22(2):86-93. WANG Zhongjiang,ZHAI Furong,WANG qi,et al. Disintegration of the Xifengintrueive body in Liaoning province:geologicalimplication[J].Geological and Resources,2013,22(2):86-93.
代丽霞,辛玉莲,王伯臣,等.辽宁省开原市八棵树一带地质构造特征[J].吉林地质,2011,30(3):38-42. DAI Lixia,XIN Yulian,WANG Bochen, et al.Bakeshu geological structural characteristics of Kaiyuan City, Liaoning Province[J]. Geology of Jilin,2011,30(3):38-42.
孙罡,周凯,花艳秋,等.辽北-吉西南地区早白垩世富碱花岗岩地质特征[J].吉林地质,2008,27(4):20-25. SUN Gang,ZHOU Kai,HUA Yanqiu,et al. Geologic features of the early Cretaceous alkali-rich graniteof the northern part of Liaoning-southwestern part of Jilin Province[J]. Geology of Jilin, 2008,27(4):20-25.
陆孝平, 陈跃军,彭玉鲸,等.吉林省1:25万辽源市幅区域地质调查修测报告[R].吉林:吉林省地质调查院,2004.
刘锦,杨仲杰,豆世勇,等.辽宁省1:5万房木、八棵树等四幅区域地质矿产调查报告[R].辽宁:辽宁省地质矿产调查院,2015.
侯可军. LA-MC-ICP-MS锆石Hf同位素的分析方法及地质应用[J]. 岩石学报,2007,23(10):2595-2604. HOU Kejun. Laser ablation-MC-ICP-MS technique for Hf isotope microanalysis of zircon and its geological applications[J]. Acta Petrologica Sinica, 2007,23(10):2595-2604.
陈跃军,彭玉鲸,陆孝平,等.锆石U-Pb同位素定年的原理、方法及应用[J].吉林大学学报:地球科学版;2002,32(2):134-139. LU Yuejun,PENG Yujing,LU Xiaoping,et al.Proterozoic tectonic slices along the northern margin of north China plate[J]. Journal of Jilin University:Earth Science Editionv, 2002,32(2):134-139.
刘正宏, 刘雅琴, 冯本智. 锆石U-Pb同位素测年原理及应用[J].长春科技大学学报,2000,30(2):110-114. LIU Zhenghong,LIU Yaqin,FENG Benzhi.The establishment and tectonic evolution of proterozoicorogenic belt in the northmargin of north China plate[J]. Journal of Changchun University of Science and Technology.2000,30(2):110-114.
王来春,李艳.地学科技期刊中锆石U-Pb同位素测年误差的表示方法[J].辽宁地质,1998,1:28-39. WANG Laichun,LI Yan.Archean metamorphic plutonic rocks in YiXian county Liaoning Province[J]. Geology of Liaoning, 1998,1:28-39.
于淑艳,许英霞,郭正林,等.新疆苏普特背斜花岗岩和变安山质凝灰岩LA-ICP-MS锆石U-Pb年代学特征及意义[J].西北地质,2011,44(2):15-24. YU Shuyan,XU Yingxia,GUO Zhenglin,et al.LA-ICP-MS Zircon U-Pb Dating for Granite and Meta-Andesitic Tuff and Its Geological Significance——Case Study Supute Anticline in the Southern Margin of the Altay, Xinjiang[J].Northwestern Geology, 2011,44(2):15-24.
李甘雨,李永军,王冉,等.西准噶尔哈拉阿拉特组火山岩LA-ICP-MS锆石U-Pb年龄[J].西北地质,2015,(3):12-21. LI Ganyu,LI Yongjun,WANG Ran, et al.Zircon LA-ICP-MS U-Pb Dating of Volcanics in Hala'alate Formation of Western Junggar[J].Northwestern Geology, 2015,(3):12-21.
刘治博,张维杰.内蒙古阿拉善右旗杭嘎勒晚二叠世闪长岩地球化学特征和LA-ICP-MS锆石U-Pb定年[J].西北地质,2014,47(1):84-95. LIU Zhi bo,ZHANG Weijie.Geochemical Characteristics and LA-ICP-MS Zircon U-Pb Dating of the Late Permian Diorite in Hanggale, Alax Right Banner, Inner Mongolia[J].Northwestern Geology, 2014,47(1):84-95.
MOREL M L A, NEBEL O, NEBEL-JACOBSEN Y J, et al. Hafnium isotope characterization of the GJ-1 zircon reference material by solution and laser-ablation MC-ICPMS[J]. Chemical Geology, 2008, 255:231-235.
SLÁMA J, KOSLER J, CONDON D J, et al. Plesovice zircon-A new natural reference material for U-Pb and Hf isotopic microanalysis[J]. Chemical Geology,2008,249:1-35.
-
