西昆仑甜水海地体早寒武世花岗岩浆作用及其构造意义
Magmatism and Tectonic Implications of Early Cambrian Granitoid Plutons in Tianshuihai Terrane of the Western Kunlun Orogenic Belt, Northwest China
-
摘要: 瓦仍孜拉甫岩体和阿依里西岩体出露于西昆仑造山带的甜水海地体中。LA-ICP-MS锆石U-Pb定年表明，阿依里西岩体的花岗质斑岩的侵位年龄为（530±6）Ma，瓦仍孜拉甫岩体的黑云母二长花岗质片麻岩的侵位年龄为（515±2）Ma，都形成于早寒武世。岩石地球化学特征表明，阿依里西岩体中花岗质斑岩的SiO2含量为67.7%~69.4%，具有较高的Mg#值（44~46），A/CNK值为0.81~0.93；K2O含量为2.15%~3.02%，呈钙碱性至高钾钙碱性特征；其εHf（t）值为-3.3~-0.8；以轻重稀土分异较为明显，富集Cs、Rb、K、Th、Zr、Hf、Y等元素，而亏损Ba、Nb、Ta、Sr、P和Ti等元素为特点，是由幔源岩浆与壳源岩浆发生混合作用而成。瓦仍孜拉甫岩体黑云母二长花岗质片麻岩的SiO2含量高其变化范围为75.0%~76.3%，Mg#值比较低，为18~26；A/CNK值为1.01~1.30，K2O含量为4.31~4.98，表现为高钾钙碱性、过铝质特征，其εHf（t） 值为+2.5~+4.3；属于高分异I型花岗岩，源于高钾钙碱性的安山岩和玄武质安山岩的部分熔融。根据这些地球化学特征，结合西昆仑不同地质单元中早古生代花岗岩体的分布特征、地质年代学和岩石成因特征，研究认为这2个花岗质岩体形成于岛弧环境，其为进一步深入研究西昆仑造山带早古生代的构造演化过程提供了新的地质资料。Abstract: The Ayilixi and Warengzilafu plutons are located in the Tianshuihai terrane of the Western Kunlun Orogenic Belt (WKOB).Detailed LA-ICP-MS zircon U-Pb dating has yielded the crystallization ages of ca. (530±6) Ma and ca. (515±2) Ma for the Ayilixi pluton and Warengzilafu pluton, respectively, signifying their formation in Cambrian. The Ayilixi rocks are high-K calc-alkaline to shoshonitic granite porphyries, with a limited range of SiO2 (67.7%~69.4%), high Mg# (44~46), A/CNK ratios (0.81~0.93) and K2O (2.15%~3.02%). They are also marked by negative εHf(t) values of -3.3 to -0.8, obviously fractionated between light and heavy rare earth element, enrichments in Cs, Rb, K, Th, Zr, Hf, Y, and depletions in Ba, Nb, Ta, Sr, P, T. They are considered to have been most likely derived from magma mixing processes by mantle-derived magma and crustal magmatic melt. The Warengzilafu biotite monzonitic granite gneisses are high-K calc-alkaline and peraluminous. Compared to the rocks of the Ayilixi pluton, they generally have higher SiO2 (75.0%~76.3%), lower Mg# (18~26), with higher A/CNK ratios (1.01~1.30) and positive εHf(t) values of +2.5 to +4.3. Elemental and isotopic data suggest that the Warengzilafu rocks are highly fractionated I-type granites, which were mainly generated by partial melting of high-K calc-alkaline andesite and basaltic andesite. The two plutons represent the early Cambrian magmatism under island-arc setting in Tianshuihai terrane, which are related to the subduction of Proto-Tethys.
-
Key words:
- Western Kunlun /
- Tianshuihai terrane /
- Early Cambrian /
- granitoid plutons /
- zircon U-Pb dating
-
-
边小卫, 崔建堂, 王炬川,等. 西昆仑康西瓦南一带康西瓦岩群的厘定及其地质意义[J]. 西北地质, 2015, 48(3):31-38.
BIAN Xiaowei, CUI Jiantang, WANG Juchuan, et al.Redefinition of the Kangxiwa Group in South Kangxiwa Area of West Kunlun and Its geological significance[J]. Northwestern geology, 2015, 48(3):31-38.
陈海云, 孙妍, 包平, 等. 西昆仑上其木干岩体岩石成因及地质意义——地球化学及U-Pb年代学证据[J]. 岩石矿物学杂志, 2014, 33(04): 657-670.
CHEN Haiyun, SUN Yan, BAO Ping, et al. Petrogenesis and geological significance of Shangqimugan plutons in Western Kunlun: Evidence from geochemistry and U-Pb chronology[J]. Acta Petrologica et Mineralogica, 2014, 33 (4): 657-670.
崔建堂, 王炬川, 边小卫, 等. 西昆仑康西瓦北侧早古生代角闪闪长岩、英云闪长岩的地质特征及其锆石SHRIMP U-Pb测年[J]. 地质通报, 2006a, 25 (12): 1441-1449.
CUI Jiantang, WANG Juchuan, BIAN Xiaowei, et al. Geological Characteristics of Early Paleozoic Amphibolite and Tonalite in Northern Kangxiwar. West, Kunlun, China and their zircon SHRIMP U-Pb dating[J]. Geological Bulletin of China, 2006a, 25 (12): 1441-1449.
崔建堂, 王炬川, 边小卫, 等. 西昆仑康西瓦一带早古生代石英闪长岩的地质特征及其锆石SHRIMP U-Pb测年[J]. 地质通报, 2006b, 25 (12): 1450-1457.
CUI Jiantang, WANG Juchuan, BIAN Xiaowei, et al. Geological characteristics of Early Paleozoic quartz diorite in the vicinity of Kangxiwar, West Kunlun, China and its zircon SHRIMP U-Pb dating[J]. Geological Bulletin of China, 2006b, 25 (12): 1450-1457.
崔建堂, 王炬川, 边小卫, 等. 西昆仑康西瓦北部冬巴克片麻状英云闪长岩锆石SHRIMP U-Pb测年[J]. 地质通报, 2007a, 26 (06): 726-729.
CUI Jiantang, WANG Juchuan, BIAN Xiaowei, et al. Zircon SHRIMP U-Pb dating of the Dongbake gneissic tonalite in northern Kangxiwa[J]. Geological Bulletin of China, 2007a, 26 (06): 726-729.
崔建堂, 王炬川, 边小卫, 等. 西昆仑康西瓦北侧蒙古包-普守-带早古生代花岗岩锆石SHRIMP U-Pb测年[J]. 地质通报, 2007b, 26 (06): 710-719.
CUI Jiantang, WANG Juchuan, BIAN Xiaowei, et al. Zircon SHRIMP U-Pb dating of early Paleozoic granite in the Menggubao-Pushou area on the northern side of Kangxiwar. Geological Bulletin of China, 2007b, 26 (06): 710-719.
邓万明. 喀喇昆仑-西昆仑地区蛇绿岩的地质特征及其大地构造意义[J]. 岩石学报, 1995, (S1): 98-111.
DENG Wanming. Geological features of ophiolite and tectonic significance in the Karakorum-west Kunlun Mts[J]. Acta Petrologica Sinica, 1995, (S1): 98-111.
冯江鹏, 曹福根, 宋倩倩,等. 西昆仑柳什塔格南二长花岗岩SHRIMP定年、地球化学特征及其地质意义[J]. 西北地质, 2014, 47(04):163-169.
FENG Jiangpeng, CAO Fugen, SONG Qianqian, et al. SHRIMP U-Pb ages, Geochemical Characteristics and Geological Implications of the Monzonitic Granite at South Liushitage, West Kunlun[J].Northwestern Geology, 2014, 47(04):163-169.
高晓峰, 校培喜, 康磊, 等. 西昆仑大同西岩体成因: 矿物学, 地球化学和锆石 U-Pb 年代学制约[J]. 岩石学报, 2013, 29(9): 3065-3079.
GAO Xiaofeng, XIAO Peixi, KANG Lei, et al. Origin of Datongxi pluton in the west Kunlun orogen: constraints from mineralogy, elemental geochemistry and zircon U-Pb age[J]. Acta Petrological Sinica, 2013, 29 (9): 3065-3079.
姜春发, 王宗起, 李锦铁. 中央造山带开合构造[M]. 北京: 地质出版社, 2000.
JIANG Chunfa, WANG Zongqi, LI Jinyi. Opening-Closing Tectonics of Center Orogenic Belt[M].Beijing, Geological Publishing House, 2000.
姜耀辉, 芮行健, 贺菊瑞, 等. 西昆仑山加里东期花岗岩类构造的类型及其大地构造意义[J]. 岩石学报, 1999, 15(1): 105-115.
JIANG Yaohui, RUI Xingjian, HE Jurui, et al. Tectonic type of caledonian granitoids and tectonic significance in the west Kunlun Mts[J]. Acta Petrologica Sinica, 1999, 15(1): 105-115.
康磊, 校培喜, 高晓峰, 等. 西昆仑慕士塔格岩体的LA-ICP-MS锆石U-Pb定年:对古特提斯碰撞时限的制约[J]. 地质论评, 2012a, 58(04): 763-774.
KANG Lei, XIAO Peixi, GAO Xiaofeng, et al.LA-ICP-MS U-Pb Dating of the Zircon from Muztagata Pluton in Western Kunlun Orogenic Belt: Constraints on the Time of Paleotethys'Collision[J]. Geological Review, 2012, 58(04): 763-774.
康磊, 校培喜, 高晓峰, 等. 西昆仑慕士塔格岩体的岩石地球化学特征、岩石成因及其构造意义[J]. 地质通报, 2012b, 31(12): 2001-2014.
KANG Lei, XIAO Peixi, GAO Xiaofeng, et al. Geochemical characteristics and petrogenesis of Muztagata intrusion in Western Kunlun orogenic belt and their tectonic significance[J]. Geological Bulletin of China, 2012, 31(12): 2001-2014.
康磊, 校培喜, 高晓峰, 等.西昆仑西北缘大洋斜长花岗岩带的岩石地球化学特征、成因及其构造环境[J]. 岩石学报, 2015a, 31(09): 2566-2582.
KANG Lei, XIAO Peixi, GAO Xiaofeng, et al. Geochemical characteristics, petrogenesis and tectonic setting of Oceanic plagiogranites belt in the northwestern margin of western Kunlun[J]. Acta Petrologica Sinica, 2015a, 31(09): 2566-2582.
康磊, 校培喜, 高晓峰, 等. 西昆仑西段晚古生代一中生代花岗质岩浆作用及构造演化过程[J]. 中国地质, 2015b, 42(3): 533-552.
KANG Lei, XIAO Peixi, GAO Xiaofeng, et al. Neopaleozoic and Mesozoic granitoid magmatism and tectonic evolution of the West Kunlun Mountains[J]. Geology in China, 2015b, 42(3): 533-552.
李荣社, 计文化, 杨永成. 昆仑山及邻区地质[M], 北京: 地质出版社, 2008: 1-5.
LI Rongshe, JI Wenhua, YANG Yongcheng. Geology of Kunlun Mountain and Adjacent Areas[M].Beijing, Geological Publishing House, 2008: 1-5.
林尚康, 汤好书, 任涛. 西昆仑赞坎铁矿区英安班岩锆石U-Pb年代学研究[J]. 河南科学, 2015, 33(06): 986-992.
LIN Shangkang, TANG Haoshu, REN Tao. IN-Situ U-Pb Ages and Hf Isotopic Analyses of Zircons from Rhyodacite in Zankan,West Kunlun Area[J]. Henan science, 2015, 33(06): 986-992.
曲军峰, 张立飞, 艾永亮, 等. 西昆仑塔什库尔干高压麻粒岩PT轨迹、SHRIMP锆石定年及其大地构造意义[J]. 中国科学(D辑:地球科学), 2007, 37(04): 429-441.
QU Junfeng, ZHANG Lifei, AI Yongliang, et al. Discovery and P-T path of high pressure granulite in Taxkorgan, western Kunlun and its tectonic significance[J]. Science in China (series D), 2007, 37(04): 429-441.
王超, 刘良, 何世平, 等. 西昆仑早古生代岩浆作用过程: 布隆花岗岩地球化学和锆石 U-Pb-Hf 同位素组成研究[J]. 地质科学, 2013, 48(4): 997-1014.
t al. Petrogenesis and tectonic implications of early Silurian high-K calc-alkaline granites and their potassic microgranular enclaves, western Kunlun orogen, NW Tibetan Plateau[J]. International Geology Review, 2013, 55: 958-97猵帮帼br褾晌乏塁乏帠屓幙洬朠届坉赁牎彇匠兙奈圬朠遊慉乁NG SY圬贠遥扴 al. Subducting sediment-derived arc granitoids: evidence from the Datong pluton and its quenched enclaves in the western Kunlun orogen, northwest China[J]. Mineralogy and Petrology, 2010, 100: 55-74.
敌畉繕吠屙腓氬匠均赁睏丠屓,攠畈繕吠屚脬氠卥却圠坡赬弮 Con却乩n坥赮兴牡祬 and oceanic crust焠镲浥cy陣晬兩ng昭敩彮du筣ed攠畭塥乬年尭幰坥卲id幯籴屩彴e 鑩睮年癥卲獡卣兴坩赯慮乳 in t坨赥造扔rans-North China Orogen: U-Pb dating, Hf isotopes and trace elements in zircons from mantle xenoliths[J]. Journal of Petrology, 2010, 51, 537-571.
LIU Z, JIANG YH, JIA RY, et al. Origin of Middle Cambrian and Late Silurian potassic grani杴敯彩ds删艦ro晭猠乴he笠we襳晴乥塲乮帠屋幵卮敬杵n 驯卲og卥赮丬丠癮硯孲却全杷遥坳赴愠乃hina:丠噡礠孭ag坭瑡祴孩c response to the Proto-Tethys evolution[J]. Mineralogy and Petrology, 2014, 108: 91-110.
LUDWIG KR. Isoplot/Ex, Version 3. A Geochronological Toolkit for Microsoft Excel: Berkeley[J]. Geochronology Center Berkeley, California, 2003.
MANIAR PD, PICCOLI PM. Tectonic discrimination 彯佦朠gr乡浮镩to獩牤噳[J筝. 襇晥乯襬歯乧卩繣乡籬舠屓屯幣齩浥孴卹儠杯遦愠乁meric坡贠孂扵lletin, 1989, 101, 635-643.
MATTE P, TAPPONNIER P, AMAUD N, et al. Tectonics of Western Tibet, between the Tarim and the Indus[J]. Earth and Planetary Science Letters, 1996, 142: 311-330.
MATTERN F, SCHNEIDER张佗朮 S陵杴幵ri乮浧锠of笠th靥蔠驐卲卯罴襯昭丠遡屮幤朠遰潡卬eo札腔镥睴hys ocea卮s in the we浳年癥譲据 Kunl乵噮礠嬨Xinj轩ang, China)[J]. Journal of Asian Earth Sciences, 2000, 18: 637-650.
MüLLER D, ROCK NM, GROVES DI. Geochemical discrimination between shoshonitic and potassic volcanic rocks in different tectonic settings: a pilot study[J]. Mineralogy and Petrology, 1992, 46: 259-289.
RAPP RP, WATSON EB.造獄塥hy杤繲敡ti獯腮 m敥畬襴晩乮敧匠畯书传六履坴瑡卢孡牳彡卬坴贠慡乴 8-32褠卫坢赡r: implications for continental growth and crust-mantle recycling[J]. Journal of Petrology,1995, 36(4): 891-931.
ROBERTS MP, CLEMENS JD. Origin of high-potassium, talc-alkaline, I-type granitoids[J]. Geology, 1993, 21(9): 825-828.
SISSON TW, RATAJESKI K, HANKINS WB, et al. Voluminous granitic magmas from common basaltic sources[J]. Contributions to Mineralogy and Petrology, 2005, 148, 635-661.
SUN SS, McDonough WF. Chemical and isotopic systematics of oceanic basalts: implications for mantle composition and processes[J]. Geological Society, London, Special Publications, 1989,42(1): 313-345.
TAYLOR SR, McLennan SM. The continental crust: its composition and evolution[J].1985.
PECCERILLO A, TAYLOR SR. Geochemistry of Eocene calc-alkaline volcanic rocks from the Kastamonu area, northern Turkey[J]. Contributions to Mineralogy and Petrology, 1976, 58, 63-81.
PAN YS. Geological Evolution of the Karakorum and Kunlun Mountains[J]. Seismological Press, Beijing, China, 1996.
PATINO Douce AE. What do experiments tell us about the relative contributions of crust and mantle to the origin of granitic magmas?[J]. Geological Society, London, Special Publications, 1999. 168: 55-75.
WANG ZH. Tectonic evolution of the western Kunlun orogenic belt, western China[J]. Journal of Asian Earth Sciences, 2004, 24, 153-161.
WHALEN JB, CURRIE KL, CHAPPELL BW. A-type granites-geochemical characteristics, discrimination and petrogenesis[J]. Contributions to Mineralogy and Petrology, 1987, 95: 407-419.
WU FY, JAHN BM, WILDE SA, et al. Highly fractionated I-type granites in NE China (I): geochronology and petrogenesis[J]. Lithos, 2003, 66(3/4): 241-273.
XIAO B, LI QG, LIU SW, et al. Highly fractionated Late Triassic I-type granites and related molybdenum mineralization in the Qinling orogenic belt: Geochemical and U-Pb-Hf and Re-Os isotope constraints[J]. Ore Geology Reviews, 2014, 56: 220-233.
XIAO WJ, WINDLEY BF, HAO J, et al. Arc-ophiolite obduction in the Western Kunlun Range (China): implications for the Palaeozoic evolution of central Asia[J]. Journal of the Geological Society, 2002, 159, 517-528.
XIAO WJ, WINDLEY BF, LIU DY, et al. Accretionary tectonics of the Western Kunlun Orogen, China: a Paleozoic-early Mesozoic, long-lived active continental margin with implications for the growth of southern Eurasia[J]. The Journal of Geology, 2005, 113, 687-705.
YE HM, LI XH, LI ZX, et al. Age and origin of high Ba-Sr appinite-granites at the northwestern margin of the Tibet Plateau: implications for early Paleozoic tectonic evolution of the Western Kunlun orogenic belt[J]. Gondwana Research, 2008, 13, 126-138.
-
