Eruption Cycles and Petrochemical Features of Early Carboniferous Volcanic Rocks in Ejina Banner, Inner Mongolia
-
摘要: 研究区位于珠斯楞-杭乌拉构造带。根据火山岩的分布与接触关系，以及后期侵入火山岩中花岗岩的锆石U-Pb年龄（333.5±3）Ma，可以判定该火山岩形成时代为早石炭世中期（大约为Mississippian世Visean阶），结合区域对比将其置于下石炭统白山组。笔者系统采集到16件火山岩样品，分析数据显示其均为钙碱性系列，中酸性火山岩。其微量元素蛛网图显示亏损高场强元素P、Ti、Ti、Nb、Y、Ta，富集Rb、Ba、Th、Sr等大离子亲石元素，稀土元素配分具有轻稀土富集、重稀土亏损的右倾型配分模式，暗示该火山岩形成于火山弧环境。按照由基性到酸性岩浆喷发旋回，结合喷发间歇宁静期，可以将早石炭世火山活动可划分为5个火山喷发旋回。该区早石炭世火山活动与哈萨克斯坦板块的汇聚拼贴有密切关系，塔里木板块北缘处于活动大陆边缘。Abstract: This study area is located in Zhusileng-Hangwula structure belt. Based on the distribution and contact relation of volcanic rocks and the zircon U-Pb age (333.5±3) Ma of granite in later intrusive rocks, it can be judged that these volcanic rocks were formed in middle stage of early Carboniferous (it's about Visea Stage of Mississippian Epoch); Combined with features of regional comparison and the above discussion, these volcanic rocks have been placed as the Lower Carboniferous Baishan Formation. In this paper, the sixteen samples of volcanic rock have been systematically collected, and the analysis date of these samples showed that they are Calc-alkaline series and medium-acid volcanic rocks. The trace elements spider diagram of these volcanic rocks indicates that the Carboniferous volcanic rocks are enriched in large-ion lithophile elements (such as Rb,Ba,Th,Sr) and depleted in high field strength elements (such as P, Ti, Nb, Y, Ta). The distribution of the rare-earth element has been divided into right-inclined distribution pattern, with the enrichment of light REE and the loss of heavy REE, showing that these volcanic rocks in the Baishan Formation were formed in the volcanic arc environment. According to magma eruption cycle from basic to acid and the erupting interval, the Early Carboniferous volcanic activity can be divided into five volcanic eruption cycles. This studying area is located at edge of the active continent during early Carboniferous period, and the intense volcanic eruptions are closely related to the convergence of the Kazakhstan plate.
-
-
鲍庆中,张长捷,吴之理,等.内蒙古东南部晚古生代裂谷区花岗质岩石锆石SHRIMP U-Pb 定年及其地质意义[J].中国地质,2007,34(5):790-798.
BAO Qingzhong,ZHANG Changjie,WU Zhili,et al. Zircon SHRIMPU-Pb dating of granitoids in a Late Paleozoic rift area,southeastern Inner Mongolia,and its in plications[J].Geology in China,2007,34(5:)790-798.
卜建军,牛志军,吴俊,等.内蒙古西部额济纳旗及邻区上石炭统-下二叠统阿木山组的沉积特征和时代[J].地质通报,2012,31(10):1669-1683.
BU Jianjun,NIU Zhijun,WU Jun,et al.Sedimentary characteristics and age of Amushan formation in Ejin Banner and its adjacent areas,western Inner Mongolia[J]. Geological Bulletin of China,2012,31(10):1669-1683.
党犇,赵虹,林广春,等.内蒙古西部银根-额济纳旗盆地及邻区二叠纪火山岩的地球化学特征和构造环境[J].地质通报,2011,30(6):923-931.
DANG Ben,ZHAO Hong,LIN Guangchun,et al. Geochemistry and tectonic setting of permian volcanic rocks in yingen-ejinaqi banner basin and its neighboring areas,Inner Mongolia,China[J].Geological Bulletin of China,2011,30(6):923-931.
党犇,赵虹,林广春,等.阿拉善北部地区石炭纪火山岩岩石成岩及构造意义[J].地球科学-中国地质大学学报,2013,38(5):963-974.
DANG Ben,ZHAO Hong,LIN Guangchun, Petrogenesis and tectonic significance of carboniferous volcanic rocks in northern alxa and its neighboring areas,inner mongolia, China[J]. Earth Science-Journal of China University of Geosciences,2013,38(5):963-974.
范超峰.内蒙古自治区拐子湖一带石炭纪白山组火山岩研究[D].西安:长安大学,2015.
FAN ChaoFeng. Study on the Volcanic Rocks of the Baishan formation in the carboniferious in the guaizi lake area of the Inner Mongolia[D].Xi'an:Changan University,2015.
胡治华,申春生,刘宗宾,等. 渤海湾盆地火山岩喷发旋回和期次研究的方法及应用[J].油气地球物理,2013,11(20):30-33.
HU Zhihua,SHEN Chunsheng,LIU Zongbin,et al.The research method and application of the volcanic rock eruption cycle and stage in the Bohai Bay Basin[J].Petroleum Geophysics, 2013,11(20):30-33.
姜亭,李玉宏,陈高潮,等.内蒙古西部额济纳旗及邻区上石炭统-下二叠统阿木山组火山岩的地球化学特征[J].地质通报,2011,30(6):932-942.
JIANG Ting,LI Yuhong,CHEN Gaochao,et al. Geochemical characteristics of carboniferous-permian Amushan formation volcanic rocks in Ejin Banner and its vicinities,western Inner Mongolia[J]. Geological Bulletin of China,2011,30(6):932-942.
李文国,内蒙古自治区地质矿产局编著.内蒙古自治区岩石地层[M].武汉:中国地质大学出版社,1996.
LI Wenguo,Bureau of Geology and Mineral Resources of Inner Mongolia Autonomous Region.Stratigraphy of Inner Mongolia autonomous region[M].Wuhan:China University of Geosciences Press,1996.
李昌年.火成岩微量元素岩石学[M].武汉:中国地质大学出版社,1992.
LI Changnian. Minor element petrology of Igneous Rocks[M]. Wuhan:Press of China University of Geosciences,1992.
邵积东.内蒙古大地构造分区及其特征[J].内蒙古地质,1998,87(2):1-23.
SHAO Jidong. The tectonic zone and characteristics ofInner Mongolia[J].Geology of Inner Mongolia,1998,87(2):1-23.
田昌烈,曹从周,杨芳林,等.中朝陆台北侧褶皱带(中段)蛇绿岩的地球化学特征[J].中国地质科学院院报1989,19:107-129.
TIAN Changlie,CAO Congzhou,YANG Fanglin,et al.Geochemical features of ophiolite in the fold belt on the north side of the sino-korean platform[J]. Bulletin of the Chinese Academy of Geological Sciences,1989,19:107-129.
王廷印,王金荣,王士政.阿拉善北部恩格尔乌苏蛇绿混杂岩带的发现及其构造意义[J].兰州大学学报,1992,28(2):194-196.
WANG Tingyin,WANG Jinrong,WANG Shizheng.Discovery and tectonic significance of engerwusu ophiolite melange belt in northern Alxa region in Inner Mongolia[J]. Journal of Lanzhou University,1992,28(2):194-196.
王廷印,吴茂炳.阿拉善地区北板块北部陆缘区成矿作用的研究[J].兰州大学学报,1993,29(4):252-256.
WANG Tingyin,WU Maobing. A Studay on the Mineralization of the northern China Plate in Alashan region[J].Journal of Lanzhou University,1993,29(4):252-256.
王廷印,刘金坤,王士政,等.阿拉善北部中蒙边界地区晚古生代拉伸作用及构造岩浆演化[J].中国区域地质,1993,(4):317-327.
WANG Tingyin,LIU Jinkun,WANG Shizheng,et al. Late paleozoic extension and tectonomagmatic evolution in the sino-mongolia border region in the northern part of Alxa[J].Regional Geology of China,1993,(4):317-327.
王廷印,王士政,王金荣.阿拉善地区古生代陆壳的形成和演化[M].兰州:兰州大学出版社,1994.
WANG Tingyin,WANG Shizheng,WANG Jinrong. The formation and evolution of the paleozoic continental crustat Alashan[M].Lanzhou:Lanzhou University Press,1994.
王廷印,高军平,王金荣,等.内蒙古阿拉善北部地区碰撞期和后造山期岩浆作用[J].地质学报,1998,72(2):126-137.
WANG Tingyin,GAO Junping,WANG Jinrong,et al. Magmatism of collisional and post-orogenic period in northern Alaxa region in Inner Mongolia[J].Acta Geologica Sinica,1998,72(2):126-137.
王金荣,王士政.阿拉善北部恩格尔乌苏蛇绿混杂岩的形成机制[J].兰州大学学报,1995,31(2):140-147.
WANG Jinrong,WANG Shizheng.The original mechanism of the engger us ophiolitic melange,north Alaxa[J]. Journal of Lanzhou University,1995,31(2):140-147.
吴泰然,何国琦.阿拉善地块北缘的蛇绿混杂岩带及其大地构造意义[J].现代地质,1992,6(3):286-296.
WU Tairan,HE Guoqi. Ophiolitic melange belts in the northern margin of the Alashan block[J].Geoscience,1992,6(3):286-296.
吴泰然,何国琦.内蒙古阿拉善地块北缘的构造单位划分及各单位的基本特征[J].地质学报,1993,67(2):98-108.
WU Tairan,HE Guoqi.Tectonic units and their fundamental characteristics on the northern margin of the Alxa block[J].Acta Geologica Sinica,1993,67(2):98-108.
夏林圻.造山带火山岩研究[J].岩石矿物学杂志,2001,20(3):225-232.
XIA Lin Qi.A study of Volcanic Rocks in orogenic belts[J].Acta Petrologica et Mineralogica,2001,20(3):225-232.
闫海卿,陈元,范模春,等.内蒙古额济纳旗拐子湖地区花岗岩地球化学特征及其地质意义[J].中国工程科学,2015,17(2):97-105.
YAN Haiqing,CHEN Yuan,FAN Mochun,et al.Geochmeical features and geological significance of Granitoid Rocks in Guaizihu,Ejinaqi,Inner Mongolia[J].Engineering Sciences,2015,17(2):97-105.
闫海卿,赵焕强,丁瑞颖,等.甘肃北山大山头基性杂岩体SHRIMP锆石U-Pb年龄及其地质意义[J].西北地质,2012,45(4):216-228.
YAN Haiqing,ZHAO Huanqiang,DING Ruiying,et al. Zircon SHRIMP U-Pb Dating of the Dashantou Basic Complex and Its Geological Significance in Beishan Area, Gansu Province[J]. Northwestern Geology, 2012,45(4):216-228.
周立发,赵重远,郭忠铭.阿拉善及邻区沉积盆地的形成与演化[M].西安:西北大学出版社,1995,57-92.
ZHOU Lifa,ZHAO Chongyuan,GUO Zhongming. Formation and evolution of the sedimentary basins in Alaxa and adjacent regions[M]. Xi'an:Northwest University Press,1995,57-92.
赵省民,陈登超,邓坚.银根-额济纳旗及邻区石炭系-二叠系的沉积特征及石油地质意义[J].地质学报,2010,29(3):351-359.
ZHAO Xinmin,CHEN Dengchao,DENG Jian,Depositional characteristic of permo-carboniferous system from Yingen-Ejinaqi and their surrounding areas,inner mongolia,China and it implications for petroleum[J].Acta Geologica Sinica,2010,29(3):351-359.
左国朝,刘义科,刘春燕,等.甘新蒙北山地区构造格局演化[J].甘肃地质学报,2003,12(1):1-15.
ZUO Guochao,LIU Yike,LIU Chunyan,et al. Framework and evolution of the tectonic structure in Beishan area across Gansu Province,Xinjiang autonomous region[J].Acta Geologica Gansu,2003,12(1):1-15.
内蒙古地矿局.内蒙古自治区区域地质志[M].北京:中国地质大学出版社,1991.
Bureau of Geology and Mineral Resources of Nei Mongol autonomous region. Regional geology of the Nei Mongol autonomous region[M].Beijing:Geological PubliShing House,1991.
LI JY. Permian geodynamic setting of Northeast China and adjacent regions:Closure of the Paleo-Asian Ocean and subduction of the Paleo-Pacific Plate[J].Journal of Asian Earth Sciences,2006,26:207-224.
LEHMANN J,SCHULMANN K,LEXA O,et al.Structural constraints on the evolution of the Central Asian Orogenic Belt in southern Mongolia[J].American Journal of Science,2010,310:575-628.
WANG Q,LIU X. Paleoplate tectonics between Cathaysia and Angaraland in Inner Mongolia of China[J].Tectonics,1986,5:1073-1088.
XIAO W,WINDLEY B F,HA J,et al. Accretion leading to collision and Permian Solonker suture,Inner Mongolia,China:Termination of the Central Asian Orogenic Belt[J].Tectonics,2003,22(6):1069-1088.
XIAO W J,WINDLEY B F,HUANG B C,et al.End-Permian to MidTriassic termination of the accretionary processes of the southern Altaids:Implications for the geodynamic evolution, Phanerozoic continental growth, and metallogeny of Central Asia[J].Int.J.Earth Sci,2009,98 (6):1189-1217.
-
