Diagenesis of Middle Jurassic-Lower Cretaceous Reservoirs in Shinan Area, Junggar Basin
-
摘要: 通过岩心观察、铸体薄片、X射线衍射和扫描电镜等方法，对准噶尔盆地石南地区中侏罗-下白垩统西山窑组（J2x）、头屯河组（J2t）和清水河组（K1q）储层的成岩作用特征和成岩演化序列进行了研究，并总结了研究区成岩作用对储层孔渗的影响。结果表明：中侏罗-下白垩统储层以细砂岩、中细砂岩、中砂岩为主，成分成熟度较低，结构成熟度中等。储层孔渗相关性较好，喉道以中喉道为主，部分为细喉；整体上属于中孔中低渗储层。储集空间类型主要是原生孔隙，溶蚀形成的次生孔隙所占比重很小。通过对储层成岩作用特征和孔隙类型组合分析可知，石南地区中侏罗-下白垩统储层主要处于早成岩阶段A期-早成岩阶段B期，储集岩的成岩作用序列大致为：绿泥石薄膜和早期的方解石胶结→岩屑和长石的溶解→早期高岭石和硅质胶结→次生石英加大和晚期高岭石→晚期铁方解石和铁白云石；而压实作用则贯穿整个埋藏成岩过程。研究区储层主要经历了压实、胶结、溶蚀等成岩作用；其中导致研究区储层孔隙损失的最主要原因是压实作用，其次为胶结作用，而溶蚀作用对储层孔隙增生的贡献量有限。Abstract: Based on the core observation, thin sections, SEM and X-ray diffraction combined with the reservoir properties analysis, the relationship between diagenesis and porosity evolution of middle Jurassic-lower Cretaceous reservoirs (Xishanyao Formation (J2x), Toutunhe Formation (J2t) and Qingshuihe Formation (K1q))in Shinan area, Junggar basin have been researched in this paper. The results show that these reservoirs are mainly consist of fine sandstone, mid-fine grained sandstone and medium sandstone, with low composition maturity and medium structural maturity. The correlation of pore and permeability is good, and the throat is dominated by middle throat, with part of fine throat. These reservoirs belong to middle and low permeability reservoir on the whole. The reservoirs porosities are primarily composed of primary porosity, and the second porosity caused by dissolution is very rare. The Middle Jurassic-Lower Cretaceous reservoirs primarily are formed in A period of early diagenesis and B period of early diagenesis, according to the diagenetic characteristics and pore assemblage in Shinan area. The diagenetic sequence of the reservoirs primarily is chlorite precipitation and early calcite cementation, feldspar and lithic dissolution, early kaolin and siliceous cementation, secondary kaolinite precipitation and quartz overgrowth, late ankerite and ferro calcite cementation. The result shows that the compaction was occurred through the whole burial diagenetic process, and the middle Jurassic-lower Cretaceous reservoirs have mainly undergone a series of diagenesis, such as compaction, cementation and dissolution. The compaction is the main cause leading to the reduction of the reservoirs porosity, which followed by the cementation, with limited contribution of dissolution to reservoir pore increase.
-
Key words:
- Junggar basin /
- Shinan area /
- middle Jurassic-lower Cretaceous /
- diagenesis
-
-
冯动军.准噶尔盆地石南地区侏罗纪-早白垩世沉积体系研究[D].北京:中国地质大学,2006:56-85.
FENG Dongjun. Study on the sedimentary system of Jurassic and early Cretaceous Epoch in Shinan area of Junggar Basin[D]. Beijing:China University of Geosciences, 2006:56-85.
徐亚楠,冀冬生.准噶尔盆地石南44地区白垩系沉积相分析[J].长江大学学报自然科学版:理工卷,2012,9(8):47-50.
XU Yanan, JI Dongsheng. Study on the sedimentary facies of the Cretaceous in Shinan 44, Junggar Basin[J]. Journal od Yangtze University(Nat Sci Edit) Sci & Eng, 2012, 9(8):47-50.
凌云,刘得光,黄国荣,等.石南地区田头屯河组沉积相研究[J].新疆石油天然气,2006,2(2):19-22.
LING Yun, LIU Deguang, HUANG Guorong, et al. The study on sedimentary facies of Toutunhe Formation in Shinan area[J].Xinjiang Oil & Gas, 2006, 2(2):19-22.
饶政,姚鹏翔,张春光,等.准噶尔盆地石南31井区下白垩统清水河组-段辫状河三角洲相及沉积演化[J].古地理学报,2008,10(1):43-52.
RAO Zheng, YAO Pengxiang, ZHANG chunguang, et al. Braided fluvial delta facies and sedimentary evolution of the Member 1 of Qingshuihe Formation of lower Cretaceous in Shinan 31wellblock, Junggar Basin[J]. Journal of Palaeogeography, 2008, 10(1):43-52.
肖明国,安志渊,曹少芳,等.准噶尔盆地石南31井区下白垩统清-段湖泊辫状河三角洲沉积体系[J].地层学杂志,2008,32(4):381-388.
XIAO Mingguo, AN Zhiyuan, CAO Shaofang, et al. Lake-braided rivers delta depositional systems of the Member 1 of the lower Cretaceous Qingshuihe Formation at the well Shinan 31 in the Junggar Basin[J]. Journal of Stratigraphy, 2008, 32(4):381-388.
黄兴文.坳陷湖盆缓坡层序地层学研究与岩性地层圈闭有利区带预测[D].北京:中国地质大学,2006:22-23.
HUANG Xingwen. Sequence stratigraphy research and lithologic-stratigraphic trap prospective area prediction in gentle slope of depression basin:Using Shinan area, central Junggar Basin asexample[D].Beijing:China University of Geosciences, 2006:22-23.
谢寅符,李洪奇,孙中春.准噶尔盆地石南地区侏罗系-白垩系间风化壳的发现及其地层学意义[J].地质论评,2006,52(1):137-144.
XIE Yinfu, LI Hongqi, SUN Zhongchuan. Discovery of a weathering crust between Jurassic & Cretaceous and its stratigraphic significance in the Shinan area of the Junggar Basin[J]. Geological Review, 2006, 52(1):137-144.
张顺存,刘振宇,刘巍,等.准噶尔盆地西北缘克-百断裂下盘二叠系砂砾岩储层成岩相研究[J].岩性油气藏,2010,22(4):46-54.
ZHANG Shuncun, LIU Zhengyu, LIU Wei, et al. Diagenesis facies of Permian sandy conglomerate reservoir in footwall of Kebai Fault in northwestern margin of Junggar Basin[J]. Lithologic Reservoirs, 2010, 22(4):46-54.
梁则亮,张顺存,贾春明,等.准噶尔盆地西北缘车拐地区三叠系储层特征研究[J].岩性油气藏,2012,24(3):18-23.
LIANG Zeliang, ZHANG Shuncun, JIA Chunming, et al. Characteristics of the Triassic reservoirs in Cheguai area, nothwestern margin of Junggar Basin[J]. Lithologic Reservoirs, 2012, 24(3):18-23.
葛家旺,秦成岗,朱筱敏,等.惠州凹陷HZ25-7构造带文昌组低孔低渗砂岩储层特征和成因机理[J].岩性油气藏,2014,26(4):36-43.
GE Jiawang, QIN Chenggang, ZHU Xiaomin, et al. Characteristics and origin of low porosity and low permeability sandstone reservoir of Wenchang Formation in HZ25-7structural belt of Huizhou Depression[J]. Lithologic Reservoirs, 2014, 26(4):36-43.
潘荣,朱筱敏,王星星,等.深层有效碎屑岩储层形成机理研究进展[J].岩性油气藏,2014,26(4):73-80.
PAN Rong, ZHU Xiaomin, WANG Xingxing, et al. Advancement on formation mechanism of deep effective clastic reservoir[J]. Lithologic Reservoirs, 2014, 26(4):73-80.
陈波,刘云利,刘海上,等.准噶尔盆地乌尔禾地区二叠系夏子街组储层特征及评价[J].岩性油气藏,2015,27(4):53-60.
CHEN Bo, LIU Yunli, LIU Haishang, et al. Reservoir characteristics and evaluation of the Permian Xiazijie Formation in Wuerhe area, Junggar Basin[J]. Lithologic Reservoirs, 2015, 27(4):53-60.
吉鸿杰,李小燕,陶辉飞,等.准噶尔盆地阜东斜坡区侏罗系头屯河组储层孔隙结构特征研究[J].岩性油气藏,2016,28(2):47-55.
JI Hongjie, LI Xiaoyan, TAO Huifei, et al. Pore structure characteristics of Jurassic Toutunhe Formation in eastern slope of Fukang Depression, Junggar Basin[J]. Lithologic Reservoirs, 2016,28(2):47-55.
SY/T 5477-2003,中华人民共和国石油天然气行业标准:碎屑岩成岩阶段划分[S].北京:石油工业出版社,2003.
SY/T 5477-2003,Petroleum and natural gas industry standard of People's Republic of China. Diagenesis stage division of clastic sandstones[S]. Beijing:Petroleum Industry Publishing House, 2003.
邱楠生,杨海波,王绪龙.准噶尔盆地构造-热演化特征[J].地质科学,2002,37(4):423-429.
QIU Nansheng, YANG Haibo, WANG Xulong. Tectono-thermal evolution in the Junggar Basin[J]. Chinese Journal of Geology, 2002, 37(4):423-429.
田建锋,陈振林,凡元芳,等.砂岩中自生绿泥石的产状,形成机制及其分布规律[J].矿物岩石地球化学通报,2008,27(2):200-205.
TIAN Jianfeng, CHEN Zhenlin, FAN Yuanfang, et al. The occurrence, growth mechanism and distribution of authigenic chlorite in sandstones[J]. Bulletin of Mineralogy, Petrology and Geochemistry, 2008, 27(2):200-205.
邱隆伟,陈文学.一种新的储层孔隙成因类型-石英溶解型次生孔隙[J].沉积学报,2002,20(4):621-627.
QIU Longwei, CHEN Wenxue. A new type of secondary porosity:quartz dissolution porosity[J]. Acta Sedimentologica Sinica, 2002, 20(4):621-627.
赵国泉,李凯明,赵海玲,等.鄂尔多斯盆地上古生界天然气储集层长石的溶蚀与次生孔隙的形成[J].石油勘探与开发,2005,32(1):53-55.
ZHAO Guoquan, LI Kaiming, ZHAO Hailing, et al. Feldspar corrosion and secondary pore formation in the upper Paleozoic gas reservoir, Ordos Basin[J]. Petroleum Exploration and Development, 2005,32(1):53-55.
郭春清,沈忠民,张林晔,等.砂岩储层中有机酸对主要矿物的溶蚀作用及机理研究综述[J].地质地球化学,2003,31(3):53-57.
GUO Chunqing, SHEN Zhongmin, ZHANG Linye, et al. The corrosion and its mechanism of organic acids on main minerals in oil-gas reservoir sand rocks[J]. Geology-Geochemstry, 2003, 31(3):53-57.
WORDEN R H, BURLEY S D. Sandstone Diagenesis:Recent and Ancient (Reprint Series 4 of the IAS)[M]. Hoboken:John Wiley & Sons, 2003:3-44.
SCHUTJENS P, HANSSEN T H, HETTEMA M H H, et al. Compaction-induced porosity/permeability reduction in sandstone reservoirs:data and model for elasticity-dominated deformation[J]. SPE Reservoir Evaluation & Engineering, 2004, 7(3):202-216.
MORAD S.Carbonate Cementation in Sandstones (Special Publication 26 of the IAS)[M]. Hoboken:John Wiley & Sons, 1998:1-26.
WORDEN R H, Morad S. Quartz cementation in sandstones (Special Publications 29 of the IAS)[M]. Hoboken:John Wiley & Sons, 2000:1-20.
WORDEN R H, MORAD S. Clay minerals in sandstones (Special Publications 34 of the IAS)[M]. Hoboken:John Wiley & Sons, 2003:3-41.
STOESSELL R K, PITTMAN E D. Secondary Porosity Revisited:The Chemistry of Feldspar Dissolution by Carboxylic Acids and Anions[J]. AAPG Bulletin, 1990, 74(12):1795-1805.
DOWEY P J, HODGSON D M, WORDEN R H. Pre-requisites, processes, and prediction of chlorite grain coatings in petroleum reservoirs:A review of subsurface examples[J]. Marine and Petroleum Geology, 2012, 32(1):63-75.
HAILE B G, HELLEVANG H, AAGAARD P, et al. Experimental nucleation and growth of smectite and chlorite coatings on clean feldspar and quartz grain surfaces[J]. Marine and Petroleum Geology, 2015, 68(10):664-674.
AAGAARD P, JAHREN J S, HARSTAD A O, et al. Formation of grain-coating chlorite in sandstones. Laboratory synthesized vs. natural occurrences[J]. Clay Minerals, 2000, 35(1):261-269.
HOUSEKNECHT D W. Assessing the relative importance of compaction processes and cementation to reduction of porosity in sandstones[J]. AAPG bulletin, 1987, 71(6):633-642.
PATE C R. Assessing the relative importance of compaction processes and cementation to reduction of porosity in sandstones:discussion[J]. AAPG Bulletin, 1989, 73(10):1270-1273.
HOUSEKNECHT D W. Assessing the relative importance of compaction processes and cementation to reduction of porosity in sandstones:reply[J]. AAPG Bulletin, 1989, 73(10):1277-1279.
-
