Contrastive Study of Sample-pretreatment Effects on Analytical Results of Inorganic Carbon Isotopes in Water Sample
-
摘要: 水中溶解性无机碳(DIC)的碳同位素前处理方法由传统的BaCl2沉淀法，逐步发展到野外采样后直接通过连续流系统(GasBench-IRMS)测试。当前对于BaCl2沉淀法和连续流测试结果的差异，以及最佳DIC的前处理方法均需要开展深入研究。本文应用BaCl2沉淀法、医用无菌高密度聚乙烯瓶装样、GasBenchⅡ顶空样品瓶野外直接生成CO2气体三种前处理方法，对比研究前处理方法对采自桂林盘龙洞洞穴滴水和地下河水样中DIC碳同位素测试的影响。结果表明，由于BaCl2沉淀法使水样中游离CO2逸出，导致测定的DIC碳同位素值相对于另两种方法均偏正：地下河水样的碳同位素值最大偏正0.26‰；洞穴滴水的碳同位素值最大偏正0.33‰。因为野外水样采集环境的温度、大气压强与实验室内部环境变化较小，没有引起CO2、HCO-3的溶解度改变，用医用无菌高密度聚乙烯瓶和GasBenchⅡ顶空样品瓶采集水样的碳同位素测试结果相同；相对而言，利用GasBenchⅡ顶空样品瓶直接产生CO2气体，能够避免外界环境条件变化导致CO2、HCO-3的溶解度发生变化引起碳同位素分馏，是精确测定水中DIC碳同位素最佳的前处理方法。Abstract: The pretreatments for the measurement of dissolved inorganic carbon (DIC) isotopes in field water samples were developed from traditional BaCl2 precipitation methods to directly continuous flow (GasBench-IRMS) methods. Further research needs be conducted to distinguish the difference between the traditional BaCl2 precipitation methods and the continuous flow (GasBench-IRMS) method in order to select the best pretreatment for DIC. This study compared the results obtained by three pretreatment methods: BaCl2 precipitation, medical sterile high-density polyethylene bottles and acidification of the sample in GasBench headspace vials in field work. Drip water and underground water samples were collected from Panlong cave in Guilin. The results show that because of CO2 escape from the water sample, by using the BaCl2 precipitation the value of the carbon isotope was more positive than other sample-pretreatment methods. The maximum deviation of the carbon isotope value from the underground river is 0.26. The maximum deviation of the carbon isotope value from the cave drip water is 0.33. The temperature and atmospheric pressure are similar in the field and the laboratory, therefore it did not cause solubility change of CO2 and HCO-3 in water samples. The DIC results of the medical sterile high-density polyethylene bottles and GasBench headspace vials are the same. The GasBench headspace vials pretreatment method can effectively avoid the solubility change of CO2 and HCO-3 caused by environmental changes, which leads to the CO2 escape from the water sample or dissolved into the water sample from the atmosphere of CO2. This change may cause carbon isotopic fractionation in DIC of water samples. Using GasBench headspace vials, which directly produce and collect CO2 gas in the field is the recommended DIC pretreatment method.
-
-
表 1 野外水样HCO3-、pH、温度和实验室温度、压强测量结果
Table 1. The measurement results of HCO3-,pH,temperature in field samples and the temperature and pressure in laboratory
样品编号 HCO3-浓度
c/(mmol·L-1)pH值 温度
θ/℃大气压
p/PaP地 4.1 7.28 19.5 995.9 P6 7.1 7.85 17.8 995.9 实验室 - - 18.5 998.2
下载: 导出CSV
表 2 不同前处理方法的碳同位素分析结果
Table 2. Analytical results of carbon isotope determined with different sample pretreatment methods
样品编号 δ13CV-PDB/‰ BaCl2沉淀法 医用聚乙烯瓶采样 顶空样品瓶采样 P地 -14.30 -14.54 -14.67 P地-平行样品 -14.36 -14.52 -14.61 P6 -16.06 -16.39 -16.41 P6-平行样品 -16.05 -16.36 -16.39
下载: 导出CSV
-
[1] World Meteorological Organization. Greenhouse Gas bulletin: The State of Greenhouse in the Atmosphere Based on Global Observations Through 2009[R]. 2010: 2-3.
[2] 袁道先.地球系统的碳循环和资源环境效应[J].第四纪研究,2001,21(3): 223-232. http://www.cnki.com.cn/Article/CJFDTOTAL-DSJJ200103003.htm
[3] 刘再华,王海静.一种由全球水循环产生的可能重要的CO2汇[J].科学通报,2007,52(20): 2418-2422. doi: 10.3321/j.issn:0023-074x.2007.20.013
[4] 袁道先.现代岩溶学与全球变化研究[J].地学前缘,1997,14(1-2): 17-24. http://www.cnki.com.cn/Article/CJFDTOTAL-DXQY7Z1.003.htm
[5] Liu Z, Dreybrodt W, Wang H. A new directing in effective accounting for the atmospheric CO2 budget: Considering the combined action of carbonate dissolution, the global water cycle and photosynthetic uptake of DIC by aquatic organisms[J].Earth-Science Reviews,2010,99: 162-172. doi: 10.1016/j.earscirev.2010.03.001
[6] Amiotte-Suchet P, Aubert D, Probst J L, Gauthier-Lafayea F, Probsta A, Andreuxb F, Vivillec D. δ13C pattern of dissolved inorganic carbon in a small granitic catchment: The strengbach case study (Vosges Mountains, France)[J].Chemical Geology,1999,159: 129-145. doi: 10.1016/S0009-2541(99)00037-6
[7] Wachniew P. Isotopic composition of dissolved inorganic carbon in a large polluted river: The Vistula, Poland[J].Chemical Geology,2006,233: 293-308. doi: 10.1016/j.chemgeo.2006.03.012
[8] 李干蓉,刘丛强,陈椽,王宝利,李军,李思亮,刘小龙,汪福顺.猫跳河流域梯级水库夏-秋季节溶解无机碳(DIC)含量及其同位素组成的分布特征[J].环境科学,2009,30(10): 2891-2897. doi: 10.3321/j.issn:0250-3301.2009.10.013
[9] 焦树林,陶贞,高全洲,刘昆,佘建伟,丁健,刘祖发.西江河口段溶解无机碳稳定同位素组成的时空变化[J].地理科学,2008,63(5): 553-560. http://www.cnki.com.cn/Article/CJFDTOTAL-DLXB200805013.htm
[10] Bishop P K. Precipitation of dissolved carbonate species from natural waters for δ13C analysis-A critical appraisal[J].Chemical Geology,1990,80: 251-259.
[11] 李廷勇.重庆地区石笋古环境信息影响因素及末次冰期以来气候变化的初步研究[D].重庆:西南大学,2007.
[12] Matthews D E. Hayes J M. Isotope ration-motioning gas chromatography-mass spectrometry[J].Analytical Chemistry,1978,50(11): 1465-1473. doi: 10.1021/ac50033a022
[13] 陶成,张美珍,杨华敏,闫秋实,把立强.GasBench-IRMS水平衡氢同位素分析方法研究及应用[J].质谱学报,2006,24(4): 215-220. http://www.cnki.com.cn/Article/CJFDTOTAL-ZPXB200604004.htm
[14] 孙青,王晓华,石丽明,刘美美,储国强.GasBench-IRMS水平衡氢氧同位素分析方法研究[J].岩矿测试,2009,28(1): 1-4. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS200901002.htm
[15] 张琳,陈宗宇,刘福亮,贾艳琨,张向阳,陈立.水中氢氧同位素不同分析方法的对比[J].岩矿测试,2011,30(2): 160-163. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201102009.htm
[16] 杨会,王华,应启和,林宇,涂林玲.不同检测方法对氢氧同位素分馏的影响[J].岩矿测试,2012,31(2): 225-228. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201202004.htm
[17] 陈锦芳,曹建平,纪丽红.河口水体中溶解CO2及其稳定同位素在线同时测定的技术研究[J].地球与环境,2012,40(4): 611-617.
[18] 杨涛,蒋少涌,赖鸣远,杨红,葛璐,凌洪飞.连续流同位素质谱法测定水中溶解无机碳含量和同位素组成的方法研究[J].地球化学,2006,35(6): 675-680. http://www.cnki.com.cn/Article/CJFDTOTAL-DQHX200606014.htm
[19] 张美良,朱晓燕,林玉石,陈坤琨,何师意,王华,杨琰.桂林洞穴滴水及现代碳酸钙(CaCO3)沉积的碳同位素记录及其环境意义[J].地球学报,2009,30(5): 634-642.
[20] 张美良,朱晓燕,李涛,邹丽霞.桂林现代洞穴碳酸盐-石笋的沉积速率及其环境意义[J].海洋地质与第四纪地质,2011,31(1): 125-134. http://www.cnki.com.cn/Article/CJFDTOTAL-HYDZ201101019.htm
[21] 杜广鹏,王旭,张福松.GasBench Ⅱ顶空瓶内空气背景对< 100μg碳酸盐中碳氧同位素在线测定的影响及校正方法初探[J].岩矿测试,2010,29(6): 631-638. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201006002.htm
-
