Fused Pellet-Determination of 16 Elements in Copper Ores by X-ray Fluorescence Spectrometry
-
摘要: 铜矿石类型繁多,矿石赋存状态各异,成分复杂。在现有的铜矿石熔融制样X射线荧光光谱(XRF)分析方法中,选取标准物质个数和矿石类型少、分析范围宽,与实际样品类型相差太大,且制备的熔融片质量不高。本文选用铜含量既有良好浓度变化范围,又符合铜矿石常见含量的包括铜金银铅锌钼铜镍等各类矿石的24个标准物质,以四硼酸锂-偏硼酸锂-氟化锂为混合熔剂,熔剂与样品质量比为30:1,以溴化锂为脱模剂,改进样品预处理方式,将通常采用样品预氧化后或熔融中加入脱模剂的方式,改进为加入脱模剂后再用混合熔剂完全覆盖的方法制备了高质量的熔融片,建立了XRF测定铜矿石中铜锌铅硅铝铁钛锰钙钾镁钼铋锑钴镍16种元素的分析方法。分析铜矿石国家标准物质GBW 07164、GBW 07169,各元素的精密度(RSD)为0.1%~5.4%。分析国家标准物质GBW 07163(多金属矿石)、GBW 07170(铜矿石)的测定值与标准值相符;分析实际铜矿石样品,铜锌铅钼铋锑钴镍的测试结果与电感耦合等离子体发射光谱法和其他方法的测定值相符。本文方法扩大了基体的适应性,提高了实际应用价值。Abstract: Accuracy and precision of the analytical results for major and minor components in copper ores by the X-ray Fluorescence Spectrometry (XRF) fusion method can be seriously affected by the type of copper ore being analysed and the complex components it contains. The existing XRF analysis method is limited by the following factors: only having a small number of reference materials and ore types, single and wide scope of analysis not matching the actual samples, and low quality of pellet. In this study, we choose 24 ores of reference materials including copper, gold, silver, lead, zinc, molybdenum, copper and nickel which has a good range of copper content with common Cu levels. Lithium tetraborate-lithium metaborate-lithium fluoride was used as flux, the ratio of flux and sample being 30:1. Using LiBr as the release agent, the high quality melt sheet was prepared by adding later mixed flux which completely covered the release agent, but not by adding release agent after the pre-oxidation or during molten, as is the most common method used. The quantitative analytical method for determination of 16 elements including Cu, Zn, Pb, SiO2, Al2O3, TFe2O3, TiO2, MnO, CaO, K2O, MgO, Mo, Bi, Sb, Co and Ni in copper ore by X-ray fluorescence spectrometry with fused pellet was established. The method was verified by the analysis of the copper ore certified reference materials of GBW 07164 and GBW 07169, and the relative standard deviations (RSD) were from 0.1% to 5.4%. Analysis results of certified reference materials (GBW 07163, GBW 07170) which did not participate in regression were basically in good agreement with certified values. The results of Cu, Zn, Pb, Mo, Bi, Sb, Co and Ni for practical samples by the proposed method were consistent with those obtained by Inductively Coupled Plasma Spectrometry and other analysis methods. The method expanded the adaptability of ore matrix and improved value in the practical application.
-
Key words:
- copper ores /
- X-ray Fluorescence Spectrometry /
- ore reference materials /
- release agent
-
-
表 1 各分析元素的测量条件
Table 1. Measurement parameters of elements by XRF
元素 分析线 晶体 准直器
(μm)探测器 电压
(kV)电流
(mA)2θ
(°)背景
(°)PHD范围 Cu Kα LiF 200 150 Flow 60 60 45.0098 0.7506 - 20~66 Zn Kα LiF 200 150 Scint 60 60 41.7592 0.8550 - 15~78 Pb Lβ1 LiF 200 150 Scint 60 60 28.2176 0.9272 - 21~78 Co Kα LiF 200 150 Flow 60 60 52.7724 0.8384 - 16~67 Mo Kα LiF 200 150 Scint 60 60 20.2598 0.6332 - 25~78 Bi Lβ LiF 200 150 Scint 60 60 32.9694 0.5986 - 19~78 Sb Kα LiF200 150 Scint 60 60 13.4486 0.2812 - 29~69 Ni Kα LiF200 300 Flow 60 60 48.6614 0.8022 - 18~66 Si Kα PE 002 300 Flow 25 144 109.1028 2.1706 - 24~78 Al Kα PE 002 300 Flow 25 144 144.8902 -1.6524 - 22~78 Fe Kα LiF 200 150 Flow 60 60 57.5136 -0.7198 - 15~68 Ti Kα LiF 200 150 Flow 40 90 86.1444 0.591 - 25~71 Mn Kα LiF 200 150 Flow 60 60 62.9702 0.636 - 25~68 K Kα LiF 200 300 Flow 25 144 136.698 -1.0938 - 25~74 Ca Kα LiF 200 150 Flow 30 120 113.109 1.7412 - 25~73 Mg Kα PX1 300 Flow 25 144 22.9698 2.0386 -1.5060 25~66 Na Kα PX1 300 Flow 25 144 27.8904 1.9338 -1.8892 25~65 Rh Kαc LiF 200 150 Scint 60 60 18.4294 - - 25~78 表 2 各元素校准曲线范围
Table 2. Concentration range of elements in the calibration curve
元素 含量(%) Cu 0.01~12.79 Pb 0.019~4.17 Zn 0.01~4.26 SiO2 9.27~82.95 Al2O3 1.73~15.18 TFe2O3 3.50~55.58 TiO2 0.017~0.53 MnO 0.026~2.21 CaO 1.52~28.86 MgO 0.082~28.40 K2O 0.021~3.85 Mo 60~15100 Bi 70~2830 Co 40~1500 Sb 80~6800 Ni 40~7970 注:Mo、Bi、Co、Sb、Ni元素的含量范围最低限为检出限。 表 3 Cu、Pb、Zn校准曲线的计算值与标准值对比
Table 3. Comparison of calculated values and proposed values four Cu, Pb, Zn in calibration curves
标准物质编号 Cu Pb Zn 标准值
(%)校准曲线计算值
(%)标准值
(%)校准曲线计算值
(%)标准值
(%)校准曲线计算值
(%)GBW 07162 0.26 0.25 0.43 0.42 0.83 0.84 GBW 07164 2.80 2.82 0.056 0.06 0.14 0.14 GBW 07169 5.49 5.51 1.12 1.12 0.61 0.60 GBW 07197 0.62 0.62 <0.02 - 0.078 0.080 GBW 07198 0.11 0.11 <0.02 - 0.045 0.050 GBW 07233 1.15 1.15 <0.02 - 0.06 0.06 GBW 07234 0.19 0.19 <0.02 - 0.013 0.014 GBW 07235 0.20 0.20 4.17 4.20 0.06 0.06 GBW 07237 0.71 0.71 0.25 0.24 2.75 2.54 GBW 07238 0.01 0.01 <0.02 - <0.01 - ZBK335 6.78 6.76 0.11 0.11 0.45 0.45 ZBK336 12.77 12.78 0.04 0.04 0.64 0.63 ZBK337 10.71 10.72 0.02 0.02 0.05 0.05 ZBK339 8.46 8.44 0.09 0.09 0.50 0.50 YSS023-2004 2.33 2.31 1.76 1.80 1.94 1.94 GBW(E) 070068 0.30 0.29 1.61 1.63 0.22 0.22 GBW(E) 070069 0.12 0.12 0.61 0.61 0.10 0.10 GBW(E) 070070 0.19 0.19 <0.02 - <0.01 - GBW(E) 070071 0.50 0.49 0.02 0.02 <0.01 - GBW(E) 070072 0.68 0.68 <0.02 - 0.011 0.011 GBW(E) 070073 0.29 0.29 <0.02 - 0.01 0.01 GBW(E) 070074 0.90 0.89 <0.02 - 0.02 0.02 GBW(E) 070075 3.84 3.85 0.024 0.02 0.083 0.08 GBW(E) 070076 8.53 8.52 0.027 0.02 0.19 0.19 表 4 滴加不同滴数饱和LiBr溶液对铜测定结果的影响
Table 4. Effect of different drops for saturated LiBr solution on analytical results of Cu
标准物质编号 Cu的标准值
(%)Cu的测定值(%) 2滴 4滴 6滴 8滴 10滴 12滴 GBW(E) 070071 0.50 0.50 0.49 0.50 0.48 0.46 0.45 GBW(E) 070075 3.84 裂纹 3.83 3.82 3.80 3.76 3.72 ZBK339 8.46 爆裂 8.37 8.44 8.41 8.40 8.32 表 5 方法检出限
Table 5. Detection limits of the method
元素 方法检出限
(μg/g)Cu 100 Pb 200 Zn 100 SiO2 200 Al2O3 330 TFe2O3 200 TiO2 80 MnO 100 CaO 240 MgO 100 K2O 160 Sb 80 Mo 60 Bi 70 Co 40 Ni 40 表 6 方法精密度
Table 6. Precision tests of the method
元素 GBW 07164 GBW 07169 含量(%) RSD(%) 含量(%) RSD(%) Cu 2.78 0.3 5.50 0.3 Pb 0.055 0.4 1.10 0.3 Zn 0.14 0.1 0.62 0.5 SiO2 40.5 2.5 48.0 3.8 Al2O3 7.77 1.1 11.4 1.8 TFe2O3 16.2 3.4 13.1 5.4 MnO 0.30 0.3 0.14 0.1 CaO 17.1 0.8 4.60 1.3 MgO 2.33 1.4 0.80 2.6 K2O 1.76 1.0 1.42 1.1 TiO2 0.37 0.1 1.12 0.1 Mo* 140 1.7 - - Bi* 82.0 2.5 1520 1.4 Co* 80.0 0.8 118 1.9 Ni* - - 218 0.5 Sb* 100 1.5 6791 2.6 注:带*的数据单位为μg/g。 表 7 标准物质分析结果
Table 7. Analytical results of reference materials
元素 GBW 07163 GBW 07170 标准值
(%)测定值
(%)标准值
(%)测定值
(%)Cu 1.05 1.04 12.59 12.62 Pb 2.17 2.15 2.24 2.20 Zn 4.26 4.24 1.21 1.20 SiO2 47.9 47.8 23.12 23.20 Al2O3 11.2 11.2 4.64 4.59 TFe2O3 12.0 12.1 12.76 12.60 MnO 0.49 0.48 0.14 0.14 CaO 4.70 4.68 24.49 24.31 MgO 1.39 1.36 2.48 2.52 K2O 3.10 3.07 0.021 0.022 TiO2 - 0.54 0.21 0.21 Bi* 75 77 607 638 Ni* - <40 376 352 Sb* 610 630 12500 11800 Co* - 44 221 209 Mo* 24 <60 - <60 注:带*的数据单位为μg/g。 表 8 实际样品不同分析方法结果对照
Table 8. Analytical results of elements in real copper samples by different methods
元素 样品1 样品2 样品3 样品4 XRF
(%)ICP-AES
(%)XRF
(%)ICP-AES
(%)XRF
(%)ICP-AES
(%)XRF
(%)ICP-AES
(%)Cu 3.20 3.18 1.36 1.38 0.58 0.60 1.17 1.20 Pb 0.47 0.47 0.09 0.09 0.03 0.04 0.11 0.11 Zn 1.12 1.15 0.76 0.76 0.24 0.22 0.18 0.17 Bi 0.077 0.075 0.11 0.10 0.026 0.024 0.010 0.011 Ni 0.014 0.014 0.008 0.008 0.076 0.081 0.050 0.053 Sb 0.04 0.04 0.06 0.06 <0.008 0.003 0.0084 0.010 Mo 0.13 0.12* 0.60 0.62* 0.006 0.005* <0.006 0.005* Co 0.15 0.14 0.084 0.086 0.09 0.10 0.05 0.05 注:Mo元素带“*”数据是分光光度法的测定值。 -
