Research Development in in-situ X-ray Fluorescence Analysis Techniques
-
摘要: 本文从携带式X射线荧光仪器、现场分析技术和技术应用三方面论述了现场X射线荧光分析技术的进展。从X射线激发源、X射线探测器和电子线路单元等角度，将携带式X射线荧光仪划分为四代，即以放射性同位源为激发源、以NaI(Tl)闪烁计数器为X射线探测器为技术特征的第一代仪器；以放射性同位素源和正比计数器为技术特征的第二代仪器；以放射性同位素、电制冷半导体探测器和以嵌入式微处理器为控制核心的多道脉冲幅度分析器为技术特征的第三代仪器；以低功率微型X射线发生器为激发源、电制冷半导体探测器和全数字化X射线能谱采集器为技术特征的第四代仪器。在现场分析技术方法方面，论述了X射线仪器谱解析技术、基体效应校正技术和现场原位分析中不平度效应、湿度效应、荧光颗粒不均匀效应校正技术进展。介绍了现场X射线荧光分析技术在地质矿产普查、环境污染调查、文物现场鉴定和合金分析等领域的应用进展。指出了目前国产携带式X射线荧光仪处于第三代和第四代仪器水平之间，低功率微型X射线发生器和电制冷半导体探测器还依赖于进口，全数字X射线能谱采集器还有待商品化；现场多元素分析的准确度和方法检出限都有待进一步改善；便携式仪器的应用领域有待拓宽。Abstract: The developments of in-situ X-ray Fluorescence (XRF) analysis techniques in the fields of Portable XRF Spectrometer, in-situ analytical methods and its applications are described in this paper. Portable XRF Spectrometer has been divided into four generations, based on the aspects of X-ray excitation sources, X-ray detectors and electrical circuit units. The paper also documents some in-situ analytical methodologies for analyzing X-ray spectra, overcoming the influence of the matrix effect, unevenness effect, moisture effect and heterogeneous effect on in-situ XRF analysis results. Finally, some applications in mineral exploration, environmental investigation, cultural relic discrimination and alloy analysis are introduced. The domestic Portable XRF Spectrometer was between generations Ⅲ and Ⅳ. The low power miniature X-ray generator and electric refrigeration semiconductor detector were dependent upon importation from foreign countries. The full digital X-ray energy spectrum collector is not yet available commercially. It is also pointed out that there are some capabilities for improving the accuracy and method detection limit of in-situ analysis. Research fields need be broadened to include the applications of Portable XRF Spectrometer.
-
-
[1] 葛良全,周四春,赖万昌.原位X辐射取样技术[M].成都:四川科学出版社,1997.
[2] 章晔,谢庭周,曹利国.X射线荧光探矿技术[M].北京:地质出版社,1984.
[3] Rhodes J R, Ahier T G, Boyce I S. Determination of tin in tin ores by radioisotope X-ray fluorescence[J].Radiochemical Methods of Analysis, 1965, 2:431.
[4] Clayton C G. Applications of Radioisotope X-ray Fluo-rescence Analysis in Geological Assay Mining and Mineral Processing [C]//Proceeding of Symposium on the Use of Nuclear Techniques in the Prospecting and Development of Mineral Resources,IAEA, 1969: 293-324.
[5] Rhodes J R, Furuta T, Berry P F. A Radioisotope X-ray fluorescence Drill Hole Probe [C]//Proceeding of Symposium on the Use of Nuclear Techniques in the Prospecting and Development of Mineral Resources,IAEA, 1969,34: 353-362.
[6] Si-PIN X-ray Detector.http://www.amptek.com[EB/OL].
[7] Si-PIN X-ray Detector and X-ray Generator.http://www.moxtek.com[EB/OL].
[8] Portable X-ray Flourscence Spectrometry.http://www.niton.com/en[EB/OL].
[9] Jordanov V T, Pantazis J A, Huber A C. Compact circuit for pulse rise-time discrimination [J]. Nuclear Instruments and Methods in Physics Research,1996,22: 353-357.
[10] Huber A C, Pantazis J A, Jordanov V T. High performance X-ray and Gamma-ray detectors [J]. Nuclear Instruments and Methods in Physics Research,1995, 33: 665-668.
[11] Jordanov V T, Pantazis J A, Huber A C. Thermoelectr-ically-cooled cadmium zinc telluride detectors (CZT) for X-ray and Gamma-ray detection [J]. Radiation, 1996,34: 796-799.
[12] Karydas A G, Zarkadas A, Kyriakis A, Pantazis J, Huber A, Redus R, Potiriades C, Paradellis T. Improvement of peak to background ratio in PIXE and XRF methods using small thickness thin Si-PIN detectors [J]. X-Ray Spectrometry, 2003,32: 93-105. doi: 10.1002/(ISSN)1097-4539
[13] Pantazis J A, Huber A C, Okun P, Squillante M R, Waer P, Entine G. New high performance nuclear spectroscopy system using Si-PIN diodes and CdTe detectors [J]. IEEE Transactions on Nuclear Science,1994,41: 134-138.
[14] Redus R H, Huber A, Pantazis J. Improved thermoelectrically cooled X/Gamma-ray detectors and electronics [J]. Nuclear Instruments and Methods in Physics Research,2001,46: 214-219.
[15] 章晔,谢庭周.放射性同位素X射线荧光技术在地质勘探中的应用[J].核技术,1981,4(3):13-18. http://www.cnki.com.cn/Article/CJFDTOTAL-HJSU198103004.htm
[16] 章晔,谢庭周.X射线荧光测井仪的研制及其在金属矿上应用[J].成都地质学院学报,1979(3):35-37. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG198202010.htm
[17] 章晔,谢庭周.微电脑轻便型X射线荧光分析仪的研制[J].成都地质学院学报,1985(4):43-47. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG198504010.htm
[18] 赵秀慧,韩龙,陶锡珍.TXF- 901 X 荧光分析仪硬件电路的研制[J].矿冶,1997(4):79-83.
[19] 葛良全,章晔,周四春.放射性同位素X荧光测井技术的研究[J].核技术,1997,20(4): 18-23. http://www.cnki.com.cn/Article/CJFDTOTAL-HJSU701.003.htm
[20] 葛良全,赖万昌,周四春.海底X射线荧光探测系统的研制[J].成都理工学院学报,2001(1): 80-86. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG200101015.htm
[21] 赖万昌,葛良全.新型高灵敏度XRF分析仪的研制与应用[J].核技术,2003,26(11): 891-904. doi: 10.3321/j.issn:0253-3219.2003.11.021
[22] 谷懿,杨强,赖万昌,葛良全.一体化X射线管激发荧光分析仪的研制[J].核电子学与探测技术,2010(5):686-689. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE201005026.htm
[23] 申凤君,葛良全,杨强.X射线荧光测井仪系统研制[J].核技术,2011,34(4): 304-308. http://www.cnki.com.cn/Article/CJFDTOTAL-HJSU201104011.htm
[24] 杨强,葛良全,赖万昌,任翔,谷懿.X荧光测井探管的研制及其初步应用[J].物探与化探,2010,34(4): 508-511. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH201004019.htm
[25] 任翔,葛良全,张庆贤,于新华,梁文俊.原位X射线荧光测井井液的影响与校正[J].核技术,2009,32(10): 756-759. doi: 10.3321/j.issn:0253-3219.2009.10.009
[26] 葛良全,孙传敏,谷懿,杨健,曾国强,赖万昌.微束微区X荧光矿物探针分析仪的研制[J].矿物岩石,2010,30(3): 105-108. http://www.cnki.com.cn/Article/CJFDTOTAL-KWYS201003014.htm
[27] 宋卫杰,葛良全,杨健,张帮,殷经鹏.微束微区X荧光探针分析仪在矿石微粒分析中的应用[J].核电子学与探测技术,2009, 29(4): 828-831. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200904028.htm
[28] 杨健,葛良全,张邦,王汉彬.微束微区X荧光探针仪的机械系统设计[J].机械设计与研究,2009(2): 90-92. http://www.cnki.com.cn/Article/CJFDTOTAL-JSYY200902027.htm
[29] 手持式X射线荧光仪.http://www.china-ray.com[EB/OL].
[30] 手持式多元素分析仪. http://www.xrfa.com/[EB/OL].
[31] 手持式X射线荧光仪. http://www.skyray-instrument.com/[EB/OL].
[32] 葛良全,曾国强,赖万昌.航空数字伽玛能谱测量系统的研制[C]//中国核学会2009年学术年会论文集.2009: 66.
[33] 曾国强,葛良全.卡尔曼滤波在航空γ能谱勘查系统自动稳谱中的应用[J].核电子学与探测技术,2010,30(5): 698-702. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE201005029.htm
[34] 曾国强,倪师军,葛良全.乘法器与乘法型DAC在核仪器程控增益放大器中的设计[J].核电子学与探测技术,2010,30(6): 861-864. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE201006033.htm
[35] 张庆贤,葛良全,曾国强,谷懿.基于傅里叶变换的NaI(Tl)仪器谱散射本底估计方法[J].原子能科学技术,2011, 45(10): 1258-1261. http://www.cnki.com.cn/Article/CJFDTOTAL-YZJS201110020.htm
[36] 李飞,葛良全,曾国强,谷懿.基于高斯函数分布的数字化能谱模拟软件在X荧光分析中的应用[J].核技术,2011,34(9): 663-665. http://www.cnki.com.cn/Article/CJFDTOTAL-HJSU201109004.htm
[37] Luo L Q,Chettle D R, Huiling N, McNeill F E, Popovic M. The effect of filters and collimators on Compton scatter and Pb K-series peaks in XRF bone lead analysis [J].Nuclear Instruments and Methods in Physics Research,2007,32: 258-261.
[38] 谢忠信.X射线光谱分析[M].北京: 科学技术出版社,1982.
[39] 张家骅.放射性同位素X射线荧光分析[M].北京: 原子能出版社,1981.
[40] 葛良全,章晔.一种校正基体效应的方法[J].成都理工大学学报,1990(4): 118-125. http://www.cnki.com.cn/Article/CJFDTOTAL-CDLG199004019.htm
[41] 戴振麟,葛良全.能量色散X射线荧光分析基本参数法研究[J].核电子学与探测技术,2008,28(1): 146-149. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200801038.htm
[42] 乔鹏,葛良全.X射线荧光光谱分析法同时测定化探样品中多组分的含量[J].核电子学与探测技术,2011,31(11): 1295-1299. doi: 10.3969/j.issn.0258-0934.2011.11.026
[43] 周四春,章晔.X取样方法的研究与应用(三)测量几何条件的最佳化[J].核电子学与探测技术,1990, 10(1): 12-17.
[44] Ge L Q, Zhang Y, Chen Y S. Study of surface geometrical structure effect of in-situ XRF analysis [J].Applied Radiation and Isotopes,1998,49(12): 1713-1720. doi: 10.1016/S0969-8043(98)00037-2
[45] Zhang Y, Ge L Q.Determination of the ore grade of tunnel walls by in-situ X-ray fluorescence analysis [J].Nuclear Geophysics,1994,2: 195-200.
[46] Ge L Q, Lai W C, Lin Y C. Influence of and correction for moisture in rocks, soils and sediments on in-situ XRF analysis [J]. X-ray Spectrometry, 2005,34: 28-34. doi: 10.1002/(ISSN)1097-4539
[47] 周四春,赵友清,张玉环.克服矿化不均匀效应的X荧光取样最佳测网[J].核技术,2000,23(9): 632-637. http://www.cnki.com.cn/Article/CJFDTOTAL-HJSU200009007.htm
[48] Potts P J M. West Portable X-ray Fluorescence Spectro-metry—Capabilities for in-situ Analysis[M]. Cambridge: The Royal Society of Chemistry Publishing, 2008,21: 141-172.
[49] 章晔,谢庭周,周四春,黄国强.现场X射线测量勘查金矿[J].地质与勘探,1987(8): 48-53. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH198703002.htm
[50] 章晔,谢庭周.核地球物理学的X射线荧光技术在我国固体矿产资源中的研究与应用[J].地球物理学报,1989(4): 441-450. http://www.cnki.com.cn/Article/CJFDTOTAL-DQWX198904008.htm
[51] 张勤,樊守忠,潘宴山,李国会,李小莉. Minipal4便携式能量色散X射线荧光光谱仪在勘查地球化学中的应用[J].岩矿测试,2007,26(5): 377-380. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS200705006.htm
[52] 程锋,葛良全,赖万昌.新一代便携式X射线荧光仪及其在铀分析中的初步应用[J].铀矿地质,2008,24(6): 375-379. http://www.cnki.com.cn/Article/CJFDTOTAL-YKDZ200806008.htm
[53] 葛良全,赖万昌,林延畅.现场X射线荧光检测技术研究[J].四川地质学报,2006(2): 117-120. http://www.cnki.com.cn/Article/CJFDTOTAL-SCDB200602016.htm
[54] 徐海峰,李成文,葛良全,张庆贤,李凤林.手提式X荧光分析仪在矿产普查中寻找伴生矿的应用研究[J].核电子学与探测技术,2009, 29(2): 445-448. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE200902051.htm
[55] 米争峰,葛良全,张庆贤,谷懿.西天山某航磁异常点查证中现场X荧光分析技术的应用[J].核电子学与探测技术,2011, 31(7): 798-801. http://www.cnki.com.cn/Article/CJFDTOTAL-HERE201107022.htm
[56] 郑兴国,陈方强,葛良全,周四春.钻孔岩芯多元素原位X荧光分析技术及应用[J].金属矿山,2011(4): 104-107. http://www.cnki.com.cn/Article/CJFDTOTAL-JSKS201104026.htm
[57] 柳建新,葛良全,张庆贤.WD-XRF在新疆某地区化探样品上的应用[J].光谱实验室,2011, 28(6): 3231-3234. http://www.cnki.com.cn/Article/CJFDTOTAL-GPSS201106114.htm
[58] Potts P J, Webb P C, Thorpe O W. Investigation of a correction procedure for surface irregularity effects based on scatter peak intencities in the field analysis of geological and archaeological rock samples by portable X-ray fluorescence spectrometry [J]. Journal of Analytical Atomic Spectrometry, 1997, 12: 769-776. doi: 10.1039/a606639i
[59] Potts P J, Eills A T, Holmos M. X-ray fluorescence spectrometry [J]. Journal of analysis Atomic Spectrometry, 2000, 15: 1417-1442. doi: 10.1039/b005284l
[60] Peinado F M, Ruano S M, González B C, Molina E. A rapid field procedure for screening trace elements in polluted soil using portable X-ray fluorescence (PXRF) [J].Geoderma, 2010,159: 76-82. doi: 10.1016/j.geoderma.2010.06.019
[61] Sterling D A, Lewis R D, Luke D A, Shadel B N.A portable X-ray fluorescence instrument for analyzing dust wipe samples for lead: Evaluation with field samples [J].Environmental Research,2000,83(2): 174-179. doi: 10.1006/enrs.2000.4058
[62] Melquiades F L, Parreira P S, Yabe M J, Corazza M Z, Funfas R, Appoloni C R. Factorial design for Fe, Cu, Zn, Se and Pb preconcentration optimization with APDC and analysis with a portable X-ray fluorescence system [J].Talanta,2007, 73: 121-126. doi: 10.1016/j.talanta.2007.03.004
[63] Melquiades F L, Parreira P S, Appoloni C R, Silva W D.Quantification of metals in river water using a portable EDXRF system [J]. Applied Radiation and Isotopes,2011, 69: 327-333. doi: 10.1016/j.apradiso.2010.09.021
[64] Cechak T, Hlozak M. X-ray fluorescence in investigations of archaeological finds [J]. Nuclear Instruments and Methods in Physics Research,2007, 263: 54-57. doi: 10.1016/j.nimb.2007.04.176
[65] Cesareo R, Castellano A, Buccolieri G, Marabelli M. A portable apparatus for energy-dispersive X-ray fluorescence analysis of sulfur and chlorine in frescoes and stone monuments [J]. Nuclear Instruments and Methods in Physics Research,1999,155: 326-330. doi: 10.1016/S0168-583X(99)00256-6
[66] Castellano A, Cesareo R. A portable instrument for en-ergy dispersive X-ray fluorescence analysis of sulfur [J].Nuclear Instruments and Methods in Physics Research,1997,129: 281-283. doi: 10.1016/S0168-583X(97)00206-1
[67] Valerio P. EDXRF and micro-EDXRF studies of Late Bronze Age metallurgical productions from Canedotes (Portugal) [J].Nuclear Instruments and Methods in Physics Research,2007,263: 477-482. doi: 10.1016/j.nimb.2007.07.004
[68] Karydasa A G, Kotzamani D, Bernard R. A composi-tional study of a museum jewellery collection (7th-1st BC) by means of a portable XRF spectrometer [J]. Nuclear Instruments and Methods in Physics Research, 2004, 226: 15-28. doi: 10.1016/j.nimb.2004.02.034
[69] Zarkadas C, Karydas A G. A portable semi-micro-X-ray fluorescence spectrometer for archaeometrical studies [J]. Spectrochimica Acta,2004,59: 1611-1618. doi: 10.1016/j.sab.2004.05.029
-
