Determination of Organochlorine Pesticides and Polychlorinated Biphenyls in Grains Using Gas Chromatography with Accelerated Solvent Extraction
-
摘要: 针对大米、小麦、玉米和黄豆等谷物样品中有机氯农药(OCPs)和多氯联苯(PCBs)检测的前处理过程较为复杂，消耗溶剂多，易导致部分挥发性化合物损失而影响分析的准确度，本文优化了加速溶剂萃取(ASE)提取大米、小麦、玉米和黄豆等谷物样品中OCPs和PCBs的条件，比较了凝胶渗透色谱(GPC)和固相萃取柱(SPE)两种净化方式净化样品的效果，采用气相色谱-电子捕获检测器实现了样品中17种OCPs和8种PCBs单体的系统分析。结果表明，选择二氯甲烷-丙酮混合溶剂(体积比1:1)，采用ASE萃取，同时加入弗罗里硅土在线净化，可满足样品提取需求；除了黄豆和黑豆等豆制品样品需采用GPC结合SPE的净化方法外，大米、小麦、玉米等大部分谷物样品采用SPE净化即可满足测定需求。采用弗罗里硅土SPE净化，仅用9 mL正己烷-乙酸乙酯淋洗液(体积比1:1)即可将所有目标物回收，克服了有机试剂用量大、同时使用多种试剂及试剂毒性大的问题。添加低、高两个浓度水平0.69 μg/kg和5.52 μg/kg，OCPs和PCBs单体的平均回收率为71.0%～112.0%，相对标准偏差为3.6%～16.7%(n=7)；方法检出限为0.07～0.30 μg/kg，低于国家标准方法的检出限。该方法净化效率高，操作简单，分析成本较低，适用于大批量谷物样品中多种OCPs和PCBs的快速分析。Abstract: The pollution of grains is growing worse due to the soil environment being polluted. The pre-treatment for organochlorine pesticides (OCPs) and polychlorinated biphenyls (PCBs) detected in samples of rice, wheat, corn and soybean is a complicated process with a large amount of solvents, easily leading to volatile compound loss and effects on the accuracy of the analysis. Therefore, choosing a suitable extraction and purification method is very important to the determination of 25 OCPs and PCBs in grains with Gas Chromatography. In this paper, the extraction and purification procedures of this method have been improved greatly by optimizing the parameters of accelerated solvent extraction (ASE) and comparing gel permeation chromatography (GPC) and solid phase extraction (SPE) are described. In addition to soy products, such as soybean and black bean samples needed to be purified by GPC and SPE, most of the rice, wheat, corn and other cereal samples are purified by SPE alone. The sample was extracted with dichloromethane and acetone (V:V=1:1) by ASE (Florisil clean up in the extraction cell), cleaned up by SPE with only 9 mL n-hexane/ethylacetate (V:V=1:1) to recover all the target compounds. The problems of using a large amount of organic reagent and the highly toxic reagent were overcome. The method detection limits of 17 OCPs and 8 PCBs ranged from 0.07 to 0.3 μg/kg, better than the index in national standard method. The average recoveries of 25 OCPs and PCBs were 71.0%-112.0% in the solutions of low and high level contents of 0.69 μg/kg and 5.52 μg/kg. The relative standard deviations (RSDs) for all the compounds were 3.6%-16.7% (n=7). It was confirmed that the method was accurate and credible through determination of spiked rice samples and other grain samples. Compared with traditional methods, this method is simple and convenient to conduct with the advantages of high efficiency, rapidity and low cost. Thereby, it is feasible for the simultaneous determination of OCPs and PCBs in different kinds of grain samples.
-
-
表 1 不同提取溶剂提取玉米样品中油脂的质量
Table 1. The extracted mass of lipid in corn sample extracted by different solvents
提取溶剂 m/g 浓缩时间t/min 样品瓶
质量油脂加样
品瓶质量油脂
质量二氯-丙酮(体积比1:1) 50.9927 51.0449 0.0522 16 正己烷-丙酮(体积比1:1) 48.3526 48.4132 0.0606 20 乙酸乙酯 49.7050 49.7625 0.0575 25 乙腈 45.3123 50.0927 0.0418 30
下载: 导出CSV
表 2 ASE在线加弗罗里硅土净化后玉米样品中的油脂量
Table 2. The extracted mass of lipid in corn sample extracted by ASE with adding Florsil and without Florsil
ASE提取 m/g 样品瓶质量 油脂加样品瓶质量 油脂质量 在线加弗罗里硅土 48.3510 48.3884 0.0374 不加弗罗里硅土 50.2665 50.3240 0.0575
下载: 导出CSV
表 3 大米基质加标的精密度、回收率和方法检出限
Table 3. Spiked recoveries and detection limits of the method for OCPs and PCBs
化合物 低浓度水平 高浓度水平 方法检出限/(μg·kg-1) 0.69 μg/kg 5.52 μg/kg 平均回收率/% RSD/% 平均回收率/% RSD/% α-HCH 87.2 9.55 85.7 6.68 0.18 六氯苯 71.0 9.28 82.8 5.90 0.14 β-HCH 96.0 7.03 89.6 3.58 0.15 γ-HCH 94.4 6.44 88.0 4.43 0.13 δ-HCH 94.6 6.21 93.9 5.46 0.13 七氯 87.4 3.65 94.4 10.5 0.07 艾氏剂 89.2 5.85 87.1 10.7 0.11 环氧七氯 94.8 5.65 97.9 5.90 0.12 反式-氯丹 94.5 9.67 85.6 9.67 0.20 顺式-氯丹 87.7 7.84 91.6 6.30 0.15 p,p′-DDE 112.0 10.8 100.0 5.98 0.26 狄氏剂 88.3 10.1 91.3 10.3 0.19 异狄氏剂 92.1 7.25 100.0 5.72 0.29 p,p′-DDD 88.2 6.09 87.5 6.16 0.12 o,p′-DDT 87.9 6.43 88.6 8.34 0.12 p,p′-DDT 87.7 13.5 93.7 7.49 0.26 灭蚁灵 92.0 5.78 87.3 5.39 0.12 PCB 15 81.3 5.69 88.9 9.58 0.30 PCB 28 92.6 9.12 86.1 5.58 0.18 PCB 52 89.5 6.48 89.3 16.3 0.13 PCB 101 87.5 9.87 85.7 7.77 0.19 PCB 118 83.1 4.10 83.6 9.43 0.07 PCB 153 85.2 9.92 87.7 16.7 0.18 PCB 138 102.0 10.4 90.4 8.60 0.23 PCB 180 96.9 8.68 93.7 8.87 0.18
下载: 导出CSV
表 4 谷物样品GC-ECD部分检测结果
Table 4. Determination results of OCPs and PCBs in grains by GC-ECD
化合物名称 wB/(μg·kg-1) 玉米籽 小麦 荞麦 小米 α-HCH - - - - 六氯苯 2.49 - 1.08 - β-HCH - - - - γ-HCH - - - - p,p′-DDE - - 1.26 2.03 p,p′-DDT - - - - 替代物回收率/% 2,4,5,6-四氯间二甲苯 80.32 83.16 89.97 79.88 PCB 103 92.98 95.72 107.14 97.87 PCB 204 105.87 100.4 107.92 99.46
下载: 导出CSV
-
[1] 谢武明,胡勇有,刘焕彬,许振成.持久性有机污染物(POPs)的环境问题与研究进展[J].中国环境监测,2004,20(2): 58-61. http://www.cnki.com.cn/Article/CJFDTOTAL-IAOB200402020.htm
[2] Colume A, Cardenas S, Gallego M, Valcarcel M. Semiautomatic method for the screening and determination of 23 organochlorine pesticides in horticultural samples by gas chromatography with electron-capture detection[J].Journal of Chromato-graphy A, 1999, 849(1): 235-243. doi: 10.1016/S0021-9673(99)00542-7
[3] 杨佳佳,吴淑琪,佟玲.多氯联苯的环境特性及分析测试进展[J].岩矿测试,2009,28(5): 444-451. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS200905013.htm
[4] 刘丹,钱传范.有机磷和有机氯杀虫剂在谷物籽粒中多残留分析方法的研究[J].农药学学报,2000,2(2): 77-82. http://www.cnki.com.cn/Article/CJFDTOTAL-NYXB200002012.htm
[5] 张伟国,储晓刚,李重九.气相色谱/离子阱质谱-选择离子方法同时检测大米中百种农药残留[J].分析化学,2005,34(4): 484-488. http://www.cnki.com.cn/Article/CJFDTOTAL-FXHX200604011.htm
[6] 刘芃岩,刘庆学,马育松,刘金巍,贾璇.大米中多种残留农药的固相萃取-气相色谱-质谱分析[J].色谱,2006,24(3): 228-234. http://www.cnki.com.cn/Article/CJFDTOTAL-SPZZ200603003.htm
[7] 佟玲,周瑞泽,吴淑琪,张玲金.加速溶剂提取凝胶渗透色谱净化气相色谱质谱快速测定玉米中多环芳烃[J].分析化学,2009,37(3): 357-362. http://www.cnki.com.cn/Article/CJFDTOTAL-FXHX200903010.htm
[8] Kobayashi R, Okamoto R A, Maddalena R L, Kado N Y. Polycyclic aromatic hydrocarbons in edible grain: A pilot study of agricultural crops as a human exposure pathway for environmental contaminants using wheat as a model crop [J].Environmental Research, 2008,107(2): 145-151. doi: 10.1016/j.envres.2007.11.002
[9] Chen L G, Ding L, Jin H Y, Song D Q, Zhang H R, Li J T, Zhang K, Wang Y T, Zhang H Q.The determination of organochlorine pesticides based on dynamic microwave-assisted extraction coupled with on-line solid-phase extraction of high-performance liquid chromatography [J]. Analytica Chimica Acta, 2007, 589(2): 239-246. doi: 10.1016/j.aca.2007.03.003
[10] 侯圣军,陈丹丹,李翔,李刚,杨强,闵顺耕,仲维科,储晓刚,王大宁.气相色谱/质谱-选择离子检测法同时测定大米中的25种持久性有机污染物[J].色谱,2005,23(3): 229-233. http://www.cnki.com.cn/Article/CJFDTOTAL-SPZZ200503003.htm
[11] 薛海全,崔兆杰,杜世勇.ASE萃取-GPC净化-GC/ECD测定小麦中有机氯农残和多氯联苯[J].山东大学学报: 理学版,2011,46(1): 11-15. http://www.cnki.com.cn/Article/CJFDTOTAL-SDDX201101004.htm
[12] Perez-Ruiz T, Martinez-Lozano C, Tomas V, Martin J. High-performance liquid chromatographic assay of phosphate and organophosphorus pesticides using a post-column photochemical reaction and fluorimetric detection [J].Analytica Chimica Acta,2005,540(2): 383-391. doi: 10.1016/j.aca.2005.03.055
[13] 侯圣军,郝向洪,申丽,闵顺耕.基质固相萃取-气相色谱电子捕获检测器同时测定大米中12种有机氯农药残留量[J].分析试验室,2007,26(5): 115-118. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY200705034.htm
[14] 阎正,张亚莉,冯天铸,周文英,马晓莉.毛细管气相色谱法测定5种中草药中有机氯农药的残留量[J].分析化学,2003,31(1): 95-98. http://www.cnki.com.cn/Article/CJFDTOTAL-FXHX200301027.htm
[15] GB/T 19649—2006,粮谷中475种农药及相关化学品残留量的测定;气相色谱/质谱法[S].
[16] Saito K, Ikeuchi R, Kataoka H. Determination of ochratoxins in nuts and grain samples by in-tube solid-phase microextraction coupled with liquid chromato-graphy-mass spectrometry [J].Journal of Chromato-graphy A, 2012, 1220(13): 1-6.
[17] 佟玲,杨佳佳,吴淑琪,张玲金.土壤中25种有机氯农药和多氯联苯的气相色谱分析方法研究[J].岩矿测试,2010,29(3): 277-281. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201003018.htm
[18] Abrha Y, Raghavan D. Polychlorinated biphenyl (PCB) recovery from spiked organic matrix using accelerated solvent extraction (ASE) and Soxhlet extraction [J].Journal of Hazardous Materials, 2000, 80(1-3): 147-157. doi: 10.1016/S0304-3894(00)00285-5
[19] Sparham C, Egmond R, Hastie C, O′Connor S, Gore D, Chowdhury N. Determination of decamethylcyclo-penta-siloxane in river and estuarine sediments in the UK[J].Journal of Chromatography A, 2011, 1218(6): 817-823. doi: 10.1016/j.chroma.2010.12.030
[20] 史双昕,邵丁丁,黄业茹.ASE萃取土壤中多氯联苯的萃取条件探讨[J].福建分析测试,2008,17(1): 31-35. http://www.cnki.com.cn/Article/CJFDTOTAL-FJFC200801013.htm
[21] 杨佳佳,吴淑琪,佟玲,宋淑玲,田芹.离子阱串联质谱法测定土壤及沉积物中的有机氯农药与多氯联苯[J].分析测试学报,2011,30(4): 374-380. http://cdmd.cnki.com.cn/Article/CDMD-82501-2011012307.htm
[22] Muller A, Bjorklund E, Holst C V. On-line clean-up of pressurized liquid extracts for the determination of polychlorinated biphenyls in feeding stuffs and food matrices using gas chromatography-mass spectrometry [J].Journal of Chromatography A, 2001, 925(1-2): 197-205. doi: 10.1016/S0021-9673(01)01028-7
[23] Wang P, Zhang Q H, Wang Y W, Wang T, Li X M, Ding L, Jiang G B. Evaluation of Soxhlet extraction, accelerated solvent extraction and microwave-assisted extraction for the determination of polychlorinated biphenyls and polybrominated diphenyl ethers in soil and fish samples[J].Analytica Chimica Acta,2010,663(1): 43-48. doi: 10.1016/j.aca.2010.01.035
[24] 曾浩,汤桦,陈大舟,王冠男,冯洁,汪瑾彦,李蕾.同位素稀释三重串联四极杆质谱法测定鱼组织中24种多环芳烃[J].分析试验室,2011,30(9): 11-16. http://www.cnki.com.cn/Article/CJFDTOTAL-FXSY201109004.htm
[25] Zhuang W S, McKague B, Reeve D, Carey J. A comparative evaluation of accelerated solvent extraction and polytron extraction for quantification of lipids and extractable organochlorine in fish [J].Chemosphere,2004,54(4): 467-480. doi: 10.1016/j.chemosphere.2003.08.024
[26] 李春风,沈伟健,蒋原,沈崇钰,赵增运,余可垚,桂茜雯,孙宁宁,袁宗辉.分散固相萃取气相色谱-负化学离子源质谱法测定大豆和玉米中20种农药的残留量[J].色谱,2009,27(2): 176-180. http://www.cnki.com.cn/Article/CJFDTOTAL-SPZZ200902010.htm
[27] 佟玲,杨佳佳,吴淑琪,张玲金.沉积物样品中干扰物的去除及多种持久性有机污染物气相色谱分析[J].岩矿测试,2011,30(5): 601-605. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS201105018.htm
-
