Applications of Accelerated Solvent Extraction in Preparation of Poly-nuclear Aromatic Hydrocarbons in Oil and Gas Geochemical Exploration Samples
-
摘要: 油气化探样品测定芳烃物质的提取方法通常采用振荡提取，在实际的样品测试过程中，这种前处理方法效率较低，得到的提取液用于分析测定的结果重现性较差。本文对油气化探样品稠环芳烃的提取方法进行改进，采用加速溶剂萃取技术，对实际样品进行试验，考察了压力、静态萃取时间和萃取温度对稠环芳烃萃取效率的影响，确定最佳的萃取条件为：萃取压力8.3 MPa，静态时间5 min，萃取温度80 ℃。对比了加速溶剂萃取与传统振荡提取应用于油气化探样品前处理的提取效率，证实了加速溶剂萃取技术可以显著提高萃取效率，稠环芳烃的荧光强度提高60.5%~152.6%，方法的稳定性好，测定结果的精密度高，相对标准偏差(RSD, n=7)低于4%。加速溶剂萃取技术优于传统振荡法，更能满足油气化探样品分析测试的准确度与精密度要求，可以应用于油气化探样品前处理过程。Abstract: The method of oscillations-extraction was used to obtain target compounds for the analysis of geochemical exploration of oil and gas. The efficiency and precision of the results were unsatisfactory for practical samples when using this method. In order to improve the conventional method, accelerated solvent extraction technology was used to prepare poly-nuclear aromatic hydrocarbons samples. The experimental conditions (pressure, static extraction time and extraction temperature) are discussed and optimized with an extraction pressure of 8.3 MPa, extraction temperature of 80℃ and heating time of 5 min. Under the optimized experimental conditions, a comparison of the extraction efficiency of the accelerated solvent extraction with the conventional oscillation method was performed. The extraction efficiencies of 3 different samples were improved from 60.5% to 152.6%, and the satisfactory precision and stability were obtained with RSDs (n=7) of less than 4%. Accelerated Solvent Extraction technology is superior to traditional methods and gives more satisfactory results in accuracy and precision requirements. It can be applied to oil and gas geochemical exploration samples by pre-treatment processing.
-
-
表 1 不同压力条件下测量的荧光强度
Table 1. The fluorescence intensity under different extraction pressure
压力
p/MPa320 nm 360 nm 405 nm 荧光强度平均值 RSD/% 荧光强度平均值 RSD/% 荧光强度平均值 RSD/% 6.9 375.93 3.39 208.74 6.34 47.01 7.61 8.3 382.39 0.84 203.17 1.38 50.46 2.21 10.3 381.92 1.65 205.67 1.01 53.72 3.36
下载: 导出CSV
表 2 不同静态时间条件下测量的荧光强度
Table 2. The fluorescence intensitiy under different static extraction time
静态时间
t/min320 nm 360 nm 405 nm 荧光强度平均值 RSD/% 荧光强度平均值 RSD/% 荧光强度平均值 RSD/% 3 369.65 3.06 193.06 2.76 47.68 5.31 5 381.28 1.25 204.20 1.02 52.91 4.04 7 380.16 1.41 207.59 1.45 54.66 1.88 10 384.66 0.92 208.98 1.21 60.46 2.70
下载: 导出CSV
表 3 不同温度条件下测量的荧光强度
Table 3. The fluorescence intensity under different temperature
温度
θ/℃320 nm 360 nm 405 nm 荧光强度平均值 RSD/% 荧光强度平均值 RSD/% 荧光强度平均值 RSD/% 40 300.26 2.99 137.79 1.74 35.14 5.84 70 366.25 3.13 197.24 1.60 52.22 3.96 100 395.75 1.17 214.47 1.57 54.74 1.49
下载: 导出CSV
表 4 振荡提取和ASE提取方法测量的荧光强度
Table 4. The fluorescence intensities under the oscillations-extraction and ASE
提取方法 发射波长
λ/nm样品1 样品2 样品3 荧光强度平均值 RSD/% 荧光强度平均值 RSD/% 荧光强度平均值 RSD/% 振荡提取 320 128.15 4.62 239.48 5.21 356.87 4.51 360 54.23 4.84 107.58 4.32 174.53 4.29 405 8.51 5.65 21.11 5.25 36.22 3.78 ASE提取 320 213.32 2.82 384.57 1.89 576.24 2.10 360 117.54 2.14 206.38 1.28 321.17 1.56 405 19.83 1.83 53.32 1.03 81.07 1.22
下载: 导出CSV
-
[1] 吴传璧,邱郁文,陈玉明.油气化探发展脉络与思考[M].北京:地质出版社,1996:9-18.
[2] 刘崇喜.本世纪初我国油气化探的发展方向[J].油气化探,2001,8(2):7-18.
[3] 吴传璧.中国油气化探50年[J].地质通报,2009,28(11):1572-1604. doi: 10.3969/j.issn.1671-2552.2009.11.007
[4] 刘崇禧,徐世荣.油气化探方法与应用[M].合肥:中国科学技术大学出版社,1992: 71-72.
[5] 程同锦.油气化探技术的现状与发展、问题与对策[J].油气化探,1997,4(3): 6-11. http://cpfd.cnki.com.cn/Article/CPFDTOTAL-ZGDJ200409002011.htm
[6] 杨育斌,张金来,吴学明.油气地球化学勘查[M].武汉:中国地质大学出版社,1995: 46-75.
[7] 许金钩,王尊本.荧光分析法[M].北京:科学出版社,2006:137-140.
[8] 李本超,李明,雷剑泉.荧光法在油气化探中的有效应用[J].油气化探,1997,4(2):39-40.
[9] 戴家才,郭海敏.石油荧光检测方法及其在生产测井中的应用初探[J].石油天然气学报,2009(4):96-99. http://www.cnki.com.cn/Article/CJFDTOTAL-JHSX200904025.htm
[10] 朱扬明.塔里木原油芳烃的地球化学特征[J].地球化学,1996,25(1):10-18. http://www.cnki.com.cn/Article/CJFDTOTAL-DZKQ201101019.htm
[11] 宋继梅,李武,胡斌.油气化探中芳烃油气性的辨识[J].物探与化探, 2006, 30(1):45-47. http://www.cnki.com.cn/Article/CJFDTOTAL-WTYH200601009.htm
[12] Requejo A G,Sassen R,Msdonild T. Polynuclear aromatic hydrocarbons (PAH) as indicators of the source and maturity of marine crude oils [J].Organic Geochemistry,1996,25(11):1017-1033.
[13] 刘洛夫,王伟华,徐新德,毛东风.塔里木盆地群5井原油芳烃地球化学研究[J].沉积学报,1996,14(2):47-55. http://www.cnki.com.cn/Article/CJFDTOTAL-CJXB602.005.htm
[14] SY/T 6009.8—2003,油气化探试样测定方法 第8部分:稠环芳烃测定荧光法[S].
[15] 刘静.戴安公司ASE快速溶剂萃取技术——解决您化学实验样品前处理的最新技术[J].检验检疫科学,2003,13(2):58. http://www.cnki.com.cn/Article/CJFDTOTAL-XDSJ200302025.htm
[16] 牟世芬,刘勇建.加速溶剂萃取的原理及应用[J].现代科学仪器,2001(3):18-20. http://www.cnki.com.cn/Article/CJFDTOTAL-XDYQ200103005.htm
[17] John E.ASE of pesticide residue in food products [J].GIT Laboratory Journal,2000,4(1):17-19.
[18] Sekine T, Hasegawa Y. Solvent Extraction Chemistry:Fundamentals and Applications [M].New York:Marcel Dekker,1977.
[19] 赵海香,袁光耀.加速溶剂萃取技术(ASE)在农药残留分析中的应用[J].农药,2006,45(1):15-17. http://cdmd.cnki.com.cn/Article/CDMD-10075-1014038865.htm
[20] 李兵,朱铁群,王金谨,肖文帅.加速溶剂萃取技术在多环芳烃提取及检测中的应用[J].广东化工, 2012(1):55-56. http://www.cnki.com.cn/Article/CJFDTOTAL-GDHG201201034.htm
[21] 王丽媛,周灵辉.快速溶剂萃取技术在环境监测中的应用[J].黑龙江环境通报,2011,35(4):59-61. http://www.cnki.com.cn/Article/CJFDTOTAL-HLJO201104023.htm
[22] 龚迎莉,孙玮琳,汪双清,沈斌.生油岩中有机质加速溶剂萃取和索氏萃取方法对比[J].岩矿测试,2009,28(5):416-422. http://www.cnki.com.cn/Article/CJFDTOTAL-YKCS200905007.htm
[23] 龚迎莉.加速溶剂萃取技术(ASE)在烃源岩氯仿沥青抽提中的应用[D].北京:中国地质科学院,2008.
[24] 王潇磊,王玲玲,李斐.土壤中多环芳烃的ASE前处理方法研究[J].环境科学导刊,2009,28(5):1-2. http://www.cnki.com.cn/Article/CJFDTOTAL-YNHK200905001.htm
[25] 李庆玲,徐晓琴,黎先春,王小如.加速溶剂萃取-气相色谱-质谱测定海洋沉积物中的痕量多环芳烃[J].分析测试学报,2006,25(5):33-37. http://www.cnki.com.cn/Article/CJFDTOTAL-TEST200605007.htm
[26] Richter B E, Jones B A, Ezzell J L, Porter N L. Accelerated solvent extraction:A technique for sample preparation [J].Analytical Chemistry,1996, 68(6):1033-1039. doi: 10.1021/ac9508199
-
