Research on the charging periods of the ultra-shallow play in front of the Hashan area, northwestern margin of the Junggar Basin
-
摘要:
准噶尔盆地西北缘哈山山前超剥带油气资源丰富，具有多层系含油、源−藏关系复杂的特点。超浅层是目前哈山地区油气勘探的重点层系，明确其油气藏充注时期和调整过程等成藏机理问题，对于研究哈山油藏富集规律具有重要的理论和实际意义。通过对哈山山前地区油气藏样品进行流体包裹体均一温度、盐水包裹体盐度特征以及定量颗粒荧光、方解石U-Pb定年等分析，开展油气包裹体特征、地层古温度和古油藏流体界面的研究，标定热事件时间，探讨该区超浅层油藏成藏机制、特征及成藏期次和聚集规律。研究结果表明，流体包裹体类型多样，其荧光颜色和强度变化表明发育多期不同成熟度的烃类流体，且流体包裹体均一温度主要集中在70~90 ℃和100~130 ℃区间。定量颗粒荧光技术显示，油气运移具有明显的动态过程，主要表现为从南向北的多次调整和聚集，侏罗系和白垩系分别以持续充注型和晚期充注型颗粒荧光特征为主，反映了不同地层的油气充注特征。方解石的U-Pb同位素测年结果表明，在研究区分别于133 Ma和73 Ma发生过至少2次热事件。结合流体包裹体盐水均一温度测量和定量颗粒荧光分析，揭示研究区经历了2期油气充注和调整过程，油气成藏时间为早白垩世和晚白垩世。应用流体包裹体、定量颗粒荧光和方解石U-Pb定年耦合技术为复杂构造带油气成藏提供了重要的方法手段，为厘定成藏期次提供了精确方法。
Abstract:Objective The Hala’alat Mountain front-overthrust belt, renowned for its abundant hydrocarbon resources, is characterized by multi-layer oil-bearing systems and intricate source-reservoir relationships. Ultra-shallow strata have emerged as an important domain for resource evaluation and exploration in this region. However, the timing of hydrocarbon charging and adjustment processes and the complex accumulation mechanisms of ultra-shallow reservoirs remain inadequately understood, posing significant challenges for exploration planning and appraisal programs. This study endeavors to unravel the genetic characteristics, accumulation stages, and dynamic mechanisms of ultra-shallow reservoirs in the Hala’alat Mountain front, with the goals of enhancing the theoretical framework for hydrocarbon enrichment patterns in structurally complex zones and providing actionable insights for future exploration endeavors.
Methods To achieve this objective, an integrated suite of analytical techniques was meticulously employed. Homogenization temperature measurements and salinity analysis of fluid inclusions were conducted to decipher thermal histories and fluid evolution. Quantitative grain fluorescence (QGF) analysis was utilized to track hydrocarbon migration pathways and accumulation dynamics. Calcite U–Pb geochronology provided precise temporal constraints for thermal events and hydrocarbon charging episodes. These methods were systematically applied to reservoir rock samples, enabling a comprehensive investigation of fluid inclusion characteristics, paleo-temperature evolution, and paleo-fluid interfaces. By constraining the thermal event chronology, we aimed to reconstruct the intricate hydrocarbon charging and adjustment processes that have shaped the current reservoir configuration.
Results (1) The analysis revealed a diverse array of fluid inclusion types, with variations in fluorescence color and intensity indicative of multiple stages of hydrocarbon charging, each with a distinct maturity levels. The homogenization temperatures of aqueous inclusions exhibited two predominant intervals: 70–90°C and 100–130°C. These temperature ranges correspond to distinct thermal episodes, reflecting varying paleo-thermal regimes that influenced hydrocarbon maturation and migration. (2) The QGF profiles provided compelling evidence of dynamic hydrocarbon migration processes, showcasing multiple northward adjustments and accumulations over geological time scales. Notably, Jurassic strata displayed continuous charging characteristics, suggesting prolonged hydrocarbon influx, while Cretaceous reservoirs exhibited late-stage charging patterns, reflecting differential hydrocarbon charging histories across stratigraphic units. This stratigraphic variation in charging behavior offers crucial insights into the temporal and spatial distribution of hydrocarbons within the study area. (3) Calcite U–Pb dating identified two major thermal events at approximately 133 Ma (Early Cretaceous) and 73 Ma (Late Cretaceous). These events are temporally correlated with significant tectonic activities in the study area, including regional compression and fault reactivation. (4) The integration of homogenization temperatures, QGF data, and U–Pb ages revealed a two-phase hydrocarbon charging history. The first phase occurred during the Early Cretaceous (133 Ma), characterized by initial hydrocarbon accumulation driven by regional tectonic compression. The second phase took place during the Late Cretaceous (73 Ma), marked by structural adjustment and hydrocarbon redistribution. These phases were primarily driven by tectonic forces that facilitated vertical migration and redistribution of hydrocarbons into ultra-shallow traps, highlighting the interplay between tectonic events and hydrocarbon accumulation.
Conclusions The ultra-shallow reservoirs in the Hala’alat front have undergone two critical accumulation phases: the Early Cretaceous initial charging phase and the Late Cretaceous structural adjustment phase. Hydrocarbon migration pathways were predominantly controlled by fault systems, which acted as migration carriers. The northward adjustments were facilitated by differential uplift and the caprock integrity, ensuring the preservation of hydrocarbons within the reservoirs. The coupling of fluid inclusion thermometry, QGF, and U–Pb dating has proven to be a robust and innovative toolkit for resolving multi-stage accumulation processes in complex thrust belts. This methodological integration not only enhances our understanding of hydrocarbon accumulation mechanisms but also provides a precise framework for identifying and dating these events. This study establishes a novel and comprehensive methodology for deciphering multi-phase hydrocarbon accumulation in tectonically active regions. [Significance] By offering critical insights into the timing, pathways, and driving mechanisms of hydrocarbon charging, this study provides a solid foundation for predicting ultra-shallow reservoir distributions in similar geological settings. The integration of chronostratigraphic and fluid dynamic analyses advances the theoretical understanding of hydrocarbon enrichment mechanisms in foreland thrust belts, with direct implications for exploration strategies and resource evaluation in analogous basins. Furthermore, the methodological framework developed in this study can be adapted and applied to other complex structural zones, potentially revolutionizing our approach of hydrocarbon exploration in challenging geological environments.
-
-
[1] BAI G J, 2009. The tectonic feature and hydrocarbon accumulation in the northwest part of Junggar Basin[D]. Xi’an: Northwest University. (in Chinese with English abstract
[2] FENG J W, 2008. The tectonic evolution and it’s controlling on hydrocarbon in Wuxia fault belt of Junggar Basin[D]. Qingdao: China University of Petroleum (East China). (in Chinese with English abstract
[3] GAO J B, ZHANG H H, PANG X Q, et al., 2011. Application of quantitative grain fluorescence (QGF) analysis in low permeability sandstone reservoirs: a case study of Chang4+ 5 oil formation in Ordos Basin[J]. Journal of Oil and Gas Technology, 33(10): 1-5. (in Chinese with English abstract
[4] HAN X L, WU Q Q, LIN H X, et al., 2016. Types of carrier system and models of hydrocarbon migration and accumulation of Hala’alat Mountain structural belt in the northern margin of Junggar Basin[J]. Natural Gas Geoscience, 27(4): 609-618. (in Chinese with English abstract
[5] HE D F, GUAN S W, ZHANG N F, et al. , 2006. Thrust belt structure and significance for petroleum exploration in Hala'alat mountain in northwestern margin of Junggar Basin[J]. Xinjiang Petroleum Geology, 27(3): 267-269, 298. (in Chinese with English abstract
[6] HESTNES Å, DROST K, SØMME T O, et al., 2023. Constraining the tectonic evolution of rifted continental margins by u–pb calcite dating[J]. Scientific Reports, 13(1): 7876, doi: 10.1038/s41598-023-34649-z
[7] HU Y, XIA B, 2012. An approach to the tectonic evolution and hydrocarbon accumulation in the Halaalate Mountain area, northern Xinjiang[J]. Sedimentary Geology and Tethyan Geology, 32(2): 52-58. (in Chinese with English abstract
[8] HUANG S H, QIN M K, SELBY D, et al., 2018. Geochemistry characteristics and Re-Os isotopic dating of Jurassic oil sands in the northwestern margin of the Junggar Basin[J]. Earth Science Frontiers, 25(2): 254-266. (in Chinese with English abstract
[9] LI Z H, 2011. Analysis on the tectonic event and paleo-geothermal feature of Yanshanian in the Northern Junggar Basin[D]. Xi’an: Northwest University. (in Chinese with English abstract
[10] LIANG Y Y, 2020. Strike-slip fault system at the northwestern margin of Junggar Basin and its relationship with hydrocarbon accumulation[D]. Beijing: China University of Petroleum (Beijing). (in Chinese with English abstract
[11] LIN H X, GUO R C, GONG Y J, et al., 2017. Geochemical characteristics of crude oil and cogenetic-bidirectional charging effect in Hashan Area[J]. Special Oil and Gas Reservoirs, 24(2): 35-39. (in Chinese with English abstract
[12] LISK M, O’BRIEN G W, EADINGTON P J, 2002. Quantitative evaluation of the oil-leg potential in the Oliver gas field, Timor sea, Australia[J]. AAPG Bulletin, 86(9): 1531-1542.
[13] LIU K Y, LU X S, GUI L L, et al., 2016. Quantitative fluorescence techniques and their applications in hydrocarbon accumulation studies[J]. Earth Science, 41(3): 373-384. (in Chinese with English abstract
[14] National Energy Administration, 2021. Classification of oil reservoir: SY/T 6169-2021[S]. Beijing: Petroleum Industry Press. (in Chinese)
[15] RAO S, ZHU Y K, HU D, et al., 2018. The thermal history of Junggar Basin: constraints on the Tectonic attribute of the Early-Middle Permian basin[J]. Acta Geologica Sinica, 92(6): 1176-1195. (in Chinese with English abstract
[16] WANG S Z, ZHANG K H, XIAO X F, et al., 2012. Study on meshwork-carpet hydrocarbon pool-forming features in Hashan area, the sloping zone, the northern border of Junggar Basin[J]. Journal of Xi’an Shiyou University (Natural Science Edition), 27(6): 19-24. (in Chinese with English abstract
[17] WANG S Z, 2015. The formation and evolution of Hashan structural belt and its controlling on hydrocarbon in the Northern of Junggar Basin[D]. Qingdao: China University of Petroleum (East China). (in Chinese with English abstract
[18] WANG S Z, LIN H X, ZHANG K H, et al., 2015. Formation mechanism and hydrocarbon charging of Jurassic reservoirs in Hashan area northern sloping zone of Junggar Basin[J]. Natural Gas Geoscience, 26(3): 477-485. (in Chinese with English abstract
[19] WANG S Z, WU Q Q, CHENG S W, et al., 2017. Hydrocarbon transmission system and accumulation in Hala’alat mountain structural belt in the northern margin of Junggar Basin[J]. Acta Sedimentologica Sinica, 35(2): 405-412. (in Chinese with English abstract
[20] WANG S Z, WU Q Q, SONG M Y, et al., 2018. Quantitative evaluation of the transportation of fault zone and its controlling effect on hydrocarbon migration and accumulation: case study of Hala’alat Mountain tectonic belt in the north margin of Junggar Basin[J]. Natural Gas Geoscience, 29(11): 1559-1567. (in Chinese with English abstract
[21] WANG Z W, 2009. Research on the tectonic event and thermal evolution history of piedmont zone in northern margin of Junggar Basin[D]. Xi’an: Northwest University. (in Chinese with English abstract
[22] XU G S, DING S B, LIU W J, et al., 2014. Geochemical characteristics and correlation of oil with source correlation of hydrocarbon source rock in Hassan area of Xinjiang, China[J]. Journal of Chengdu University of Technology (Science & Technology Edition), 41(6): 752-759. (in Chinese with English abstract
[23] XU Y D, WANG L, LIU Z C, et al., 2020. Characteristics of fluid inclusions and time frame of hydrocarbon accumulation for volcanic reservoirs in Chepaizi Uplift[J]. Fault-Block Oil & Gas Field, 27(5): 545-550. (in Chinese with English abstract
[24] XUE Y, LIN H X, ZHANG K H, et al., 2017. Tectonic characteristics and genetic simulation of Hala’alate mountain area[J]. Geotectonica et Metallogenia, 41(5): 843-852. (in Chinese with English abstract
[25] YANG Y Z, LIU Q X, ZHANG F Q, et al., 2023. Study on quantitative grain fluorescence analysis technique applied to shallow reservoirs in Hashan area, Junggar Basin[J]. Mud Logging Engineering, 34(3): 22-31. (in Chinese with English abstract
[26] YU C Y, JIA Y M, LI X X, et al., 2022. Determination of Carboniferous-Permian hydrocarbon accumulation period and time in Hala′alate Mountain area, Junggar Basin[J]. Mud Logging Engineering, 33(3): 110-116. (in Chinese with English abstract
[27] ZHANG K H, 2014. Study on depositional features and hydrocarbon accumulation control factors of Jurassic in Hashan slope belt of Junggar Basin[D]. Qingdao: China University of Petroleum (East China). (in Chinese with English abstract
[28] ZHANG K H, SUN Z L, ZHANG G L, et al., 2023. Shale dominant lithofacies and shale oil enrichment model of Lower Permian Fengcheng Formation in Hashan area, Junggar Basin[J]. Petroleum Geology & Experiment, 45(4): 593-605. (in Chinese with English abstract
[29] ZHANG Y, 2018. Research on geochemical characteristics and accumulation process of upper Paleozoic reservoir in Hashan Area[D]. Beijing: China University of Petroleum (Beijing). (in Chinese with English abstract
[30] ZHOU J, 2016. Research on the role of the basin-marginal sequence architectural model in controlling the development of sand-bodies and traps: a case study of the Jurassic system in Hashan Area[J]. Science Technology and Engineering, 16(21): 177-185. (in Chinese with English abstract
[31] 白国娟,2009. 准噶尔盆地西北部构造特征与油气成藏关系研究[D]. 西安:西北大学.
[32] 冯建伟,2008. 准噶尔盆地乌夏断裂带构造演化及控油作用研究[D]. 青岛:中国石油大学(华东).
[33] 高剑波,张厚和,庞雄奇,等,2011. 定量颗粒荧光技术在低渗透致密砂岩油藏研究中的应用:以鄂尔多斯盆地姬塬地区长4+5油层组为例[J]. 石油天然气学报,33(10):1-5. doi: 10.3969/j.issn.1000-9752.2011.10.001
[34] 国家能源局,2021. 油藏分类:SY/T 6169-2021[S]. 北京:石油工业出版社.
[35] 韩祥磊,吴倩倩,林会喜,等,2016. 准噶尔盆地北缘哈拉阿拉特山构造带油气输导系统类型及运聚模式[J]. 天然气地球科学,27(4):609-618. doi: 10.11764/j.issn.1672-1926.2016.04.0609
[36] 何登发,管树巍,张年富,等,2006. 准噶尔盆地哈拉阿拉特山冲断带构造及找油意义[J]. 新疆石油地质,27(3):267-269,298. doi: 10.3969/j.issn.1001-3873.2006.03.001
[37] 胡杨,夏斌,2012. 新疆北部哈山地区构造演化特征及油气成藏条件初步分析[J]. 沉积与特提斯地质,32(2):52-58. doi: 10.3969/j.issn.1009-3850.2012.02.008
[38] 黄少华,秦明宽,SELBY D,等,2018. 准噶尔盆地西北缘超覆带侏罗系油砂地球化学特征及Re-Os同位素定年[J]. 地学前缘,25(2):254-266.
[39] 李振华,2011. 准噶尔盆地北部燕山期构造事件及其古地温特征分析[D]. 西安:西北大学.
[40] 梁媛媛,2020. 准噶尔盆地西北缘走滑构造特征及其控藏作用研究[D]. 北京:中国石油大学(北京).
[41] 林会喜,郭瑞超,宫亚军,等,2017. 哈山地区原油地化特征及同源双向充注效应[J]. 特种油气藏,24(2):35-39.
[42] 刘可禹,鲁雪松,桂丽黎,等,2016. 储层定量荧光技术及其在油气成藏研究中的应用[J]. 地球科学,41(3):373-384.
[43] 饶松,朱亚珂,胡迪,等,2018. 准噶尔盆地热史恢复及其对早—中二叠世时期盆地构造属性的约束[J]. 地质学报,92(6):1176-1195.
[44] 王圣柱,张奎华,肖雄飞,等,2012. 准北缘哈山地区斜坡带网毯式油气成藏规律[J]. 西安石油大学学报(自然科学版),27(6):19-24.
[45] 王圣柱,2015. 哈山复杂构造带形成演化对油气成藏的控制作用[D]. 青岛:中国石油大学(华东).
[46] 王圣柱,林会喜,张奎华,等,2015. 准北缘哈山斜坡带侏罗系原油稠化机理及充注特征[J]. 天然气地球科学,26(3):477-485.
[47] 王圣柱,吴倩倩,程世伟,等,2017. 准噶尔盆地北缘哈山构造带油气输导系统与运聚规律[J]. 沉积学报,35(2):405-412.
[48] 王圣柱,吴倩倩,宋梅远,等,2018. 断裂带内部结构及其对油气运聚的控制作用:以准噶尔盆地北缘哈山构造带为例[J]. 天然气地球科学,29(11):1559-1567.
[49] 王志维,2009. 准噶尔盆地北缘山前带构造事件与热演化史研究[D]. 西安:西北大学.
[50] 徐国盛,丁圣斌,刘文俊,等,2014. 哈山地区烃源岩地球化学特征及油源对比[J]. 成都理工大学学报(自然科学版),41(6):752-759.
[51] 徐佑德,王林,刘子超,等,2020. 车排子地区火山岩油藏流体包裹体特征与成藏期次[J]. 断块油气田,27(5):545-550.
[52] 薛雁,林会喜,张奎华,等,2017. 哈拉阿拉特山地区构造特征及成因机制模拟[J]. 大地构造与成矿学,41(5):843-852.
[53] 杨蕴泽,刘庆新,张发强,等,2023. 定量颗粒荧光分析技术在准噶尔盆地哈山地区浅部储层中的应用研究[J]. 录井工程,34(3):22-31. doi: 10.3969/j.issn.1672-9803.2023.03.004
[54] 于春勇,贾雨萌,李晓祥,等,2022. 准噶尔盆地哈山地区石炭-二叠系油气成藏期次及时间厘定[J]. 录井工程,33(3):110-116. doi: 10.3969/j.issn.1672-9803.2022.03.019
[55] 张奎华,2014. 准噶尔盆地哈山斜坡带侏罗系沉积特征及成藏控制因素研究[D]. 青岛:中国石油大学(华东).
[56] 张奎华,孙中良,张关龙,等,2023. 准噶尔盆地哈山地区下二叠统风城组泥页岩优势岩相与页岩油富集模式[J]. 石油实验地质,45(4):593-605. doi: 10.11781/sysydz202304593
[57] 张阳,2018. 哈山地区上古生界油藏地球化学特征及成藏过程分析[D]. 北京:中国石油大学(北京).
[58] 周健,2016. 盆缘层序构成模式下的控砂控圈作用研究:以哈山地区侏罗系为例[J]. 科学技术与工程,16(21):177-185. doi: 10.3969/j.issn.1671-1815.2016.21.028
-
